DISHSTAR/DELTA I/O MODULE KIT - 06401-004-76-15
WARNING: This part should be installed only by qualified service personnel to reduce the risk of
!
electric shock, serious injury, or fire. A plumbing permit and the services of a licensed plumber and
electrician might be required in some areas.
WARNING
Turn off the power supply and place the dishwasher disconnect (if applicable) in the off position.
Lockout/tagout to prevent the power supply from being turned back on inadvertently.
!
CAUTION: Failure to install this part within the guidelines might adversely affect safety, performance,
component life, and warranty coverage.
CAUTION
TOOLS REQUIRED
•
7/16" Wrench
•
Phillips Screwdriver
PARTS INCLUDED
QTY
1
1
I/O MODULE
REPLACEMENT
7/16" wrench used
in this step.
07610-004-34-16-A
DESCRIPTION
I/O Module
Instructions, I/O Module Replacement
1. Remove front panel using 7/16" wrench and set aside.
I/O MODULE REPLACEMENT
DISHSTAR SERIES/
DELTA HT-E-SEER
PART NUMBER
05945-004-36-34
07610-004-34-16
1 of 3
