19 USB Port

VVX 500 Series and VVX 600 Series Hardware

The following figure displays the hardware features on the VVX 500, 501, 600, and 601 business media
phones. The table lists each feature numbered in the figure.
VVX 500 series and VVX 600 series hardware features
VVX 500 Series and 600 Series Hardware Feature Descriptions
Reference Feature
Number
1 Reversible tab
2 Speaker
3 Dialpad keys
4 Security slot (on
side)
5 Microphone
6 Volume keys
7 Mute key
Polycom, Inc.
Enables you to attach a USB flash drive or USB headset (VVX 411 only).
Feature Description
Secures the handset in the cradle when your phone stand is positioned at
a high angle. To secure the handset, remove the tab, reverse it so the
protrusion points up, and re-insert it. Position the handset so the protrusion
on the tab fits into the slot on the handset.
Provides ringer and speakerphone audio output.
Enable you to enter numbers, letters, and special characters. You can also
use the dialpad keys to select menu items that have index numbers.
Enables you to attach a universal security cable lock to your phone so you
can secure it to a desktop.
Transmits audio to other phones.
Adjust the volume of the handset, headset, speaker, and ringer.
Mutes local audio during calls and conferences. The key glows red when
activated.
Getting Started with a VVX Business Media Phone
11
