- Page 1 All manuals and user guides at all-guides.com MP6512i Installation and Operation Manual MP6512i Loudness RADIO READY MENU/ENTER-PRESS LOUD LO/DX...
- Page 2 All manuals and user guides at all-guides.com...
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com MP6512i TABLE OF CONTENTS Introduction ....................1 Installation ....................2 Wiring .......................5 Front Panel Release ................6 Operation ....................7 Tuner Operation ..................10 CD Player Operation ................12 MP3/WMA Operation ................13 Satellite Radio Operation ...............17 iPod Operation ..................19 Remote Control ..................20... - Page 4 All manuals and user guides at all-guides.com...
-
Page 5: Introduction
All manuals and user guides at all-guides.com MP6512i INTRODUCTION Congratulations on your purchase of the Jensen MP6512i Mobile Receiver. • SD Card - Playback of MP3 and WM It’s a good idea to read all of the instructions before beginning the •... -
Page 6: Installation
1. Disconnect Battery Before you begin, always disconnect the battery negative terminal. NOTE: If the MP6512i is to be installed in a car equipped with an on- board drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. - Page 7 All manuals and user guides at all-guides.com MP6512i Kit Installation CAUTION: For proper operation of the CD player, the chassis must be If your vehicle requires the use of an installa mounted within 20° of horizontal. Make sure the unit is mounted within follow the instructions included with the inst this limitation.
- Page 8 All manuals and user guides at all-guides.com Removing the Radio To remove the radio after installation, remove the trim ring by lifting in the center and pulling it off from either side. Insert the removal keys straight back until they lock, then pull the radio out.
-
Page 9: Wiring
All manuals and user guides at all-guides.com MP6512i WIRING NOTE: The amplifier in this radio is only designed for use with four speakers. Never combine (bridge) outputs for use with two speakers. Never ground negative speaker leads to chassis ground. -
Page 10: Front Panel Release
All manuals and user guides at all-guides.com FRONT PANEL RELEASE The open button (1) releases the mechanism that holds the front panel to the chassis. Detaching the Front Panel To detach the front panel: 1. Press and hold the power button (2) to turn the unit off. 2. -
Page 11: Operation
All manuals and user guides at all-guides.com MP6512i OPERATION Power Press the power button (2) to turn the unit on. Press and hold the power button again to turn the unit off. MP6512i NOTE: LCD panels may take longer to respond when subjected to cold READY temperatures for an extended period of time. - Page 12 All manuals and user guides at all-guides.com Mid-Range Balance To adjust Mid-Range options, press the MENU button (22) to access the To adjust the balance from “12L” (full left) to audio menu. Turn the rotary encoder until “MID” appears in the display. MENU button (22) to access the audio men Press the MENU button repeatedly to access the following Mid-Range “BAL”...
- Page 13 All manuals and user guides at all-guides.com MP6512i select “OFF”, “LOW”, “MID” or “HIGH”. When activated, “LOUDNESS” Brightness Adjustment appears on the display panel. This option allows you to adjust the brightne rotary encoder to select a brightness level b Local/Distant Reception (LO/DX) being the brightest.
-
Page 14: Tuner Operation
All manuals and user guides at all-guides.com TUNER OPERATION The MP6512i allows you to receive channels in U.S.A. or EUROPE mode. Preview Scan See “Frequency Spacing (AREA SET)” on page 9 to learn how to change Press the SCAN button (16) to scan all stro the tuner options. - Page 15 All manuals and user guides at all-guides.com MP6512i • Language • Religious Music • Religious Talk • Personality • Public • College • Weather • Emergency Test • Emergency To search for stations in a PTY category: 1. Press the PTY button (17) to view the current PTY category.
-
Page 16: Cd Player Operation
10 seconds. Eject CD Press the OPEN/EJECT button (1) and the motorized front panel will slide MP6512i automatically down to display the disc slot. The unit will automatically stop CD play and eject the disc. If the disc is not... -
Page 17: Mp3/Wma Operation
Many types of software are available for converting audio • Sampling frequency: 8, 11.025, 12, 16, files into MP3/WMA formats. Jensen recommends Nero or Roxio Easy CD When using a CD writer to record MP3/WM Creator. Depending on the media type and recording method, some CD-R/ capacity, disable additional writing. - Page 18 To remove the USB device, press the SRC mode and then remove the USB device from The MP6512i player will only recognize three folder levels and does not display folders containing only other folders. In the example above, the unit will display folders 3, 4, 6, and 8, but not 2 and 7 since they do not contain any tracks directly.
- Page 19 All manuals and user guides at all-guides.com MP6512i Track Select Press the TUNE/TRACK >>| or |<< buttons advance to the next track on the source, or f MP6512i UNIVERSAL SERIAL BUS forward or fast reverse through the track. Pl is released.
- Page 20 All manuals and user guides at all-guides.com MP3/WMA File or Folder Search The unit offers three methods of searching for files or folders on a disc. Direct Track Search 1. Press the AS button (15) to activate the Track Search function. The LCD will display "TRK SCH".
-
Page 21: Satellite Radio Operation
All manuals and user guides at all-guides.com MP6512i SATELLITE RADIO OPERATION Selecting a Station ® Press the TUNE/TRACK >>| or |<< button ( Listeners can subscribe to XM Radio on the Web by visiting www.xmradio.com, or by calling (800) 967-2346. Customers should station. - Page 22 All manuals and user guides at all-guides.com Category Tuning Mode To select stations in a specific category, perform the following steps. 1. Press the AS button (15) twice. “CATEGORY” appears on the screen. 2. Turn the rotary encoder to move through the available categories. 3.
-
Page 23: Ipod Operation
All manuals and user guides at all-guides.com MP6512i IPOD OPERATION Accessing iPod Mode iPod Category Search Press the SRC button (7) to change to iPod playback mode. iPod playback Press the 6 UP button (13) to enter the iPod begins automatically when an iPod is connected. -
Page 24: Remote Control
All manuals and user guides at all-guides.com REMOTE CONTROL The remote control will allow you to control many functions of the MP6512i. Replacing the Battery When the range of operation of the card rem stops functioning, replace the battery with a... -
Page 25: Care And Maintenance
All manuals and user guides at all-guides.com MP6512i CARE AND MAINTENANCE CD Player Compact Discs The following guidelines will help you extend the life of your CD player: CD-R and CD-RW Capability 1. When cleaning the vehicle interior, do not get water or cleaning fluids on Depending on media type and method of "re... -
Page 26: Troubleshooting
All manuals and user guides at all-guides.com TROUBLESHOOTING Problem Cause Corrective Action Does not operate No power to yellow Check connection with test (display does not wire; no power to red light; check vehicle fuse with light) wire test light Inline fuse blown Replace fuse No power to unit... -
Page 27: Specifications
All manuals and user guides at all-guides.com MP6512i SPECIFICATIONS General CEA Power Ratings Power Supply ....... - Page 28 All manuals and user guides at all-guides.com...
- Page 29 All manuals and user guides at all-guides.com Limited Warranty DO NOT RETURN THIS PR CD or Multimedia Radios/Headunits Audiovox Electronics Corporation (“the Company”) is committed to Limitations quality and customer service, and are pleased to offer you this THE EXTENT OF THE COMPANY'S LIABIL Warranty.
- Page 30 All manuals and user guides at all-guides.com Audiovox Electronics Corporation Hauppauge, NY 11788 Technical Assistance: 1-800-323-4815 www.jensen.com © 2007 Audiovox Ver. 052107 Printed in China...
