QFX5200-48Y Quick Start Guide
Mounting the QFX5200-48Y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Connecting Power to the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Performing the Initial Software Configuration for QFX5200 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Warnings Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Power Cable Warning (Japanese) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Contacting Juniper Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Mounting the QFX5200-48Y

The QFX5200-48Y is available in AC and DC power models. Only mount QFX5200-48Y models in a four-post rack. This procedure
describes the installation into a four-post rack and connecting AC power. For DC connection procedures, see the complete
QFX5200-48Y hardware documentation at
To install a Juniper Networks QFX5200-48Y, you need:
Electrostatic discharge (ESD) grounding strap (not provided)
One pair of front mounting brackets (provided)
One pair of adjustable rear mounting blades (provided)
One pair of rear mounting brackets to attach the mounting blades to the chassis (provided)
Twenty black flat head screws to secure the mounting rails and mounting blades to the chassis (provided)
Eight screws and cage nuts to secure the chassis and rack-mount kit to the rack (not provided)
Two washer head Phillips screws to lock the mounting blades to the rear brackets (provided)
Screwdriver appropriate for your rack-mounting screws (not provided)
Two power cords with plugs appropriate for your geographical location (provided)
RJ-45 cable and RJ-45 to DB-9 serial port adapter (provided)
Management host, such as a PC laptop, with a serial port (not provided)
Grounding cable and lug (not provided)
Two Phillips screws with star washers to ground the chassis (provided) (For instructions to attach the grounding cable and lug
to earth ground, see the
https://www.juniper.net/documentation/
.)
QFX5200 Hardware Guide
.

Advertisement

loading

Related Manuals for Juniper QFX5200-48Y

Summary of Contents for Juniper QFX5200-48Y

  • Page 1: Table Of Contents

    Mounting the QFX5200-48Y The QFX5200-48Y is available in AC and DC power models. Only mount QFX5200-48Y models in a four-post rack. This procedure describes the installation into a four-post rack and connecting AC power. For DC connection procedures, see the complete QFX5200-48Y hardware documentation at https://www.juniper.net/documentation/...
  • Page 2 NOTE: If you are mounting multiple units in the rack, mount the heaviest device at the bottom and mount the others from bottom to top in order of decreasing weight. The QFX5200-48Y weighs between 20.78 lb (9.43 kg) and 21.16 lb (9.6 kg) with power supplies and fans installed. Installing these devices in a rack or cabinet requires two people to lift the switch and secure it to the rack.
  • Page 3 Ensure that the chassis is level by verifying that all the screws on the front of the rack are aligned with the screws at the back of the rack. Secure the mounting rails to the rear mounting brackets using the two washer head screws. Tighten the screws. See Figure 5. Copyright © 2018, Juniper Networks, Inc.

  • Page 4: Connecting Power To The Device

    Understanding Zero Touch Provisioning in the Installation and Upgrade Guide. Before you begin connecting and configuring a QFX5200, set the following parameter values on the console server or PC: Baud Rate—9600 Flow Control—None Data—8 Parity—None Copyright © 2018, Juniper Networks, Inc.
  • Page 5 ) and (labeled ) are found on the FRU end of the switch. On the QFX5200-48Y, the management port is the top right-hand RJ-45 port on the port panel. (Optional) Configure the static routes to remote prefixes with access to the management port.

  • Page 6: Safety Warnings Summary

    Power Cable Warning (Japanese) The attached power cable is only for this product. Do not use this cable for another product. Copyright © 2018, Juniper Networks, Inc.

  • Page 7: Contacting Juniper Networks

    Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. and/or its affiliates in the United States and other countries. All other trademarks may be property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document.
