Humminbird 1158c Combo Installation And Operation Manual page 95

8
Upper Depth Range
1
Temperature Graph
2
Depth Lines
3
RTS® Window
4
Sonar Color Bar
5
Lower Depth Range
6
NOTE: If the Depth number is flashing, it means that the unit is having trouble locating the bottom. This usually
happens if the water is too deep, the transducer is out of the water, the boat is moving too fast, or for any other
reason that the unit can't accurately receive continuous data.
Sonar View
10
9
Course: the current direction the boat is traveling measured in degrees from North
83
1
2
3
7
6
11
Temp: Water Surface Temperature
Speed: Speed of Boat
4
5
12
Structure 7
Depth 8
9
10
11
VLT: Voltage 12
Views
