Remote Control
Packed Utility Packed Utility Status:
Status Confirmation:
Packed Alarm Packed Alarm Status:
Status Confirmation:
5.9.5

Stored Alarms

The 100 alarms are date/time stamped and stored in memory as they occur. The alarm
entry also is updated with its date/time of clearance. The entry remains in memory until it
is removed by command.
Total Stored Retrieve Total Alarms:
Alarms Confirmation:
Clear All Stored Clear Alarms:
Alarms Confirmation:
List All Alarms List All Alarms:
Confirmation:
16
KPA080 Ku-Band Solid-State Power Amplifier
<DEV/PACRUS_'cr'
>DEV/PACRUS_abbcdeeff'cr'' lf']
<DEV/PACRAS_'cr'
>DEV/PACRAS_abcdefghijkl'cr'' lf']
<DEV/TSA_'cr'
>DEV /TSATOTAL :nnn'cr'
LAST:hh:mm:ss mm/dd/yy'cr'' lf']
<DEV/CAA_YES'cr'
>DEV/CAA_CLEARED'cr'' lf']
<DEV/LAA_'cr'
>DEV/LAA'cr'
xxx yyyyyyyyyyy hh:mm:ss mm /dd/yy'cr'
xxx yyyyyyyyyyy hh:mm:ss mm/dd/yy'cr'
xxx yyyyyyyyyyy hh:mm:ss mm /dd/yy'cr'
xxx yyyyyyyyyyy hh:mm:ss mm/dd/yy'cr'
xxx yyyyyyyyyyy hh:mm:ss mm /dd/yy'cr'
xxx yyyyyyyyyyy hh:mm:ss mm/dd/yy'cr'' lf']
Where:
a = COM1 Mode; 0 =EIA-232,
1 = EIA-485-2; 2 = EIA-485-4
bb = Address in Hex (01 to FF)
c = 0 if Baud Rate = 9600
1 if Baud Rate = 4800
2 if Baud Rate = 2400
3 if Baud Rate = 1200
4 if Baud Rate = 300
d = 0 if Parity Even, 1 if Parity Odd
ee = LCD Contrast (0 to 30)
ff = LCD Brightness (0 to 30)
Where:
a = 1 if +28 Fault, else 0
b = 1 if +12 Fault, else 0
c = 1 if –12 Fault, else 0
d = 1 if + 5 Fault, else 0
e = 1 if – 5 Fault, else 0
f = 1 if + 9 PS#1 Fault, else 0
g = 1 if + 9 PS#2 Fault, else 0
h = 1 if TEMP Fault, else 0
I = 1 if SHTD Fault, else 0
j = 1 if FAN1 Fault, else 0
k = 1 if FAN2 Fault , else 0
l = 1 if PROC Fault, else 0
This command retrieves the total number
of stored alarms and the time and date of
the most recent alarm.
Where :
xxx = stored fault number
yyyyyyyyyyy = fault description
hh:mm:ss = fault time
mm/dd/yy = fault date
