Panasonic SA-HT995EE Service Manual

Dvd home theater sound system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Specifications

lGeneral
Power Source:
Power consumption:
Dimensions (W×H×D):
Mass:
lAmplifier section
RMS Output Power: Dolby Digital Mode
lTotal RMS Dolby Digital
mode Power:
At 1kHz and total harmonic of 10%
lFront:
lCenter:
lSurround:
At 100Hz and total harmonic of 10%
lSubwoofer:
DIN Output Power: Dolby Digital Mode:
lTotal DIN Dolby Digital mode Power:
At 1kHz and total harmonic of 1%
lFront:
lCenter:
AC 230V, 50Hz
120 W
430×60×354 mm
3.35kg
1000 W
125 W/ Channel (3Ω)
250 W/ Channel (6Ω)
65 W/ Channel (4Ω)
250 W/ Channel (6Ω)
470 W
80 W/ Channel (3Ω)
75 W/ Channel (6Ω)
DVD Home Theater Sound System
SA-HT995EE
Colour
(S).......................Silver Type
lSurround:
At 100Hz and total harmonic of 1%
lSubwoofer:
lPreset Memory:
lFrequency Modulation (FM)
Frequency Range:
Sensitivity:
S/N 26dB
Antenna Terminals:
lAmplitude Modulation (AM/MW)
Frequency Range:
AM Sensitivity S/N 20dB at
999kHz:
lDigital audio input:
Optical digital input:
Sampling frequency:
lPhone Jack:
Terminal:
lMic Jack:
© 2006 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO.MD0607242CE
80 W/ Channel (3Ω)
75 W/ Channel (6Ω)
FM 15 stations
AM/MW 15 stations
87.50-108.00MHz
(50kHz step)
2.5µV (IHF)
2.2µV
75Ω (unbalanced)
522-1629kHz (9kHz step)
560µV/m
Optical terminal (1 system)
32kHz, 44.1kHz, 48kHz
Stereo 3.5 mm jack
Unauthorized
copying
and
