Page 6
English Introduction Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome or via the SkinAnalyst app. Introducing Philips’ first ever complete shaving and skincare system. Assess and measure the...
Page 7
English Read this important information carefully before you use the shaver, the Skinanalyst sensor and save it for future reference. The accessories supplied may vary for different products. Danger - Keep the supply unit dry. Warning - To charge the battery, only use the detachable supply unit (type HQ8505) provided with the shaver.
Page 8
English - Do not open the shaver to replace the rechargeable battery. Caution - Never use water hotter than 80°C to rinse the shaver. - Never rinse the SkinAnalyst sensor under the tap. - Only use the shaver and the SkinAnalyst sensor for its intended purpose as shown in the user manual.
Page 9
Radio waves may impair the operation of pacemakers and other medical devices. Electromagnetic fields (EMF) - This Philips shaver complies with all shaver standards and regulations regarding exposure to electromagnetic fields. General - This shaver is waterproof. It is suitable for use in the bath or shower and for cleaning under the tap.
English The display 'Notification' symbol The shaver is equipped with a notification symbol. This symbol lights up when important advice is available in the app. Go to the app to obtain this advice. It reminds you to unplug the shaver before you switch it on and to clean it for optimal performance.
English Shaving unit detector The shaving unit detector lights up to indicate that the shaving unit has been attached to the handle. Cleansing brush detector The cleansing brush detector lights up to indicate that the cleansing brush has been detected. Cleaning reminder When you switch off the shaver, the cleaning reminder flashes to remind you to clean the...
Page 12
English Activating the travel lock 1 Press the on/off button for 3 seconds to enter the travel lock mode. 3 sec. While you activate the travel lock, the travel lock symbol flashes. When the travel lock is activated, the travel lock symbol lights up continuously. Deactivating the travel lock 1 Press the on/off button for 3 seconds.
English Battery fully charged When the battery is fully charged, the battery charge indicator lights up blue continuously. Note: The shaver can only be used without cord. Note: When the battery is full, the display switches off automatically after 30 minutes. If you press the on/off button during charging, the notification symbol lights up blue to remind you that you have to disconnect the shaver from the wall socket.
English Preparing for use Pairing the shaver and your iPhone For this shaver a special app is available. You can download the SkinAnalyst app from the App store. By using the app, your skincare and shaving routine will be personalized. The app gives you expert advice based on your skin, shaving method, local weather conditions, etc.
English 6 In the app, the pop-up message 'press pair' appears. When your iPhone and the shaver have been paired successfully, the Bluetooth symbol flashes briefly and then goes out. If this does not happen, please see 'Troubleshooting'. 7 Once the shaver and the app have been paired, the shaver automatically selects the right personal settings depending on the attachment you have clicked on.
English 4 Insert the jack plug of the SkinAnalyst sensor into your iPhone. 5 Remove the protection cap from the SkinAnalyst sensor. Note: Above instructions are also shown in the app. The SkinAnalyst sensor only works if you remove the case of your iPhone. 6 Follow the instructions in the app to measure your skin.
English 5 Keep your iPhone and shaver close to each other in order to stay connected. Caution: Do not use your iPhone in moist surroundings. Moisture and water can damage your iPhone. Switching the shaver on and off 1 To switch on the shaver, press the on/off button once.
English Using the attachments Note: Attach the cleansing brush on the cleansing brush base first, before you place it on the shaver. Removing or attaching the attachments 1 Make sure the shaver is switched off. 2 Pull the attachment straight off the shaver. Note: Do not twist the attachment while you pull it off the shaver.
Page 19
English 2 Moisten the cleansing brush with water. Note: Do not use the shaver with a dry cleansing brush, as this can irritate the skin. 3 Moisten your face with water and apply a cleanser to your face. 4 Place the cleansing brush on your cheek. 5 Switch on the shaver.
Page 20
English Note: We advise you to not overdo the cleansing and to not cleanse any zone longer than 15-20 seconds. 9 After the treatment, rinse and dry your face.Your face is now ready for the next step of your daily skincare routine. 10 Clean the cleansing brush after use.
Page 21
English Note: Do not press too hard, this can cause skin irritation. 3 Clean the shaver after use. Wet shaving You can also use this shaver on a wet face with shaving foam or shaving gel. To shave with shaving foam or shaving gel, follow the steps below: 1 Apply some water to your skin.
English Note: Make sure you rinse all foam or shaving gel off the shaver. Shave settings The app has a feature that allows you to personalize your shave settings. Go to the Usage Tracker and change the shaving settings. You can adjust the settings and choose between three settings depending on your personal shaving needs: extra sensitive (xs), sensitive (s) and normal...
English Cleaning the shaving unit under the tap Clean the shaving unit after every shave for optimal performance. Be careful with hot water. Always check if the water is not too hot, to prevent burning your hands. Never dry the shaving unit with a towel or tissue, as this may damage the shaving heads.
English 7 Attach the shaving head holder to the bottom part of the shaving unit (‘click’). Cleaning the cleansing brush Clean the cleansing brush every time you have used it. 1 Switch off the shaver. 2 Detach the brush head from the attachment holder.
Page 25
English 3 Gently clean the two mirror plates inside the SkinAnalyst sensor with a cotton swab which has been dipped in alcohol. 4 Dry the mirror plates with a clean cotton swab. Storage Note: We advise you to let the shaver and its attachments dry before you put the protection caps on the cleansing brush and SkinAnalyst sensor and store the shaver in the pouch.
Replace damaged shaving heads immediately. Always replace the shaving heads with original Philips shaving heads (see 'Ordering accessories'). 1 Switch off the shaver. 2 Pull the shaving head holder off the bottom part of the shaving unit.
English 5 Place the new shaving heads in the shaving head holder. Note: Make sure the notches on both sides of the shaving heads fit exactly onto the projections in the shaving head holder. 6 Place the retaining rings back onto the shaving heads and turn them clockwise to reattach the retaining ring.
Ordering accessories To buy accessories or spare parts, visit www.shop.philips.com/service or go to your Philips dealer. You can also contact the Philips Consumer Care Center in your country (see the international warranty leaflet for contact details). The following accessories and spare parts are...
Page 29
English the battery, make sure that the shaver is disconnected from the mains and that the battery is completely empty. Take any necessary safety precautions when you handle tools to open the shaver. Be careful, the battery strips are sharp. 1 Remove the screw in the back panel with a screwdriver.
SkinAnalyst sensor and its accessories. If you are unable to solve the problem with the information below, visit www.philips.com/support for a list of frequently asked questions or contact the Consumer Care Center in your country.
Page 31
English Problem Possible cause Solution Bluetooth is not Make sure Bluetooth switched on. is enabled on the shaver and your iPhone. The shaver is not Make sure the shaver charged. is charged. I want to use the You can also use the shaver without the shaver without the app.
Page 32
English Problem Possible cause Solution The shaver does not The shaving heads Replace the shaving shave as well as it are damaged or worn. heads (see used to. 'Replacing the shaving heads'). Hairs or dirt obstruct Clean the shaving the shaving heads. heads in the regular way or clean them thoroughly.
Page 33
English Problem Possible cause Solution The shaver doesn't The attachment is Try to clean the detect the right heavily polluted or attachment (see attachment. damaged. 'Cleaning and maintenance'); if the issue persists, switch off the detection feature from the app and select the attachment manually by pressing the...
Page 34
English Problem Possible cause Solution I get an error in the You did not place the Place the SkinAnalyst app during skin SkinAnalyst sensor sensor flat on your measurement. flat on your skin. skin. You did not insert the Remove the plug of plug of the the SkinAnalyst SkinAnalyst sensor...
