SCALANCE X-200
SIMATIC NET
Industrial Ethernet Switches
SCALANCE X-200
Operating Instructions
03/2015
C79000-G8976-C284-06
___________________
Preface
___________________
Functions
___________________
Description of the device
___________________
Safety notices
___________________
Installation
___________________
Connecting up
___________________
Approvals
___________________
Technical specifications
___________________
Dimension drawings
___________________
Test of mechanical stability
___________________
Training, Service & Support
1
2
3
4
5
6
7
A
B
C

Advertisement

Table of Contents
loading

Related Manuals for Siemens SCALANCE X-200

Summary of Contents for Siemens SCALANCE X-200

  • Page 1 ___________________ SCALANCE X-200 Preface ___________________ Functions ___________________ SIMATIC NET Description of the device ___________________ Safety notices Industrial Ethernet Switches SCALANCE X-200 ___________________ Installation ___________________ Connecting up Operating Instructions ___________________ Approvals ___________________ Technical specifications ___________________ Dimension drawings ___________________ Test of mechanical stability ___________________ Training, Service &...

  • Page 2: Legal Information

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    ● One 4-pin plug-in terminal block ● One DVD (configuration manual, operating instructions, Primary Setup Tool, GSD file, SNMP OPC profile) The following components are supplied with a SCALANCE X-200 IE switch with the PRO supplement: ● One device ● Protective caps for the data interfaces ●...
  • Page 4 ● On the data medium that ships with some products: – Product CD / product DVD – SIMATIC NET Manual Collection ● On the Internet pages of Siemens Industry Online Support (http://support.automation.siemens.com/WW/view/en/33118791/133300). Validity of the Operating Instructions These operating instructions are valid for the following devices:...
  • Page 5 Unless mentioned otherwise, the descriptions in these operating instructions refer to all devices of the SCALANCE X-200 product line named above in the section on Validity. In the remainder of the instructions, these will also be referred to as IE switches or also simply as X-200.

  • Page 6: Operating Instructions, 03/2015, C79000-G8976-C284

    SIMATIC NET products that you can operate along with the devices of this product line in an Industrial Ethernet network. You will find the system manuals on the Internet pages of Siemens Industry Online Support under the following entry IDs: ●...
  • Page 7 Preface Where to find Siemens documentation ● Article numbers You will find the article numbers for the Siemens products of relevance here in the following catalogs: – SIMATIC NET - Industrial Communication / Industrial Identification, catalog IK PI – SIMATIC - Products for Totally Integrated Automation and Micro Automation, catalog...
  • Page 8 ● On the Internet under the following entry ID: 50305045 (http://support.automation.siemens.com/WW/view/en/50305045) Trademarks The following and possibly other names not identified by the registered trademark sign ® registered trademarks of Siemens AG: SIMATIC NET, SCALANCE, C-PLUG, OLM SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 9: Table Of Contents

    Power supply via terminal block ..................... 44 5.2.2 Supply for X208PRO ......................45 5.2.3 Supply for IRT-PRO devices ....................45 Grounding ..........................48 Signaling contact ........................49 Attachment to Industrial Ethernet ................... 51 5.5.1 Electrical connections ......................51 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 10 5.5.3 Push-pull connector for IRT-PRO devices ................58 Approvals ..............................59 Technical specifications ........................... 67 Dimension drawings ..........................77 Test of mechanical stability ........................83 Training, Service & Support ........................85 Index ................................ 87 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 11: Functions

    ● WBM - Web Based Management ● Configuration with STEP 7 ● SNMP ● Ring redundancy including redundancy manager ● Passive Listening ● FM devices support the Fiber Monitoring Protocol and allow the monitoring of optical line sections. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 12 • Between a port set to 10 Mbps and a port set to 100 Mbps. • When two packets are to be sent at the same time on one port. In this case, an X-200 IE switch changes to Store&Forward and the delay increases. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 13 The number before the hyphen in the product name indicates the number of electrical connectors. The number following the hyphen indicates the number of optical connectors of the device. For example, the switch X212-2 has twelve electrical and two optical connectors. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 14 Functions SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 15: Description Of The Device

    3 Connector for signaling contact 4 Connector for power supply 5 SET button 6 Optical attachment to Industrial Ethernet 7 Electrical attachment to Industrial Ethernet 8 (on rear of device, not shown in figure:) Slot for C- PLUG SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 16 Connector for power supply Connector for signaling contact (behind the connectors, not shown in figure:) SET button (on side of device, not shown in figure:) Slot for C-PLUG LEDs for attachments to Industrial Ethernet SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 17: The Leds

    No power supply is connected or the voltage is < 14 VDC or with TS devices < 8 VDC. Note The following devices do not have a redundant power supply: • X201-3P IRT PRO • X202-2P IRT PRO • X204IRT PRO SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 18: Fault Led "F" (Yellow/Red Led)

    The device is operating in the role of redundancy manager. An interruption was de- tected in the ring. The device has switched through. The device is not operating in the role of redundancy manager. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 19: Standby Led "Rm" (Yellow Led)

    The standby function is activated, the switch is in active mode. Yellow Flashes slowly The standby function is activated, the switch is in passive mode. Yellow Flashes quickly Standby partner lost. The standby function is not activated. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 20: Port Leds "P" (Green/Yellow Leds)

    All port LEDs of the addressed node flash green at 2 Hz. With the Primary Setup Tool (PST) V3.0 or higher, you can trigger this function with "Module \ Flash". SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 21: The Set Button

    The RM LED is lit permanently. If you release the button in phase 5, the redundancy function is activated and the device is configured as HRP manager. All LEDs flash. The device is reset to the factory defaults. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 22: The C-Plug

    PLUG is taken from the failed component and inserted in the replacement device. The first time it is started up, the replacement device has the same configuration as the failed device except for the MAC address set by the vendor. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 23 C-PLUG. If you operate a device with a C-PLUG, the C-PLUG can either be initialized with the factory settings or with the settings stored internally on the device. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 24 • Insert and remove the C-PLUG only when power is off. • In a device with a varnished printed circuit board, you may only use a C-PLUG with a varnished board. Figure 2-2 C-PLUG and slot SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 25 Web Based Management and in the Command Line Interface. In this case, you will need to set the device to operation without C-PLUG. For further information, refer to the section "System C-PLUG" in the section on the WBM menu in the configuration manual. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 26 Description of the device 2.4 The C-PLUG SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 27: Safety Notices

    The current descriptions of the currently available products can be found on the Product Support pages under the entry IDs below: ● Configuration manual SIMATIC NET PH SCALANCE X-200 63203259 (http://support.automation.siemens.com/WW/view/en/63203259) ● System manual SIMATIC NET Industrial Ethernet Network Manual 27069465 (http://support.automation.siemens.com/WW/view/en/27069465)
  • Page 28 Safety notices 3.1 Safety notices in general Special safety notices You should also read the safety notices relating to handling in the individual sections, particularly in the sections "Installation" and "Connecting up". SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 29: Safety Notices For Hazardous Areas

    This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non- hazardous locations only. This equipment is suitable for use in Class I, Zone 2, Group IIC or non-hazardous locations only. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 30: Security Recommendations

    Software (security functions) ● Keep the software up to date. Check regularly for security updates of the product. You will find information on this at: www.siemens.com/industrialsecurity (http://www.siemens.com/industrialsecurity) ● Only activate protocols that you really require to use the device.
  • Page 31 The following list provides you with an overview of the open ports on this device. Keep this in mind when configuring a firewall. The table includes the following columns: ● Protocol All protocols that the device supports ● Port number Port number assigned to the protocol SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 32 TCP/80 Open Open HTTPS TCP/443 Open Open SNTP UDP/123 Open Closed NTP (secure) (when configured) SNMP UDP/161 Open Open (when configured) PROFINET IO UDP/34964 Open Open UDP/1026, 1027 PROFINET IO TCP/84 Open Open Service SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 33: Installation

    80 °C, special precautions must be taken. If the equipment is operated in an air ambient in excess of 50 °C, only use cables with admitted maximum operating temperature of at least 80 °C. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 34 IECEx approval according to Ex nA [op is Gb] IIC T4 Gc, refer to the section "Approvals (Page 59). This is indicated on the type plate. With these devices the FO bus connections may run through or in a Zone 1 hazardous area. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 35 With the following IE switches, an ambient temperature of maximum +40 °C is permitted if the device is installed on a vertical rail: • X204-2TS • X204-2LD TS • XF204 • XF204-2 • XF206-1 • XF208 • XF204IRT SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 36: Installation Options

    ● Wall mounting Unless stated otherwise, the mounting options listed below apply to all X-200 IE switches. Exception XF-200 The XF devices (flat design) can only be installed on a 35 mm DIN rail. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 37: Installation On A Din Rail

    To remove an X-200 from a DIN rail, follow the steps below: 1. First disconnect all connected cables. 2. Use a screwdriver to release the lower DIN rail catch of the device and pull the lower part of the device away from the rail. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 38: Installation On A Standard Rail

    To remove an X-200 from a standard rail, follow the steps below: 1. First disconnect all connected cables. 2. Release the screws on the bottom of the standard rail. 3. Then lift the X-200 away from the standard rail. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 39: Wall Mounting

    2. Connect the electrical cable connecting cables. 3. Fit the connectors for the signaling contact. 4. Insert the terminal blocks or M12 cable connectors into the sockets on the IE Switch X- 200. 5. Screw the device to the wall. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 40 Installation 4.5 Wall mounting SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 41: Connecting Up

    For the devices listed below, there are no requirements according to NEC Class 2 or LPS. For these devices, note the conditions described in the section Supply for IRT-PRO devices (Page 45). ● X201-3P IRT PRO ● X202-2P IRT PRO ● X204IRT PRO SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 42 WARNING Take measures to prevent transient voltage surges of more than 40% of the rated voltage. This is the case if you only operate devices with SELV (safety extra-low voltage). SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 43 A suitable device is, for example, the Dehn Blitzductor BVT AVD 24 V type no. 918 422 or a comparable protective element. Manufacturer: DEHN+SÖHNE GmbH+Co.KG, Hans-Dehn-Str.1, Postfach 1640, D-92306 Neumarkt, Germany. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 44: Power Supply

    L2: 24 VDC With TS devices: L2: 12 to 24 VDC Note Special features with X208PRO and the IRT-PRO devices Note the special requirements for the power supply for the devices in the following sections. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 45: Supply For X208Pro

    (IP65/IP67) and is suitable for use outside cabinets and complies with PROFINET connector technology. The Power Plug PRO does not ship with the device and can be ordered under the following order number: 6GK1907-0AB10-6AA0 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 46 • Suitable for DC (min. 60 V / max. 16 A) • Breaking current at least 10 kA • Approved according to IEC/EN 60127-1 • Breaking characteristics – With circuit breakers: B or C – With fuses: slow blow SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 47 SCALANCE X204IRT PRO only: +70°C Pin assignment of the connectors The following table shows the pin assignment of the two power supply connectors: Pin no.: Assignment L1: 24 VDC L2: 24 VDC FE (Functional Earth) SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 48: Grounding

    If an IE Switch X-200 is mounted on a non-conducting base, a grounding cable must be installed. The grounding cable is not supplied with the device. Connect the paint-free surface of the device to the nearest grounding point using the grounding cable. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 49: Signaling Contact

    The signaling contact can be subjected to a maximum load of 100 mA (safety extra-low voltage (SELV), 24 VDC). Connection via 2-pin terminal block The signaling contact is connected to a 2-pin plug-in terminal block. The following table shows the pin assignment: Assignment no.: SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 50 Connection via M12 socket With the X-200 IRT PRO devices and with the X208PRO, the connection is via a 5-pin, b- coded M12 socket. The following table shows the pin assignment: Assignment no.: n.c. n.c. n.c. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 51: Attachment To Industrial Ethernet

    – Select "Enable Standby Master". – The "Standby Connection Name" must match the name of the partner device. – You must also configure the standby port. You will find detailed information in the SCALANCE X-200 configuration manual. 5.5.1 Electrical connections 5.5.1.1...

  • Page 52: Scalance X

    This means it may be necessary to use a crossover cable. Auto polarity exchange If the pair of receiving cables is incorrectly connected, in other words, RD+ and RD- are swapped over, the polarity is reversed automatically. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 53: Electrical Connectors Of The X208Pro

    Formation of loops Please note that the direct connection of two ports on the switch or accidental connection over several switches causes an illegal loop. Such a loop can lead to network overload and network failures. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 54 The IE FC M12 Plug PRO has a high degree of protection (IP65/67) and is suitable for connecting the X208PRO to Industrial Ethernet. You can obtain this plug using the following order number: 6GK1 901-0DB20-6AA0. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 55: Optical Attachments To Industrial Ethernet

    125 μm Light source Maximum range (segment length) 5 km Note No autonegotiation With optical transmission, the full duplex mode and transmission speed cannot be changed. For this reason, the autonegotiation function cannot be selected. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 56: Single Mode Fiber-Optic Cable

    The following X-200 IE switches use Plastic Optical Fiber (POF) or Polymer Cladded Fiber (PCF) as the transmission medium: ● X200-4P IRT ● X201-3P IRT ● X201-3P IRT PRO ● X202-2P IRT ● X202-2P IRT PRO SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 57 With optical transmission, the full duplex mode and transmission speed cannot be changed. For this reason, the autonegotiation function cannot be selected. GI-PCF For segment lengths longer than 100 m, you can use GI-PCF cables. Note the information of the manufacturer. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 58: Push-Pull Connector For Irt-Pro Devices

    IE SC RJ POF Plug PRO and IE SC RJ PCF Plug PRO For the optical attachment, use one of the following connectors: ● IE SC RJ POF Plug PRO Order no.: 6GK1 900-0MB00-6AA0 ● IE SC RJ PCF Plug PRO Order no.: 6GK1 900-0NB00-6AA0 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 59: Approvals

    Approvals for shipbuilding are not printed on the device type plate. Current approvals on the Internet You will also find the current approvals for the product on the Internet pages of Siemens Industry Online Support under the following entry ID: 33118791 (http://support.automation.siemens.com/WW/view/en/33118791)
  • Page 60 The current versions of the standards can be seen in the EU Declaration of Conformity. II 3 G Ex nA IICT4 Gc The IE switches SCALANCE X-200 meet the requirements according to II 3 G Ex nA IIC T4 Gc, certificate no.: KEMA 07ATEX0145 X:...
  • Page 61 Approvals II 3 (2) G Ex nA [op is] IIC T4 The IE switches SCALANCE X-200 listed below have additional approval according to II 3 (2) G Ex nA [op is] IIC T4, certificate no.: DEKRA11ATEX0060 X: X204-2 XF204-2 •...
  • Page 62 ● IEC 60079-0 (Explosive atmospheres - Part 0: Equipment - General requirements) ● IEC 60079-28 (Explosive atmospheres - Part 28: Protection of equipment and transmission systems using with optical radiation) The following SCALANCE X-200 IE switches also meet these requirements: X204-2 XF204-2 •...
  • Page 63 Cl. 1, Div. 2, GP A, B, C, D T4 Cl. 1, Zone 2, GP IIC T4 Report no. E240480 CSA Approval for Information Technology Equipment CSA Certification Mark Canadian Standard Association CSA C22.2 No. 60950-1-03 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 64 CSA Approval for Industrial Control Equipment CSA Certification Mark Canadian Standard Association CSA C22.2 No. 142-1987 FDA and IEC approvals The following SCALANCE X-200 switches meet the FDA and IEC requirements listed below: ● X204-2LD ● X204-2LD TS ● X206-1LD ●...
  • Page 65 Approvals Railway approval The TS variant of the device meets the requirements of the Railway standard EN 50155:2007 "Railway Applications - Electronic equipment used on rolling stock". SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 66 Approvals SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 67: Technical Specifications

    60 x 125 x 124 X202-2P IRT PRO 90 x 125 x 124 1000 X204IRT 60 x 125 x 124 X204IRT PRO 90 x 125 x 124 1000 XF204IRT 75 x 125 x 73 DIN rail mounting only. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 68 2-pin plug-in terminal RJ-45 jacks with MDI X SC RJ jacks (push-pull) block, redundant block pinning (100 Mbps, full duplex to 10/100 Mbps (half / full 100BaseFX) duplex) X200-4P IRT X201-3P IRT X202-2P IRT SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 69: Electrical Data

    600 mA / 60 V X208PRO 4.4 W 185 mA 600 mA / 60 V X212-2 7.92 W 330 mA 1.1 A / 33 V X212-2LD 7.92 W 330 mA 1.1 A / 33 V SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 70 [dBm] max. [dBm] Sensitivity min. [dBm] Input power max. [dBm] X204-2 X204-2TS X204-2FM X206-1 X212-2 XF204-2 XF206-1 X202-2IRT X204-2LD X204-2LD TS X206-1LD X212-2LD X200-4P IRT X201-3P IRT X201-3P IRT X202-2P IRT X202-2P IRT SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 71 IE FC TP marine / trailing / flexible / FRNC / festoon / food cable with IE FC RJ-45 Plug ● 0 to 100 m: IE FC TP standard cable with IE FC RJ-45 plug 180 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 72 6 dB max. permitted cable attenuation with 3 dB link power margin X204-2 X204-2TS X204-2FM X204-2LD X204-2LD TS X206-1 X206-1LD X212-2 X212-2LD XF204-2 XF206-1 X200-4P IRT X201-3P IRT X201-3P IRT PRO X202-2IRT X202-2P IRT X202-2P IRT PRO SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 73 30 s Store and forward 5 μs X-200IRT 4096 30 s (configurable) Store and forward / cut through < 5 μs XF204IRT 4096 30 s (configurable) Store and forward / cut through < 5 μs SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 74 2000 m at max. 56 ℃ 3000 m at max. 50 ℃ XF206-1 -40 °C to +60 ℃ *) -40 °C to +70 ℃ ‹ 95 % 2000 m at max. 56 ℃ 3000 m at max. 50 ℃ SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 75 • Between a port set to 10 Mbps and a port set to 100 Mbps. • When two packets are to be sent at the same time on one port. In this case, an X-200 IE switch changes to Store&Forward and the delay increases. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 76 Technical specifications SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 77: Dimension Drawings

    Dimension drawings Figure A-1 Drilling pattern SCALANCE X204-2, X204-2TS, X204-2FM, X204-2LD, X204-2LD TS, X206-1, X206-1LD, X208, X200-4P IRT, X201-3P IRT, X202-2IRT, X202-2P IRT, X204IRT SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 78 Dimension drawings Figure A-2 Drilling pattern SCALANCE X212-2, X212-2LD and X216 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 79 Dimension drawings Figure A-3 Drilling pattern SCALANCE X224 Figure A-4 Side view SCALANCE X-200 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 80 Dimension drawings Figure A-5 Side view SCALANCE X-200 POF with POF interface Figure A-6 Dimension drawings of the SCALANCE X208PRO, SCALANCE X201-3P IRT PRO, SCALANCE X202-2P IRT PRO and SCALANCE X204IRT PRO SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 81 Dimension drawings Figure A-7 Drilling pattern of the SCALANCE X208PRO, SCALANCE X201-3P IRT PRO, SCALANCE X202-2P IRT PRO and SCALANCE X204IRT PRO SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 82 Dimension drawings Figure A-8 SCALANCE XF-200 dimension drawings SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 83: Test Of Mechanical Stability

    6 shocks per axis 1 octave/min, 20 sweeps XF204-2 5 – 9 Hz: 3.5 mm 15 g, 6 ms duration 9 – 500 Hz: 1 g 6 shocks per axis 1 octave/min, 20 sweeps SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
  • Page 84 If only ports of different port groups are used, the device meets the requirements for Environment B in compliance with IEEE 802.3, Section 33.4.1.1. If ports of the same port group are used, the requirements for Environment A are met. SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 85: Training, Service & Support

    In addition to the product documentation, the comprehensive online information platform of Siemens Automation Customer Support supports at any time and at any location in the world. You will find the Service & Support pages on the Internet at the following address: (http://support.automation.siemens.com/WW/llisapi.dll?func=cslib.csinfo2&aktprim=99&lang=...
  • Page 86 Training, Service & Support SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...

  • Page 87: Index

    Glossary, 8 MDI / MDI-X autocrossover, 52, 53 Node localization, 20 Number of connectors, 13 Operating instructions, 4 Order number C-PLUG, 24 Power Plug PRO, 45 Overview of the functions, 13 Polarity reversal, 52 SCALANCE X-200 Operating Instructions, 03/2015, C79000-G8976-C284-06...
