Power to/from PE653RC with P5043ME

NOTE: Contact Tech Support at Intermatic for additional diagrams.
NEUTRAL BUS
Hot Line #1 Red
Hot Line #2 Black
Hot Line #1
Hot Line #2
Hot Line #1
2-Pole Breaker
P5043ME
Figure 3-7. Wiring 240V incoming power to PE653RC and P5043ME.
Installing — Ratings, 120V/240V Wiring, Power In/Out
RECEIVER
POWER
SUPPLY
120V
240V
21
Hot Line #1
