SAR-M CHASSIS INSTALLATION GUIDE
Alcatel-Lucent 7705
SERVICE AGGREGATION ROUTER | RELEASE 5.0
SAR-M CHASSIS INSTALLATION GUIDE
Alcatel-Lucent Proprietary
This document contains proprietary information of Alcatel-Lucent and is not to be
disclosed or used except in accordance with applicable agreements.
Copyright 2011 © Alcatel-Lucent. All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Alcatel-Lucent 7705

Summary of Contents for Alcatel-Lucent 7705

  • Page 1 SERVICE AGGREGATION ROUTER | RELEASE 5.0 SAR-M CHASSIS INSTALLATION GUIDE Alcatel-Lucent Proprietary This document contains proprietary information of Alcatel-Lucent and is not to be disclosed or used except in accordance with applicable agreements. Copyright 2011 © Alcatel-Lucent. All rights reserved.
  • Page 2 This document may contain information regarding the use and installation of non-Alcatel-Lucent products. Please note that this information is provided as a courtesy to assist you. While Alcatel-Lucent tries to ensure that this information accurately reflects information provided by the supplier, please refer to the materials provided with any non-Alcatel-Lucent product and contact the supplier for confirmation.

  • Page 3: Table Of Contents

    EMC/EMI Compliance ...........................46 General................................46 Laser Interface ..............................47 Safety Approval for DC Systems ........................47 Protective Earth ............................47 Approval for External AC Rectifiers .......................47 Eco-Environmental ............................48 Material Content Compliance ........................49 Australia/New Zealand Regulations ........................50 ACMA Regulations ............................50 7705 SAR-M Chassis Installation Guide...
  • Page 4 Safety ................................51 Packaging Collection and Recovery Requirements ..................51 Material Content Compliance ........................51 7705 SAR-M Overview.......................... 53 In This Chapter ..............................53 Overview of the 7705 SAR-M Variants.......................54 7705 SAR-M Components..........................56 Chassis................................56 Control and Switching ...........................58 Module Slot (Available on Two Variants) ......................59 Filler Plate ...............................60...
  • Page 5 Connecting an External Synchronization Input ...................126 Providing an External Synchronization Output ....................127 Making External Alarm Connections ........................128 Connecting an External Alarm ........................128 Making Router Management Connections .......................129 Initializing and Provisioning......................131 In This Chapter ..............................131 7705 SAR-M Chassis Installation Guide...
  • Page 6 Appendix A: 7705 SAR-M Connectors and LEDs ................145 In This Chapter ..............................145 7705 SAR-M Connectors and LEDs (Variants with Module Slot, Actively Cooled) ..........146 7705 SAR-M Connectors and LEDs (Variants with No Module Slot, Passively Cooled)........152 Appendix B: Pinout Assignments..................... 159 In This Chapter ..............................159...
  • Page 7 List of Terms ..........................36 7705 SAR-M Overview.......................... 53 Table 4 Ordereable Compact Flashes .......................59 Site Preparation ............................ 67 Table 5 7705 SAR-M Chassis Specifications per Variant ................71 Table 6 Environmental Specifications per Variant ..................72 Table 7 Chassis Power Consumption ......................74 Table 8 Module Physical Specifications .....................75...
  • Page 8 ADP Stage LED Indicators ......................138 Table 28 Console Port Default Settings .....................139 Table 29 CLI Port Identifiers ........................143 Appendix A: 7705 SAR-M Connectors and LEDs ................145 Table 30 7705 SAR-M Connector and LED Descriptions .................146 Table 31 Module LED Descriptions ......................151 Table 32 7705 SAR-M Connector and LED Descriptions .................153...
  • Page 9 WEEE Symbol for post-August 13, 2005 Product................48 7705 SAR-M Overview.......................... 53 Figure 5 Exploded View: 7705 SAR-M Chassis Variant with Module Slot and 16 T1/E1 Ports ....57 Figure 6 Faceplate: 7705 SAR-M Chassis Variant with Module Slot and 16 T1/E1 Ports ......57 Figure 7 Faceplate: 7705 SAR-M Chassis Variant with Module Slot and No T1/E1 Ports ......57...
  • Page 10 Appendix B: Pinout Assignments..................... 159 Figure 37 7705 SAR-M Port Connectors (Variant with Module Slot, Actively Cooled) ........160 Figure 38 7705 SAR-M Port Connectors (Variants with No Module Slot, Passively Cooled) ......160 Figure 39 Management Port Pin Numbers....................161 Figure 40 ToD Port Pin Numbers.........................163...

  • Page 11: List Of Acronyms

    ANSI American National Standards Institute Apipe ATM VLL 7705 SAR-M Chassis Installation Guide...
  • Page 12 (first packet of a fragment) committed burst size excess burst size BECN backward explicit congestion notification Bellcore Bell Communications Research bidirectional forwarding detection border gateway protocol BITS building integrated timing supply BMCA best master clock algorithm 7705 SAR-M Chassis Installation Guide...
  • Page 13 BRAS Broadband Remote Access Server Base Station Controller BSTA Broadband Service Termination Architecture base transceiver station channel associated signaling common bonding networks committed buffer space control channel continuity check continuity check message 7705 SAR-M Chassis Installation Guide...
  • Page 14 CPM management ports in the CLI. central processing unit command/response cyclic redundancy check CRC-32 32-bit cyclic redundancy check CRON a time-based scheduling service (from chronos = time) Control and Switching Module CSNP complete sequence number PDU 7705 SAR-M Chassis Installation Guide...
  • Page 15 DHCP dynamic host configuration protocol DHCPv6 dynamic host configuration protocol for IPv6 designated intermediate system DLCI data link connection identifier DLCMI data link connection management interface delay measurement domain name server denial of service 7705 SAR-M Chassis Installation Guide...
  • Page 16 (last packet of a fragment) ECMP equal cost multi-path Ethernet in the first mile exterior gateway protocol EIA/TIA-232 Electronic Industries Alliance/ Telecommunications Industry Association Standard 232 (also known as RS-232) excess information rate ELER egress label edge router 7705 SAR-M Chassis Installation Guide...
  • Page 17 FEAC far-end alarm and control forwarding equivalence class FECN forward explicit congestion notification fixed filter forwarding information base FIFO first in, first out fault notification generator 7705 SAR-M Chassis Installation Guide...
  • Page 18 3 HDLC high-level data link control protocol header error control HMAC hash message authentication code Hpipe HDLC VLL hot standby HSDPA high-speed downlink packet access HSPA high-speed packet access HVPLS hierarchical virtual private line service 7705 SAR-M Chassis Installation Guide...
  • Page 19 Internet Protocol IPCP Internet protocol control protocol IPIP IP in IP Ipipe IP interworking VLL IPoATM IP over ATM IS-IS Intermediate System-to-Intermediate System IS-IS-TE IS-IS-traffic engineering (extensions) International Organization for Standardization interworking 7705 SAR-M Chassis Installation Guide...
  • Page 20 ID loss measurement local management interface link-state advertisement LSDB link-state database label switched path link-state PDU (for IS-IS) label switch router link-state request link-state update linktrace line termination equipment linktrace message LSP ID to NHLFE 7705 SAR-M Chassis Installation Guide...
  • Page 21 Metro Ethernet Forum maintenance entity group MEG-ID maintenance entity group identifier Metro Ethernet network maintenance association end point multi-field classification MIP half function management information base management information base 7705 SAR-M Chassis Installation Guide...
  • Page 22 MAC Service Data Unit MS-PW multi-segment pseudowire MTIE maximum time interval error MTSO mobile trunk switching office maximum transmission unit multi-tenant unit M-VPLS management virtual private line service microwave microwave awareness newton meter NBMA non-broadcast multiple access (network) 7705 SAR-M Chassis Installation Guide...
  • Page 23 OAMPDU OAM protocol data units optical carrier level 3 optical line termination optical network terminal off premise extension outbound route filtering operating system Open Systems Interconnection (reference model) OSINLCP OSI Network Layer Control Protocol 7705 SAR-M Chassis Installation Guide...
  • Page 24 PFoE power feed over Ethernet per-hop behavior physical layer protocol ID peak information rate PLCP Physical Layer Convergence Protocol point of local repair point of presence packet over SONET point-to-point protocol 7705 SAR-M Chassis Installation Guide...
  • Page 25 RADIUS Remote Authentication Dial In User Service Radio Access Network robbed bit signaling route distinguisher remote defect indication random early discard RESV reservation routing information base RJ-45 registered jack 45 Radio Network Controller 7705 SAR-M Chassis Installation Guide...
  • Page 26 Radio and Telecommunications Terminal Equipment remote terminal unit rack unit service assurance agent service access point SAR-8 7705 Service Aggregation Router - 8-slot chassis SAR-18 7705 Service Aggregation Router - 18-slot chassis SAR-F 7705 Service Aggregation Router - fixed form-factor chassis...
  • Page 27 List of Acronyms Table 1: Acronyms (Continued) Acronym Expansion SAR-M 7705 Service Aggregation Router - four variants: • actively cooled chassis with 16 T1/ E1 ports, 7 Ethernet ports, and 1 hot-insertable module slot • actively cooled chassis with 0 T1/...
  • Page 28 1 spanning tree protocol switched virtual circuit synchronize TACACS+ Terminal Access Controller Access- Control System Plus traffic class (formerly known as bits) transmission control protocol TDEV time deviation time division multiplexing traffic engineering 7705 SAR-M Chassis Installation Guide...
  • Page 29 Universal Mobile Telecommunications System (3G) user-to-network interface V.11 ITU-T V-series Recommendation 11 V.24 ITU-T V-series Recommendation 24 V.35 ITU-T V-series Recommendation 35 virtual circuit virtual channel connection VCCV virtual circuit connectivity verification virtual circuit identifier 7705 SAR-M Chassis Installation Guide...
  • Page 30 WCDMA wideband code division multiple access (transmission protocol used in UMTS networks) WRED weighted random early discard wait to restore X.21 ITU-T X-series Recommendation 21 7705 SAR-M Chassis Installation Guide...

  • Page 31: Preface

    (listed below) for details on the boot process, software configuration, and Command Line Interface (CLI) information to configure system and network parameters. List of Technical Publications The 7705 SAR OS documentation set for the 7705 SAR-M is composed of the following guides: •...

  • Page 32: Warnings And Notes

    This guide describes how to configure service parameters such as service access points (SAPs), service destination points (SDPs), customer information, and user services. • 7705 SAR OS Quality of Service Guide This guide describes how to configure Quality of Service (QoS) policy management. • 7705 SAR OS Routing Protocols Guide This guide provides an overview of dynamic routing concepts and describes how to configure them.

  • Page 33: Information Symbols

    Note This symbol provides additional operational information. Class 1 laser products are identified in this document. Only approved Class 1 replaceable laser transceivers should be used with those products. CLASS 1 LASER PRODUCT 7705 SAR-M Chassis Installation Guide...

  • Page 34: Technical Support

    Technical Support Technical Support If you purchased a service agreement for your 7705 SAR-M and related products from a distributor or authorized reseller, contact the technical support staff for that distributor or reseller for assistance. If you purchased an Alcatel-Lucent service agreement, check this link for instructions to contact Support personnel: Web: http://support.alcatel-lucent.com...

  • Page 35: Mandatory Regulations

    Mandatory Regulations In This Chapter The following sections describe the mandatory regulations that govern the installation and operation of the 7705 SAR-M: • List of Terms • General Requirements • Canada Regulations • United States Regulations • European Union Regulations •...

  • Page 36: List Of Terms

    NRTL Nationally Recognized Testing Laboratory OSHA (USA) Occupational Safety and Health Administration (USA) RoHS Restriction of the use of certain Hazardous Substances SELV Safety Extra Low Voltage Underwriters Laboratories WEEE Waste Electrical and Electronic Equipment 7705 SAR-M Chassis Installation Guide...

  • Page 37: General Requirements

    General Requirements The sections that follow outline the mandatory regulations that govern the installation and operation of the 7705 SAR-M. The information in this section also describes instructions and information related to overall conformance with the mandatory regulations. You must adhere to these instructions so that your system meets regulatory requirements.

  • Page 38: Grounding

    ESD grounding for the chassis. Before a 7705 SAR-M chassis is installed, connect the ESD wrist strap to a grounded rack or other ground point. After the 7705 SAR-M chassis is installed in a grounded rack or cabinet, connect the anti-static wrist strap to the ESD strap ground point on one of the ground studs identified by the wrist strap label.

  • Page 39: Unit Repair

    Do not use VOM-type meters to measure resistance, as this can damage electrostatic-sensitive devices. • Use only anti-static (metallized) desoldering tools. Equipment Interconnection Points Interconnection points of the 7705 SAR-M are defined as the following SELV connectors: • T1/E1 (variants with T1/E1 ports) • Ethernet (10/100/1000 Base-T) •...

  • Page 40: Selv

    Locations. Laser Interface The 7705 SAR-M uses a fiber-optic communications method and is an FDA and IEC Class 1 Laser product. Only trained service personnel thoroughly familiar with laser radiation hazards should install or remove the fiber-optic cables and cards in this system.

  • Page 41: Emc Compliance

    • T1 and E1 interfaces (variants with T1/E1 ports) Regulatory Symbols The 7705 SAR-M uses various regulatory approvals symbols. They may be used on product markings such as approvals labels. These symbols are described in IEC 417. Figure 2 Figure 3 show symbols of a terminal that you must connect to earth ground before you make any other connections to the equipment.

  • Page 42: Canada Regulations

    7705 SAR-M in Canada. Industry Canada Regulations ICES-003: Interference-Causing Equipment Standard Digital Apparatus Note: Changes or modifications not expressly approved by Alcatel-Lucent could void the user’s authority, granted by Alcatel-Lucent’s certification by Industry Canada, to operate the equipment. This Class A digital apparatus complies with Canadian ICES-003.

  • Page 43: Safety Approval For Dc Systems

    CSA standard C22.2 No. 60950-1. Use the equipment with a SELV secondary source that is electrically isolated from the AC source and that is reliably grounded. The 7705 SAR-M is safety certified according to CSA standard C22.2 No. 60950-1 by CSA. 7705 SAR-M Chassis Installation Guide...

  • Page 44: United States Regulations

    FCC Part 68 The T1 network interface on the 7705 SAR-M meets the FCC specifications. This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA.

  • Page 45: Nrtl

    ANSI Z 136.1: Safe Use of Lasers and ANSI Z 136.2: Safe Use of Lasers in Optical Fiber Communications Systems. You can obtain these documents and other instructional material from: Laser Institute of America 13501 Ingenuity Drive, Suite 128 Orlando, FL 32826 http://www.laserinstitute.org 7705 SAR-M Chassis Installation Guide...

  • Page 46: European Union Regulations

    Directive 1999/05/EC and 2004/108/EC. The technical documentation as required by the Conformity Assessment procedure is kept at the Alcatel-Lucent location that is responsible for this product. For more information, please contact your local Alcatel-Lucent Customer Service Organization. EU Compliance Statement This product has been CE marked in accordance with the requirements of European Directive 1999/05/EC, the Radio and Telecommunications Terminal Equipment Directive (R&TTE),...

  • Page 47: Laser Interface

    AC input voltage and frequency for the country where it is installed. Set the output of the rectifier according to the installation and operating instructions of the manufacturer, to provide output levels that coincide with the nominal DC input ratings of the system. 7705 SAR-M Chassis Installation Guide...

  • Page 48: Eco-Environmental

    13 August 2005. This product is compliant with the WEEE marking requirements of DIRECTIVE 2002/96/EC Waste Electrical and Electronic Equipment (WEEE). Figure 4: WEEE Symbol for post-August 13, 2005 Product WEEE Symbol 21828 7705 SAR-M Chassis Installation Guide...

  • Page 49: Material Content Compliance

    Moreover, in compliance with legal requirements and contractual agreements, where applicable, Alcatel-Lucent will offer to provide for the collection and treatment of Alcatel-Lucent products bearing the logo at the end of their useful life, or products displaced by Alcatel-Lucent equipment offers. For information regarding take-back of equipment by...

  • Page 50: Australia/New Zealand Regulations

    7705 SAR-M in Australia and New Zealand. ACMA Regulations The 7705 SAR-M complies with the ACMA requirements, and the product is marked with the 'A Tick' under the Supplier Code N594. This Class A digital apparatus complies with AS/NZS CISPR22.

  • Page 51: China Regulations

    In accordance with the People’s Republic of China Electronic Industry Standard “Marking for the Control of Pollution Caused by Electronic Information Products” (SJ/T11364-2006), customers may access the Alcatel-Lucent Hazardous Substances Table, in Chinese, from the following location: http://www.alcatel-sbell.com.cn/wwwroot/images/upload/private/1/media/ChinaRoHS.pdf...
  • Page 52 China Regulations 7705 SAR-M Chassis Installation Guide...

  • Page 53: 7705 Sar-M Overview

    7705 SAR-M Overview In This Chapter This chapter provides an introduction to the Alcatel-Lucent 7705 SAR-M: • Overview of the 7705 SAR-M Variants • 7705 SAR-M Components → Chassis → Control and Switching → Module Slot (Available on Two Variants) →...

  • Page 54: Overview Of The 7705 Sar-M Variants

    7 Ethernet ports, 0 T1/E1 ports, 0 module slots, passively cooled The term 7705 SAR-M is used in this document as a generic collective reference to all variants of the chassis. Where hardware differences occur, the chassis variant is specified.
  • Page 55 7705 SAR-M Overview The port number can be 1 to 7 for Ethernet ports, or 1 to 16 for T1/E1 ports (only on chassis equipped with these ports). 7705 SAR-M Chassis Installation Guide...

  • Page 56: 7705 Sar-M Components

    19-inch rack. For the actively cooled variant of the 7705 SAR-M chassis, a separate kit can be ordered for mounting the unit in an ETSI rack. The protective earth connection is provided via the chassis grounding stud on the right-hand side mounting bracket.

  • Page 57: Figure 5 Exploded View: 7705 Sar-M Chassis Variant With Module Slot And 16 T1/E1 Ports

    7705 SAR-M Overview Figure 5: Exploded View: 7705 SAR-M Chassis Variant with Module Slot and 16 T1/E1 Ports 7705 SAR-M -48/+24 VDC +Batt A -Batt A +Batt B -Batt B Mgmt T1/E1 Ports 1.7 in. Stat Stat Stat Stat Stat...

  • Page 58: Control And Switching

    • routing, switching, and services functions for the entire system Each variant of the 7705 SAR-M chassis is shipped with a 256 Mbyte compact flash memory device that stores system boot software, OS software, and configuration files and logs. The compact flash device is accessible via an access cover that is positioned on the left side of the rear chassis plate.

  • Page 59: Module Slot (Available On Two Variants)

    Alarms port 21101 Module Slot (Available on Two Variants) The two actively cooled variants of the 7705 SAR-M chassis have a module slot for expandability, providing additional network interfaces. A module can be inserted or removed while the system is powered.

  • Page 60: Filler Plate

    Figure 12: Filler Plate 21283 T1/E1 and Ethernet Ports Two variants of the 7705 SAR-M chassis are equipped with T1/E1 ports. All variants of the 7705 SAR-M chassis are equipped with Ethernet ports. Figure 13 identifies the T1/E1 and Ethernet interface ports.

  • Page 61: Power Supply Inputs

    7705 SAR-M Overview All four variants of the 7705 SAR-M chassis have 7 Ethernet ports: 3 ports to support 1000Base-T Ethernet interfaces via Ethernet connectors, and 4 SFP ports for 10/100/1000 SFPs (optical or electrical). The SFP modules are hot-swappable and field-replaceable by qualified personnel.

  • Page 62: Chassis Cooling

    DC power LEDs 21104 Chassis Cooling Two variants of the 7705 SAR-M chassis are actively cooled using fans and two variants are passively cooled. Actively Cooled Chassis Variants The two actively cooled variants of the 7705 SAR-M chassis have five internal fans that provide cooling for the components.

  • Page 63: Monitoring Temperature

    • off – all fans are off An example of the Fan Information portion of the show chassis display is shown below: Fan Information # of on-board fans Status : up Speed : half speed 7705 SAR-M Chassis Installation Guide...

  • Page 64: Passively Cooled Chassis Variants

    7705 SAR-M Components Passively Cooled Chassis Variants The two passively cooled variants of the 7705 SAR-M chassis are equipped with fins for heat dissipation. Maintain the following clearances around the unit: • at least 2.5 in. (6.4 cm) at the front of the chassis for cable management •...

  • Page 65: 7705 Sar-M System Installation Process

    7705 SAR-M Overview 7705 SAR-M System Installation Process To install a 7705 SAR-M chassis, perform the installation procedures in the following order: Step 1. Prepare the site. Step 2. Unpack the chassis. Step 3. Rack mount and ground the chassis.
  • Page 66 7705 SAR-M System Installation Process 7705 SAR-M Chassis Installation Guide...

  • Page 67: Site Preparation

    Chassis Specifications → Environmental Specifications → 7705 SAR-M Power Consumption → Module Specifications → CBN and IBN Grounding Requirements → Power and Cabling Requirements → Storage → Compliance • Installation Locations → Chassis Location Requirements 7705 SAR-M Chassis Installation Guide...

  • Page 68: Warnings And Notes

    • The 7705 SAR-M needs a disconnect device on each power feed (such as an external circuit breaker, switch, or fuse) to disconnect DC power from it. Disconnect both A and B feeds before servicing.
  • Page 69 Chassis Location Requirements. • Maintain a clearance of at least 2.5 in. (6.4 cm) at the front of the 7705 SAR-M chassis for cable management. • Maintain a clearance of at least 2 in. (5.1 cm) on each side of the 7705 SAR-M chassis to ensure adequate air flow.
  • Page 70 T1/E1 port receiver. Adjust LBO settings such that the T1/E1 port receiver’s nominal input voltage level is < 3Vp. Refer to “Configuring T1 Line Buildout” in the 7705 SAR OS Interface Configuration Guide for detailed information on attenuating transmit signals.

  • Page 71: System Specifications

    Site Preparation System Specifications Chassis Specifications Table 5: 7705 SAR-M Chassis Specifications per Variant Parameter 7 Ethernet Ports, 7 Ethernet Ports, 7 Ethernet Ports, 7 Ethernet Ports, 16 T1/E1 Ports, 0 T1/E1 Ports, 16 T1/E1 Ports, 0 T1/E1 Ports, 1 Module Slot,...

  • Page 72: Environmental Specifications

    11 ms 11 ms Vibration: 0.1 g Vibration: 0.1 g Vibration: 0.1 g Vibration: 0.1 g from 5 to 100 Hz from 5 to 100 Hz from 5 to 100 Hz from 5 to 100 Hz 7705 SAR-M Chassis Installation Guide...
  • Page 73 Pollution degree is as defined in IEC 60950. Pollution Degree 2 applies where there is only non-conductive pollution that might temporarily become conductive due to occasional condensation. The AC operating voltage range applies only to the external AC power supply. 7705 SAR-M Chassis Installation Guide...

  • Page 74: 7705 Sar-M Power Consumption

    7705 SAR-M Power Consumption Table 7 lists the power consumption estimates for each variant of the 7705 SAR-M chassis, with no module installed in those variants equipped with module slots. For those variants equipped with module slots, installing a module increases the average and maximum power draw of the chassis.

  • Page 75: Module Specifications

    The CWDM OADM module requires power for the SEEP inventory purposes. The optical signal processed by the module will continue to flow even if no power is available because the CWDM OADM module is passive. 7705 SAR-M Chassis Installation Guide...

  • Page 76: Cbn And Ibn Grounding Requirements

    IBN zone. • In a CBN installation, if you use the 7705 SAR-M chassis ground stud (located on the right-hand side mounting bracket) to connect the chassis ground terminal(s) to the frame ground on the rack, then you must use a second nut on the stud to secure the attachment.

  • Page 77: Dc Power Requirements

    Site Preparation DC Power Requirements • A means of disconnect must be provided within 10 ft (3 m) of the 7705 SAR-M. • A circuit breaker or fuse with recommended current rating 5 A (minimum) to 10 A (maximum) must be provided (applies to both –48 VDC and +24 VDC installations).

  • Page 78: Storage

    System Specifications Storage To store an uninstalled 7705 SAR-M, repackage it in its original packaging or an appropriately sized container and keep it in a dry, dust-free, temperature-controlled environment. Table 10: Storage Specifications (All Variants) Parameter Description Storage and shipping temperature From –40°...

  • Page 79: Installation Locations

    The 7705 SAR-M, 7705 SAR-8, and 7705 SAR-F are intended to be installed at cell sites or other facilities that provide weather protection and an extended temperature-controlled environment. The 7705 SAR-M, 7705 SAR-8, and 7705 SAR-F are not intended for installation outdoors.

  • Page 80: Chassis Location Requirements

    The 7705 SAR-M supports extended temperature operation, from –40° to 149°F (–40 to 65°C) and a cold start from –40°F (–40°C). The 7705 SAR-8 and the 7705 SAR-F support extended temperature operation, from –40° to 149°F (–40 to 65°C) and a cold start from –4°F (–20°C).

  • Page 81: Table 11 Chassis Clearance Specifications (Actively Cooled Variants)

    (40°C) under full system power loading combined with worst-case environmental deployment conditions. • Ensure that the 7705 SAR-M system intake is not located immediately adjacent to the exhaust of another chassis such that preheated air above 104°F (40°C) is drawn into the system.

  • Page 82: Passively Cooled Variants

    Rear: No clearance required Side: 2 in. (5.1 cm) minimum required for airflow Rack upright: a channel enclosure of 5 in. (12.7 cm) maximum is required for airflow Top and bottom: 1.75 in. (4.3 cm) required for airflow 7705 SAR-M Chassis Installation Guide...

  • Page 83: Installing The Chassis

    Installing the Chassis In This Chapter This chapter provides information on installing a 7705 SAR-M chassis: • Unpacking the Chassis → Unpacking Precautions • Installing the Chassis in a Rack → Rack-Mounting the Chassis → Installing ETSI Rack-Mount Brackets •...

  • Page 84: Unpacking The Chassis

    The 7705 SAR-M chassis has no field-replaceable parts, other than the compact flash. The chassis is the only piece of hardware packed in its shipping container. Warning: If the 7705 SAR-M is to be relocated at a later time, observe the following to properly transport and relocate the chassis: •...

  • Page 85: Table 13 7705 Sar-M Packing Components

    Installing the Chassis Figure 17 displays the components of a packed 7705 SAR-M chassis. Table 13 lists the 7705 SAR-M packing components. Figure 17: Unpacking the 7705 SAR-M Chassis 22716 Table 13: 7705 SAR-M Packing Components Description Shipping container 7705 SAR-M chassis (wrapped in an anti-static bag)

  • Page 86: Installing The Chassis In A Rack

    • When rack-mounting the chassis in an equipment rack, do not stack one 7705 SAR-M chassis or any other equipment directly on top of another 7705 SAR-M chassis, such that the bottom chassis is supporting other devices.

  • Page 87: Table 14 Rack-Mounting Components

    Installing the Chassis Figure 18: Installing the 7705 SAR-M Chassis in a Rack -48/+24 VDC T1/E1 Ports Mgmt +BattA -BattA +BattB -BattB Stat Stat Stat Stat Stat Stat Stat Stat Link Link Link Link Crit. Link Link Link Sync Maj.

  • Page 88: Installing Etsi Rack-Mount Brackets

    Installing the Chassis in a Rack To install the chassis in the rack: Step 1. Lift the 7705 SAR-M and position it in the rack. Step 2. Align the mounting holes on each bracket with the mounting holes on the rack upright.

  • Page 89: Chassis Ground Wiring

    • All surfaces that are used for intentionally grounding the 7705 SAR-M must be brought to a bright finish, and an antioxidant solution must be applied to the surfaces being joined.

  • Page 90: Table 15 Ground Wire Descriptions

    Figure 20: Attaching the Chassis Ground Connector (Cable Routed Down) -48/+ 24 VDC +Ba ttA -Ba ttA +Ba ttB -Ba BAT A BAT B Exte rnal Alar ms Max, 50 mA 22724 7705 SAR-M Chassis Installation Guide...

  • Page 91: Table 16 Chassis Ground Connection Components

    20) or up the rack upright (Figure 21). Secure the lug with the Keps nut. Tighten the nut to a torque of 8 to 10 lbf-in (0.9 to 1.13 N m) maximum. Do not over-tighten. 7705 SAR-M Chassis Installation Guide...
  • Page 92 Step 6. Connect the opposite end of the ground wire to the appropriate ground point at your installation site. Ensure that the chassis ground connection is made according to local safety codes. Step 7. Connect the 7705 SAR-M to the DC or AC power source. See DC Power Connections AC Power Connections.

  • Page 93: Dc Power Connections

    This chapter provides information about wiring and connecting the DC power source to the 7705 SAR-M: • Wiring and Connecting DC Power → Warnings and Notes • DC-Input Power Connections → Wiring the DC Inputs 7705 SAR-M Chassis Installation Guide...

  • Page 94: Wiring And Connecting Dc Power

    7705 SAR-M right-hand side mounting bracket, or a properly grounded rack or work bench. • For IBN installations, the battery return terminal(s) on the 7705 SAR-M must always be connected to the building ground at the power source. For redundant supply configurations, separate battery return wires must be used.
  • Page 95 DC Power Connections Note: • The 7705 SAR-M requires a minimum of one DC power source to operate, but using two DC power sources is recommended for redundancy. • The 7705 SAR-M is suitable for both DC-I and DC-C power configurations.

  • Page 96: Dc-Input Power Connections

    Wiring the DC Inputs The 7705 SAR-M has a standard dual-feed terminal block attached to the front of the chassis. The terminals are the DC power feed points for source voltage from the DC circuit. For redundant power configurations, you must use both DC power feeds (one for each pair of power terminals).

  • Page 97: Table 18 Wiring The Dc Power Supplies Descriptions

    Terminal strip with protective cover Disconnect device DC source A DC source B Battery wire Battery return wire Required tools and hardware: • two or four lengths of wire (two lengths per supply) • torque driver for slot screws 7705 SAR-M Chassis Installation Guide...

  • Page 98: For -48 Vdc Installations

    Attach the battery wire to the disconnect device. iv. For redundant power supply configurations, repeat substeps i to iii for the other battery wire. Step 4. Check that the DC supply wiring is correct. Step 5. Install the SFPs. See SFPs. 7705 SAR-M Chassis Installation Guide...

  • Page 99: For +24 Vdc Installations

    For +24 VDC systems, use the -Batt terminal. Tighten to a torque of 8 to 10 lbf-in (0.9 to 1.13 N m) maximum. v. For redundant power supply configurations, repeat substeps i to iv for the other battery return wire. 7705 SAR-M Chassis Installation Guide...
  • Page 100 → Attach the battery wire to the disconnect device. → For redundant power supply configurations, repeat substeps i to iii for the other battery wire. Step 4. Check that the DC supply wiring is correct. Step 5. Install the SFPs. See SFPs. 7705 SAR-M Chassis Installation Guide...

  • Page 101: Ac Power Connections

    AC Power Connections In This Chapter This chapter provides information about wiring and connecting the AC power source to the 7705 SAR-M via an AC power converter: • Wiring and Connecting AC Power → Warnings and Notes → Wiring the AC Power Converter to the DC Inputs...

  • Page 102: Wiring And Connecting Ac Power

    Do not install equipment that appears to be damaged. • Do not connect the AC power converter to a +24 VDC 7705 SAR-M system. The AC power converter operates at 120/240 VAC and provides true -48 VDC output that will damage components if connected to a +24 VDC system.

  • Page 103: Wiring The Ac Power Converter To The Dc Inputs

    Wiring the AC Power Converter to the DC Inputs The 7705 SAR-M has a standard, dual-feed terminal block attached to the front of the chassis. The terminals are the DC power feed points for DC voltage from the AC power converter.

  • Page 104: Table 19 Pigtail Cord Connection Descriptions

    Figure 26: AC Power Converter 21523 Table 20: AC Power Converter Description Male 6-pin connector AC cord set Note: Two AC cord sets are supplied with the AC power converter to match North American and European style AC outlets. 7705 SAR-M Chassis Installation Guide...

  • Page 105: For -48 Vdc Installations

    Step 6. For redundant power supply configurations, repeat steps 1 to 5 for the other pigtail cord. Step 7. Plug the AC power converter cord into an AC power supply. Step 8. Check that the AC supply wiring is correct. Step 9. Install the SFPs. See SFPs. 7705 SAR-M Chassis Installation Guide...

  • Page 106: Table 21 Connecting The Ac Power Converter To The -48 Vdc System

    Ring lug connector suitable for No. 6 screw 6-pin connector AC power converter AC plug Note: Two AC cord sets are supplied with the AC power converter to match North American and European style AC outlets. 7705 SAR-M Chassis Installation Guide...

  • Page 107: Sfps

    SFPs In This Chapter This chapter provides information about installing and removing SFPs in the 7705 SAR-M: • Installing and Removing SFPs → Warnings and Notes → SFPs → Fiber Cable Preparation → Locking and Release Mechanisms → SFP Support →...

  • Page 108: Installing And Removing Sfps

    7705 SAR-M. • Before using the optics on the 7705 SAR-M, verify that the optical path is in compliance with the parameters of the optical components. In particular, pay close attention to any minimum attenuation requirements for the optics. If minimum attenuation requirements are not met, the optical receiver components may be permanently damaged.

  • Page 109: Sfps

    Min. BATT A BATT B Stat ACO/ Console Sync External Alarms Max, 50 mA L i n L i n L i n L i n 21109 Table 22: SFP Installation Components Description SFP receptacle 7705 SAR-M Chassis Installation Guide...

  • Page 110: Fiber Cable Preparation

    Refer to the Optical Handling Reference Guide (part number 95-5795-01-00), available by logging on to Alcatel-Lucent Online Customer Support (OLCS) (http://www.alcatel-lucent.com/myaccess). From the “Technical Content for” drop-down menu, choose 7705 SAR, and click on “Manuals and Guides” to access the documentation. Locking and Release Mechanisms SFPs approved by Alcatel-Lucent can use different lock and release methods.

  • Page 111: Table 23 Sfps For The 7705 Sar-M

    SFPs Table 23: SFPs for the 7705 SAR-M Part Number Short Description Media Wave- Connector Distance Operating SyncE length Type Temp. 3HE00062AA PBA GigE TX SFP Copper RJ-45 100 m 0° to 85°C Copper Module (32° to (1000Base-T) 185°F) Category 5, 10/...
  • Page 112 Installing and Removing SFPs Table 23: SFPs for the 7705 SAR-M (Continued) Part Number Short Description Media Wave- Connector Distance Operating SyncE length Type Temp. 3HE00029AA PBA GigE ZX SFP Fiber 1550 nm 70 km –5° to 85°C Optics Module - (23°...
  • Page 113 SFPs Table 23: SFPs for the 7705 SAR-M (Continued) Part Number Short Description Media Wave- Connector Distance Operating SyncE length Type Temp. 3HE00868CB GigE BX10-D SFP Fiber 10 km –40° to 85°C ROHS-6/6 Optics 1490 nm (–40° to Module - LC - 185°F)
  • Page 114 Installing and Removing SFPs Table 23: SFPs for the 7705 SAR-M (Continued) Part Number Short Description Media Wave- Connector Distance Operating SyncE length Type Temp. 3HE04323AB 100M BX40-D Fiber 40 km –40° to 85°C SFP ROHS-6/6 1490 nm (–40° to Optics Module - 185°F)
  • Page 115 SFPs Table 23: SFPs for the 7705 SAR-M (Continued) Part Number Short Description Media Wave- Connector Distance Operating SyncE length Type Temp. 3HE00070BH GigE CWDM SFP Fiber 1611 nm 120 km –5° to 85°C Optics Module - (23° to 185°F)
  • Page 116 Installing and Removing SFPs Table 23: SFPs for the 7705 SAR-M (Continued) Part Number Short Description Media Wave- Connector Distance Operating SyncE length Type Temp. 3HE04117AA GigE SFP 100/ Fiber 1310 nm Duplex LC 10 km –40° to 85°C 1000 LX SGMII (–40°...
  • Page 117 SFPs Table 23: SFPs for the 7705 SAR-M (Continued) Part Number Short Description Media Wave- Connector Distance Operating SyncE length Type Temp. 3HE05936CB GigE CWDM Fiber 1491 nm 80 km –40° to 85°C Optics Module (–40° to (1000Base) 185°F) 3HE05936CC...

  • Page 118: Bidirectional Sfps

    1490 nm, the near-end SFP must transmit at 1490 nm and receive at 1310 nm. T3/E3 SFP The T3/E3 SFP is used to interconnect two 7705 SARs over a T3 physical interface.The E3 interface is not supported. The SFP can only operate with 7705 SARs at either end.

  • Page 119: Installing Sfps

    SFP optical port and place a dust cover on the fiber cable connector. Note: If you are not immediately replacing the SFP, leave the Ethernet port empty. It is not necessary to install protective plugs in the ports on the 7705 SAR-M. 7705 SAR-M Chassis Installation Guide...
  • Page 120 Installing and Removing SFPs 7705 SAR-M Chassis Installation Guide...

  • Page 121: Connecting Cables

    Connecting Cables In This Chapter This chapter provides information about connecting cables to the 7705 SAR-M: • Warnings and Notes • Cable Connections → Ethernet and Copper Cables → Fiber Cables → Shield Ground Connections • Making External Synchronization Connections →...

  • Page 122: Warnings And Notes

    ESD strap to a nearby ground point that is connected to the site grounding point when working on the 7705 SAR-M. Typical ground points include the ground connection point on the 7705 SAR-M left-hand side mounting bracket (but only after the...

  • Page 123: Cable Connections

    Connecting Cables Cable Connections All port cable connections are made from the front of the 7705 SAR-M. Ports can be connected using copper or fiber-optic cables. Ethernet and Copper Cables Figure 29 illustrates how Ethernet and copper wire cables are routed on the 7705 SAR-M.

  • Page 124: Fiber Cables

    To meet surge protection requirements, the shield of any open-ended cable (at the far end) must be grounded to a convenient chassis ground point, such as the equipment rack. 7705 SAR-M Chassis Installation Guide...
  • Page 125 Step 3. Separate the ground shield (braid, foil, and drain wire) from the signal conductors. Step 4. Securely attach the shield to the chassis ground point. Use a screw and star washer large enough to make a proper ground connection. Use proper cable dressing and strain relief techniques. 7705 SAR-M Chassis Installation Guide...

  • Page 126: Making External Synchronization Connections

    Making External Synchronization Connections Making External Synchronization Connections The 7705 SAR-M provides 1.0/2.3 DIN connectors for external synchronization input and output. Figure 30 shows the location of the Sync In and Sync Out connectors. Table 25 describes the location of the Sync In and Sync Out connectors.

  • Page 127: Providing An External Synchronization Output

    Step 1. Attach one end of the synchronization cable to the Sync Out connector on the 7705 SAR-M. Step 2. Attach the other end of the synchronization cable to the device requiring a synchronization source. 7705 SAR-M Chassis Installation Guide...

  • Page 128: Making External Alarm Connections

    Making External Alarm Connections Making External Alarm Connections The 7705 SAR-M provides an HD-15 female connector for external alarm connections. The input and output ratings are 5 VDC and 100 mA (source or sink). The External Alarms interfaces are equipped with relays that can be used to trigger external alarm indicators.

  • Page 129: Making Router Management Connections

    Connecting Cables Making Router Management Connections Refer to Establishing Router Management Connections for detailed information. 7705 SAR-M Chassis Installation Guide...
  • Page 130 Making Router Management Connections 7705 SAR-M Chassis Installation Guide...

  • Page 131: Initializing And Provisioning

    Power-Up and Initialization → Troubleshooting Initial Startup • Automatic Discovery Protocol • Establishing Router Management Connections → Console Connection → Telnet Connection → Running Telnet • Provisioning the 7705 SAR-M → T1/E1, Ethernet, and Module Port Identifiers 7705 SAR-M Chassis Installation Guide...

  • Page 132: Powering Up The Router

    The primary copy of the 7705 SAR-M TiMOS software is located on the compact flash memory device that is factory-installed. The compact flash device is accessible via an access cover that is positioned on the left side of the rear chassis plate. Accessing the compact flash device facilitates the commissioning process as the device can be installed pre-programmed with the desired software and configuration files.
  • Page 133 Step 7. (Optional at this time) Run automatic discovery protocol (ADP). ADP is a factory-installed boot option that automates the initial commissioning of 7705 SAR-M nodes. ADP runs automatically the first time the system is powered up. The Status LED blinks green and amber while ADP is running. You can terminate ADP while it is running by pressing the ACO/LT button or via the CLI.

  • Page 134: Troubleshooting Initial Startup

    “Hit a key within 3 seconds to change boot parms...” is displayed. Follow the provisioning menu to create a new bof.cfg file if it is missing. If this procedure fails to save the new bof.cfg file, then the 7705 SAR-M should be replaced and the faulty router returned to Alcatel-Lucent.

  • Page 135: Figure 32 Files On The Compact Flash

    BOF. The file includes configurations for the chassis, control and switching functions, and ports, as well as system, routing, and service configurations. Figure 32 displays the compact flash directory structure and file names. Figure 32: Files on the Compact Flash Root bof.cfg boot.ldr config.cfg TiMOS-m.n.Yz both.tim 19644 7705 SAR-M Chassis Installation Guide...
  • Page 136 — minor release number Y: type of release → A — Alpha release → B — Beta release → M — maintenance release → R — released software z — version number • both.tim — application software file 7705 SAR-M Chassis Installation Guide...

  • Page 137: Automatic Discovery Protocol

    • modify the location where the newly discovered configuration will be stored For more information about ADP and the BOF file, refer to the 7705 SAR OS Basic System Configuration Guide, “Automatic Discovery Protocol”. ADP can be controlled via the CLI while it is running or by the ACO/LT button on the 7705 SAR-M chassis.

  • Page 138: Table 27 Adp Stage Led Indicators

    If still in a halted state after 15 min, ADP times out and reboots the system. During the reboot, ADP will attempt to run again. If ADP is halted, the major and minor alarm LEDs on the 7705 SAR-M chassis indicate the ADP stage.

  • Page 139: Establishing Router Management Connections

    Console connection • Telnet connection Console Connection The Console port on the front of the 7705 SAR-M is a female RJ-45 connector (see Figure 33). To establish a console connection, you need the following: • an ASCII terminal or a PC running terminal emulation software set to the parameters...

  • Page 140: Telnet Connection

    0 to 32 For more information about configuring router parameters, refer to the 7705 SAR OS Router Configuration Guide. For pinout information, refer to Management Port Pinouts. Figure 34: Management Port Connection...

  • Page 141: Running Telnet

    Initializing and Provisioning Running Telnet After the Ethernet Management port IP address is configured, the 7705 SAR-M CLI can be accessed with a Telnet connection. To establish a Telnet connection, run a Telnet program and issue the telnet command, followed by the Management port IP address.

  • Page 142: Provisioning The 7705 Sar-M

    Provisioning the 7705 SAR-M Provisioning the 7705 SAR-M The 7705 SAR-M does not require provisioning above port level because it is provisioned at the factory with the following permanent configuration: • card type in slot 1 is iom-sar • mda type in slot 1/1 is i7-1gb (for Ethernet ports) •...

  • Page 143: T1/E1, Ethernet, And Module Port Identifiers

    1 to N, 1/3/port_id where N is the number of ports available on the module To configure ports, refer to the card and port configuration sections in the 7705 SAR OS Interface Configuration Guide. 7705 SAR-M Chassis Installation Guide...
  • Page 144 Provisioning the 7705 SAR-M 7705 SAR-M Chassis Installation Guide...

  • Page 145: Appendix A: 7705 Sar-M Connectors And Leds

    In This Chapter This chapter provides information on the connectors and LEDs on the front of the 7705 SAR-M. There are no connectors or LEDs on the back of the router: • 7705 SAR-M Connectors and LEDs (Variants with Module Slot, Actively Cooled) •...

  • Page 146: 7705 Sar-M Connectors And Leds (Variants With Module Slot, Actively Cooled)

    Sync External Alarms Max, 50 mA 21118 Table 30 describes the connectors and LEDs on the 7705 SAR-M variants that have a module slot and that are actively cooled. Table 30: 7705 SAR-M Connector and LED Descriptions Label/Part Sub- Description...
  • Page 147 Appendix A: 7705 SAR-M Connectors and LEDs Table 30: 7705 SAR-M Connector and LED Descriptions (Continued) Label/Part Sub- Description category Ethernet Ports Four Ethernet ports have receptacles for SFP modules. The SFP port connectors number (1 to 4) is displayed above each port. The associated Link and Act(ivity) LEDs are located to the left of each port.
  • Page 148 7705 SAR-M Connectors and LEDs (Variants with Module Slot, Actively Cooled) Table 30: 7705 SAR-M Connector and LED Descriptions (Continued) Label/Part Sub- Description category Alarm LEDs Crit. Red: Indicates that a critical condition exists, such as the failure of two or more fans or a power feed, or a critical external alarm input detected.
  • Page 149 Appendix A: 7705 SAR-M Connectors and LEDs Table 30: 7705 SAR-M Connector and LED Descriptions (Continued) Label/Part Sub- Description category ACO/LT Push — The Audible Alarm Cutoff/Lamp Test button verifies LED operation, Button turns off the external alarm control bits, and controls the ADP interface during startup.
  • Page 150 Connector The ToD port has an RJ-45 connector and provides a mechanism to send out Time of Day/phase sync from the 7705 SAR-M, over IEEE 1588v2 messaging. The ToD port includes a 1 pulse per second signal and an RS-422 serial link. This port is output only.

  • Page 151: Table 31 Module Led Descriptions

    Appendix A: 7705 SAR-M Connectors and LEDs Table 31: Module LED Descriptions Label Description Power Blue: Indicates that power is on Unlit: Indicates that there is no power to the module or that power is faulty Status Stat Green: Indicates that the module is operationally up and...

  • Page 152: 7705 Sar-M Connectors And Leds (Variants With No Module Slot, Passively Cooled)

    7705 SAR-M Connectors and LEDs (Variants with No Module Slot, Passively Cooled) 7705 SAR-M Connectors and LEDs (Variants with No Module Slot, Passively Cooled) Figure 36 identifies the connectors and LEDs on the front of the router. Figure 36: 7705 SAR-M Connectors and LEDs...

  • Page 153: Table 32 7705 Sar-M Connector And Led Descriptions

    Appendix A: 7705 SAR-M Connectors and LEDs Table 32 describes the connectors and LEDs on the 7705 SAR-M variants that have no module slot and that are passively cooled. Table 32: 7705 SAR-M Connector and LED Descriptions Label/Part Sub- Description...
  • Page 154 7705 SAR-M Connectors and LEDs (Variants with No Module Slot, Passively Cooled) Table 32: 7705 SAR-M Connector and LED Descriptions (Continued) Label/Part Sub- Description category T1/E1 Ports RJ-45 Each T1/E1 port has an RJ-45 connector for attaching user devices. (only for...
  • Page 155 Appendix A: 7705 SAR-M Connectors and LEDs Table 32: 7705 SAR-M Connector and LED Descriptions (Continued) Label/Part Sub- Description category Stat (Status) — The system status LED indicates the combined status of the router’s three main functional blocks (the control and switching functional block, the T1/E1 ports functional block (for the variant with T1/E1 ports), and the Ethernet ports functional block).
  • Page 156 7705 SAR-M Connectors and LEDs (Variants with No Module Slot, Passively Cooled) Table 32: 7705 SAR-M Connector and LED Descriptions (Continued) Label/Part Sub- Description category Sync The “In” synchronization port has a 1.0/2.3 coaxial connector that can be used to receive an external synchronization input signal.
  • Page 157 Appendix A: 7705 SAR-M Connectors and LEDs Table 32: 7705 SAR-M Connector and LED Descriptions (Continued) Label/Part Sub- Description category Chassis Threaded The chassis ground stud allows a direct connection to the building ground Ground Stud stud for the chassis ground point.
  • Page 158 7705 SAR-M Connectors and LEDs (Variants with No Module Slot, Passively Cooled) 7705 SAR-M Chassis Installation Guide...

  • Page 159: Appendix B: Pinout Assignments

    This chapter provides information about the pinout assignments for the port connectors on the 7705 SAR-M: • 7705 SAR-M Ports → Management Port → Console Port → ToD Port → External Alarms Port → Ethernet Ports → T1/E1 Ports 7705 SAR-M Chassis Installation Guide...

  • Page 160: 7705 Sar-M Ports

    7705 SAR-M Ports Figure 37 identifies the port connectors that are accessible on the 7705 SAR-M variants that have a module slot and that are actively cooled. The chassis variant shown has T1/E1 ports. Figure 37: 7705 SAR-M Port Connectors (Variant with Module Slot, Actively Cooled)

  • Page 161: Management Port

    Differential transmit data – positive Output Differential transmit data – negative Input Differential receive data – positive — Not connected — Not connected Input Differential receive data – negative — Not connected — Not connected 7705 SAR-M Chassis Installation Guide...

  • Page 162: Console Port

    The Console port uses an RJ-45 connector to provide serial console access for the 7705 SAR-M. The Console port is used to configure router and system parameters. It can also be used for monitoring purposes. It supports baud rates of 9600, 19 200, 38 400, 57 600, and 115 200.

  • Page 163: Tod Port Pinouts

    Time of Day In – negative TOD_IN_P — Time of Day In – positive PPS_OUT_P Output 1 Pulse per Second Out – positive TOD_OUT_N Output Time of Day Out – negative TOD_OUT_P Output Time of Day Out – positive 7705 SAR-M Chassis Installation Guide...

  • Page 164: External Alarms Port

    For information on configuring the log events on the pins, refer to the 7705 SAR OS System Management Guide, “Event Control.” To display the status of the log events, use the show>chassis>environment command (see the 7705 SAR OS Basic System...

  • Page 165: External Alarms Port Pinouts

    Alarm input 3 Input User-configurable Alarm input 4 Input User-configurable — Not connected Alarm output 1, pin 2 Output Contact opens on critical alarm Alarm output 1, pin 1 Output Contact opens on critical alarm 7705 SAR-M Chassis Installation Guide...

  • Page 166: Alarm Examples

    Ethernet Ports There are three RJ-45 and four optical (SFP) connectors on the front of the 7705 SAR-M that provide Ethernet access to seven Ethernet ports. Use CAT5E (Gigabit Ethernet) shielded cables to attach customer equipment to the 7705 SAR-M RJ-45 Ethernet ports.

  • Page 167: Ethernet Port Pinouts

    3 – negative T1/E1 Ports There are 16 RJ-45 connectors on the front of the 7705 SAR-M that provide 100-Ω T1 or 120-Ω E1 access to 16 T1/E1 ports. The T1/E1 ports can be used for either access or network connectivity.

  • Page 168: T1/E1 Port Pinouts

    T1/E1 Port Pinouts Table 39 specifies the T1/E1 port pin assignments. Table 39: T1/E1 Pinouts—Port RJ-45 Female Signal Description Receive – Ring Receive – Tip — Transmit – Ring Transmit – Tip — — — 7705 SAR-M Chassis Installation Guide...

  • Page 169: Standards And Protocol Support

    DEVICES”, Code of Federal Regulations, Title 47 -- Network Telecommunications Equipment Telecommunication, Chapter I – Federal Communications Verizon VZ-TPR-9305 Issue 4—Verizon NEBSTM Compliance: Commission, Part 15 – Radio Frequency Devices, NEBS Compliance Clarification Document Verizon 47CFR15 Technical Purchasing Requirements 7705 SAR-M Chassis Installation Guide...

  • Page 170: Protocol Support

    (DTE) and data circuit- terminating equipment (DCE) RFC 2918—Route Refresh Capability for BGP-4 ITU-T V.28 (V.35)—V.28 Electrical characteristics for unbalanced RFC 3107—Carrying Label Information in BGP-4 double-current interchange circuits RFC 3392—Capabilities Advertisement with BGP-4 7705 SAR-M Chassis Installation Guide...
  • Page 171 ITU-T G.992.5 Annex K (ADSL2+) RFC 2966—Domain-wide Prefix Distribution with Two-Level IS- ITU-T G.998.4 G.inp—Physical layer retransmission ITU-T G.991.2 Annex A, B, F and ITU-T G.991.2 Amendment 2 RFC 2973—IS-IS Mesh Groups Annex G—SHDSL standards compliance 7705 SAR-M Chassis Installation Guide...
  • Page 172 RFC 1619—PPP over SONET/SDH RFC 2138—RADIUS RFC 1661—The Point-to-Point Protocol (PPP) RFC 2206—RSVP-MIB RFC 1662—PPP in HDLC-like Framing RFC 2571—SNMP-FRAMEWORKMIB RFC 1989—PPP Link Quality Monitoring RFC 2572—SNMP-MPD-MIB RFC 1990—The PPP Multilink Protocol (MP) RFC 2573—SNMP-TARGET-&-NOTIFICATION-MIB 7705 SAR-M Chassis Installation Guide...
  • Page 173 Message Type Value RFC 3209—Extensions to RSVP for LSP Tunnels VPLS RFC 3210—Applicability Statement for Extensions to RSVP for RFC 4762—Virtual Private LAN Services Using LDP LSP Tunnels RFC 4090—Fast Reroute Extensions to RSVP-TE for LSP Tunnels 7705 SAR-M Chassis Installation Guide...
  • Page 174 Standards and Protocol Support Proprietary MIBs TIMETRA-ATM-MIB.mib TIMETRA-CAPABILITY-7705-V1.mib TIMETRA-CFLOWD-MIB.mib TIMETRA-CHASSIS-MIB.mib TIMETRA-CLEAR-MIB.mib TIMETRA-FILTER-MIB.mib TIMETRA-GLOBAL-MIB.mib TIMETRA-LDP-MIB.mib TIMETRA-LOG-MIB.mib TIMETRA-MPLS-MIB.mib TIMETRA-OAM-TEST-MIB.mib TIMETRA-PORT-MIB.mib TIMETRA-PPP-MIB.mib TIMETRA-QOS-MIB.mib TIMETRA-ROUTE-POLICY-MIB.mib TIMETRA-RSVP-MIB.mib TIMETRA-SAP-MIB.mib TIMETRA-SDP-MIB.mib TIMETRA-SECURITY-MIB.mib TIMETRA-SERV-MIB.mib TIMETRA-SYSTEM-MIB.mib TIMETRA-TC-MIB.mib 7705 SAR-M Chassis Installation Guide...

  • Page 175: Documentation Feedback

    Customer documentation and product support Customer documentation http://www.alcatel-lucent.com/myaccess Product manuals and documentation updates are available at alcatel-lucent.com. If you are a new user and require access to this service, please contact your Alcatel-Lucent sales representative. Technical support http://support.alcatel-lucent.com Documentation feedback...
  • Page 176 © 2011 Alcatel-Lucent. All rights reserved. 3HE 06147 AAAB TQZZA Edition 01...
