ETHERNET/GIGABIT ETHERNET ADAPTER CARD INSTALLATION GUIDE
Alcatel-Lucent 7705
SERVICE AGGREGATION ROUTER | RELEASE 6.0.R1
ETHERNET/GIGABIT ETHERNET ADAPTER CARD INSTALLATION GUIDE
Alcatel-Lucent Proprietary
This document contains proprietary information of Alcatel-Lucent and is not to be
disclosed or used except in accordance with applicable agreements.
Copyright 2013 © Alcatel-Lucent. All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Alcatel-Lucent 7705

Summary of Contents for Alcatel-Lucent 7705

  • Page 1 SERVICE AGGREGATION ROUTER | RELEASE 6.0.R1 ETHERNET/GIGABIT ETHERNET ADAPTER CARD INSTALLATION GUIDE Alcatel-Lucent Proprietary This document contains proprietary information of Alcatel-Lucent and is not to be disclosed or used except in accordance with applicable agreements. Copyright 2013 © Alcatel-Lucent. All rights reserved.
  • Page 2 This document may contain information regarding the use and installation of non-Alcatel-Lucent products. Please note that this information is provided as a courtesy to assist you. While Alcatel-Lucent tries to ensure that this information accurately reflects information provided by the supplier, please refer to the materials provided with any non-Alcatel-Lucent product and contact the supplier for confirmation.

  • Page 3: Table Of Contents

    Installation Procedures ............................24 Warnings and Notes............................24 Installing or Replacing an Adapter Card......................25 Installing or Replacing an Adapter Card on the 7705 SAR-8 ..............27 Installing or Replacing an Adapter Card on the 7705 SAR-18 ..............30 SFPs............................... 35 In This Chapter ..............................35 Installing and Removing SFPs ...........................36...
  • Page 4 Table of Contents 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 5 T3/E3 Configured Settings ......................47 Connector and LED Descriptions ....................... 49 Table 7 8-port Ethernet Adapter Card Features ..................50 Table 8 RJ-45 Port Pinouts—RJ-45 Female ....................52 Table 9 8-port Gigabit Ethernet Adapter Card Features ................53 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 6 List of Tables 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 7: List Of Figures

    Figure 4 Installing an 8-port Ethernet Adapter Card on the 7705 SAR-8.............29 Figure 5 Removing an 8-port Gigabit Ethernet Adapter Card from a 7705 SAR-18 ........31 Figure 6 Installing an 8-port Gigabit Ethernet Adapter Card on a 7705 SAR-18 .........32 Connector and LED Descriptions .......................
  • Page 8 List of Figures 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 9: Preface

    Note: This manual may contain some content that is not currently available in this release but will be available in later maintenance releases. Please refer to the 7705 SAR OS 6.0.Rx Software Release Notice, part number 3HE07992000xTQZZA, for information on features supported in each load of the Release 6.0 software.

  • Page 10: Warnings And Notes

    Observe the warnings and notes to avoid injury or router damage during installation and maintenance. Follow the safety procedures and guidelines when working with and near electrical equipment. Warning statements and notes are provided in each chapter. 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 11: Audience

    This symbol provides additional operational information. Class 1 laser products are identified in the adapter card installation guides. Only approved Class 1 replaceable laser transceivers should be used with this product. CLASS 1 LASER PRODUCT 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 12: Technical Support

    Technical Support Technical Support If you purchased a service agreement for your 7705 SAR-8 or 7705 SAR-18 and related products from a distributor or authorized reseller, contact the technical support staff for that distributor or reseller for assistance. If you purchased an Alcatel-Lucent service agreement, check this link for instructions to contact Support personnel: Web: http://support.alcatel-lucent.com...

  • Page 13: Overview

    In This Chapter This chapter provides an introduction to the 8-port Ethernet Adapter card and 8-port Gigabit Ethernet Adapter card used in the 7705 SAR-8 and the 7705 SAR-18: • Overview of the 8-port Ethernet Adapter Card and 8-port Gigabit Ethernet Adapter...

  • Page 14: Overview Of The 8-Port Ethernet Adapter Card And 8-Port Gigabit Ethernet Adapter Card

    The 8-port Gigabit Ethernet Adapter card is equipped with a universal -48 VDC to +24 VDC power supply and is capable of a 1 or 2.5 Gb/s fabric interface. On the 7705 SAR-8, the card supports a 1 Gb/s fabric interface. On the 7705 SAR-8 v2, the card supports a 1 or 2.5 Gb/s fabric interface.

  • Page 15: 8-Port Gigabit Ethernet Adapter Card Versions

    1 is a8-1gb-sfp and for version 2 it is a8-1gb-v2-sfp. Both versions are supported on the 7705 SAR-8 and the 7705 SAR-18. The two versions are identical except that version 2 has more memory to support larger tables, such as FIBs, ACLs, and so on.
  • Page 16 Overview of the 8-port Ethernet Adapter Card and 8-port Gigabit Ethernet Adapter Card 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 17: Installing Adapter Cards

    Power Consumption • Provisioning Requirements • Provisioning an Adapter Card → Configuration Example • Removing an Adapter Card Configuration • Installation Procedures → Warnings and Notes → Installing or Replacing an Adapter Card 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 18: Power Consumption

    (version 1 and version 2) For information such as power consumption, environmental specifications, and adapter card physical specifications for the 7705 SAR-8 or 7705 SAR-18 hardware, refer to the “System Specifications” section in the 7705 SAR-8 Chassis Installation Guide and the 7705 SAR-18 Chassis Installation Guide.

  • Page 19: Provisioning Requirements

    Installing Adapter Cards Provisioning Requirements To configure cards and ports, you must be able to access the 7705 SAR-8 or 7705 SAR-18 by console or Telnet connection. Refer to the 7705 SAR-8 Chassis Installation Guide or 7705 SAR-18 Chassis Installation Guide for information and instructions on console and Telnet connections.

  • Page 20: Provisioning An Adapter Card

    8-port Ethernet Adapter card version 1 in slots MDA 1 and 2 on a 7705 SAR-8. The 7705 SAR-8 supports up to 6 adapter cards and the 7705 SAR-18 supports up to 12 adapter cards in any combination that does not exceed the maximum. However, for a network application, at least one of the installed cards must be a network-capable adapter card.

  • Page 21: Configuration Example

    The following example displays the card, card-type, mda and mda-type commands to specify the IOM as an iom-sar type, and provision 8-port Ethernet Adapter cards in slots MDA 1 and 2 on a 7705 SAR-8. ALU-1>config# card 1 ALU-1>config>card# card-type iom-sar ALU-1>config>card# mda 1...
  • Page 22 Provisioning an Adapter Card Use the config>show card state command to display administrative and operational states for all cards on a 7705 SAR-8: ALU-1>config# show card state =============================================================================== Card State =============================================================================== Slot/ Provisioned Equipped Admin Operational Num Comments Type Type...

  • Page 23: Removing An Adapter Card Configuration

    If you will be replacing it with a card of the same type, you do not need to remove the associated configuration. Refer to the 7705 SAR OS Interface Configuration Guide for details on configuring cards and ports.

  • Page 24: Installation Procedures

    Do not power up a 7705 SAR-8 or 7705 SAR-18 before verifying that all common equipment (chassis, power, cooling, and grounding) is connected properly. • The Fan module and all cards in the 7705 SAR-8 chassis must have the same voltage type. •...

  • Page 25: Installing Or Replacing An Adapter Card

    8-port Ethernet Adapter card version 2 is available in either a -48 VDC/-60 VDC variant or a +24 VDC variant. Only the -48/-60 VDC variant of the 8-port Ethernet Adapter card version 2 can be installed in the 7705 SAR-18 chassis as the 7705 SAR-18 does not support +24 VDC power.

  • Page 26: Figure 1 7705 Sar-8 Csm And Adapter Card Slot Identification

    Installation Procedures Figure 1: 7705 SAR-8 CSM and Adapter Card Slot Identification Batt A CSM A CSM B MDA 1 MDA 2 Batt B MDA 3 MDA 4 MDA 5 MDA 6 19635 Figure 2: 7705 SAR-18 CSM and Adapter Card Slot Identification...

  • Page 27: Installing Or Replacing An Adapter Card On The 7705 Sar-8

    • torque driver for Phillips screws In order to ensure the best performance and to ensure that the 7705 SAR-8 chassis remains compliant with EMC requirements, when installing or removing adapter cards or filler plates in/from the 7705 SAR-8 chassis, the following procedure must be followed.

  • Page 28: Table 4 8-Port Ethernet Adapter Card Installation And Removal Features

    To insert an adapter card, see Figure 4 Table Figure 4 shows the installation of an 8-port Ethernet Adapter card on the 7705 SAR-8 chassis; this procedure also applies to the 8-port Gigabit Ethernet Adapter card. 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 29: Sfps

    0.45 N Step 7. If you replaced the adapter card, check the Power LED on the adapter card faceplate. If the adapter card is properly inserted and the 7705 SAR-8 has valid power, the Power LED is lit blue. Refer to Connector and LED Descriptions more information on the LEDs.

  • Page 30: Installing Or Replacing An Adapter Card On The 7705 Sar-18

    To remove an adapter card, see Figure 5 Table Figure 5 shows the removal of an 8-port Gigabit Ethernet Adapter card from the 7705 SAR-18 chassis; this procedure also applies to the 8-port Ethernet Adapter card. 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 31: Figure 5 Removing An 8-Port Gigabit Ethernet Adapter Card From A 7705 Sar-18

    Installing Adapter Cards Figure 5: Removing an 8-port Gigabit Ethernet Adapter Card from a 7705 SAR-18 7705 SAR-18 XMDA 1 XMDA 2 XMDA 3 XMDA 4 CSM A CSM B MDA 1 MDA 2 MDA 3 MDA 4 MDA 5...

  • Page 32: Figure 6 Installing An 8-Port Gigabit Ethernet Adapter Card On A 7705 Sar-18

    The recommended torque is 3 to 4 lbf-in (0.34 to 0.45 N Step 7. If you replaced the adapter card, check the Power LED on the adapter card faceplate. If the adapter card is properly inserted and the 7705 SAR-18 has valid power, the Power LED is lit blue. Refer to Connector and LED Descriptions more information on the LEDs.
  • Page 33 Installing Adapter Cards Step 8. Install any SFPs and attach cables. Refer to SFPs for information on SFPs. Step 9. If applicable, reattach the cables removed in Step 1. 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 34 Installation Procedures 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 35: Sfps

    This chapter provides information on the following topics: • Installing and Removing SFPs → Warnings and Notes → Fiber Cable Preparation → Locking Mechanisms → SFP Support → Installing SFPs → Removing and Replacing SFPs 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 36: Installing And Removing Sfps

    Typical ground points include the ground stud on the 7705 SAR-8 or 7705 SAR-18 mounting bracket, or a properly grounded rack or work bench.

  • Page 37: Fiber Cable Preparation

    Support (OLCS) (http://www.alcatel-lucent.com/myaccess), under the 7705 SAR documentation, for the Optical Handling Reference Guide (part number 95-5795-01-00). Locking Mechanisms SFPs approved by Alcatel-Lucent can use different lock and release methods. Possible lock and release mechanisms include: • locking handle—a locking handle or lever on the front of the SFP that you gently raise or lower to insert or remove the SFP from the port •...

  • Page 38: Sfp Support

    Table 5 are for the SFP case temperature. The ambient temperature outside the 7705 SAR will influence the SFP case temperature, depending on which chassis the SFP is installed in. The maximum system inlet ambient temperature to SFP temperature rise is as follows: •...
  • Page 39 Optics Module - (-40° to 185° F) 3HE00024CA 100FX SFP Fiber 1310 nm -40° to 400 m ROHS-6/6 85° C 2 km Optics Module - (-40° to LC - DDM 185° F) 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 40 (1000Base-BX- D) Bidirectional 3HE00869CA 100M BX10-U Fiber 10 km -40° to SFP ROHS-6/6 1310 nm 85° C Optics Module - (-40° to LC - DDM 1490 nm 185° F) (1000Base- BX-U) Bidirectional 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 41 1490 nm 85° C Optics Module - (-40° to LC (100Base-B- 1310 nm 185° F) X-D) Bidirectional 3HE04685AA Copper DIN 1.0/ 68.5 m -40° to T3/E3 SFP 65° C (-40° to 149° F) 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 42 -5° to 85° C SFP Optics (23° to Module - LC 185° F) 3HE00070BH GigE CWDM Fiber 1611 nm 120 km -5° to 85° C SFP Optics (23° to Module - LC 185° F) 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 43 Optics Module - (-40° to LC DDM 185° F) 3HE00070CH GigE CWDM Fiber 1611 nm 120 km -40° to SFP ROHS-6/6 85° C Optics Module - (-40° to LC DDM 185° F) 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 44 40 km 0° to 70° C Optics Module (32° to (1000Base) 158° F) 3HE04939CG GigE CWDM Fiber 1591 nm 40 km 0° to 70° C Optics Module (32° to (1000Base) 158° F) 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 45 80 km 0° to 70° C Optics Module (32° to (1000Base) 158° F) 3HE05936CG GigE CWDM Fiber 1591 nm 80 km 0° to 70° C Optics Module (32° to (1000Base) 158° F) 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 46: Bidirectional Sfps

    1490 nm, the near-end SFP must transmit at 1490 nm and receive at 1310 nm. T3/E3 SFP The T3/E3 SFP is used to interconnect two 7705 SARs over a T3 physical interface. The E3 interface is not supported. The SFP can only operate with 7705 SARs at either end. The 8-port Gigabit Ethernet Adapter card does not support the T3/E3 SFP.

  • Page 47: Installing Sfps

    Removing and Replacing SFPs When you are replacing an SFP, have the following parts ready: • a replacement SFP • protective plugs for the SFP and a dust cover for the fiber cable connector 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 48 Note: If you are not immediately replacing the SFP, leave the adapter card port empty. It is not necessary to install protective plugs in the ports on the adapter card. 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 49: Connector And Led Descriptions

    Connector and LED Descriptions In This Chapter This chapter provides information on the following topics: • 8-port Ethernet Adapter Card Connectors and LEDs • 8-port Gigabit Ethernet Adapter Card Connectors and LEDs 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 50: 8-Port Ethernet Adapter Card Connectors And Leds

    Green (blinking): Initializing Green (solid): Operationally up, administratively up Amber: Operationally down, administratively up; or hardware booting up Unlit: Administratively down, shut down Blue: Valid power Unlit: No power or faulty power 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 51: Figure 8 Rj-45 Connector Pin Orientation

    Captive screw Tighten both captive screws to secure the adapter card; loosen both screws to remove the card. Figure 8: RJ-45 Connector Pin Orientation Pin 8 Pin 1 19593 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 52: Table 8 Rj-45 Port Pinouts-Rj-45 Female

    Differential transmit data - positive Output Differential transmit data - negative Input Differential receive data - positive — Not connected — Not connected Input Differential receive data - negative — Not connected — Not connected 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 53: 8-Port Gigabit Ethernet Adapter Card Connectors And Leds

    Green (blinking): Initializing Green (solid): Operationally up, administratively up Amber: Operationally down, administratively up; or hardware booting up: Unlit: Administratively down, shut down Blue: Valid power Unlit: No power or faulty power 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...
  • Page 54 Rotate the ejector levers inward to insert the adapter card in the slot and outward to release the card from the slot. Captive screw Tighten both captive screws to secure the adapter card; loosen both screws to remove the card. 7705 SAR Ethernet/Gigabit Ethernet Adapter Card Installation Guide...

  • Page 55: Documentation Feedback

    Customer documentation and product support Customer documentation http://www.alcatel-lucent.com/myaccess Product manuals and documentation updates are available at alcatel-lucent.com. If you are a new user and require access to this service, please contact your Alcatel-Lucent sales representative. Technical support http://support.alcatel-lucent.com Documentation feedback...
  • Page 56 © 2013 Alcatel-Lucent. All rights reserved. 3HE 07728 AAAA TQZZA Edition 01...
