Alcatel-Lucent 7705
SERVICE AGGREGATION ROUTER | RELEASE 1.0
1 6 - P O R T T 1 / E 1 A S A P A D A P T E R C A R D I N S T A L L A T I O N G U I D E
Alcatel-Lucent Proprietary
This document contains proprietary information of Alcatel-Lucent and is not to be disclosed
or used except in accordance with applicable agreements.
Copyright 2008 © Alcatel-Lucent. All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Alcatel-Lucent 7705

Summary of Contents for Alcatel-Lucent 7705

  • Page 1 1 6 - P O R T T 1 / E 1 A S A P A D A P T E R C A R D I N S T A L L A T I O N G U I D E Alcatel-Lucent Proprietary This document contains proprietary information of Alcatel-Lucent and is not to be disclosed or used except in accordance with applicable agreements.
  • Page 2 The customer hereby agrees that the use, sale, license or other distribution of the products for any such application without the prior written consent of Alcatel-Lucent, shall be at the customer's sole risk. The customer hereby agrees to defend and hold Alcatel-Lucent harmless from any claims for loss, cost, damage, expense or liability that may arise out of or in connection with the use, sale, license or other distribution of the products in such applications.

  • Page 3: Table Of Contents

    Table of Contents Preface ................3 Installing Adapter Cards .
  • Page 4 Table of Contents Page 4 16-port T1/E1 ASAP Adapter Card Installation Guide...
  • Page 5 List of Tables Preface ................3 Table 1: Information Symbols .
  • Page 6 List of Tables Page 6 16-port T1/E1 ASAP Adapter Card Installation Guide...
  • Page 7 7705 SAR-8 Slot Identification ........
  • Page 8 List of Figures Page 8 16-port T1/E1 ASAP Adapter Card Installation Guide...

  • Page 9: Preface

    Command Line Interface (CLI) information to configure system and network parameters. List of Technical Publications The 7705 SAR OS documentation set is composed of the following guides: • 7705 SAR OS Basic System Configuration Guide This guide describes basic system configurations and operations.
  • Page 10 (SAPs), service destination points (SDPs), customer information, user services, and Operations, Administration and Management (OAM) tools. • 7705 SAR OS Quality of Service Guide This guide describes how to configure Quality of Service (QoS) policy management. Warnings and Notes Observe the warnings and notes to avoid injury or router damage during installation and maintenance.

  • Page 11: Table 1: Information Symbols

    Technical Support If you purchased a service agreement for your 7705 SAR and related products from a distributor or authorized reseller, contact the technical support staff for that distributor or reseller for assistance. If you purchased an Alcatel-Lucent service agreement, contact your...
  • Page 12 Preface Page 12 16-port T1/E1 ASAP Adapter Card Installation Guide...

  • Page 13: Installing Adapter Cards

    Installing Adapter Cards In This Chapter This chapter provides information about installing and removing the adapter cards in the 7705 SAR-8 chassis: • Provisioning Requirements on page 14 • Component Power Consumption on page 15 • Provisioning an Adapter Card on page 16 →...

  • Page 14: Provisioning Requirements

    Provisioning Requirements Provisioning Requirements To configure cards and ports, you must be able to access the 7705 SAR-8 by console or Telnet connection. Refer to the 7705 SAR-8 Installation Guide for information and instructions on console and Telnet connections. The CSM does not require provisioning. However, the IOM, which is an integral part of the CSM software module, must be activated before any adapter cards and port parameters can be provisioned and configured.

  • Page 15: Component Power Consumption

    28 W (unpopulated, all fans operating) 17 W 16-port T1/E1 ASAP Adapter card 17 W Refer to the 7705 SAR-8 Installation Guide for more information on the power consumption of other components. 16-port T1/E1 ASAP Adapter Card Installation Guide Page 15...

  • Page 16: Provisioning An Adapter Card

    CLI commands to provision the adapter card. The steps config below provision 16-port T1/E1 ASAP Adapter cards in slots MDA 5 and 6. In Release 1.0, a maximum of six 16-port T1/E1 ASAP Adapter cards can be configured on a 7705 SAR-8. Command Syntax Example Step 1.
  • Page 17 Installing Adapter Cards . . . ---------------------------------------------- echo "Card Configuration" #--------------------------------------------- card 1 card-type iom-1g mda 5 mda-type a16-chds1 exit mda 6 mda-type a16-chds1 exit exit ---------------------------------------------- ALU-1>config# Use the command to display administrative and operational config>show card state states for all cards: ALU-1>config# show card state =============================================================================== Card State...

  • Page 18: Installation Procedures

    • Always place components on a flat anti-static surface. • For first-time power up during chassis installation, do not power up a 7705 SAR-8 until all components are installed and verified as having been installed correctly.

  • Page 19: Installing An Adapter Card

    Installing Adapter Cards Installing an Adapter Card A maximum of six 16-port T1/E1 ASAP Adapter cards can be installed on the 7705 SAR-8 in MDA slots 1 through 6. Figure 1 identifies the location of the MDA slots. Figure 2 illustrates the installation of an adapter card.

  • Page 20: Removing And Replacing An Adapter Card

    4-6 lbf.-in. Check the Power LED. If the adapter card is properly inserted and power to the Step 5. 7705 SAR-8 has been applied, the Power LED is lit blue. See Connector and LED Descriptions on page 23 for a description of LED activity.

  • Page 21: Figure 3: Removing An Adapter Card

    Installing Adapter Cards type, no configuration change is necessary. Refer to the 7705 SAR OS Interface Configuration Guide for details on configuring cards and ports. If you are removing the card, but not replacing it, install a slot cover over the empty slot.
  • Page 22 Installation Procedures Tools required: • Phillips screwdriver • torque driver for Phillips screws To remove and replace an adapter card: If you are replacing an adapter card with a different type, change the configuration to Step 1. reflect the new adapter card type. See Changing an Adapter Card Configuration on page Disconnect all cable connections to the adapter card.

  • Page 23: Connector And Led Descriptions

    Connector and LED Descriptions In This Chapter This chapter provides information on the following topics: • 16-port T1/E1 ASAP Adapter Card Connectors and LEDs on page 24 16-port T1/E1 ASAP Adapter Card Installation Guide Page 23...

  • Page 24: 16-Port T1/E1 Asap Adapter Card Connectors And Leds

    16-port T1/E1 ASAP Adapter Card Connectors and LEDs 16-port T1/E1 ASAP Adapter Card Connectors and LEDs Figure 4 shows the connectors and LEDs on the 16-port T1/E1 ASAP Adapter card. Figure 4: 16-port T1/E1 ASAP Adapter Card Connectors and LEDs A1 6-C HD S1 Stat Port...

  • Page 25: Connector And Led Descriptions

    Connector and LED Descriptions Table 4: 16-port T1/E1 ASAP Adapter Card Features (Continued) Label Description Ejector lever Rotate both levers inward to insert the adapter card in the slot, and outward to release the card from the slot. Note: The captive screws must be loosened before the card can be removed from the slot.
  • Page 26 16-port T1/E1 ASAP Adapter Card Connectors and LEDs Page 26 16-port T1/E1 ASAP Adapter Card Installation Guide...

  • Page 27: T1/E1 Cable Pinout Assignments

    T1/E1 Cable Pinout Assignments In This Chapter There are two types of T1/E1 cable available for the 16-port T1/E1 ASAP Adapter card. The pinout assignments described in this chapter are: • 68-pin AMP to 68-pin AMP T1/E1 Cable — Pinout Assignments on page 28 •...

  • Page 28: 68-Pin Amp To 68-Pin Amp T1/E1 Cable - Pinout Assignments

    16-port T1/E1 ASAP Adapter card. The cable is 3.25 ft (1 m) long. The connectors at each end of the cable have identical pinout assignments. Pins 1, 34, 35, and 68 are ground connections. The T1/E1 cable is available from Alcatel-Lucent. Figure 5: 68-pin AMP to 68-pin AMP Cable...

  • Page 29: T1/E1 Cable Pinout Assignments

    T1/E1 Cable Pinout Assignments Table 5: 68-pin AMP to 68-pin AMP T1/E1 Cable Pinout Assignments (Continued) Port Cable Tx/Rx Tip/Ring (Tx or Rx) Tx Tip Tx Ring Rx Tip Rx Ring Tx Tip Tx Ring Rx Tip Rx Ring Tx Tip Tx Ring Rx Tip Rx Ring...
  • Page 30 68-pin AMP to 68-pin AMP T1/E1 Cable — Pinout Assignments Table 5: 68-pin AMP to 68-pin AMP T1/E1 Cable Pinout Assignments (Continued) Port Cable Tx/Rx Tip/Ring (Tx or Rx) Tx Tip Tx Ring Rx Tip Rx Ring Tx Tip Tx Ring Rx Tip Rx Ring Tx Tip...

  • Page 31: 68-Pin Amp To Open-Ended Wire T1/E1 Cable - Pinout Assignments

    34, 35, and 68 are ground connections and are connected to the braided shield of the cable. The open-ended wire T1/E1 cable is available from Alcatel-Lucent in 28 AWG and 26 AWG and in lengths of 49 ft (15 m) or 98 ft (30 m). Use 28 AWG for installations using 28 AWG-compliant punch-down blocks, wire-wrap posts, or screw-down terminals.

  • Page 32: Table 7: 68-Pin Amp To Open-Ended Wire Pinout Assignments

    68-pin AMP to Open-ended Wire T1/E1 Cable — Pinout Assignments Table 7: 68-pin AMP to Open-ended Wire Pinout Assignments Port Cable 68-pin AMP Open End Color (Tx or Rx) Tx/Rx +/- 1, 34, 35, 68 White Blue White Blue White Orange White Orange...
  • Page 33 T1/E1 Cable Pinout Assignments Table 7: 68-pin AMP to Open-ended Wire Pinout Assignments (Continued) Port Cable 68-pin AMP Open End Color (Tx or Rx) Tx/Rx +/- Yellow Orange Yellow Orange Yellow Green Yellow Green Yellow Brown Yellow Brown Yellow Gray Yellow Gray Violet...
  • Page 34 68-pin AMP to Open-ended Wire T1/E1 Cable — Pinout Assignments Table 7: 68-pin AMP to Open-ended Wire Pinout Assignments (Continued) Port Cable 68-pin AMP Open End Color (Tx or Rx) Tx/Rx +/- Violet Brown Violet Brown Violet Gray Violet Gray Black Blue Black...
  • Page 35 Customer documentation http://www.alcatel-lucent.com/osds Product manuals and documentation updates are available through the Alcatel-Lucent Support Documentation and Software Download service at alcatel-lucent.com. If you are a new user and require access to this service, please contact your Alcatel-Lucent sales representative. Technical support http://www.alcatel-lucent.com/support...
  • Page 36 © 2008 Alcatel-Lucent. All rights reserved. 3HE 03255 AAAA TQZZA Edition 01...
