*1 Effective pixels are more than 99.99%.
*2 This is the light output value that results from setting [PRESET] to [HIGH-BRIGHT] and setting [LIGHT ADJUST] to [100%]. If
any other mode is selected for [PRESET], the brightness becomes lower.
*3 This indicates the average value in the total shipment of the product. Compliance with ISO21118-2012.
*4 Numerical value with the LV unit NP-LV01BD installed.
*5 C1 connection is the case when the AC power to the projector power supply and the light power supply is provided by a single
cable.
C2 connection is the case when the AC power to the projector power supply and the light power supply is provided by separate
cables.
*6 If you are unable to view material via the HDMI input, DisplayPort input and HDBaseT input, this does not necessarily mean the
projector is not functioning properly. With the implementation of HDCP technology, there may be cases in which certain content
is protected with HDCP and might not be displayed due to the decision/intention of the HDCP community (Digital Content Protec-
tion, LLC).
Video: Deep Color, 8/10/12-bit
HDMI: Supports HDCP 1.4/2.2
DisplayPort: Supports HDCP 1.4
HDBaseT: Supports HDCP 1.4/2.2
* Described the certification standard for laser products in "Important Information" of this manual.
* Note that these specifications and design can change without prior notice.
Option lens (sold separately)
L2K-10F1
L4K-11ZM
L4K-15ZM
L4K-20ZM
L2K-30ZM
L2K-43ZM1
L2K-55ZM1
Power lens shift, Power focus
(Throw ratio 0.93:1, F2.5, f = 28.95 mm)
Power lens shift, Power zoom, Power focus, [LENS MEMORY] support
(Throw ratio 1.24–1.73:1, F2.5/2.5, f = 35.2–53.7 mm)
Power lens shift, Power zoom, Power focus, [LENS MEMORY] support
(Throw ratio 1.52–2.10:1, F2.5/2.5, f = 45.3–65.6 mm)
Power lens shift, Power zoom, Power focus, [LENS MEMORY] support
(Throw ratio 1.98–3.34:1, F2.5/2.5, f = 61.4–105.2 mm)
Power lens shift, Power zoom, Power focus, [LENS MEMORY] support
(Throw ratio 2.71–3.92:1, F2.5/2.5, f = 85.0–121.63 mm)
Power lens shift, Power zoom, Power focus, [LENS MEMORY] support
(Throw ratio 3.91–5.52:1, F2.5/2.5, f = 122.76–172.33 mm)
Power lens shift, Power zoom, Power focus, [LENS MEMORY] support
(Throw ratio 5.00–7.80:1, F2.5/2.5, f = 156.54–243.12 mm)
137
8. Appendix
