ASSEMBLY

Assembly requires two people. Place all parts of the elliptical trainer in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included allen wrench, assembly requires a phillips screwdriver
wrenches
Use the chart below to identify the small parts used in assembly. The number in parenthesis below each part
refers to the key number of the part, from the PART LIST on page 14. The number after the dash indicates the
quantity needed for assembly. Note: Some parts may have been pre-attached for shipping. If a part is not
in the parts bag, check to see if it has been pre-attached.
M8 Nylon
Locknut (38)–6
M4 x 12mm M4 x 19mm Flange
Screw (42)–4
M10 x 74mm Button Bolt (67)–2
1. Identify the Front Stabilizer (10). While another per-
son lifts the front of the Frame (1), attach the Front
Stabilizer to the Frame with two M10 x 75mm
Carriage Bolts (34) and two M10 Nylon Locknuts
(33). Make sure that the Front Stabilizer is turned
so the Wheels (22) are not touching the floor.
, a rubber mallet
M10 Nylon
Locknut (33)–6
Screw (36)–6
Pedal Arm Bolt Set (40)–2
, and a pair of pliers
M10 Split
Washer (59)–2 Washer (35)–2
M8 x 25mm Button
Screw (56)–2
M10 x 75mm Carriage Bolt (34)–4
1
22
5
, two adjustable
.
M8.5
M10.5
Washer (55)–2
M8 x 45mm Button Bolt (50)–4
22
10
1
33
34
