Summary of Contents for Chevrolet 2010 Silverado

Page 1 2010 Chevrolet Silverado and GMC Sierra Two-mode Hybrid In Brief ..........1-1 Driving Your Vehicle .
Page 2: Canadian Owners
Canadian Owners GENERAL MOTORS, GM and the GM Emblem, CHEVROLET, the CHEVROLET Emblem, GMC, the Propriétaires Canadiens GMC Emblem, and the names SILVERADO and SIERRA are registered trademarks of General Motors. A French language copy of this manual can be obtained...
Page 3: Index
Introduction Index Your hybrid pickup is designed to be more fuel efficient A good place to look for what you need is the Index in than the standard pickup, which results in reduced back of this supplement. It is an alphabetical list of what carbon dioxide emissions.
Page 4 NOTES I n f o r ma t i o n P r o v i d e d b y :...
Page 5: In Brief
Section 1 In Brief Initial Drive Information ......1-2 Regenerative Braking ......1-4 Transmission .
Page 6: Initial Drive Information
Initial Drive Information Press the plus/minus buttons, located on the steering column shift lever, to select the desired range of gears for current driving conditions. See Automatic Transmission Transmission Operation in the owner manual. Cruise control can be used while the vehicle is in Range Range Selection Mode Selection Mode.
Page 7: Auto Stop
Fuel Economy Gage Automatic Engine Start/Stop Feature Start the engine as you would any other engine. See Starting the Engine in the owner manual for more information on starting. The hybrid system provides very quiet engine starting. If pulling a trailer with trailer brakes, see Towing a Trailer on page 5 2 for more information.
Page 8 Auto Start occasionally hear the motor driven pump when it recharges the system. This is normal. In the event of a The vehicle also has an Auto Start feature. The engine controller problem, the brake pedal may be harder to will remain off while in Auto Stop mode until vehicle push and the stopping distance may be longer.
Page 9: Seats And Restraint System
Section 2 Seats and Restraint System Rear Seats ......... 2-2 Restraint System Check .
Page 10: Rear Seats
Rear Seats Restraint System Check Rear Seat Operation (Hybrid Full Replacing Restraint System Parts Bench) After a Crash If an airbag inflates or the vehicle has been in a crash, Folding Rear Seat the vehicle's sensing system may command the Folding a rear seat with the safety belts automatic hybrid battery disconnect to open.
Page 11: Table Of Contents
Section 3 Features and Controls Storage Areas ........3-2 Starting and Operating Your Vehicle .
Page 12: Storage Areas
Storage Areas Tonneau Cover (Hard Tonneau) Installing the Cover CAUTION: An improperly stored cargo cover could be thrown about the vehicle during a collision or sudden maneuver. Someone could be injured. If the cover 1. Position the tonneau cover onto the top of the pickup box with the locator tabs positioned into is removed, always store it in the proper storage the front stake pockets.
Page 13 4. Tilt the clamp assembly so that the locator is in 7. There are locking features on the front clamps the slot, pull down on the assembly, and slide only. With the handle in the clamped position, push the clamp under the edge of the inner lip of the the locking tab to engage the lock.
Page 14 3. Lower the rear set of clamp assemblies from the 6. The clamp should be securely engaged. Shake the stored position. handle assembly to make sure the handle does not move. 7. Repeat the clamp attachment steps 3 through 6 for the opposite side.
Page 15: Removing The Tonneau Cover
Removing the Tonneau Cover 1. Open the cover by following the procedure described previously, under Opening the Tonneau Cover . 6. The handle should lie flat on the panel with the handles facing inward. Press firmly to secure. This step must be done before stowing the cover. 7.
Page 16 Tightening the Clamp 1. Push the handle forward to release it from the clamped position. 2. Disengage the clamp from the inner edge of the bed rail and slide the assembly inward. 3. Adjust the clamp height on the bolt by turning the entire clamp assembly counter-clockwise.
Page 17 Tonneau Cover (Soft Tonneau) Installation 1. The adjuster screw end Side Rail of each side rail should point in the direction of the cab. WARNING: An improperly stored cargo cover could be thrown about the vehicle during a collision or sudden maneuver.
Page 18 Clamp 3. If the pickup box has molded bed rail Installation protectors (A), remove the insert (C) from the outer groove on the clamp, and position the clamp on the side rail (B) using the outer groove (D). 4. Slide the inner clamp (B) into the outer clamp (A).
Page 19 6. Tighten the clamp by turning the latch (C) toward the side rail. Make sure there is no gap between the rubber clamp pad and the side rail. 7. If the truck box has a molded bed rail protector, 9. Remove the paper from the provided clear tape insert the latch into the top notch on the inner strip and apply to the painted surface below the clamp.
Page 20 Cover Installation 2. Verify the gap between the adjuster screws and pivot mounts is 3/16 in. Adjust if needed. 1. Place the cover assembly into the front pivot mounts firmly against the adjustment screws. 3-10 I n f o r ma t i o n P r o v i d e d b y :...
Page 21 3. Loosen the wing bolt (A), then slide the latch 4. Unbuckle both straps and roll the cover out. Make outboard into the side rail. Tighten down the wing sure that each bow falls in between the side rails. bolt (A). Do this on both sides. Both latches must If the bows do not fit between the side rails, verify remain engaged and the wing bolts tightened while that the clamps are pushed fully outboard without...
Page 22 7. Secure the buckles by folding them once, then slide them under the cord located on the cover. Secure in Open Position 1. To open the cover, open tailgate and push down on the cover. The 5. When the cover is rolled out, place the rear rail pull back on pull strap.
Page 23 Removal Adjustment 1. Secure the cover (A) 1. If the cover is too into the open position. loose, turn the tensioning screw 2. Loosen wing bolts (B) clockwise to tighten the on both driver and tension of the vinyl. passenger side of front This makes it harder to rail, then slide latches operate the rear...
Page 24: Starting The Vehicle
Auto Stop Starting and Operating Your Vehicle The vehicle has an Auto Stop feature. After a successful engine start, the engine may turn off and operate in the Auto Stop mode. Some of the vehicle Starting the Vehicle conditions that allow the engine to stop running and enter the Auto Stop mode are: WARNING: Ignition switch is in the ON/RUN position.
Page 25 The hybrid battery voltage, temperature or power Keep your foot firmly on the brake pedal until you are limits are exceeded. ready for the vehicle to move. A remote vehicle start has been requested. Engine OFF and AUTO STOP modes are indicated on the tachometer display.
Page 26: Automatic Transmission Operation
Automatic Transmission Operation WARNING: The vehicle has an electronic shift position indicator within the instrument panel cluster. It is dangerous to get out of the vehicle if the shift There are several different positions for the shift lever. lever is not fully in P (Park) with the parking brake firmly set.
Page 27 WARNING: WARNING: If you have Four-Wheel Drive, the vehicle will Shifting into a drive gear while the engine is be free to roll even if the shift lever is in running at high speed is dangerous. Unless your P (Park) if the transfer case is in Neutral.
Page 28 Range Selection Mode Downshifting the transmission in slippery road conditions could result in skidding. See Skidding under Loss of Control in the owner manual for more information. When temperatures are very cold, the transmission's gear shifting may be delayed, providing more stable shifts until the engine warms up.
Page 29: Engine Coolant Heater
The vehicle can automatically shift to lower gears as In the M1 gear range, effective engine braking occurs at it adjusts to driving conditions. When 3 (Third) is speeds above 10 mph (16 km/h). selected, 1 (First) through 3 (Third) gears are When operating in M (Manual Mode), Auto Stop is automatically shifted by the vehicle, but 4 (Fourth) disabled.
Page 30: To Use The Engine Coolant Heater
To Use the Engine Coolant Heater WARNING: 1. Turn off the engine. 2. Open the hood and unwrap the electrical cord. The Plugging the cord into an ungrounded outlet could cord is secured to a wiring harness between the engine and the Hybrid Auxiliary Underhood Fuse cause an electrical shock.
Page 31: Regenerative Braking
Regenerative Braking Running the Vehicle While Parked Regenerative braking is a hybrid technology that It is better not to park with the engine running. But if you enables the electric drive motor to operate as a ever have to, here are some things to know. generator when coasting or braking.
Page 32 NOTES 3-22 I n f o r ma t i o n P r o v i d e d b y :...
Page 33: Instrument Panel
Section 4 Instrument Panel Climate Controls ........4-2 Engine Coolant Temperature Gage .
Page 34: Climate Controls
Climate Controls At mild temperatures, select a warmer air conditioner temperature or turn the air conditioner off to get For more information on the vehicle's climate control maximum fuel economy. Continuous air conditioner use can cause the vehicle to Auto Start more frequently. system, see Climate Control System in the owner manual.
Page 35: Warning Lights, Gages, And Indicators
Warning Lights, Gages, and Indicators Instrument Panel Cluster United States version shown, Canada similar I n f o r ma t i o n P r o v i d e d b y :...
Page 36: Tachometer
Tachometer Charging System Light This 12 V battery light comes on briefly when the ignition is turned to ON/RUN, but the engine is not running, as a check to show it is working. It should go out once the engine has been started. If it stays on, or comes on while driving, there could be a problem with the 12 V charging system.
Page 37: Fuel Economy Gage
Fuel Economy Gage White Zones : Decreased fuel efficiency driving behavior makes the indicator display in the two white zones. The indicator in the white zone on the left side of the gage indicates decreased fuel efficiency with a large amount of decelerations.
Page 38 This light also comes on due to low brake fluid. See the owner manual for more information. WARNING: The brake system might not be working properly if the brake system warning light is on. Driving with the brake system warning light on can lead to a crash.
Page 39: Antilock Brake System (Abs) Warning Light
® Antilock Brake System (ABS) StabiliTrak Indicator Light Warning Light For vehicles with StabiliTrak, this warning For vehicles with the light comes on briefly Antilock Brake System when the ignition is in (ABS), this light comes ON/RUN. on briefly when the engine is in ON/RUN.
Page 40: Engine Coolant Temperature Gage
Engine Coolant Temperature Gage Oil Pressure Gage United States Canada United States Canada This gage shows the engine coolant temperature. The oil pressure gage shows the engine oil pressure in psi (pounds per square inch) when the engine is It also provides an indicator of how hard the vehicle is running.
Page 41: Oil Pressure Light
Oil Pressure Light WARNING: WARNING: Do not keep driving if the oil pressure is low. The engine can become so hot that it catches fire. Do not keep driving if the oil pressure is low. The Someone could be burned. Check the oil as soon engine can become so hot that it catches fire.
Page 42: Fuel Gage
Listed are four situations that may occur with the fuel If the light comes on and stays on, it means that oil is gage, none of these indicate a problem: not flowing through the engine properly. The vehicle At the gas station, the fuel pump shuts off before could be low on oil and might have some other system the gage reads F (full).
Page 43: Driver Information Center (Dic)
DIC Warnings and Messages Driver Information Center (DIC) Warning messages are displayed on the DIC to notify Trip/Fuel Menu Items the driver that the status of the vehicle has changed and that some action may be needed by the driver to Press the trip/fuel button to display the Trip/Fuel Menu correct the condition.
Page 44: Service Brake System
HOOD OPEN Warning Light in the owner manual Index. Driving with this message on could drain the battery. Have the If the hood is not fully closed or there is a problem with electrical system checked as soon as possible. the hood switch, this message will be displayed.
Page 45: Audio System(S)
Audio System(s) The display shows: Auto Stop Navigation/Radio System Battery Charging Engine Idle For vehicles with a navigation radio system, see the Navigation System manual for more information. 2 Wheel and 4 Wheel Drive Modes for: Engine Power Battery Power Hybrid Power To view the hybrid screen, press the MENU button on the radio.
Page 46 NOTES 4-14 I n f o r ma t i o n P r o v i d e d b y :...
Page 47: Driving Your Vehicle
Section 5 Driving Your Vehicle Your Driving, the Road, and the Vehicle ..5-2 Towing ..........5-2 Electric Power Steering .
Page 48: Your Driving, The Road, And The Vehicle
Towing a Trailer Your Driving, the Road, and the Vehicle For more information, see Towing a Trailer in the owner manual Index. Electric Power Steering Weight of the Trailer This vehicle has On-Demand Electric-Assist Power How heavy can a trailer safely be? Steering instead of conventional full-time hydraulic It depends on how the rig is used.
Page 49: Trailer Brakes
Vehicle Axle Ratio Maximum Trailer Weight GCWR* 2WD 6.0 L V8 3.08 6,100 lbs (2 767 kg) 12,000 lbs (5 443 kg) 4WD 6.0 L V8 3.08 5,900 lbs (2 676 kg) 12,000 lbs (5 443 kg) *The Gross Combination Weight Rating (GCWR) is the total allowable weight of the completely loaded vehicle and trailer including any passengers, cargo, equipment and conversions.
Page 50 NOTES I n f o r ma t i o n P r o v i d e d b y :...
Page 51: Service And Appearance Care
Section 6 Service and Appearance Care Service ..........6-2 Brakes .
Page 52: Service
Service WARNING: Doing Your Own Service Work You can be injured and the vehicle could be damaged if you try to do service work on a vehicle WARNING: without knowing enough about it. Be sure you have sufficient knowledge, Never try to do your own service on hybrid experience, the proper replacement parts, components.
Page 53: Checking Things Under The Hood
If doing some of your own service work, use the proper Checking Things Under service manual. It tells you much more about how to the Hood service the vehicle than this manual can. To order the proper service manual, see Service Publications Ordering Information in the owner manual.
Page 54: Engine Compartment Overview
Engine Compartment Overview When you open the hood on your vehicle, you will see: I n f o r ma t i o n P r o v i d e d b y :...
Page 55: Automatic Transmission Fluid
Automatic Transmission Fluid A. See Engine Air Cleaner/Filter in the owner manual. When to Check and Change Automatic B. Drive Motor/Generator Control Module (DMCM). Transmission Fluid See Drive Motor/Generator Control Module (DMCM) Cooling System on page 6 9. It is usually not necessary to check the transmission C.
Page 56: How To Check Automatic Transmission Fluid
How to Check Automatic Transmission 6. Using the TRANS TEMP reading, determine and perform the appropriate check procedure. If the Fluid TRANS TEMP reading is not within the required temperature ranges, allow the vehicle to cool, Notice: Too much or too little fluid can damage your or operate the vehicle until the appropriate transmission.
Page 57 3. Install the dipstick by pushing it back in all the way, Hot Check Procedure wait three seconds, and then pull it back out again. Use this procedure to check the transmission fluid level 4. Check both sides of the dipstick and read the lower when the transmission fluid temperature is between level.
Page 58: Drive Motor/Generator Control Module (Dmcm) Coolant Surge Tank Pressure Cap
Consistency of Readings Always check the fluid level at least twice using the procedure described previously. Consistency (repeatable readings) is important to maintaining proper fluid level. If readings are still inconsistent, contact your dealer/retailer. Drive Motor/Generator Control Module (DMCM) Coolant Surge Tank Pressure Cap See Engine Compartment 5.
Page 59 When you decide it is safe to lift the hood, here is what The Drive Motor/Generator Control Module (DMCM) you will see: coolant surge tank pressure cap must be fully installed on the hybrid coolant surge tank. Notice: If the pressure cap is not tightly installed, coolant loss and possible damage to the Drive Motor/Generator Control Module (DMCM) may occur.
Page 60: Cooling System
How to Add Coolant to the DMCM If the coolant inside the DMCM coolant surge tank is boiling, do not do anything else until it cools down. Coolant Surge Tank The coolant level should be at or above the FULL If no problem has been found yet, check to see if COLD mark with the vehicle parked on a level surface.
Page 61 If the DMCM coolant is empty , the vehicle must be WARNING: serviced by your dealer and a special fill procedure must be followed. Notice: Attempting to fill the DMCM cooling surge Steam and scalding liquids from a hot cooling tank yourself when the fluid level is empty can system can blow out and burn you badly.
Page 62 Turn the DMCM coolant surge tank pressure cap 5. Add the pre mixed DEX COOL , available at your slowly counterclockwise (left) about one full turn. dealer/retailer, until the coolant level is maintained Wait 30 seconds. at the FULL COLD mark. This should take no longer than two minutes of hybrid cooling pump operation.
Page 63: Power Steering Fluid
Power Steering Fluid There are only two reasons why the brake fluid level in the reservoir might go down: The vehicle has electric power steering and does not use power steering fluid. The brake fluid level goes down because of normal brake lining wear.
Page 64: Checking Brake Fluid
Checking Brake Fluid Do not top off the brake fluid. Adding fluid does not correct a leak. If fluid is added when the linings are Check brake fluid by looking at the brake fluid reservoir. worn, there will be too much fluid when new brake See Engine Compartment Overview on page 6 4.
Page 65 What to Add Notice: Using the wrong fluid can badly damage Use only new DOT 3 brake fluid from a sealed brake hydraulic system parts. For example, container. See Recommended Fluids and Lubricants just a few drops of mineral-based oil, such in the owner manual.
Page 66: Brake Wear
Brake Wear Notice: Continuing to drive with worn-out brake pads could result in costly brake repair. This vehicle has disc brakes. Disc brake pads have Some driving conditions or climates can cause a brake built-in wear indicators that make a high-pitched squeal when the brakes are first applied or lightly warning sound when the brake pads are worn and new applied.
Page 67: Battery
Replacing Brake System Parts Only a trained service technician with the proper knowledge and tools should inspect, test, or replace The braking system on a vehicle is complex. Its many the hybrid battery. See your dealer/retailer if the hybrid parts have to be of top quality and work well together if battery needs service.
Page 68: Vehicle Storage
Vehicle Storage Jump Starting WARNING: WARNING: Batteries have acid that can burn you and gas Personal injury, death, or damage to the vehicle that can explode. You can be badly hurt if you are can result if you try jump starting or using a not careful.
Page 69 Notice: Ignoring these steps could result in costly in N (Neutral) before setting the parking brake. damage to the vehicle that would not be covered by If you have a four-wheel-drive vehicle, be sure the the warranty. transfer case is in a drive gear, not in N (Neutral). Trying to start the vehicle by pushing or pulling it Notice: If you leave the radio or other accessories will not work, and it could damage the vehicle.
Page 70 WARNING: An electric fan can start up even when the engine is not running and can injure you. Keep hands, clothing and tools away from any underhood electric fan. WARNING: Using an open flame near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded.
Page 71 7. Connect the red positive (+) cable to the WARNING: positive (+) terminal of the vehicle with the dead battery. Use a remote positive (+) if the vehicle has one. Fans or other moving engine parts can injure you 8. Do not let the other end touch metal. Connect it to badly.
Page 72 Jumper Cable Removal 10. Connect the other end of the negative ( ) cable to the remote negative ( ) terminal, on the vehicle with the dead battery. 11. Now start the vehicle with the good battery and run the engine for a while. 12.
Page 73: Electrical System
To disconnect the jumper cables from both vehicles: Electrical System 1. Disconnect the black negative ( ) cable from the vehicle that had the bad battery. High Voltage Devices and Wiring 2. Disconnect the black negative ( ) cable from the vehicle with the good battery.
Page 74: Fuses And Circuit Breakers
Fuses and Circuit Breakers information on its location. For more information on the main underhood fuse block, see Underhood Fuse The wiring circuits in the vehicle are protected from Block in the owner manual. short circuits by a combination of fuses, circuit breakers and fusible thermal links.
Page 75: Appearance Care
Fuses Usage Relays Usage Drive Motor/Generator Control FAN LOW Cooling Fan Low Speed Relay Module 1 FAN MID 1 Cooling Fan Mid 1 Drive Motor/Generator Control FAN HI Cooling Fan High Speed Relay Module 2 FAN MID 2 Cooling Fan Mid 2 BECM FAN CNTRL Cooling Fan Control...
Page 76: Capacities And Specifications
Capacities and Specifications Capacities Application English Metric Automatic Transmission* (Pan Removal and Filter 11.5 qt 10.9 L Replacement) Cooling System Drive Motor Generator Control Module Cooling System 2.9 qt 2.7 L 6.0L V8 Engine Cooling System 17.2 qt 16.3 L Fuel Tank 26.0 gal 98.4 L...
Page 77 Section 7 Maintenance Schedule Maintenance Schedule ......7-2 Recommended Fluids and Lubricants ... 7-2 Engine Drive Belt Routing .
Page 78: Recommended Fluids And Lubricants
Engine Drive Belt Routing Maintenance Schedule Recommended Fluids and Lubricants Fluids identified below are specific to the hybrid vehicle and can be obtained from your dealer/retailer. See the owner manual for the other fluids and lubricants recommended for the vehicle. Usage Fluid/Lubricant Always use the pre-mixed...
Page 79 Antilock Brake System (ABS) Drive Motor/Generator Control Module (DMCM) Warning Light ........4-7 Coolant Surge Tank Pressure Cap .
Page 80 Gages Jump Starting ........6-18 Engine Coolant Temperature .
Page 81 Regenerative Braking ......3-21 Restraint System Check Navigation/Radio System ......4-13 Replacing Restraint System Parts After a Crash .
Page 82 Tachometer ......... .4-4 Vehicle Tonneau Cover .
