Dometic RHC 460 Instructions For Use Manual

Minibar compressor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTIONS for USE
INSTALLATION INSTRUCTIONS
RECORD THIS INFORMATION FOR FUTURE REFERENCE
BEFORE INSTALLING THE UNIT:
Model No.
Product No.
Date Purchased
Sales Office
Intercon Marketing
1540 Northgate Blvd.
Sarasotu, Fl 34234
Phone: 941-355-4488
SERVICE OFFICE
The Dometic Corp.
509 So. Poplar St.
La Grange, IN 46761
Phone: 219 463 4858
FOR SERVICE CENTER
ASSISTANCE
CALL: 800 544 4881
Improper installation, adjustment, alteration, service or mainten-
ance can cause injury or property damage. Refer to this manual.
For assistance or additional information consult a qualified
installer or service agency .
ENGLISH
Type HC20/60
822 6100-35
Serial No.
Place of Purchase
RHC 460
RHC 860AC
MBC 600A
WARNING
IMPORTANT INSTRUCTIONS
READ CAREFULLY
9801370
miniBar
compressor
T.D. 03/2003

Advertisement

Table of Contents
loading

Related Manuals for Dometic RHC 460

Summary of Contents for Dometic RHC 460

  • Page 1 Product No. Date Purchased Place of Purchase Sales Office Intercon Marketing 1540 Northgate Blvd. Sarasotu, Fl 34234 RHC 460 Phone: 941-355-4488 SERVICE OFFICE The Dometic Corp. 509 So. Poplar St. La Grange, IN 46761 Phone: 219 463 4858 RHC 860AC...

  • Page 2: Table Of Contents

    INTRODUCTION FOR YOUR SAFETY 2.1 Warnings and Safety Advice 2.2 Coolant WARRANTY AND CUSTOMER SERVICE INSTALLATION 4.1 The Purpose of this Manual 4.2 Tools/Materials Required 4.3 Unpacking 4.4 Cleaning 4.5 Technical Data 4.6 Connecting the Device to the Electricity Supply 4.7 Securing 4.8 Installation 4.9 Changing the Sliding Hinge...

  • Page 3: Introduction

    Any damage due to improper use is not covered by the warranty. The warranty does not cover any modifications to the appliance or the use of non-original Dometic parts; the warranty does not apply if the installation and operating instructions are not adhered to and no liability shall be entertained. Parts can be ordered from our Dometic service department.

  • Page 4: Installation

    Check that the voltage noted on the model label corresponds to the mains voltage. Depending on the model, the following parts can be found in the miniBar : RHC 460 Cleaning Before operating the miniBar, we recommend you clean it both inside and outside.

  • Page 5: Technical Data

    If this is not the case, do not connect the device and contact your dealer! If the connection cable is damaged it must be replaced by the Customer Service at Dometic, or by respectively qualified personnel, in order to pre- vent any hazards. Securing The miniBar must be screwed onto the cupboard using the lower hinges.

  • Page 6: Installation

    Installation min. 200cm² min. 20mm min. 200cm² IMPORTANT: Please follow the installation details below carefully. Guarantee is valid for products installed as described only. 1. The miniBar must be level both directions. 2. There should be 20mm clearance to the wall. 3.

  • Page 7: Changing The Sliding Hinge

    Changing the Sliding Hinge Distance to cupboard door (A) 1. When closed, the cupboard door (A) must not lie against the rest of the surrounding cupboard area (distance 1-2mm). 2. There must be a distance of 6-8mm between the cupboard door and the miniBar.

  • Page 8: Changing The Doorhang

    4.10 Changing the Doorhang...

  • Page 9: Instruction For Use

    Changing the printed board with LEDs: 3. Remove defective 1. Pull out the 2. Remove the reflector LED-board. mains plug disk. 4. Insert new LED-board 5. Clip reflector disk back in To obtain spare bulbs, please contact your Dometic Service Centre.

  • Page 10: Check List

    Check List Failure : No cooling (the aggregate at the back of the device is cold). Possible Cause Self Help Authorised Service a.) The thermostat is set to “0”. a.) Set temperature control to middle position. b.) The device plug is not b.) Plug in device plug.

  • Page 11: Environmental Advice

    Environmental Advice miniBars manufactured by Dometic GmbH are free from CFCs / HCFCs and fluorinated hydrocarbons. The cooling unit uses R134a as the coolant Cyclopentane, which does not damage the ozone layer, is used as propellant for the insulation made from PU-foam.
  • Page 12 Dometic GmbH In der Steinwiese 16 D-57074 Siegen GERMANY Tel.: +49-(0) 271 / 692 0 Fax: +49-(0) 271 / 692 300 www.dometic.de/minibar www.dometic.com...
