Front Panel (cont.)

9. Mic Input

Plug in a balanced microphone into this XLR input for vocal or for your instru-
ment. The Loudbox Mini Charge makes an excellent mini PA or vocal monitor.
You may also connect an outboard preamp with balanced XLR out to this input.
10. Gain
Use the Gain knob to set the signal level for the Microphone input.
11. Low
Boost here to add weight to the sound. In general, boost bass at low volumes
and cut bass at higher levels. With the dial set at 12 o'clock, the control is effec-
tively out of the circuit.
12. High
Boost highs to add "air" to the sound of the microphone. With the knob set at
12 o'clock, the control is effectively out of the circuit.
13. Reverb
Controls the amount of digital reverb in the Microphone channel.

14. Master Volume

Set the overall level of the Loudbox Mini Charge with the Master Volume. In
general, put the Master Volume as high as possible using less Gain (2 o'clock to
5 o'clock) to achieve the cleanest sound.
15. Power
Lights up when the amplifi er power is on. The Power switch is located behind
the amp next to the power cord socket.
Gain
Mic
9 10
pairing
Low High Reverb
11 12
battery
low battery
charging
Master
power
13 14 15
