MICROSD CARD INFORMATION

The TRIO+ autosaves your work onto the microSD card so you don't need to worry about remembering to save
parts and songs. To ensure that you don't unexpectedly lose data, always stop the TRIO+ playback and wait at
least 5 seconds without making changes to your songs before ejecting the microSD card or removing power to
the pedal.

Supported microSD Cards

The TRIO+ supports microSD cards that meet the following specifications:
• microSDHC
• 8 GB–32 GB
• Class 10

What's Stored To The microSD Card

The microSD card stores the following information:
• Recorded Loops
• Song Info
• User Preferences (including FS3X footswitch configuration)
See 'Specifications' on page 58 for information on the maximum loop recording time.

Changing The microSD Card

To change the microSD card:
1. If any changes have been made to a part or song, wait at least 5 seconds before removing the card.
2. Press the card in with your thumb then slowly release. The card will partially eject and all 5 PART buttons
will flash amber, indicating that the TRIO+ does not have a valid microSD card inserted.
3.
Grasp the card with your fingers and pull it out, noting the orientation of the card.
4.
Insert the replacement card using the same orientation noted in the previous step. Press the card all the
way in then release. The card will lock into place and the 5 PART buttons will flash amber sequentially for
about 5 seconds, then the card will be ready for use. When a valid card is detected, the STYLE LEDs will
circle green and the last active song used for that card will be loaded.
NOTE: If an SD card is not detected by the TRIO+, all PART buttons will flash amber. If an incompatible SD
card is inserted or if there is an error when reading the card, all PART buttons will flash red.
WARNING! When a microSD card is inserted into the TRIO+ for the first time, it will be formatted for the
TRIO+ and overwritten. Any existing data on the microSD card will be lost.

Accessing The microSD Card

The song and loop data on the microSD card is stored in a highly optimized format that is not directly accessible
from a computer and must be accessed using the TRIO Manager software. See 'TRIO Manager Software/
Firmware Updates' on page 57 for more information.
