2-30. LVDS CONNECTOR

LVDS1 : LVDS Connector.
The pin assignments are as follows:
PIN
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
PSB-701LF USER
ASSIGNMENT
LVDS_VCC
CLKBM
GND
YBP2
YBM1
YBP3
YBP0
GND
CLKAM
YAP2
GND
YAM1
YAP0
YAP3
LVDS_VCC
'
S MANUAL
Chapter 2 Hardware Configuration
PIN ASSIGNMENT
2 GND
4 CLKBP
6 YBM2
8 GND
10 YBP1
12 YBM3
14 YBM0
16 CLKAP
18 GND
20 YAM2
22 YAP1
24 GND
26 YAM0
28 YAM3
30 LVDS_VCC
