2-8. EXTERNAL KEYBOARD CONNECTOR

EXKB1 : External Keyboard Connector
The pin assignment is as follows :
PIN
1
2
3
4
5

2-9. RESET CONNECTOR

JP7 (5, 7) : Reset Connector.
The pin assignment is as follows :
PIN
5
7

2-10. HARD DISK DRIVE LED CONNECTOR

JP7 (1, 3) : Hard Disk Drive LED Connector
The pin assignment is as follows :
PIN
1
3
'
PSB-701LF USER
ASSIGNMENT
5VSB
GND
NC
KBDATA
KBCLK
ASSIGNMENT
GND
RST_BTN
ASSIGNMENT
HD_LED+
HD_LED-
S MANUAL
Chapter 2 Hardware Configuration
Page: 2-9
