Catalog Number: 10-MAT-152
BioTector B7000 Online TOC TN Analyzer
USER MANUAL
March 2017, Edition 1
BS4ANP2 2.12d
Original Instructions in English
© Copyright BioTector 2017. All rights reserved. Printed by BioTector. Printed in the Republic of Ireland.

Advertisement

Table of Contents
loading

Related Manuals for Hach BioTector B7000

Summary of Contents for Hach BioTector B7000

  • Page 1 Catalog Number: 10-MAT-152 BioTector B7000 Online TOC TN Analyzer USER MANUAL March 2017, Edition 1 BS4ANP2 2.12d Original Instructions in English © Copyright BioTector 2017. All rights reserved. Printed by BioTector. Printed in the Republic of Ireland.

  • Page 2: Table Of Contents

    Table of Contents SECTION 1 SAFETY PRECAUTIONS ................5 ............5 NFORMATION AND AFETY IGNS USED IN THE ANUAL ............ 6 RECAUTIONARY ABELS TTACHED TO THE NSTRUMENT ................8 OTENTIAL YSTEM AFETY AZARDS ..................10 ENERAL AFETY RECAUTIONS ................10 RÉCAUTIONS GÉNÉRALES DE SÉCURITÉ...
  • Page 3 5.3.2 Reagent Connections ........................60 ..............62 AMPLE RAIN AND XHAUST ONNECTIONS 5.4.1 Sample Inlet Tube Position ......................62 5.4.2 Drain, Bypass and Exhaust Connections ..................64 SECTION 6 REAGENTS AND CALIBRATION STANDARDS........65 ........................65 EAGENTS ....................66 ALIBRATION TANDARDS SECTION 7 ANALYZER COMMISSIONING AND STARTUP ........
  • Page 4 CO2 Analyzer ..............................135 Cooler Program ..............................135 Software Update ..............................136 Password ................................137 Language ................................137 Hardware Configuration ............................137 SECTION 9 TROUBLESHOOTING OF SYSTEM FAULTS & WARNINGS ....138 ..................138 ECTOR AULT ONDITIONS ................. 141 ECTOR ARNING ONDITIONS ................

  • Page 5: Safety Precautions

    Section 1 Safety Precautions Please read this manual before unpacking, setting up, or operating the BioTector. BioTector should only be used by qualified trained staff and for the purpose it is intended for. Do not use or install this equipment in any way other than the methods specified in this manual. The procedures and methods described in this manual are based on assuming the user have basic, fundamental background on electronics, chemistry and analyzer equipment.

  • Page 6: Precautionary Labels Attached To The Instrument

    Precautionary Labels Attached to the Instrument The labels and tags attached to the instrument are summarized below. Please read all labels and tags attached to the instrument. If not observed, personal injury or damage to the instrument could occur. This symbol, when displayed on the instrument, indicates that the user must gather the necessary operation and/or safety information given in the instruction manual.
  • Page 7 Electrical equipment marked with this symbol may not be disposed of in European domestic or public disposal systems. Return old or end-of-life equipment to the manufacturer for disposal at no charge to the user. Page 7...

  • Page 8: Potential System Safety Hazards

    Potential System Safety Hazards The potential safety hazards, which are associated with a running BioTector system, are as follows:  Electrical hazards  Potentially hazardous chemicals  Oxygen gas and components generating Ozone gas Maintenance and operation should not be carried out unless personnel have been fully trained in the operation of the BioTector.
  • Page 9 Ozone and Toxicity Ozone is found in gaseous form as a natural ingredient of the earth's atmosphere. Some of the chemical and physical properties of ozone are as follows: Terms Properties of Ozone (O Molecule Weight 47.9982 g/g-mol -119  0.3 °C Boiling Point -192.7 ...

  • Page 10: General Safety Precautions

    General Safety Precautions Please pay attention to all caution, warning and danger statements at all times. Non-observance of the safety instructions can result in serious personal injury, death or damage to the equipment. Therefore observe the following:  Only engineers trained by the manufacturer should carry out maintenance on the BioTector. ...

  • Page 11: Electrical And Burn Precautions

    1.4.1 Electrical and Burn Precautions BioTector contains electrical components operating under high voltages. Contact may result in electric shock and severe or fatal injury. DANGER During system installation, maintenance or servicing:  Isolate the system power lines before starting any work in the electronic enclosure. ...

  • Page 12: Carrier Gas And Exhaust Gas Precautions

    1.4.2 Carrier Gas and Exhaust Gas Precautions BioTector uses oxygen (O ) gas as the carrier gas during its operation. The oxygen gas must be free of carbon dioxide (CO ) and nitrogen (N ) gases. The average rate of oxygen consumption in BioTector is 22 L/hour (367 ml/min).

  • Page 13: Chemical Precautions

    1.4.3 Chemical Precautions A number of chemicals and compounds to be used with BioTector are listed in Section 6 Reagents and Calibration Standards. Some of these compounds are harmful, corrosive, acidic and oxidizing. Appropriate precautions must be taken when handling these chemicals or solutions prepared from these chemicals. Physical contact with these chemicals and inhalation of any vapors must be minimized using appropriate safety equipment.

  • Page 14: Sample Stream Precautions

    1.4.4 Sample Stream Precautions The user is responsible to establish the potential hazard associated with each sample stream. Necessary precautions must be taken, to avoid physical contact with any harmful sample stream, which may contain chemical or biological hazards. System components and their composition, which come in contact with the sample liquid and possible volatile gases from the sample, are tabulated in table 1 below.

  • Page 15: Précautions Relatives Aux Échantillons

    1.4.4 Précautions relatives aux échantillons L’usager assume la responsabilité d’établir le danger possible que représente chaque échantillon. Il est essentiel de prendre les précautions voulues afin d’éviter le contact physique avec tout échantillon nocif qui pourrait présenter un danger chimique ou biologique. Le tableau 1 ci-dessous présente les composants de l’analyseur (et leur composition) qui entrent en contact avec l’échantillon liquide et les éventuels gaz volatiles émanant de l’échantillon.

  • Page 16: Operator's Manual

    Operator’s Manual Section 2 Membrane Keypad The BioTector is equipped with a built-in microprocessor, which has been programmed to enable the user to control the instrument using just six buttons of its membrane keypad. By pressing the appropriate button, the user can move through the various levels of the software menu.

  • Page 17: Software Menu Diagram

    Software Menu Diagram Page 17...
  • Page 18 Startup State When the BioTector is powered up, its LCD screen will automatically display the Reaction Data screen after a delay of 60 seconds. By pressing the ESCAPE key the user moves from the Reaction Data screen to the Reaction Graph screen. Pressing the ENTER key on the Reaction Graph screens brings the user back to the Reaction Data screen.
  • Page 19 Reaction Data B I O T E C T O R R U N N I N G 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 0 9 : 2 7 : 0 2 1 2 - 0 9 - 0 2 R E A C T I O N S T A R T...
  • Page 20 B I O T E C T O R R U N N I N G 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 0 9 : 2 7 : 0 2 1 2 - 0 9 - 0 2 R E A C T I O N S T A R T...
  • Page 21 Reagent Status B I O T E C T O R R U N N I N G 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 A C I D M O N I T O R 2 5 .
  • Page 22 Enter Password 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 E N T E R P A S S W O R D F O R O P E R A T I O N S E C U R I T Y D O M A I N 1 2 3 4...

  • Page 23: Operation Menu

    Operation Menu Operation Menu Diagram Operation menu allows the user to start and stop the analyzer. Menus related to system operation are also accessed using this menu. Start Stop The user can Start or Stop the BioTector using the Start Stop menu. 1.
  • Page 24 2. Start. This function starts the BioTector. When BioTector is started, the multi-stream operation sequence (if programmed) is reset. BioTector performs Ozone Purge, Pressure/Flow Test, Reactor Purge and Analyzer Purge sequences automatically before starting its analysis. Ozone Purge sequence purges any residual ozone through the ozone destructor.

  • Page 25: Reagents Setup

    Reagents Setup This menu allows the user to access the Reagent menus. 1. Install New Reagents. Menu used to install and prime the reagents in the BioTector. Any “85_Reagents Low” and “20_No Reagents” warnings and notifications can also be reset in this menu. 2.

  • Page 26: Purge Reagents & Zero

    To run the Install New Reagents cycle, the BioTector must be stopped. Confirm that all or the corresponding new reagents have been installed on the BioTector, for instance for acid reagent, select New Acid Connected, and press the ENTER key. A tick mark will appear as confirmation that the new acid has been connected. Note that when one or more reagent volumes are updated in Reagents Monitor menu, system automatically resets the new reagents volumes in this menu and also updates the figures displayed in the main Reagents Status screen.

  • Page 27: Manual Program

    Manual Program M A N U A L P R O G R A M 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < R U N A F T E R N E X T R E A C T I O N R U N...

  • Page 28: Reaction Archive

    Reaction Archive The Reaction Archive holds information on TIC, TOC, TC, VOC, COD, BOD, TN, stream valve, reaction range, start time and related analysis information for the last 9999 reactions. If the archive is full, then every new reaction overwrites the oldest one in the archive. As the Reaction Archive contains 9999 events, the user must first enter the date at which the viewing of the archive starts.

  • Page 29: Time & Date

    Time & Date This menu allows the system time and date to be set by the user. To change the system time or date (hours, minutes, seconds, day, month and year), press the ENTER key, enter the new time and date and press the ENTER key again.

  • Page 30: Calibration Menu

    Calibration Menu Calibration menu allows the user to calibrate the analyzer. Zero and Span Calibration menus allow the user to run the zero and span calibration cycles for a single range or for all system ranges available. Calibration Menu Diagram ENTER PASSWORD CALIBRATION ZERO CALIBRATION...
  • Page 31 13. Run Reagents Purge. The RUN REAGENTS PURGE function is used to prime all reagents in the BioTector. If necessary, the pump operation time for Reagent Purge cycle can be increased in the Reagents Purge menu. 14. Run Zero Calibration. Each time BioTector reagents are replaced or topped up and each time a service is carried out, it is strongly recommended to use the RUN ZERO CALIBRATION function so that the system can set the zero offset values automatically.

  • Page 32: Span Calibration

    Span Calibration S P A N C A L I B R A T I O N 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < T I C S P A N A D J U S T 1 .
  • Page 33 16. Run Span Calibration. This function starts the Span Calibration cycle. The span calibration reactions are run at a single range programmed by the RANGE in this menu below. At the end of the span calibration cycle, BioTector automatically calculates the Span Adjust factors and displays it for Span Adjusts above. Unless it is manually modified, the same Span Adjust factor calculated for the programmed RANGE in this menu is used for the other two ranges as well.

  • Page 34: Technical Specifications

    Section 3 Technical Specifications TYPICAL TECHNICAL DATA Enclosure: Fiberglass Reinforced Polyester Dimensions (HxWxD): 1250mm x 750mm x 320mm Enclosure height may increase to 1750mm, depending on system optional features. 90 kg – 120 kg Weight: Enclosure weight may change depending on system optional features. Power Consumption: 300 W (VA) Mains Connection:...
  • Page 35 OPTIONAL FEATURES Result Output: TIC, TC, VOC, TN, after correlation COD, BOD Remote Control: Input for remote start / standby Input for remote stream and range selection Input for remote manual grab sample analysis Network Control Unit for remote access over Internet or Intranet connection using HTTP over TCP/IP protocol Industrial Interface: Modbus, Profibus, Ethernet...
  • Page 36 MONITORING RANGES: TOC / TN Standard Range 0-10mg/l up to 0-20,000mg/l Ultra High Range 0-10mg/l up to 0-40,000mg/l Up to 3 ranges configurable for each component within each range band detailed above. A wide combination of TOC and TN monitoring ranges, including higher ranges, are available on request.

  • Page 37: Introduction

    Section 4 Introduction BioTector Major Components 4.1.1 Analysis Enclosure Figure 1 and table 2 below shows the major analysis enclosure components of BioTector TOC TN Analyzer. Figure 1 BioTector analysis enclosure major components Page 37...
  • Page 38 Table 2 BioTector analysis enclosure major components Cooler Ozone Generator Exhaust Valve, MV1 Injection Valve, MV7 Purge Valve, MV51 Non-return Valve (Check Valve) Mass Flow Controller Ozone Destructor Oxygen Regulator Sample Valve (ARS Valve), MV4 Dual Cell Photometer Module (DCP Module) NDIR CO Analyzer Oxidized Sample Catch-pot/Cleaning Vessel...

  • Page 39: Electronics Enclosure

    4.1.2 Electronics Enclosure Figure 2 and table 3 below shows the major electronics enclosure components of BioTector TOC TN Analyzer. Figure 2 BioTector electronics enclosure major components Table 3 BioTector electronics enclosure major components Mains Terminals Power Supply (for Main Board/Motherboard) Power Supply (for Pumps and Valves) Power PCB (Mains PCB) Main Power Switch...
  • Page 40 Figure 3 and table 4 below shows the BioTector main board (motherboard) components. Figure 3 BioTector main board components Table 4 BioTector main board components Main Board (Motherboard) Processor PCB MMC/SD Flash Memory Card Slot Battery (Varta, CR2430, Lithium, 3V, 285mAh) Hazardous area analyzers may have a special battery.

  • Page 41: Biotector Operation

    BioTector Operation The BioTector is designed to provide continuous online single-component (e.g. TOC) or multi-component (e.g. TOC & TN & TP) monitoring. The BioTector can operate with unfiltered samples including soft particulates up to 2 mm in diameter, and will give accurate measurements even when fats, high levels of salts and/or calcium is present in the sample.

  • Page 42: Biotector Sample Injection

    4.2.2 BioTector Sample Injection The BioTector analyzes a precise volume of liquid. The Sample Pump injects a pre-programmed number of pulses (half revolutions of pump) of liquid into the reactor for each measurement and therefore the volume of liquid included in each pulse is consistent irrespective of sample source pressure. Sample is initially drawn from the source by a peristaltic Sample Pump.
  • Page 43 Figure 4 BioTector TOC TN Analyzer oxidation phase analysis layout Page 43...

  • Page 44: Tic & Toc Analysis

    4.2.3.1 TIC & TOC Analysis 1. An unfiltered sample is injected into the BioTector reaction chamber (reactor). 2. An acid reagent is added and the oxygen carrier gas flow is activated to remove the inorganic carbon. The carbon dioxide gas is sparged by the addition of the acid reagent and is carried by the oxygen carrier gas and measured with a nondispersive infrared (NDIR) CO analyzer.

  • Page 45: Voc Analysis

    BioTector analysis types are optional features. In order to be able to utilize TC analysis type in BioTector, the system must be built with this option. For instance, a system built with TIC & TOC analysis option only cannot be used for TC analysis type. For TC analysis to be possible in a TIC &...

  • Page 46: Tc - Tic Analysis

    4.2.3.4 TC - TIC Analysis BioTector TC - TIC analysis type is a combination of TC analysis and TIC analysis, which are run simultaneously with two separate sample injections, in two different reactors (TC reactor and TIC reactor). 1. The oxygen carrier gas flow and the ozone generator are activated. Base reagent is injected into the reactor and hydroxyl radicals are generated by exposing the base reagent to ozone.

  • Page 47: Tn Analysis

    4.2.3.5 TN Analysis In BioTector, the Total Nitrogen (TN) analysis does not require an additional oxidation cycle because BioTector’s oxidation process breaks down all bound, organic and free nitrogen compounds present in the sample into Nitrate (NO ), which exists as an ion in the oxidized sample liquid in the BioTector reactor. 1.
  • Page 48 Figure 5 BioTector TOC TN Analyzer liquid phase analysis layout Figure 6 BioTector TN Dual Cell Photometer Module Page 48...

  • Page 49: Installation

    Section 5 Installation Basic System Requirements Power and Signal Requirements  Mains Connection: 115V AC, 60Hz or 230V AC, 50Hz (10%)  Mains Wire Specification: Number of Cores = 3 Current Rating minimum = 10 Amps CSA (Cross Sectional Area minimum) = 1.50mm ...

  • Page 50: Unpacking And Installation

    Unpacking and Installation The BioTector analyzer weighs more than 100kg (220lb). Therefore, appropriate precautions are required for unpacking and installing the BioTector. Caution The BioTector analyzer is shipped ready to be installed, with a kit of parts including sample tubes, reagent tubes and a selection of spare parts, spare fuses and ferrules.

  • Page 51: Analyzer Dimensions And Mounting

    5.2.1 Analyzer Dimensions and Mounting The BioTector TOC TN analyzer enclosure is a dual compartment Fiberglass Reinforced Polyester (FRP) cabinet. This enclosure facilitates easy access to all components and thus eases the service and maintenance procedures. Figure 7 and table 5 below gives the dimensions of various BioTector enclosures. Figure 7 BioTector Dimensions Page 51...
  • Page 52 Table 5 Various BioTector Dimensions Dimension A Dimension B Dimension C Dimension D BioTector TOC TN Analyzer 500mm 750mm 1025mm 1250mm BioTector TOC TN Analyzer with integral oxygen 750mm 750mm 1150mm 1500mm concentrator BioTector TOC TN Analyzer with extended lower 500mm 1000mm 1275mm...

  • Page 53: Wiring Power And Signal Terminals

    5.2.2 Wiring Power and Signal Terminals BioTector contains electrical components operating under high voltages. Contact may result in electric shock and severe or fatal injury. DANGER Figures 9 and 10 below show the typical mains connections for both 230 and 115 volts systems respectively and the 4-20mA signal connections in BioTector.
  • Page 54 All electrical, sample, reagent, drain and exhaust connections should be carried out in accordance with the technical specifications and drawings given in this manual. Errors as a result of non-conformity to these specifications will not be covered by the warranty. Figure 10 Mains and 4-20mA terminal diagram for 115 V systems The wiring and earth connections to the analyzer should be carried out in accordance with local regulations, and securely terminated in the phase, neutral and earth terminals in the BioTector.

  • Page 55: Wiring External Power Disconnection Switch

    5.2.3 Wiring External Power Disconnection Switch The mains power must be connected through an external 2-pole disconnection switch, so that the power to the analyzer can be isolated without opening the electronics enclosure.  The external power disconnection switch must be located in an easily accessible location, with a maximum distance of 2 meters from the analyzer.

  • Page 56: System Fuse Specifications

    5.2.4 System Fuse Specifications Table 6 below summarizes the location and specification of the fuses used in BioTector. The locations of the fuses are also displayed in figures 9 and 10 above. BioTector contains electrical components operating under high voltages. Contact may result in electric shock and severe or fatal injury.

  • Page 57: Carrier Gas And Reagent Connections

    Carrier Gas and Reagent Connections The orientation of the ferrules inside each fitting of BioTector is critical for the correct operation of the system. Incorrect ferrule orientation may create gas/liquid leak and/or introduce air bubbles into the system lines. Therefore, the ferrules on all carrier gas, reagents, drain, exhaust and vent fittings have to be fitted with the correct orientation.

  • Page 58: Carrier Gas Connection

    5.3.1 Carrier Gas Connection The recommended carrier gas for BioTector is Oxygen (O ), free of Carbon dioxide (CO ), Carbon monoxide (CO), Nitrogen (N ), Hydrocarbons and Water. In BioTector TOC TN analyzers, the carrier gas has to be Nitrogen free Oxygen gas.
  • Page 59 Figure 13 BioTector oxygen supply options Page 59...

  • Page 60: Reagent Connections

    5.3.2 Reagent Connections Special precautions are needed when working with chemical reagents, both when renewing reagents and when dealing with leaks or spills. Some reagents can cause chemical burns and may cause injury or death if swallowed. Please refer to the symbols and codes on the reagent containers. DANGER Use of 25 liter containers is recommended for each BioTector reagents.
  • Page 61 As can be seen in the figure 14 above, unlike all other reagents, base reagent container does not contain any vent (breathing) hole. The breathing air into the base container is supplied through the CO filter, which must be fitted on the base container lid. Figure 15 below shows the detailed connections on BioTector base reagent.

  • Page 62: Sample, Drain And Exhaust Connections

    Sample, Drain and Exhaust Connections 5.4.1 Sample Inlet Tube Position For the fittings to remain leak proof, they must be kept clean and should not be over tightened. Over tightening of the fittings will damage them and cause eventual leakage. Caution BioTector operates on unfiltered samples, the setup of the sampling point is important for the correct operation of the system.
  • Page 63 Page 63...

  • Page 64: Drain, Bypass And Exhaust Connections

    5.4.2 Drain, Bypass and Exhaust Connections The BioTector should be installed in a well-ventilated area with the exhaust port piped to an external vent. The installation should be carried out in accordance with Section 1 Safety Precautions. WARNING All BioTector drain tubing must be positioned correctly so that any liquid pumped will drip freely into a larger drain chamber.

  • Page 65: Reagents And Calibration Standards

    Section 6 Reagents and Calibration Standards Reagents BioTector TOC TN analyzer uses following reagents: I. Acid: 1.8 N Sulfuric Acid (H ) Reagent containing 40mg/l Manganese Sulfate Monohydrate II. Base: 1.2 N Sodium Hydroxide (NaOH) Reagent III. TN Cleaning: 0.5 N HCl and 0.042 M Sodium Oxalate (NaOx) mixture solution IV.

  • Page 66: Calibration Standards

    Calibration Standards All hygroscopic chemicals in crystal form should be dried in an oven set at 105°C for 3 hours to remove any traces of absorbed water. All prepared solutions must be mixed thoroughly with a magnetic stirrer or inverted manually at least ten times or until all crystals are completely dissolved inside the solution.
  • Page 67 The calculation of the quantities required to prepare Potassium Hydrogen Phthalate (KHP) standard solutions with various purities are given as an example below: Name: Potassium Hydrogen Phthalate Formula: Carbon, 12 Oxygen, 16 Potassium, 39 x 1 Hydrogen, 1 5____________ Total weight 204.22 g/mol 47% of KHP is Carbon.
  • Page 68 Preparation of Calibration Standard Solutions: Use eye protection and gloves. Standards solutions greater than 1000mg/l can be prepared directly without any dilution by simply mixing the necessary quantity solvent or salt with deionised water. Standard solutions below 1000mg/l concentration should be prepared by dilution technique. First a 1000mg/l standard stock solution should be prepared, and then the required lower concentration standard solution should be prepared by applying the necessary dilution procedures: ...

  • Page 69: Analyzer Commissioning And Startup

    Section 7 Analyzer Commissioning and Startup The check list below must be used to ensure that the installation has been properly carried out. Please proceed through the check list in the given order. If the BioTector analyzer is certified for hazardous areas, carefully read the hazardous area documentation supplied with the analyzer.
  • Page 70 If a SAMPLER has been supplied with the system, connect the sampler in accordance with _____ the drawings and instructions in the sampler manual. Connect the PVC-U Drain Pipe (installed outside the BioTector) to a well ventilated pressure _____ free drain using the supplied 1” braided hose. Confirm the SAMPLE OUT port is connected to the PVC-U Drain Pipe.
  • Page 71 Connect Deionised Water to the BioTector’s ZERO WATER port using ¼” PFA tube. The BioTector TOC TN analyzers require Zero Water to adjust the zero offset during the zero calibration cycle. This is different than the BioTector TOC analyzers, where only acid and base reagents are required.
  • Page 72 Confirm the HCl Water Pump (if fitted for FMI Circulation Pump) is pumping correctly. The _____ pump rate should be between 8.5ml and 11.5ml in ~18 seconds. Confirm the WMM60 Sample Pump is pumping correctly. The pump rate at 16 pulses should _____ be between 5.5ml and 7.5ml in ~8 seconds.
  • Page 73 Using the Commissioning menus, follow below procedures: In Reaction Time menu, program the INTERVAL time depending on the required sample _____ analysis frequency. In Sample Pump menu, confirm that the Sample Pump FORWARD and REVERSE times are correct. In order to test the Sample Pump forward and reverse times, go to Process Test, Sample Pump Test menu and select the PUMP FORWARD TEST and PUMP REVERSE TEST.
  • Page 74 Download BioTector “All Data” in text format into the MMC/SD card or into a PC/Laptop using the SEND ALL DATA function in Data Output menu to record all changes made in the system _____ configuration. Go to Start Stop menu and start the BioTector. When the BioTector is running online, _____ carefully observe the first two or three reactions and confirm that the CO peaks are correct.

  • Page 75: System Software Operation

    Section 8 System Software Operation Operation Menu Operation menus are covered in Section 2 Operator’s Manual. Calibration Menu Calibration menus are covered in Section 2 Operator’s Manual. Maintenance Menu Maintenance Menu Diagram MAINTENANCE ENTER PASSWORD DIAGNOSTICS PROCESS TEST PRESSURE TEST FLOW TEST OZONE TEST SAMPLE PUMP TEST...

  • Page 76: Diagnostics Menu

    8.3.1 DIAGNOSTICS MENU This menu allows the user to access the Process Test, Simulate, Data Output, Input/Output Status and Service menus for diagnostic purposes. Diagnostics Menu Diagram ENTER PASSWORD DIAGNOSTICS PROCESS TEST PRESSURE TEST FLOW TEST OZONE TEST SAMPLE PUMP TEST pH TEST PURGE TN CELL TEST CLEAN TN CELL TEST...

  • Page 77: Process Test

    Process Test This menu allows the user to simulate the: Oxidation Phase Process Tests, which are Pressure Test, Flow Test, Ozone Test, Sample Pump Test and pH Test routines. Liquid Phase Process Tests, which are Purge TN Cell Test, Clean TN Cell Test, Read DI Water Reference Test and Read TN Sample Test.

  • Page 78: Flow Test

    Flow Test F L O W T E S T 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < * E X H A U S T T E S T E X H A U S T F L O W S A M P L E...

  • Page 79: Ozone Test

    Ozone Test The ozone test uses the procedure described in information sheet “T006, Procedure to check the ozone level”. The user must read and understand the processes described in this sheet, and have all the correct parts listed before carrying out the test. WARNING General overview of the operation of the ozone test: Phase 1:...
  • Page 80 Ozone Test, Phase 3: O Z O N E T E S T 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 * S T A R T T E S T 2 < S T O P T E S T T I M E...

  • Page 81: Sample Pump Test

    Sample Pump Test S A M P L E P U M P 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 V A L V E S T R E A M 2 <...

  • Page 82: Ph Test

    pH Test The user must understand the procedure for testing the pH in the BioTector. Use eye protection and gloves. Have all the relevant parts for this test ready (primarily beaker and pH paper) before carrying out the test. WARNING For the pH test to be accurate, the previous reaction should have finished normally, so that any liquid carried over from that reaction will not affect the pH test.
  • Page 83 3. Start Test. This starts the ph test routine, which goes through the 6 phases described above. 4. Take Sample. Not applicable until the test is running. 5. Continue to next phase. Not applicable until the test is running. 6. Stop Test. When the test is running, activating this control will stop the test. Note that some phases have to be completed before the stop can be used.
  • Page 84 pH Test, Phase 3: T E S T 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < R A N G E , V A L V E S T R E A M M O D E T I C + T O C S T A R T...
  • Page 85 pH Test, Phase 5: T E S T 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < R A N G E , V A L V E S T R E A M M O D E T I C + T O C S T A R T...

  • Page 86: Liquid Phase Process Test

    Liquid Phase Process Test Purge TN Cell Test P U R G E C E L L T E S T 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < * S T A R T T E S T S T O P T E S T...

  • Page 87: Read Di Water Reference Test

    Read DI Water Reference Test R E A D D I W R E F T E S T 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < * S T A R T T E S T S T O P T E S T...

  • Page 88: Read Tn Sample Test

    Read TN Sample Test R E A D S M P L T E S T 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < * S T A R T T E S T S T O P T E S T...

  • Page 89: Simulate

    Simulate Oxidation Phase Simulate O X I D A T I O N P H A S E S I M 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 M F C = 1 0 .
  • Page 90 Each time a component is activated, the BioTector will interlock additional devices to ensure that the component being tested can be checked in a manner that will not cause consequential damage to the overall system. It is recommended that each test is evaluated carefully, for although the interlocks are extensive, it may still be possible to damage the system.
  • Page 91 7. Sample Valve. Use this function to test the Sample (ARS) Valve. The valve has three positions, SEN1 (Sample Pump to Bypass), SEN2 (Sample Pump to Reactor), and SEN3 (TIC Acid/TC Base to Reactor). To position the valve in different positions, press the ENTER key, select the required position, and press ENTER again.
  • Page 92 17. Manual Valves (if configured in the system). Use this function to test the Manual Valves. To test a Manual Valve, press the ENTER key and select the number of the valve to be tested. Press the ENTER key again and the valve will be activated. To turn the valve off, select OFF. Note that only one Manual Valve can be switched on at any given time.

  • Page 93: Liquid Phase Simulate

    Liquid Phase Simulate L I Q U I D P H A S E S I M 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 N I T R O G E N : S / R R A T I O 1 .
  • Page 94 The menu status lines, which are the lines below the time and date, show the following information: S/R RATIO - Signal and reference Ratio - Actual reading of signal intensity - Actual reading of reference intensity The intensity and ratio readings for Nitrogen only update when system is running and when the detectors in the Dual Cell Photometer are used.

  • Page 95: Signal Simulate

    Signal Simulate S I G N A L S I M U L A T E 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 C O M M O N F A U L T O F F 2 <...
  • Page 96 10. - 15. Stm Alarm 1-6 (if configured in the system). This allows the user to test the function of the Stream Alarms if they are programmed in Output Devices menu. To change the state of the device, press the ENTER key, set the device to ON/OFF, and press the ENTER key again.

  • Page 97: Data Output

    Data Output D A T A O U T P U T 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < O U T P U T D E V I C E M M C / S D C A R D S E N D...

  • Page 98: Send Reaction Archive

    Send Reaction Archive S E N D R E A C T I O N A R C H I V E 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < S T A R T D A T E 0 1 - 0 9 - 0 2...

  • Page 99: Standard Mode

    The meaning of the abbreviations used in the downloaded reaction data in both standard and engineering modes (see Print Mode in Data Program, Printer, PC, MMC/SD Card menus) are as follows: Standard Mode: TIC & TOC Analysis: TIME The time the reaction started. DATE The date the reaction started.
  • Page 100 Engineering mode (TIC & TOC analysis): TIME The time the reaction started. DATE The date the reaction started. S1:2 Reaction type and range. CO2z analyzer zero adjust for the current reaction. TICmgu The un-calibrated TIC value in mgC/l. TICmgc The calibrated TIC value in mgC/l. CO2p The height of the TIC CO peak.

  • Page 101: Send Fault Archive

    Send Fault Archive This menu is used to download the fault archive. The communication port parameters used are those set up in the Data Program menu. All items in the fault archive will be downloaded unless the user interrupts the downloading with the Pause Sending or Stop Sending functions.

  • Page 102: Input/Output Status

    Input/Output Status Input/Output Status menu is used for monitoring the analog and digital inputs and outputs. Digital Input The Digital Input menu allows the engineer to monitor the system digital inputs. This feature is useful for the system trouble-shooting or diagnostics. On the screen the digital inputs are organized in columns and rows with their code, logical states and function.

  • Page 103: Service

    Service S E R V I C E 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 < R E A C T I O N C O U N T E R 5 2 3 8 S E R V I C E R E Q U I R E D...

  • Page 104: Commissioning Menu

    8.3.2 COMMISSIONING MENU The Commissioning menus are used during the commissioning and startup of the analyzer. The functions in the menus are used to program system site specific settings. Commissioning Menu Diagram ENTER PASSWORD COMMISSIONING REACTION TIME SAMPLE PUMP STREAM PROGRAM COD / BOD PROGRAM NEW REAGENTS PROGRAM REAGENTS MONITOR...

  • Page 105: Sample Pump

    Sample Pump SAMPLER FORWARD REVERSE  BioTector Sample Pump runs forward for the FORWARD time to STREAM 1 100s bring a fresh sample from the STREAM, MANUAL and/or STREAM 2 100s CALIBRATION points to the Sample (ARS) Valve. This time STREAM 3 should be long enough to guarantee a fresh sample is injected ……………………...

  • Page 106: Cod/Bod Program

    STREAM 1 , 2 RANGE  If the CONTROL is programmed as BIOTECTOR, the multi- STREAM 2 , 1 RANGE stream valve sequence operates according to the STREAM and STREAM 3 , 4 RANGE RANGE settings defined in this menu. STREAM - , - RANGE...

  • Page 107: New Reagents Program

    New Reagents Program SPAN CALIBRATION  SPAN CALIBRATION (NO by default) defines if the Span Calibration reactions are part of the Install New Reagents procedure in Reagents Setup menu.  If SPAN CALIBRATION is activated (YES), the standard solution needs to be connected to the Calibration/Manual port of the BioTector as part of the Install New Reagents procedure.

  • Page 108: Autocal Program

    ACID VOLUME 25.0l ~ 35DAYS  ACID VOLUME allows the user to enter the volume of the acid reagent. When the volume is programmed, system automatically calculates the number of days acid reagent will last.  It is strongly recommended that each time acid and base reagents are replaced or topped up, a Zero Calibration cycle is activated using the Start New Reagent Cycle function in Install New Reagents menu or alternatively using the Run Zero...

  • Page 109: 4-20Ma Program

    4-20mA Program OUTPUT MODE DIRECT  OUTPUT MODE specifies the 4-20mA outputs operation. This parameter is programmed as: DIRECT (direct mode by default), STREAM MUX (stream multiplex mode) or FULL MUX (full multiplex mode).  In DIRECT mode, each 4-20mA output channel is dedicated to a specific stream and result type.
  • Page 110 SIGNAL UPDATE  SIGNAL UPDATE, which is deactivated with the “NO” setting by default, defines whether the programmed 4-20mA signal channels are going to signal the update of the 4-20mA signals or not before a new 4-20mA signal is sent. ...

  • Page 111: Relay Program

    Relay Program COMMON FAULT STOP/FAULT  In COMMON FAULT N/E STOP/FAULT setting, N/E (Normally Energized by default) defines the idle state of the relay. STOP/FAULT by default is the activation condition which means that the Fault Relay activates when BioTector is stopped or when there is a fault or a warning condition.

  • Page 112: Data Program

    Data Program PRINTER, PC, MMC/SD CARD  These menus allow the user to program three separate output device communication port configuration profiles, which are PRINTER, PC and MMC/SD flash card.  The functions described below covers all programming options for each device. Some devices (e.g. MMC/SD Card) may have less programming functions.

  • Page 113: System Configuration Menu

    8.3.3 SYSTEM CONFIGURATION MENU System Configuration menus are used to configure the system in the factory. The user should avoid any modifications in these menu settings unless it is absolutely necessary. System Configuration Menu Diagram ENTER PASSWORD SYSTEM CONFIGURATION ANALYSIS MODE DEMO MODE DEMO MODE CO2 DATA SYSTEM PROGRAM...

  • Page 114: Analysis Mode

    Analysis Mode OXIDATION ANALYSIS TIC+TOC  OXIDATION ANALYSIS (TIC+TOC by default) defines BioTector’s oxidation phase analysis modes, which are TIC+TOC, TC, FAST TC, VOC and TC - TIC. It is not possible to run BioTector in TC, FAST TC, VOC and TC - TIC modes, if the analyzer is built as a TIC&TOC system only.

  • Page 115: System Program

    System Program OXIDATION PROGRAM 1  OXIDATION PROGRAM 1 TIC + TOC defines the system OXIDATION PROGRAM 1 TIC + TOC parameters for Oxidation Phase operation in TIC & TOC analysis mode. In TIC & TOC analysis mode, the TIC and TOC contents of a sample are measured consecutively by means of a single sample injection into a single reactor.
  • Page 116  BioTector oxidizes the sample for the BASE OXIDATION time BASE OXIDATION 300s 10l/h (300s by default) with the oxygen flow (10 l/h) settings. If any is released during this phase, it is measured and added to the TOC result because the default setting of RESULT INTEGRATION is TOC+BASE OXID in Result Integration menu.
  • Page 117  OXIDATION PROGRAM 1 TC defines the system parameters OXIDATION PROGRAM 1 TC for Oxidation Phase operation in TC analysis mode. In TC analysis mode, the TC content of a sample is measured by means of a single sample injection into a single reactor. ...
  • Page 118 TIC SAMPLE IN 15p , P-V  TIC SAMPLE IN specifies the amount of sample (in pulses) to be injected into the TIC reactor at range 1 in TC - TIC systems. TIC ACID  TIC ACID determines the amount of acid reagent (in pulses) to be injected into the TIC reactor at range 1 in TC - TIC systems.
  • Page 119 OXIDATION PROGRAM 2 TC BASE IN 1  BASE IN 1 specifies the quantity of base reagent (in pulses) to be injected into the reactor for the Pre Oxidation phase in TC mode at range 2. SAMPLE IN 5p , M-V ...
  • Page 120 SAMPLE IN MF-180  SAMPLE IN states the amount of sample (in pulses) to be injected into the reactor at range 3. If the setting is 0p MF-180, it means that the sample injection at this range will be carried out by means of the Motorized Fixed 180°...
  • Page 121 LIQUID PHASE PROGRAM  LIQUID PHASE PROGRAM defines the system parameters for Liquid Phase operation in TN analysis mode. WAIT FOR SMPL  WAIT FOR SAMPLE is a delay time applied when the reactor purge of the oxidized sample is completed. SAMPLE RETURN 28p , 13s ...

  • Page 122: Calibration Data

    Calibration Data DECIMAL PLACES  DECIMAL PLACES setting defines the number of decimal places (0, 1, 2 or 3) system displays in the reaction results and in the relevant system menus. TOC CALIBRATION 1  Calibration menus are used to install the calibration data and TOC CALIBRATION 2 thus to calibrate the BioTector in factory.

  • Page 123: Cleaning Program

     The parameters in Cleaning Program menu identifies the operation of the specific cleaning cycle built and programmed for Cleaning Program each specific analyzer. OXIDATION PHASE CLEANING  The oxidation phase cleaning type in BioTector TOC TN analyzers is reverse wash by default. If system is built with reverse wash cleaning cycle option and if a STREAM REVERSE time is set in Sample Pump menu, the Sample Pump runs reverse with the Cleaning Valve activated to wash the sample...

  • Page 124: Zero Program

    Zero Program ZERO PROGRAM  In ZERO PROGRAM 5, 3, 3 setting, the first, second and third inputs define the minimum number of reactions to be carried out at Range 1, Range 2 and Range 3 respectively during the Zero Calibration and Zero Check cycles.

  • Page 125: Span Program

    ZERO ADJUST HISTORY  Anytime the Zero Adjust values are changed, either manually by the user or automatically by the system, the new Zero Adjust values are stored in the Zero Adjust History archive with the time, date, zero range and the zero type (calibration, check or manual) information.

  • Page 126: Reagents Purge

    TN STANDARD 50.0mgN/l  TN STANDARD specifies standard solution concentration level (mgN/l) to be used in Span Calibration or Span Check reactions.  If TN STANDARD is programmed as 0.0mg/l, system ignores the Span Calibration or Span Check results and omits any related warnings defined in TN BAND below.

  • Page 127: Pressure/Flow Test Program

    Pressure/Flow Test Program TIME 08:15  BioTector performs an automatic pressure and flow test every day at the TIME programmed (at 08:15 hours by default). PRESSURE TEST FAULT 6.0l/h  Each time BioTector is started up and everyday during online operation at the programmed TIME above, BioTector pressurizes the system with oxygen gas and uses its mass flow controller to detect any gas leak in the system.

  • Page 128: Output Devices

    PRESSURE CHCK FAULT 6.0l/h  At the end of each reaction during operation, BioTector automatically pressurizes the system with oxygen gas and uses its mass flow controller to detect any gas leak in the system. If the measured flow is less than or equal to the programmed PRESSURE CHECK FAULT flow level (6.0 l/h by default) during the test, the pressure check passes.
  • Page 129 Relay 17, 18 and 19 together with the Auxiliary Relays (if fitted) may be programmed to any one of the following options: Relay not programmed. STREAM Output set for stream valves 1-6. STM ALARM Stream alarm relay 1-6. MANUAL Output set for Manual Valves 1-6. FAULT (Normally energized output) set to operate on fault condition.

  • Page 130: Reaction Check

    POWERED ALL TIME  POWERED ALL TIME parameter specifies if the relays are powered all the time even if the system is stopped or paused (YES) or the relay is powered only when required (NO). VALVE ACTIVATION SPF/SAMPLER  VALVE ACTIVATION determines the two possible times for the multi-stream valve to change over for the next stream.

  • Page 131: Result Integration

    TIC CHECK 25ppmCO2  TIC CHECK (25ppm CO by default) represents the CO check point in the TIC phase. If the CO level is above the programmed check point at the end of the TIC phase, then the system automatically extends the TIC SPARGE TIME by 1 second and checks the CO level again.

  • Page 132: Fault Setup

    Fault Setup LOW O2 FLOW TIME  If the O flow drops more than 50% of the MFC set value for longer than the LOW O2 FLOW TIME (12s by default), a “01_LOW O2 FLOW - EX” or “02_LOW O2 FLOW - SO” fault is logged.
  • Page 133 SAMPLE STATUS 5s ,  The first parameter in SAMPLE STATUS setting is the sample detection time (5 seconds by default) BioTector processes the output of the Sample Sensor. When the parameter is set to 0s (zero seconds), the sample detection is switched off. The second parameter (75% by default) is the % sample quality threshold, which is used to activate SAMPLE STATUS output.

  • Page 134: Fault Status

     This menu gives a short status history of several system devices before a fault is registered. The default 0.0 values indicate that Fault Status there are no faults detected for the specific device. O2 FLOW  The O2 FLOW menu consists of 120 entries for the MFC setpoint value (first column) and MFC flow value (second column).

  • Page 135: Co2 Analyzer

    CO2 Analyzer INTERFACE 4-20mA  INTERFACE defines whether the connection type of BioTector Analyzer is analog (4-20mA) or digital (RS232). BAUDRATE 9600  BAUDRATE (9600bps by default) specifies the data communication signaling speed of CO Analyzer when the INTERFACE is programmed as RS232 above. ...

  • Page 136: Software Update

    Software Update LOAD FACTORY CONFIG.  Each BioTector system contains a configuration which is installed and protected by system flash memory. When any modification is carried out in system configuration, LOAD FACTORY CONFIGURATION function allows the user to revert back to the original system settings programmed in the factory. ...

  • Page 137: Password

    Password OPERATION 0000  Password menu allows any number from 1 to 9999 to be set as CALIBRATION 0000 passwords for the Operation, Calibration, Diagnostics, DIAGNOSTICS 0000 Commissioning and System Configuration menus (levels). When COMMISSIONING 0000 the setting is 0000 (by default), the password is disabled. SYSTEM CONFIGURATION 0000 ...

  • Page 138: Troubleshooting Of System Faults & Warnings

    Section 9 Troubleshooting of System Faults & Warnings BioTector Fault Conditions The following fault conditions activate the BioTector stop sequence, set all 4-20mA signals to the FAULT LEVEL (1mA by default) programmed in the 4-20mA Program menu, and activate the COMMON FAULT relay defined in Relay Program menu.
  • Page 139 FAULT CONDITION CAUSE/REMEDY 08_RELAY PCB FAULT Fuse blown in the 81204001 Relay Check the incoming 24V DC PCB. Fuse F3 blown in the 81204010 power. Check the fuses on the Signal PCB. 24V PSU faulty. Relay PCB. Check the fuse F3 on the Signal PCB.
  • Page 140 FAULT CONDITION CAUSE/REMEDY BioTector’s cabinet liquid leak detector 18_LIQUID LEAK DET Check for a liquid leak in the is activated. BioTector. Check BioTector liquid leak detector. BioTector’s DCP module liquid leak 19_DCP LIQ. LEAK DET Check for a liquid leak in the detector is activated.

  • Page 141: Biotector Warning Conditions

    BioTector Warning Conditions The following warning conditions do not activate the BioTector stop sequence and leave the 4-20mA signals un-changed and do not activate the fault relay. WARNING CONDITION CAUSE/REMEDY 21_CO2 ANL LENS DIRTY Analyzer detected dirt on its Clean the CO Analyzer.
  • Page 142 WARNING CONDITION CAUSE/REMEDY 28_NO PRESSURE TEST This warning is logged when the This warning occurs when the pressure test procedure is skipped Pressure/Flow Test is deactivated, and when the “QUICK STARTUP” during the system startup sequence. The warning cannot be acknowledged function is used.
  • Page 143 WARNING CONDITION CAUSE/REMEDY 47_TN ZERO CHCK FAIL TN Zero Check result is outside the Confirm DI Water is connected to specified TN BAND defined in the ZERO port of the BioTector Sequence Program, Zero Program during zero calibration cycle. menu. Check the stability of the zero reactions and the quality of the reagents used.
  • Page 144 WARNING CONDITION CAUSE/REMEDY 62_SMPL PUMP STOP ON Sample Pump stopped with its rotation Run the Sample Pump and check sensor ON or the sensor is faulty and it the rotation. Change Relay 2 on is always showing ON. Relay PCB. Check pump sensor ON state = LED 15 on (Signal PCB).
  • Page 145 WARNING CONDITION CAUSE/REMEDY 76_DCP WARN A problem has been found during Check the power on the DCP communication with the Dual Cell module. LEDs on DCP PCB Photometer (DCP) module. should be on. The DCP communication is lost. Check the DCP data cable connections.

  • Page 146: Biotector Notification Conditions

    BioTector Notification Conditions The following Notification conditions do not activate the BioTector stop sequence, leave the 4-20mA signal un-changed and do not activate the fault relay. NOTIFICATION CONDITION CAUSE/REMEDY 85_REAGENTS LOW BioTector has calculated that the Change reagents, and reset (can also be programmed as reagent containers are running low.

  • Page 147: Service And Maintenance

    Section 10 Service and Maintenance 10.1 Weekly Maintenance Oxidation Phase:  Check the oxygen cylinder/oxygen concentrator.  Check the oxygen pressure in the cylinder or the oxygen supply from the oxygen concentrator.  Check the oxygen pressure on the Oxygen Regulator inside the BioTector. ...

  • Page 148: Six And Twelve Month Service

    10.2 Six and Twelve Month Service Below procedure is a recommended check list for the 6 and 12 month service on the BioTector TOC TN analyzers. Please note that any special models and applications may require additional service items. Service procedures may be changed without notice due to the continuous research and development program.
  • Page 149 Replace the 3.5mm OD, 1.5mm ID EMPP 562 tube in the HCl Water Pump if installed in systems built with FMI Heavy Duty Circulation Pump (see item A in _____ _____ service kit). If there are no HCl Water In and HCl Water Out ports on the BioTector, this item does not apply.
  • Page 150 For the TN system, carry out the following 8 service items and checks listed below: Replace the tubing element (6.4mm OD, 3.2mm ID EMPP 562 tubes) of the WMM60 Nitrogen Pump (N Pump). The WMM60 replacement tubes are supplied in the service kits with fittings already attached (see item D in service _____ _____ kit).
  • Page 151 In systems built with FMI Heavy Duty Piston-Type Circulation Pump, confirm that the clearance at the bottom of the piston is greater than > 2mm. To confirm this, first mark the piston at the bottom of its stroke while it is in the pump drive.
  • Page 152 Check the BioTector for any gas/liquid leaks by running the PRESSURE TEST cycle using the Process Test menu. Note that the BioTector should be _____ _____ pressure tested at 350 mbar pressure only. Confirm all signals (4-20mA and volt free contacts) are signaling correctly to _____ _____ the external control device.

  • Page 153: System Replacement And Spare Parts

    Section 11 System Replacement and Spare Parts Hazardous area analyzers may have a different motherboard with a special battery. Contact manufacturer for details. Page 153...

  • Page 154: Warranty And Exclusions

    Section 12 Warranty and Exclusions Coverage of BioTector Warranty The BioTector comes with a standard 1 year warranty for agreed applications. The BioTector warranty is against manufacturing defects only. The warranty does not cover service/consumable items and consequential damage. Validity of Warranty For the warranty to be valid, regular 6th Monthly and 12th Monthly servicing must be carried out using Service Kits supplied by the manufacturer.

  • Page 155: Appendices

    Section 13 Appendices Appendix 1 Instructions for Connecting Printer to BioTector Protocol used by the BioTector Baud rate 9600 Data bits Stop bits Parity None Flow control None Note that these instructions refer to the Epson LX300 printer with the optional serial port fitted. If a printer cable provided by the BioTector manufacturer is used, the electrical connections are as follows: - Terminal TX on the microcontroller is connected to pin 3 on the D25 plug.

  • Page 156: Appendix 2 Setting Up Windows To Receive Data From Biotector

    Appendix 2 Setting up Windows to Receive Data from BioTector To set up Windows for receiving data from the BioTector, open the Hypertrm file found within the HyperTerminal folder. This may be carried out by selecting Start, Programs, Accessories, Communications, Hyper Terminal.

  • Page 157: Direct Mode

    Appendix 3 BioTector 4-20mA Output Modes BioTector features three different 4-20mA output operation modes programmable in 4-20mA Program menu: 1) Direct Mode – simple mode 2) Stream Multiplex Mode – more complex than Direct Mode, but significantly reduces number of necessary output channels 3) Full Multiplex Mode –...

  • Page 158: Appendix 3.2 Stream Multiplex Mode

    Appendix 3.2 Stream Multiplex Mode In Stream Multiplex Mode, one channel is dedicated to periodically change its value in steps to indicate the sample stream information and the rest of the channels output appropriate stream reaction results. The output channel, which indicates the reaction result stream information is called “Stream Identification (ID)” channel. The output channels, which output the reaction results are called “Reaction Result”...
  • Page 159 If the Direct Mode was being used in the example above, the system would require 9 dedicated output channels (3 analysis results multiplied by 3 streams). With the use of Stream Multiplex Mode, only 4 output channels (1 stream id channel plus 3 analysis result channels) are needed. Since the output channels in Stream Multiplex Mode change on periodical bases, there is a need for some sort of synchronization between the BioTector and the user device.
  • Page 160 The operation of 4-20mA READ signal is demonstrated in figure A3.2 above. Note that the 4-20mA READ signal is always activated 1 second after changes on Stream ID and all reaction result channels. This function allows the channels to stabilize their values. When this type of synchronization is used, the user device has to sample the 4-20mA READ signal and search for a condition when this signal is activated before reading the Stream ID and reaction results channels.
  • Page 161 4 - 2 0 m A P R O G R A M 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2  O U T P U T < 4 m A O U T P U T S T R E A M T O C...

  • Page 162: Appendix 3.3 Full Multiplex Mode

    Appendix 3.3 Full Multiplex Mode While 4-20mA Stream Multiplex Mode helps to eliminate most of hardware limits for multi-component BioTector systems, the Full Multiplex Mode brings the multiplex concept one step further. The 4-20mA Full Multiplex Mode allows outputting all possible system reaction results on all possible streams over only 3 output channels.
  • Page 163 Figure A3.4 An example of BioTector 4-20mA output signals in Full Multiplex Mode In the first step, the Stream ID channel is set to CHANGE level and 4-20mA READ relay is deactivated. After a programmed time period, the first result type, TIC result, is indicated on the Result Type channel and Instantaneous/Average Result Value channels are updated with TIC result from STREAM 1 valve.
  • Page 164 As in Stream Multiplex Mode, in Full Multiplex Mode, the Stream ID channel also operates in discrete levels as shown in table A3.2 below. Table A3.2 4-20mA STREAM ID channel output levels. STREAM ID CHANNEL Output Level (mA) CHANGE STM 1 STM 2 STM 3 STM 4...
  • Page 165 If the 4-20mA READ synchronization option is used, then this output has to be assigned to a valve relay in Output Devices menu as follows: O U T P U T D E V I C E S 0 9 : 1 7 : 2 8 1 2 - 0 9 - 0 2 1 <...
  • Page 166 A section of 4-20mA Program menu below shows the BioTector configuration in Full Multiplex Mode, which corresponds to the example output signals given in figure A3.4 above. As can be seen, the reaction Result channels are programmed to output TIC, TOC and TN components as follows. 4 - 2 0 m A P R O G R A M 0 9 : 1 7 : 2 8...

  • Page 167: Appendix 3.4 Result Update In Stream And Full Multiplex Modes

    Appendix 3.4 Result Update in Stream and Full Multiplex Modes As described above, the 4-20mA output channels in Stream and Full Multiplex Modes are not constant over time, they change on periodical basis. The full set of outputted reaction results in a period of time is called Results Sequence.

  • Page 168: Appendix 4 Glossary

    Appendix 4 Glossary - - - No function is programmed 4-20mA CHNG 4-20mA Change signal Amperes 24 hours average for stream 1 – 6 A1 - A6 ALLDAT All Data Amperes ARS Valve Automatic Range Selection Valve (Sample Valve) Atmospheric pressure Biochemical Oxygen Demand C-276 Hastelloy...
  • Page 169 Normally Energized NaOH Sodium Hydroxide NaOX Sodium Oxalate NDIR Nondispersive Infrared NOTE Notification NPOC Non-purgeable Organic Carbon Oxygen Ozone Outside Diameter Printed Circuit Board PEEK Poly-ether-ether-ketone Per-fluoro-alkoxy Purgeable Organic Carbon Poly-propylene Parts per billion (g/l) Parts per million (mg/l) PTFE Poly-tetra-fluoro-ethylene PVDF Poly-vinylidene-flouride...
  • Page 170 Zero and Span Page 170...

  • Page 171: A 5 C I

    HACH Company Repair Service in the Repair Service in Canada: Repair Service in World Headquarters United States: Hach Sales & Service Latin America, the Canada Ltd. P.O. Box 389 HACH Company Caribbean, the Far East, 1313 Border Street, Unit 34...
  • Page 172 HACH LANGE MAROC SARLAU Villa 14 – Rue 2 Casa Plaisance Quartier Racine Extension MA-Casablanca 20000 Tél. +212 (0)522 97 95 75 Fax +212 (0)522 36 89 34 info-maroc@hach-lange.com www.hach-lange.ma Page 172...

  • Page 173: Ec Declaration Of Conformity

    Manufacturer: BioTector Analytical Systems Ltd., Raffeen House, Ringaskiddy, Co.Cork, Ireland Tel: (+353) 21 437 42 37, Fax: (+353) 21 437 42 36, e-mail: info@biotector.com. Declares that all models of following product: BioTector B7000, all models: comply with the essential requirements of the following Directive(s): 2014/30/EU...
  • Page 174 DOC012.97.80506 User Guidance for EMC Class A Equipment 업무용을 위한 EMC 등급 A 장치에 대한 사용자 지침 사용자안내문 A급 기기 (업무용 방송통신기자재) 이 기기는 업무용(A급) 전자파적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라며, 가정외의 지역에서 사용하는 것을 목적으로 합니다.
  • Page 175 This document contains information which is only required for the export of this instrument into the People’s Republic of China. 本手册只包含出口到中华人民共和国的仪器的必要信息。 Statement on China "Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products”, Ministry of Information Industry Order #39.

Table of Contents
