MANUAL
In the MANUAL menu, manual switch functions are applied.
In the submenus PERM, OVERRIDE, TIMER or HOLIDAY, the
manual switchings can be activated/programmed.
Press MENU, use u to select MANUAL and follow the indica-
†
¾
tions on the display
MENU
u
u
MANUAL PERM
OVERRIDE
TIMER
HOLIDAY
END

Setting manual or permanent switching

Manual or permanent switching can be set via the menu in
MANUAL or (in the automatic screen) by button combination
(see picture).
•
Manual control:
Reversing the channel status to the next automatic or
programmed switching.
•
Permanent switching:
As long as a permanent switching (on or off) is activated,
the programmed switching times are ineffective
Activating manual control
Press buttons simultaneously. If FROST or DECREASE is
† ¾
active, MANUAL COMFORT will become active. If COMFORT
is active, MANUAL DECREASE will become active
Activating permanent switching
Press both buttons simultaneously for 2 seconds
† ¾
Cancelling manual/permanent switching
Press both buttons simultaneously
†
¾
COMFORT
REDUCED
FROST
Options
In the OPTIONS menu; the submenus EXT INPUT, TYPE OF
CONTROL, WALL COMP, LCD
ILLUMINATION, LANGUAGE, PIN, FACTORY SETTINGS or INFO
can be selected.
Press MENU, use u to select OPTIONS and follow the inst-
† ¾
ructions on the display.
MENU
OPTIONS
EXT INPUT TYPE OF
u u
CONTROL
NOT ACTIVE NORMAL
PERM UNDERFLOOR
COMFORT
PERM AIR HEATING
REDUCED
HYSTERESIS
PERM FROST
CONTROLLER
LANGUAGE PIN
u u
NO PIN
DEUTSCH
WITH PIN
ENGLISH
FRANCAIS

Set external input

Via the EXT INPUT different functions can be set.
•
NOT ACTIVE: The external input has no function
•
PERM
COMFORT: Comfort mode is permanently on
REDUCED: Setback mode is permanently on
FROST: Frost mode is permanently on
•
TIMER
COMFORT: Comfort mode Timer
REDUCED: Setback mode Timer
FROST: Frost mode Timer
MENU
OPTIONS
EXT INPUT NOT ACTIVE
u
PERM
TYPE OF
CONTROL
TIMER
Press MENU, use u to select EXT INPUT and follow the
† ¾
indications on the display. 4 submenus can be selected:
WALL COMP LCD-
u u
ILLUMINATION
WALL COMP AFTER 1
0.2 °C MINUTE OFF
ALWAYS ON
FACTORY INFO
u u
SETTINGS
LOAD FACTORY
SETTINGS
COMFORT
u
REDUCED
FROST
u
COMFORT
REDUCED
FROST
u
4
