- Page 1 ITNESS E Series Treadmill I n s t a l l G u i d e...
-
Page 2: Assembly And Setup
**E-TRe & E-TRxe models will have embedded touch screen and surrounding plastics packaged separately. Should any component not be present or if you have any operational questions, please call Star Trac’s Customer Care department at (800) 503-1221 or USA 1-714-669-1660. Specifically refer to your treadmill serial number and model number listed below: Serial No._________________________________________________________________________... -
Page 3: Installing The Neck
(4) lock washers. DO NOT fully tighten yet. Step 2c 2d) Route all cables through lower neck service opening into motor compartment. Refer to CONNECTING THE CABLES for cable routing and connection. Step 2d STAR TRAC E SERIES TREADMILL Install Guide... - Page 4 Use the following torque specifacations. (2)5/16-18 x 3.0” Socket Head screws- 240in-lbs (27 Nm). (12)5/16-18 x 1.0” Socket Head screws- 240in-lbs (27Nm). (4) #10 Button Head Socket screws- 35in-lbs (4.0 Nm) Step 4b STAR TRAC E SERIES TREADMILL Install Guide...
-
Page 5: Connect The Power Cable
5c) Take the cable labled DC Power and connect it to the DC Power Board. Step 5b & 5c 6. Connect the Power Cable 6a) Connect the female end of the power cord to the under side front of the treadmill. Step 6a STAR TRAC E SERIES TREADMILL Install Guide... -
Page 6: Final Assembly
7a) Fasten motor shroud and Side Bed Covers with (6) #10 Truss Head screws. Screws Screws Step 7a 7b) Pop in Front Motor Shroud Cap and install Neck Grommet. Step 7b 7c) Install Handrail Grommet. Step 7c STAR TRAC E SERIES TREADMILL Install Guide... -
Page 7: Level The Tread Mill
ATTENTION Star Trac recommends that treadmills be spaced a minimum of 20.0 inches (0.5 m) apart to allow safe and easy ingress and egress. Even more importantly, there must be at least 48 inches (1.25 m) of free space behind the treadmills.
