Dvd Section - Sanyo HV-DX1E Service Manual

Electrical Section
PART NO(LG)
S AL LOCA.NO

DVD SECTION

PWB ASSEMBLY (A46A)
CAPACITOR
C201 LG0CH1104K942
C202 LG0CH1104K942
C203 LG0CH1104K942
C204 LG0CH1104K942
C205 LG0CH1104K942
C206 LG0CH1104K942
C207 LG0CH1105D942
C208 LG0CH1104K942
C209 LG0CH1104K942
C210 LG0CH1104K942
C211 LG0CE1064F638
C212 LG0CE1064F638
C213 LG0CE1064F638
C214 LG0CH1104K942
C215 LG0CH1104K942
C216 LG0CH1104K942
C224 LG0CH1104K942
C225 LG0CH1105D942
C226 LG0CH1105D942
C229 LG0CH1104K942
C230 LG0CH1104K942
C231 LG0CH1104K942
C232 LG0CE1064F638
C238 LG0CH1104K942
C239 LG0CH1104K942
C240 LG0CH1222K562
C242 LG0CH1104K942
C245 LG0CH1105D942
C251 LG0CH1105D942
C252 LG0CH4100K112
C253 LG0CH1105D942
C254 LG0CH1105D942
C255 LG0CH1104K942
C258 LG0CH1105D942
C261 LG0CE1064F638
C262 LG0CE1064F638
C263 LG0CE1064F638
C264 LG0CE1064F638
C265 LG0CE1064F638
C272 LG0CE4764F638
C273 LG0CH1225F944
C274 LG0CE4764F638
C278 LG0CE1064F638
C279 LG0CE1064F638
C280 LG0CE1064F638
C281 LG0CE1064F638
C284 LG0CE4764F638
C285 LG0CE1064F638
C286 LG0CH1104K942
C287 LG0CE1064F638
C288 LG0CE1064F638
C290 LG0CH4180K412
C291 LG0CH4180K412
C292 LG0CH1104K942
C293 LG0CH1104K942
C294 LG0CH1104K942
C295 LG0CH1104K942
C296 LG0CH1104K942
C2A0 LG0CE4764F638
A B C DESCRIPTION
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CHIP CAPA CERAMIC M/L T.C F/S
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,FIXED CERAMIC(Temp.c
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,ELECTROLYTIC
O O O CAPACITOR,CHIP[CERAMIC M/L TC
O O O CAPACITOR,CHIP[CERAMIC M/L TC
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,CHIP[CERAMIC M/L HD
O O O CAPACITOR,ELECTROLYTIC
6-4
RUN DATE:14.MAY.2002
SPECIFICATION
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
1UF 10V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
1UF 10V Z Y5V(F) 1508 R/TP
1UF 10V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
10M SRA 16V M FM5 TP(5)
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
2200PF 50V K X7R(X) 1608 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
1UF 10V Z Y5V(F) 1508 R/TP
1UF 10V Z Y5V(F) 1508 R/TP
10P 50V D COG 1.6X0.8 R/TP
1UF 10V Z Y5V(F) 1508 R/TP
1UF 10V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
1UF 10V Z Y5V(F) 1508 R/TP
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
2.2UF 16V 80%,-20% Y5V(F) 3216
47M SRA/SS 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
47M SRA/SS 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
0.1UF 50V Z Y5V(F) 1508 R/TP
10M SRA 16V M FM5 TP(5)
10M SRA 16V M FM5 TP(5)
18P 50V J COG 1.6X0.8 R/TP
18P 50V J COG 1.6X0.8 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
0.1UF 50V Z Y5V(F) 1508 R/TP
47M SRA/SS 16V M FM5 TP(5)
REMARKS
