Page 1 WiMAX MIMO 3.5GHz Multi-User Outdoor CPE Default Login Details IP Address: http://192.168.1.1 Admin’s User Name and admin / 1234 Password: Guest’s User Name and guest / guest Password: Software Version 2.00 Edition 1, 1/2011 www.zyxel.com www.zyxel.com Copyright © 2011 ZyXEL Communications Corporation...
Page 3: About This User's Guide
Documentation Feedback Send your comments, questions or suggestions to: techwriters@zyxel.com.tw Thank you! The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 30099, Taiwan. Need More Help? More help is available at www.zyxel.com.
Page 4 • Product model and serial number. • Warranty Information. • Date that you received your device. • Brief description of the problem and the steps you took to solve it. MAX318M2W User’s Guide...
Page 5: Document Conventions
For example, “k” for kilo may denote “1000” or “1024”, “M” for mega may denote “1000000” or “1048576” and so on. • “e.g.,” is a shorthand for “for instance”, and “i.e.,” means “that is” or “in other words”. MAX318M2W User’s Guide...
Page 6 Figures in this User’s Guide may use the following generic icons. The WiMAX Device icon is not an exact representation of your product. Table 1 Common Icons WiMAX Device Computer Wireless Signal Notebook Server Base Station Telephone Switch Router Internet Cloud Network Cloud MAX318M2W User’s Guide...
Page 7: Safety Warnings
• Antenna Warning! This device meets ETSI and FCC certification requirements when using the included antenna(s). Only use the included antenna(s). • If you wall mount your device, make sure that no electrical lines, gas or water pipes will be damaged. MAX318M2W User’s Guide...
Page 8 Your product is marked with this symbol, which is known as the WEEE mark. WEEE stands for Waste Electronics and Electrical Equipment. It means that used electrical and electronic products should not be mixed with general waste. Used electrical and electronic equipment should be treated separately. MAX318M2W User’s Guide...
Page 9: Table Of Contents
WiMAX ............................63 Network Settings ........................85 Security ............................ 127 The VoIP General Screens ...................... 133 The VoIP Account Screens ...................... 139 The VoIP Line Screens ......................155 Maintenance ..........................159 Troubleshooting ........................185 Product Specifications ......................191 MAX318M2W User’s Guide...
Page 10 Contents Overview MAX318M2W User’s Guide...
Page 11: Table Of Contents
3.1 Overview ..........................31 3.1.1 Welcome to the Setup Wizard ..................31 3.1.2 LAN Settings ......................32 3.1.3 WiMAX Frequency Settings ..................34 3.1.4 WiMAX Authentication Settings ................. 35 3.1.5 VoIP Settings ......................37 3.1.6 WLAN Settings ......................38 MAX318M2W User’s Guide...
Page 12 6.5 Connect ..........................75 6.6 Wide Scan ........................... 78 6.7 Link Status ........................... 79 6.8 Link Statistics ........................81 6.9 Connection Info ........................82 6.10 Service Flow ........................82 6.11 Buzzer ..........................83 Chapter 7 Network Settings........................85 MAX318M2W User’s Guide...
Page 13 Chapter 9 The VoIP General Screens ....................133 9.1 VoIP Overview ........................133 9.1.1 What You Can Do in This Chapter ................133 9.1.2 What You Need to Know ..................133 9.1.3 Before you Begin ...................... 135 MAX318M2W User’s Guide...
Page 14 12.1 Overview .......................... 159 12.1.1 What You Need to Know ..................159 12.2 Password ......................... 166 12.3 HTTP ..........................167 12.4 Telnet ..........................168 12.5 SSH ..........................168 12.6 SNMP ..........................169 12.7 CWMP ..........................170 12.8 OMA-DM .......................... 172 MAX318M2W User’s Guide...
Page 15 Appendix B Setting Up Your Computer’s IP Address ............199 Appendix C Pop-up Windows, JavaScript and Java Permissions........227 Appendix D IP Addresses and Subnetting ................237 Appendix E Importing Certificates ..................249 Appendix F Common Services..................... 281 Appendix G Legal Information....................285 Index............................289 MAX318M2W User’s Guide...
Page 16 Table of Contents MAX318M2W User’s Guide...
Page 17: User's Guide
User’s Guide...
Page 19: Getting Started
You can define time periods and days during which content filtering is enabled and include or exclude particular computers on your network from content filtering. For example, you could block access to certain web sites. MAX318M2W User’s Guide...
Page 20: Wimax Device Hardware
The signal strength is less than or equal to -90 dBm Signal 2 On The signal strength is less than or equal to -80 dBm Signal 3 On The signal strength is less than or equal to -70 dBm MAX318M2W User’s Guide...
Page 21 The port is disconnected or the link to an Ethernet network is down. Solid Green The link to an Ethernet network is up. Blinking Green The system is transmitting/receiving to/from an Ethernet network. Solid Amber The link to a 100 Mbps Ethernet network is up. MAX318M2W User’s Guide...
Page 22 0 Counts The signal strength is less than -90 dBm. Activity The WiMAX Device is not ready. Indicator Green The WiMAX Device is connected to the network. Blinking The WiMAX Device system is seeking a viable signal. MAX318M2W User’s Guide...
Page 23: Good Habits For Device Management
If you forget your password, you will have to reset the WiMAX Device to its factory default settings. If you backed up an earlier configuration file, you would not have to totally re-configure the WiMAX Device. You could simply restore your last configuration. MAX318M2W User’s Guide...
Page 24 Chapter 1 Getting Started MAX318M2W User’s Guide...
Page 25: The Web Configurator
2.1.1 Accessing the Web Configurator Make sure your WiMAX Device hardware is properly connected (refer to the Quick Start Guide for more information). Launch your web browser. Enter "192.168.1.1" as the URL. MAX318M2W User’s Guide...
Page 26: The Reset Button
Web Configurator for five minutes. If this happens, log in again. 2.1.2 The Reset Button If you forget your password or cannot access the Web Configurator, you will need to use the Reset button (in the ODU) to reload the factory-default configuration MAX318M2W User’s Guide...
Page 27: Saving And Canceling Changes
All screens to which you can make configuration changes must be saved before those changes can go into effect. If you make a mistake while configuring the WiMAX Device, you can cancel those changes and start over. Figure 6 Saving and Canceling Changes MAX318M2W User’s Guide...
Page 28: Working With Tables
Use the menu to jump to another page. You can only jump to other pages if those pages exist. Next Page Click this to go to the previous page in the table. Last Page Click this to go to the last page in the table. MAX318M2W User’s Guide...
Page 29: The Main Screen
Note: Some features in the Web Configurator may not be available depending on your firmware version and/or configuration. Note: The available menus and screens vary depending on the user account you use for login. Figure 8 Main Screen MAX318M2W User’s Guide...
Page 30 Use this menu to select the Web Configurator’s language. Setup Wizard Click this to open the Setup Wizard, where you can configure the most essential settings for your WiMAX Device to work. Logout Click this to log out of the Web Configurator. MAX318M2W User’s Guide...
Page 31: Setup Wizard
Set up your WiMAX Device’s VoIP settings, which allows you to make calls over the Internet. Set up your WiMAX Device’s wireless LAN so that other devices, such as a laptop or a smartphone, can connect wirelessly to the Internet using the WiMAX Device. MAX318M2W User’s Guide...
Page 32: Lan Settings
Chapter 3 Setup Wizard Figure 9 Setup Wizard > Welcome 3.1.2 LAN Settings The LAN Settings screen allows you to configure your local network options. Figure 10 Setup Wizard > LAN Settings MAX318M2W User’s Guide...
Page 33 Specify the third IP address of three DNS servers that the network can use. The WiMAX Device provides these IP addresses to DHCP clients. Server Back Click to display the previous screen. Next Click to proceed to the next screen. MAX318M2W User’s Guide...
Page 34: Wimax Frequency Settings
The frequency is increased in increments equal to the Step value until the End Frequency is reached, at which time the cycle starts over with the Start Frequency. Note: This field only appears when you select By Range under Setting Type. MAX318M2W User’s Guide...
Page 35: Wimax Authentication Settings
The WiMAX Authentication Settings screen allows you to configure how your WiMAX Device logs into the service provider’s network. Note: These settings should be provided by your ISP. Note: The EAP supplicant settings on this screen vary depending on the authentication mode your select. MAX318M2W User’s Guide...
Page 36 Browse for and choose a server root certificate file, if required. Ceert. File Server Root CA This field displays information about the assigned server root certificate. Cert. Info Device cert. Browse for and choose a device certificate file, if required. File MAX318M2W User’s Guide...
Page 37: Voip Settings
The VoIP Settings screen allows you to configure how your WiMAX Device connects to up to two VoIP service providers’ network and makes calls. Note: These settings should be provided by your VoIP service provider. Figure 13 Setup Wizard > VoIP Settings MAX318M2W User’s Guide...
Page 38: Wlan Settings
Back Click to display the previous screen. Next Click to proceed to the next screen. 3.1.6 WLAN Settings The WLAN Settings screen allows you to configure wireless LAN settings. Figure 14 Setup Wizard > WLAN Settings MAX318M2W User’s Guide...
Page 39: Setup Complete
Back Click to display the previous screen. Next Click to proceed to the next screen. 3.1.7 Setup Complete Click Save to save the Setup Wizard settings and close it. Figure 15 Setup Wizard > Setup Complete MAX318M2W User’s Guide...
Page 40 WiMAX Device features available in the more advanced web configurator. Note: If you cannot access the Internet, open the web configurator again to confirm that the Internet settings you configured in the wizard setup are correct. MAX318M2W User’s Guide...
Page 41: Tutorials
Connect the WiMAX Device to the ISP’s nearest base station. See Section 6.2 on page Configure the WiMAX Device’s broadcast frequency. Section 6.3 on page Configure the WiMAX Device to connect securely to the ISP’s authentication servers. See Section 6.4 on page MAX318M2W User’s Guide...
Page 42: Configuring Lan Dhcp
IP Address to 192.168.100.1. Use the default IP Subnet Mask of 255.255.255.0. Click Save. Manually change the IP address of your computer that your are using to 192.168.100.x (for example, 192.168.100.5) and keep the subnet set to 255.255.255.0. MAX318M2W User’s Guide...
Page 43 Log into the Web Configurator and open the Networking Setting > LAN > DHCP screen. Select Server for the DHCP mode, then enter 192.168.100.10 and 192.168.100.30 as your DHCP starting and ending IP addresses. Leave the other settings as their defaults and click Save. MAX318M2W User’s Guide...
Page 44: Changing Certificate
This tutorial shows you how to import a new security certificate, which allows your device to communicate with another network servers. Goal: Import a new security certificate into the WiMAX Device. See Also: Appendix E on page 249. MAX318M2W User’s Guide...
Page 45 Note: You can also use the Internet Connection Wizard to configure the Internet access settings. You may need to configure the Options section according to the information provided by the ISP. Click Save. You should now be able to connect to the Internet through your new service provider! MAX318M2W User’s Guide...
Page 46: Blocking Web Access
“Access Violation” message when you try to access to http:// www.example.com. You may also need to block the IP address of the website if you do not want users to access to the website through its IP address. MAX318M2W User’s Guide...
Page 47: Configuring The Mac Address Filter
First of all, you have to know the MAC address of the computer. If not, you can look for the MAC address in the Network Setting > LAN > DHCP screen. (192.168.100.3 mapping to 00:02:E3:53:16:95 in this example). MAX318M2W User’s Guide...
Page 48: Setting Up Nat Port Forwarding
Xbox LIVE, Thomas needs to configure the port settings on his WiMAX Device. Xbox 360 requires the following ports to be available in order to operate Xbox LIVE correctly: TCP: 53, 80, 3074 MAX318M2W User’s Guide...
Page 49 DHCP Leased Hosts table in the Network > LAN > DHCP screen. Look for the IP address for the Xbox 360. NAT mode is required to use port forwarding. Click Network Setting > WAN and make sure NAT is selected in the Operation Mode field. Click Save. MAX318M2W User’s Guide...
Page 50 Configure the screen as follows to open TCP/UDP port 53 for the Xbox 360. Click Repeat steps 2 and 3 to open the rest of the ports for the Xbox 360. The port forwarding settings you configured are listed in the Port Forwarding screen. MAX318M2W User’s Guide...
Page 51: Access The Wimax Device Using Ddns
WiMAX Device’s WAN IP address changes dynamically. Dynamic DNS (DDNS) allows you to access the WiMAX Device using a domain name. http://mywimax.dyndns.org a.b.c.d w.x.y.z To use this feature, you have to apply for DDNS service at www.dyndns.org. MAX318M2W User’s Guide...
Page 52: Registering A Ddns Account On Www.dyndns.org
Status page. Then you will need to configure the same account and host name on the WiMAX Device later. 4.8.2 Configuring DDNS on Your WiMAX Device Configure the following settings in the Network Setting > DDNS screen. MAX318M2W User’s Guide...
Page 53: Testing The Ddns Setting
This tutorial shows how to configure a static routing rule for two network routings. In the following figure, router R is connected to the WiMAX Device’s LAN. R connects to two networks, N1 (192.168.1.x/24) and N2 (192.168.10.x/24). If MAX318M2W User’s Guide...
Page 54 A to R and then R routes the traffic to computer B. This tutorial uses the following example IP settings: Table 13 IP Settings in this Tutorial DEVICE / COMPUTER IP ADDRESS The WiMAX Device’s WAN 172.16.1.1 The WiMAX Device’s LAN 192.168.1.1 192.168.1.34 MAX318M2W User’s Guide...
Page 55 Enter 192.168.1.253 (R’s IP address on N1) in the IP Address field under Next Hop. Click Save. Now computer B should be able to receive traffic from computer A. You may need to additionally configure R’s firewall settings to accept specific traffic to pass through. MAX318M2W User’s Guide...
Page 56: Remotely Managing Your Wimax Device
Select Enable in both HTTP Server and HTTPS Server sections and leave the Port Number settings as “80” and “443”. Select Allow Connection from WAN. This allows remote management connections not only from the local network but also the WAN network (Internet). Click Save. MAX318M2W User’s Guide...
Page 57: Technical Reference
Technical Reference...
Page 59: System Status
Use this screen to view a summary of your WiMAX Device connection status. 5.2 System Status This screen allows you to view the current status of the device, system resources, and interfaces (LAN and WAN). Click System Status to open this screen as shown next. Figure 16 System Status MAX318M2W User’s Guide...
Page 60 WiMAX Device and the base station. Network Search - The WiMAX Device is scanning for any available WiMAX connections. Disconnected - No WiMAX connection is available. Network Entry - A WiMAX connection is initializing. Normal - The WiMAX connection has successfully established. MAX318M2W User’s Guide...
Page 61 This field displays the current IP address of the WiMAX Device in the LAN. Subnet Mask This field displays the current subnet mask in the LAN. This field indicates the Maximum Transmission Unit (MTU) between the WiMAX Device and the client devices to which it is connected. MAX318M2W User’s Guide...
Page 62 Chapter 5 System Status MAX318M2W User’s Guide...
Page 63: Wimax
(IEEE 802.16-2004, for example). The following figure shows an MS-equipped notebook computer MS1 moving from base station BS1’s coverage area and connecting to BS2. Figure 17 WiMax: Mobile Station MAX318M2W User’s Guide...
Page 64 EAP secured connection between the mobile station, the base station and the AAA server. See the WiMAX security appendix for more details. MAX318M2W User’s Guide...
Page 65 There are commercial certification authorities like CyberTrust or VeriSign and government certification authorities. You can use the WiMAX Device to generate certification requests that contain identifying information and public keys and then send the certification requests to a certification authority. MAX318M2W User’s Guide...
Page 66 (CA). Certificates (also called digital IDs) can be used to authenticate users and a CA issues certificates and guarantees the identity of each certificate owner. MAX318M2W User’s Guide...
Page 67: Connection Settings
Make sure your base station also supports this before selecting this. Idle Mode Set the idle duration in minutes. This is how long the WiMAX Device Interval waits during periods of no activity before going into idle mode. MAX318M2W User’s Guide...
Page 68 This field displays the average Carrier to Interference plus Noise Ratio R3/R1 for the current connection. This value is an indication of overal radio signal quality, where a higher value means a better quality signal. Search Click this to have the WiMAX Device scan for base stations. MAX318M2W User’s Guide...
Page 69: Frequency Settings
(given by your WiMAX service provider) to find available connections to base stations. Click WiMAX > Profile > Frequency Settings to open this screen as shown next. Figure 22 Frequency Settings Screen (By List) Figure 23 Frequency Settings Screen (By Range) MAX318M2W User’s Guide...
Page 70 Click this field to modify it. Step (KHz) This indicates the frequency step within each band in kilohertz (KHz). Click this field to modify it. Bandwidth This indicates the bandwidth in megahertz (MHz). (MHz) Click this field to modify it. MAX318M2W User’s Guide...
Page 71 A must be within this range. Band Start This indicates the beginning of the frequency band in kilohertz (KHz). (KHz) Band End This indicates the end of the frequency band in kilohertz (KHz). (KHz) MAX318M2W User’s Guide...
Page 72: Authentication Settings
6.4 Authentication Settings These settings allow the WiMAX Device to establish a secure (authenticated) connection with the service provider. Click WiMAX > Profile > Authentication Settings to open this screen as shown next. Figure 24 Authentication Settings Screen MAX318M2W User’s Guide...
Page 73 This field displays information about the assigned server root CA Info certificate. Device Cert Browse for and choose a device certificate file, if required. File Device Cert This field displays information about the assigned device certificate. Info MAX318M2W User’s Guide...
Page 74 Select this to use the same EAP to the outer ID when reauthenticating. OuterID in ReAuth MAC address Adds the MAC address of the WiMAX Device to the outer ID while the in EAP-TLS EAP mode is set to EAP-TLS. outer Id MAX318M2W User’s Guide...
Page 75: Connect
This screen allows you to view the available WiMAX frequency band(s) and base station(s) the WiMAX Device found through scanning and choose a base station to which to connect. Click WiMAX > Connect to open this screen as shown next. Figure 25 Connect Screen MAX318M2W User’s Guide...
Page 76 Search Click this to have the WiMAX Device scan for base stations in the frequency band(s) listed in the Applied Frequency Information table. Connected BS Info MAX318M2W User’s Guide...
Page 77 CINR (dB) This field displays the average Carrier to Interference plus Noise Ratio for the current connection. This value is an indication of overal radio signal quality, where a higher value means a better quality signal. MAX318M2W User’s Guide...
Page 78: Wide Scan
Click this to add a range of frequencies to the wide scan range list. Click this so save any changes to the wide scan range list. Wide Scan Result This table displays the available frequency band(s) found through the wide scan. MAX318M2W User’s Guide...
Page 79: Link Status
CINR R1 This field displays the average Carrier to Interference plus Noise Ratio (R1) for the current connection. This value is an indication of overal radio signal quality, where a higher value means a better quality signal. MAX318M2W User’s Guide...
Page 80 WiMAX Device last restarted. Handover Fail This field displays how many times the WiMAX Device had been failed to switch its connection from one base station to another base station, since the WiMAX Device last restarted. MAX318M2W User’s Guide...
Page 81: Link Statistics
This section provides a detailed overview of Hybrid Automatic Repeat Request link statistics. TX/RX This section provides a detailed overview of transmission and receiving link statistics. This section provides a detailed overview of Modulation and Coding Sequence (MCS) link statistics MAX318M2W User’s Guide...
Page 82: Connection Info
Figure 30 Service Flow Screen This screen contains the following fields: Table 23 Service Flow LABEL DESCRIPTION SFID This displays a 32-bit service flow identifier. SF Status This display the service flow status. SF Direction This displays the service flow direction. MAX318M2W User’s Guide...
Page 83: Buzzer
Figure 31 Buzzer Screen This screen contains the following fields: Table 24 Buzzer LABEL DESCRIPTION Enable Buzzer Select this to enable the buzzer. Whenever a connection is made to a WiMAX signal, the device emits a small buzz. MAX318M2W User’s Guide...
Page 84 Chapter 6 WiMAX MAX318M2W User’s Guide...
Page 85: Network Settings
You can also use subnet masks to divide one network into multiple sub-networks. DHCP A DHCP (Dynamic Host Configuration Protocol) server can assign your WiMAX Device an IP address, subnet mask, DNS and other routing information when it’s turned on. MAX318M2W User’s Guide...
Page 86 However, wireless networking is different from that of most traditional radio communications in that there a number of wireless networking standards available with different methods of data encryption. MAX318M2W User’s Guide...
Page 87 A NAT server set is a list of inside (behind NAT on the LAN) servers, for example, web or FTP, that you can make accessible to the outside world even though NAT makes your whole inside network appear as a single machine to the outside world. MAX318M2W User’s Guide...
Page 88 (a "trigger" port). When the WiMAX Device's WAN port receives a response with a specific port number and protocol ("incoming" port), the WiMAX Device forwards the traffic to the LAN IP address of MAX318M2W User’s Guide...
Page 89 NAT traversal allows the following: • Dynamic port mapping • Learning public IP addresses • Assigning lease times to mappings Windows Messenger is an example of an application that supports NAT traversal and UPnP. Cautions with UPnP MAX318M2W User’s Guide...
Page 90 The WiMAX Device only sends UPnP multicasts to the LAN. Content Filter Internet content filtering allows you to create and enforce Internet access policies tailored to their needs. Content filtering is the ability to block certain specific URL keywords. MAX318M2W User’s Guide...
Page 91: Wan
Protocol to create VPNs. • EtherIP - Select this if you need to tunnel Ethernet and IEEE 802.3 MAC frames across an IP Internet. Bridging LAN This option enables or disables allow ARP requests to cross the WiMAX Device. MAX318M2W User’s Guide...
Page 92 Server • From ISP - Select this to have the WiMAX Device acquire its DNS server address from the ISP. • User Define - Select this to manually enter the DNS server used by the WiMAX Device. MAX318M2W User’s Guide...
Page 93: Pppoe
• MS-CHAP v1/2 -This is Microsoft’s variant of Challenge Handshake Authentication Protocol (CHAP). It allows for mutual authentication between devices. MPPE Use this option to enable or disable authentication through Microsoft Encryption Point-To-Point Encryption (MPPE) protocol. MAX318M2W User’s Guide...
Page 94: Gre
Click Network Setting > WAN > GRE to open this screen as shown next. Figure 35 GRE Screen This screen contains the following fields: Table 27 GRE LABEL DESCRIPTION Peer IP Address Enter the IP address of the GRE peer. MAX318M2W User’s Guide...
Page 95: Etherip
This screen contains the following fields: Table 29 IP LABEL DESCRIPTION IP address Enter the IP address of the LAN interface for the WiMAX Device. IP Subnet Mask Enter the IP subnet maks of the LAN interface for the WiMAX Device. MAX318M2W User’s Guide...
Page 96: Dhcp
Server - This sets the WiMAX Device as a DHCP server for the LAN. • Relay - This sets the WiMAX Device as a DHCP relay for the LAN, allowing it to pass-through IP addresses assigned to LAN devices from the ISP servers. MAX318M2W User’s Guide...
Page 97 This displays the MAC address of the DHCP leased host. Address IP Address This displays the IP address of the DHCP leased host. Remaining This displays the how much time is left on the host’s lease. Time Refresh Click this to refresh the list. MAX318M2W User’s Guide...
Page 98: Wlan
Click Network Setting > WLAN to open this screen as shown next. Figure 39 WLAN Screen Figure 40 SSID Settings (Encryption Type: WEP) This screen contains the following fields: Table 31 WLAN LABEL DESCRIPTION WiFi Settings Enable WLAN Select this to activate the wireless LAN. MAX318M2W User’s Guide...
Page 99 Select the type of authentication that you wish to use for your network: TKIP, AES or TKIP and AES. AES is more secure. Pre-shared Type a pre-shared key from 8 to 63 case-sensitive ASCII characters (including spaces and symbols). MAX318M2W User’s Guide...
Page 100: Wps
Note: You must press the other wireless device’s WPS button within two minutes of pressing this button. 7.10 MAC Address Filter Use these screens to configure a MAC (Media Access Control) address filter to restrict access to the wireless network. MAX318M2W User’s Guide...
Page 101 MAC addresses in a valid MAC address format, that is, six hexadecimal character pairs, for example, 12:34:56:78:9a:bc. Delete Click to delete a specific MAC address from the list. Click to add a MAC address to the list. Click this button when you are done adding a MAC Address. MAX318M2W User’s Guide...
Page 102: Static Route
Click this to add a new static route to the list. 7.12 Static Route Add Use these settings to configure a static route. Click Add in the Network Setting > Route > Static Route screen to open this screen as shown next. Figure 44 Static Route Screen MAX318M2W User’s Guide...
Page 103: Rip
Enter the static route metric. 7.13 RIP Use these settings to configure how the WiMAX Device exchanges information with other routers. Click Network Setting > Route > RIP to open this screen as shown next. Figure 45 RIP Screen MAX318M2W User’s Guide...
Page 104: Port Forwarding
Use these settings to forward incoming service requests to the ports on your local network. Note: Make sure you did not configure a DMZ host in the Network Setting > NAT > DMZ screen if you want to make the settings of this screen work. MAX318M2W User’s Guide...
Page 105 Click this to delete a specified rule. Wizard Click this to open the port forwarding “wizard”. Click this to add a new port forwarding rule. Click this to save any changes made to the port forwarding list. MAX318M2W User’s Guide...
Page 106: Port Forwarding Wizard
Enter the starting port number for forwarded traffic for the port Start Port forwarding rule. Forwarding End Enter the ending port number for forwarded traffic for the port Port forwarding rule. Server IP Enter the port forwarding server IP address. MAX318M2W User’s Guide...
Page 107: Port Trigger
End Port field. If you want to delete this rule, click the Delete icon. Open Protocol This indicates which protocol is used to open the port trigger ports. Open Port(s) MAX318M2W User’s Guide...
Page 108: Port Trigger Wizard
Click Network Setting > NAT > Port Trigger > Wizard Figure 49 Port Trigger Wizard Screen MAX318M2W User’s Guide...
Page 109: Trigger Port Forwarding Example
IP address. The WiMAX Device associates Jane's computer IP address with the "incoming" port range of 6970-7170. The Real Audio server responds using a port number ranging between 6970-7170. The WiMAX Device forwards the traffic to Jane’s computer IP address. MAX318M2W User’s Guide...
Page 110: Dmz
> NAT > Port Forwarding screen. Figure 51 DMZ Screen This screen contains the following fields: Table 41 DMZ LABEL DESCRIPTION DMZ Host Enter the IP address of your network DMZ host, if you have one. 0.0.0.0 means this feature is disabled. MAX318M2W User’s Guide...
Page 111: Alg
If you are using a custom UDP port number (not 5060) for SIP traffic, enter it here. Enable SIP ALG Check this box to add the base station ID to the outgoing SIP Set BSID messages. Select this option only if the media server forwarding calls requires this information. MAX318M2W User’s Guide...
Page 112: Upnp
7.18.1 Installing UPnP in Windows XP Follow the steps below to install the UPnP in Windows XP. Click Start > Control Panel. Double-click Network Connections. In the Network Connections window, click Advanced in the main menu and select Optional Networking Components …. MAX318M2W User’s Guide...
Page 113 Select Networking Service in the Components selection box and click Details. In the Networking Services window, select the Universal Plug and Play check box. Click OK to go back to the Windows Optional Networking Component Wizard window and click Next. MAX318M2W User’s Guide...
Page 114 Make sure the computer is connected to a LAN port of the WiMAX Device. Turn on your computer and the WiMAX Device. Click Start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Right-click the icon and select Properties. MAX318M2W User’s Guide...
Page 115 You may edit or delete the port mappings or click Add to manually add port mappings. When the UPnP-enabled device is disconnected from your computer, all port mappings will be deleted automatically. MAX318M2W User’s Guide...
Page 116: Web Configurator Easy Access
IP address of the WiMAX Device first. This becomes helpful if you do not know the IP address of the WiMAX Device. Follow the steps below to access the web configurator: Click Start and then Control Panel. Double-click Network Connections. MAX318M2W User’s Guide...
Page 117 Select My Network Places under Other Places. An icon with the description for each UPnP-enabled device displays under Local Network. Right-click on the icon for your WiMAX Device and select Invoke. The web configurator login screen displays. MAX318M2W User’s Guide...
Page 118: Ddns
Right-click on the icon for your WiMAX Device and select Properties. A properties window displays with basic information about the WiMAX Device. 7.19 DDNS Use this page to configure the WiMAX Device as a dynamic DNS client. Click Network Setting > DDNS Figure 54 DDNS Screen MAX318M2W User’s Guide...
Page 119: Content Filter
Use these settings to allow ("whitelist") or block ("blacklist") connections to and from specific web sites through the WiMAX Device. Click Network Setting > Content Filter to open this screen as shown next. Figure 55 Content Filter Screen MAX318M2W User’s Guide...
Page 120: Technical Reference
When WPS is activated on a device, it has two minutes to find another device that also has WPS activated. Then, the two devices connect and set up a secure network by themselves. This WiMAX Device supports Push Button Configuration only at the time of writing. MAX318M2W User’s Guide...
Page 121 PSK or WPA2-PSK pre-shared key to the enrollee. Whether WPA-PSK or WPA2-PSK is used depends on the standards supported by the devices. If the registrar is already part of a network, it sends the existing information. If not, it generates the SSID and WPA(2)-PSK randomly. MAX318M2W User’s Guide...
Page 122 It will be the registrar in all subsequent WPS connections in which it is involved. If you want a configured AP to act as an enrollee, you must reset it to its factory defaults. MAX318M2W User’s Guide...
Page 123 CLIENT 1 ENROLLEE CLIENT 2 In step 3, you add another access point (AP2) to your network. AP2 is out of range of AP1, so you cannot use AP1 for the WPS handshake with the new access MAX318M2W User’s Guide...
Page 124 (if the device supports this feature). Then, you can enter the key into the non-WPS device and join the network as normal (the non-WPS device must also support WPA-PSK or WPA2-PSK). MAX318M2W User’s Guide...
Page 125 Check the MAC addresses of your wireless clients (usually printed on a label on the bottom of the device). If there is an unknown MAC address you can remove it or reset the AP. MAX318M2W User’s Guide...
Page 126 Chapter 7 Network Settings MAX318M2W User’s Guide...
Page 127: Security
These computers will have access to Internet services such as e-mail, FTP and the World Wide Web. However, “inbound access” is not allowed (by default) unless the remote host is authorized to use a specific service. MAX318M2W User’s Guide...
Page 128: Ip Filter
If you want to delete this rule, click the Delete icon. Delete Click this to delete a specified rule. Click this to add a new filter rule. Click this to save any changes made to the list. MAX318M2W User’s Guide...
Page 129: Mac Filter
Select what time each day you want the filter rule to be effective. Enter Time times in 24-hour format; for example, 3:00pm should be entered as 15:00. Click this to add a new filter rule. Click this to save any changes made to the list. MAX318M2W User’s Guide...
Page 130: Ddos
A Local Area Network Denial (LAND) attack is a type of denial of service attack where a spoofed TCP SYN packet targets a client device’s IP address and forces it into an infinite recursive loop of querying itself and then replying, effectively locking it down. MAX318M2W User’s Guide...
Page 131 This results in the client device suffering from a buffer overflow and subsequent system crash. Prevent from Select this to ignore ping requests from the WAN. PING from WAN MAX318M2W User’s Guide...
Page 132 Chapter 8 Security MAX318M2W User’s Guide...
Page 133: The Voip General Screens
The following terms and concepts may help as you read through this chapter. Voice Coding A codec (coder/decoder) codes analog voice signals into digital signals and decodes the digital signals back into voice signals. The WiMAX Device supports the following codecs. MAX318M2W User’s Guide...
Page 134 ToS-enabled network device. See Section 9.3.1 on page 137 for more information. The Session Initiation Protocol (SIP) is an application-layer control (signaling) protocol that handles the setting up, altering and tearing down of voice and MAX318M2W User’s Guide...
Page 135: Before You Begin
Guide. If you have not already done so, then you will not be able to test your VoIP settings. 9.2 Media Click VoIP > General > Media to set up and maintain global VoIP settings. Figure 63 VoIP > General > Media MAX318M2W User’s Guide...
Page 136: Qos
T.38 is an ITU-T standard that VoIP devices use to send fax messages Jitter Length over the Internet. Select the number of milliseconds for the jitter buffer size used for transmitting T.38 fax messages. 9.2.1 QoS This section describes the features of the Quality of Service (QoS) screen. MAX318M2W User’s Guide...
Page 137: Qos Settings
Service (TOS) field in the IP header. The DS field contains a 2-bit unused field and a 6-bit DSCP field which can define up to 64 service levels. The following figure illustrates the DS field. Figure 65 DiffServ: Differentiated Service Field DSCP Unused (6-bit) (2-bit) MAX318M2W User’s Guide...
Page 138 DiffServ network. Based on the marking rule, different kinds of traffic can be marked for different priorities of forwarding. Resources can then be allocated according to the DSCP values and the configured policies. MAX318M2W User’s Guide...
Page 139: The Voip Account Screens
• The FAX screen (Section 10.8 on page 152) lets you configure which standard the phone line uses for sending FAXes. 10.1.2 What You Need to Know The following terms and concepts may help as you read through this chapter. MAX318M2W User’s Guide...
Page 140: Sip User Agent
A and B can also both act as a SIP user agent to receive the call. Figure 66 SIP User Agent SIP Proxy Server A SIP proxy server receives requests from clients and forwards them to another server. MAX318M2W User’s Guide...
Page 141 WiMAX Device’s SIP packets and sends them to the WiMAX Device. The WiMAX Device uses the public IP address and port number in the SIP packets that it sends to the SIP server (C). Figure 68 STUN MAX318M2W User’s Guide...
Page 142 Dual-Tone Multi-Frequency (DTMF) telephone call signaling uses pairs of frequencies (one lower frequency and one higher frequency) to set up calls. It is also known as Touch Tone. Each of the keys on a DTMF telephone corresponds to a different pair of frequencies. MAX318M2W User’s Guide...
Page 143: Status
WiMAX Device's phone port, you may need to subscribe to the services from your VoIP service provider. 10.2 Status Click VoIP > Account 1 (or Account 2) > Status to view VoIP settings and current status. Figure 69 VoIP > Account 1 (or Account 2) > Status MAX318M2W User’s Guide...
Page 144 WiMAX Device last restarted or was turned Connect Click this to register the WiMAX Device to the specified register server. Disconnect Click this to disconnect the connected phone with the register server. MAX318M2W User’s Guide...
Page 145: Server
VoIP service provider. You can use up to 64 printable ASCII characters. Port Number Enter the SIP proxy server’s listening port number, if your VoIP service provider gave you one. Otherwise, keep the default value. Outbound Server MAX318M2W User’s Guide...
Page 146 STUN Server Enter the IP address or domain name of the STUN server, if your VoIP service provider gave you one. Otherwise, keep the default value. Port Number Enter the STUN server’s listening port, if your VoIP service provider gave you one. Otherwise, keep the default value. MAX318M2W User’s Guide...
Page 147: Feature
ID. Call Do Not Disturb Select this to have the WiMAX Device not forward calls to the phone (DND) line. Hide User ID Select this to not have your calling number display on the callee’s caller ID. MAX318M2W User’s Guide...
Page 148 Specify the Target phone number in the No Answer CF Target field on the right. Call Waiting Setting for this SIP account Call waiting Select this to enable call waiting on the WiMAX Device. MAX318M2W User’s Guide...
Page 149: User
Table 54 VoIP > Account 1 (or Account 2) > User LABEL DESCRIPTION SIP Account Enable Select this if you want the WiMAX Device to use this account. Clear it if you do not want the WiMAX Device to use this account. MAX318M2W User’s Guide...
Page 150 Enter the maximum number of seconds the WiMAX Device has the Ring back associated phone ring for an incoming call. After this time period is expired, the WiMAX Device has the phone stop ringing. The caller will hear a busy tone then. MAX318M2W User’s Guide...
Page 151: Dialing
Table 56 VoIP > Account 1 (or Account 2) > Speed Dial LABEL DESCRIPTION Speed Dial Status Enable Select this to enable speed dial on the WiMAX Device. Speed Dial Rules - This is a list of speed dial numbers. MAX318M2W User’s Guide...
Page 152: Fax
Click this to save the changes you made in this table. 10.8 FAX Click VoIP > Account 1 (or Account 2) > FAX to configure which standard the account uses for fax services. Figure 75 VoIP > Account 1 (or Account 2) > FAX MAX318M2W User’s Guide...
Page 153: Technical Reference
The following figure displays the basic steps in the setup and tear down of a SIP call. A calls B. Table 58 SIP Call Progression 1. INVITE 2. Ringing 3. OK 4. ACK 5.Dialogue (voice traffic) 6. BYE 7. OK MAX318M2W User’s Guide...
Page 154: Sip Client Server
When you use SIP to make a VoIP call, it originates at a client and terminates at a server. A SIP client could be a computer or a SIP phone. One device can act as both a SIP client and a SIP server. MAX318M2W User’s Guide...
Page 155: The Voip Line Screens
Voice Activity Detection/Silence Suppression/Comfort Noise Voice Activity Detection (VAD) detects whether or not speech is present. This lets the WiMAX Device reduce the bandwidth that a call uses by not transmitting “silent packets” when you are not speaking. MAX318M2W User’s Guide...
Page 156: Phone
Select the volume level transmitted by the WiMAX Device. -9 is the quietest, and 9 is the loudest. Voice Rx Level Select the volume level transmitted to the WiMAX Device. -9 is the quietest, and 9 is the loudest. Caller ID MAX318M2W User’s Guide...
Page 157: Voice
This reduces the bandwidth the WiMAX Device uses. • Silence Suppression - NO CNG • Silence Suppression - Only G.711 Annexll Type • Silence Suppression - Codec Specific CN Select Disable to turn this feature off. MAX318M2W User’s Guide...
Page 158: Profile
The following table describes the labels in this screen. Table 61 VoIP > Line 1 (or Line 2) > Profile LABEL DESCRIPTION Country Profile Select the place in which the WiMAX Device is located, USA or any other country (Default). MAX318M2W User’s Guide...
Page 159: Maintenance
If it does not match, the WiMAX Device will disconnect the session immediately. There is already another remote management session with an equal or higher priority running. You may only have one remote management session running at one time. MAX318M2W User’s Guide...
Page 160 WiMAX Device through the network. The WiMAX Device supports SNMP version one (SNMPv1) and version two (SNMPv2). The next figure illustrates an SNMP management operation. Note: SNMP is only available if TCP/IP is configured. MAX318M2W User’s Guide...
Page 161 ACS. The WiMAX Device can be configured to periodically check for updates from the auto-configuration server so that the end user need not be worried about it. MAX318M2W User’s Guide...
Page 162 • GetNext - Allows the manager to retrieve the next object variable from a table or list within an agent. In SNMPv1, when a manager wants to retrieve all elements of a table from an agent, it initiates a Get operation, followed by a series of GetNext operations. MAX318M2W User’s Guide...
Page 163 The WiMAX Device responds by sending back its credentials (2), to which the server responds with its credentials along with a string of management operations (3). The client responds to the management operations (4), perhaps confirming file alterations or confirming receipt of file uploads and so on. MAX318M2W User’s Guide...
Page 164 – Hash Message Authentication Code Also known as HMAC, this code relies on cryptographic hash functions to bolster an existing protocol, such as MD5. It is a method for generating a stronger, significantly higher encryption key. MAX318M2W User’s Guide...
Page 165 MAX318M2W User’s Guide...
Page 166: Password
Select the group for which you want to change the login password. Old Password Enter the old password for the login group. New Password Enter the new password for the login group. Retype Retype the new password for the login group. MAX318M2W User’s Guide...
Page 167: Http
Select this to allow incoming connections from the WAN over either Connection HTTP or HTTPS. from WAN HTTP Session Timeout Session Enter the number of minutes (0-99) the WiMAX Device waits to delete Timeout an inactive web connection (HTTP or HTTPS). MAX318M2W User’s Guide...
Page 168: Telnet
12.5 SSH Use this screen to allow remote access to the WiMAX Device from a network connection over SSH. Click Maintenance > Remote MGMT > SSH to open this screen as shown next. Figure 86 SSH Screen MAX318M2W User’s Guide...
Page 169: Snmp
Enter the password for the incoming Get and GetNext requests from the Community management station. The default is public and allows all requests. Write Enter the password for incoming Set requests from the management Community station. The default is public and allows all requests. MAX318M2W User’s Guide...
Page 170: Cwmp
Enter the user name sent when the WiMAX Device connects to the ACS and which is used for authentication. You can enter up to 31 alphanumeric characters (a-z, A-Z, 0-9) and underscores but spaces are not allowed. MAX318M2W User’s Guide...
Page 171 CA Certificate This displays information about the currently active CA certificate. Info Client Click Browse to upload a client certificate to the WiMAX Device. Certificate File Client This displays information about the currently active client certificate. Certificate Info MAX318M2W User’s Guide...
Page 172: Oma-Dm
HMAC - Server ID and Password are encoded using a keyed Hash Message Authentication Code. Server ID Enter the identification code for the server. This is used by the WiMAX Device during the communication handshake process to identify the server. MAX318M2W User’s Guide...
Page 173 OM-DM server initiates contact with it and if you selected the checkbox on this screen. Periodical Enter the time interval (in seconds) at which the WiMAX Device Client-Initiated connects to the OMA-DM server. Interval MAX318M2W User’s Guide...
Page 174: Date
NTP (RFC 1305) - This format is similar to Time (RFC 868). Time Server Enter the IP address or URL of your time server. Check with your ISP or Address 1~4 network administrator if you are unsure of this information. MAX318M2W User’s Guide...
Page 175: Time Zone
(Hypertext Transfer Protocol) and may take up to two minutes. After a successful upload, the system restarts. Contact your service provider for information on available firmware upgrades. Note: Only use firmware for your WiMAX Device’s specific model. MAX318M2W User’s Guide...
Page 176: The Firmware Upload Process
After two minutes, log in again, and check your new firmware version in the Status screen. You might have to open a new browser window to log in. If the upload is not successful, you will be notified by error message. MAX318M2W User’s Guide...
Page 177: Upgrade Link
12.13 CWMP Upgrade Use this screen to upgrade the firmware on the WiMAX Device using CWMP Request Download. Click Maintenance > Firmware Upgrade > CWMP Upgrade to open this screen as shown next. Figure 94 CWMP Upgrade Screen MAX318M2W User’s Guide...
Page 178: Backup
Once your device is configured and functioning properly, it is highly recommended that you back up your configuration file before making configuration changes. The backup configuration file is useful if you need to return to your previous settings. MAX318M2W User’s Guide...
Page 179: Restore
IP address (192.168.5.1). See the Quick Start Guide or the appendices for details on how to set up your computer’s IP address. You might have to open a new browser to log in again. MAX318M2W User’s Guide...
Page 180: Factory Defaults
12.17 Log Setting Use this screen to configure which type of events on the WiMAX Device are logged. Click Maintenance > LOG > Log Setting to open this screen as shown next. Figure 98 Log Setting Screen MAX318M2W User’s Guide...
Page 181: Log Display
Figure 99 Log Display Screen This screen contains the following fields: Table 79 Log Display LABEL DESCRIPTION Display Level Select the type of logs to display from this menu. Refresh Click this to refresh the logs in the display window. MAX318M2W User’s Guide...
Page 182: Ping Test
DESCRIPTION IP Address Enter the IP address or domain name of a target device to which this test will send. Traceroute Click this to start the test. The result will show at the bottom of the screen. MAX318M2W User’s Guide...
Page 183: About
Use this screen to perform a software restart of the WiMAX Device. You may log in again within a few minutes of using the reboot button. Click Maintenance > Reboot to open this screen as shown next. Figure 103 Reboot Screen MAX318M2W User’s Guide...
Page 184 Click this button to have the device perform a software restart. The Power LED blinks as it restarts and the shines steadily if the restart is successful. Note: Wait one minute before logging back into the WiMAX Device after a restart. MAX318M2W User’s Guide...
Page 185: Troubleshooting
One of the LEDs does not behave as expected. Make sure you understand the normal behavior of the LED. See Section 1.2.1 on page 20 for more information. Check the hardware connections. See the Quick Start Guide. MAX318M2W User’s Guide...
Page 186: Wimax Device Access And Login
I cannot see or access the Login screen in the web configurator. Make sure you are using the correct IP address. • The default IP address is . • If you changed the IP address (Section 7.6 on page 95), use the new IP address. MAX318M2W User’s Guide...
Page 187 Disconnect and re-connect the power adapter or cord to the WiMAX Device. If this does not work, you have to reset the WiMAX Device to its factory defaults. Section 12.16 on page 180. MAX318M2W User’s Guide...
Page 188: Internet Access
WiMAX Device), but my Internet connection is not available any more. Check the hardware connections, and make sure the LEDs are behaving as expected. See the Quick Start Guide and Section 1.2.1 on page Disconnect and re-connect the power adapter to the WiMAX Device. MAX318M2W User’s Guide...
Page 189: Reset The Wimax Device To Its Factory Defaults
If you reset the WiMAX Device, you lose all of the changes you have made. The WiMAX Device re-loads its default settings, and the password resets to 1234. You have to make all of your changes again. MAX318M2W User’s Guide...
Page 190: Pop-Up Windows, Javascript And Java Permissions
The password is “1234”. If the WiMAX Device does not restart automatically, disconnect and reconnect the WiMAX Device’s power. Then, follow the directions above again. 13.4.1 Pop-up Windows, JavaScript and Java Permissions Please see Appendix C on page 227. MAX318M2W User’s Guide...
Page 191: Product Specifications
WEEE Eco directive 2002/95/EC. Full RoHS (6/6) Water Tightness: IP65 Wind Resistance Testing: Hurricane/ Wind Speed 32.7- 36.9(m/s) Comply with WiMAX Forum Wave II standard. Environmental Specifications 2002/95/EC (RoHS) Restriction of Hazardous Substances Directive 2002/96/EC (WEEE) (WEEE) Waste Electrical and Electronic Equipment Directive MAX318M2W User’s Guide...
Page 192 3 Counts (3 sec) : -60dBm <= RSSI > -70dBm • 2 Counts (2 sec) : -70dBm <= RSSI > -80dBm • 1 Counts (1 sec) : -80dBm <= RSSI > -90dBm • 0 Counts no buzzer : -90dBm >= RSSI MAX318M2W User’s Guide...
Page 193 Receiver Diversity Maximum Ratio Combining (MRC) Receiver Adjacent Channel The receiver adjacent channel rejection measured under Rejection the conditions defined in IEEE 802.16e-2005 is at least: - 10 dB for 16QAM ¾, -4 dB for 64QAM ¾. MAX318M2W User’s Guide...
Page 194 Outdoor Unit Ethernet Port Surge Protection IEC-61000-45 /wire-wire: ± 1KV/20 Ohm Indoor Unit AC & Ethernet IEC-61000-45 /wire-ground: ± 2KV/20 Ohm (1.2/20 use) Port IEC-61000-45 /wire-ground: ± 4KV/12 Ohm (1.2/20 use) Surge Protection Outdoor Unit Ethernet Port MAX318M2W User’s Guide...
Page 195: Appendix A Wimax Security
(secret) key. The public key is used for encryption and the private key is used for decryption. You can decrypt a message only if you have the private key. Public key certificates (or ‘digital IDs’) allow users to verify each other’s identity. MAX318M2W User’s Guide...
Page 196 Sent by the RADIUS server to indicate that it has started or stopped accounting. In order to ensure network security, the access point and the RADIUS server use a shared secret key, which is a password they both know. The key is not sent over MAX318M2W User’s Guide...
Page 197 This series of ‘chained’ blocks creates a message authentication code (MAC or CMAC) that ensures the encrypted data has not been tampered with. MAX318M2W User’s Guide...
Page 198 Client authentication is then done by sending username and password through the secure connection, thus client identity is protected. For client authentication, EAP-TTLS supports EAP methods and legacy authentication methods such as PAP, CHAP, MS-CHAP and MS-CHAP v2. MAX318M2W User’s Guide...
Page 199: Appendix B Setting Up Your Computer's Ip Address
200 • Windows Vista page 203 • Mac OS X: 10.3 and 10.4 page 207 • Mac OS X: 10.5 page 211 • Linux: Ubuntu 8 (GNOME) page 214 • Linux: openSUSE 10.3 (KDE) page 220 MAX318M2W User’s Guide...
Page 200 The following example uses the default Windows XP display theme but can also apply to Windows 2000 and Windows NT. Click Start > Control Panel. Figure 104 Windows XP: Start Menu In the Control Panel, click the Network Connections icon. Figure 105 Windows XP: Control Panel MAX318M2W User’s Guide...
Page 201 Right-click Local Area Connection and then select Properties. Figure 106 Windows XP: Control Panel > Network Connections > Properties On the General tab, select Internet Protocol (TCP/IP) and then click Properties. Figure 107 Windows XP: Local Area Connection Properties MAX318M2W User’s Guide...
Page 202 In the Command Prompt window, type "ipconfig" and then press [ENTER]. You can also go to Start > Control Panel > Network Connections, right-click a network connection, click Status and then click the Support tab to view your IP address and connection information. MAX318M2W User’s Guide...
Page 203: Windows Vista
Click Start > Control Panel. Figure 109 Windows Vista: Start Menu In the Control Panel, click the Network and Internet icon. Figure 110 Windows Vista: Control Panel Click the Network and Sharing Center icon. Figure 111 Windows Vista: Network And Internet MAX318M2W User’s Guide...
Page 204 Figure 112 Windows Vista: Network and Sharing Center Right-click Local Area Connection and then select Properties. Figure 113 Windows Vista: Network and Sharing Center Note: During this procedure, click Continue whenever Windows displays a screen saying that it needs your permission to continue. MAX318M2W User’s Guide...
Page 205 Appendix B Setting Up Your Computer’s IP Address Select Internet Protocol Version 4 (TCP/IPv4) and then select Properties. Figure 114 Windows Vista: Local Area Connection Properties MAX318M2W User’s Guide...
Page 206 In the Command Prompt window, type "ipconfig" and then press [ENTER]. You can also go to Start > Control Panel > Network Connections, right-click a network connection, click Status and then click the Support tab to view your IP address and connection information. MAX318M2W User’s Guide...
Page 207 The screens in this section are from Mac OS X 10.4 but can also apply to 10.3. Click Apple > System Preferences. Figure 116 Mac OS X 10.4: Apple Menu In the System Preferences window, click the Network icon. Figure 117 Mac OS X 10.4: System Preferences MAX318M2W User’s Guide...
Page 208 Configure. Figure 118 Mac OS X 10.4: Network Preferences For dynamically assigned settings, select Using DHCP from the Configure IPv4 list in the TCP/IP tab. Figure 119 Mac OS X 10.4: Network Preferences > TCP/IP Tab. MAX318M2W User’s Guide...
Page 209 • In the IP Address field, type your IP address. • In the Subnet Mask field, type your subnet mask. • In the Router field, type the IP address of your device. Figure 120 Mac OS X 10.4: Network Preferences > Ethernet MAX318M2W User’s Guide...
Page 210 Click Apply Now and close the window. Check your TCP/IP properties by clicking Applications > Utilities > Network Utilities, and then selecting the appropriate Network Interface from the Info tab. Figure 121 Mac OS X 10.4: Network Utility MAX318M2W User’s Guide...
Page 211 The screens in this section are from Mac OS X 10.5. Click Apple > System Preferences. Figure 122 Mac OS X 10.5: Apple Menu In System Preferences, click the Network icon. Figure 123 Mac OS X 10.5: Systems Preferences MAX318M2W User’s Guide...
Page 212 From the Configure list, select Using DHCP for dynamically assigned settings. For statically assigned settings, do the following: • From the Configure list, select Manually. • In the IP Address field, enter your IP address. • In the Subnet Mask field, enter your subnet mask. MAX318M2W User’s Guide...
Page 213 Appendix B Setting Up Your Computer’s IP Address • In the Router field, enter the IP address of your WiMAX Device. Figure 125 Mac OS X 10.5: Network Preferences > Ethernet Click Apply and close the window. MAX318M2W User’s Guide...
Page 214 The following screens use the default Ubuntu 8 installation. Note: Make sure you are logged in as the root administrator. Follow the steps below to configure your computer IP address in GNOME: MAX318M2W User’s Guide...
Page 215 When the Network Settings window opens, click Unlock to open the Authenticate window. (By default, the Unlock button is greyed out until clicked.) You cannot make changes to your configuration unless you first enter your admin password. Figure 128 Ubuntu 8: Network Settings > Connections MAX318M2W User’s Guide...
Page 216 In the Authenticate window, enter your admin account name and password then click the Authenticate button. Figure 129 Ubuntu 8: Administrator Account Authentication In the Network Settings window, select the connection that you want to configure, then click Properties. Figure 130 Ubuntu 8: Network Settings > Connections MAX318M2W User’s Guide...
Page 217 • In the Configuration list, select Static IP address if you have a static IP address. Fill in the IP address, Subnet mask, and Gateway address fields. Click OK to save the changes and close the Properties dialog box and return to the Network Settings screen. MAX318M2W User’s Guide...
Page 218 Figure 132 Ubuntu 8: Network Settings > DNS Click the Close button to apply the changes. Verifying Settings Check your TCP/IP properties by clicking System > Administration > Network Tools, and then selecting the appropriate Network device from the Devices MAX318M2W User’s Guide...
Page 219 Appendix B Setting Up Your Computer’s IP Address tab. The Interface Statistics column shows data if your connection is working properly. Figure 133 Ubuntu 8: Network Tools MAX318M2W User’s Guide...
Page 220 Note: Make sure you are logged in as the root administrator. Follow the steps below to configure your computer IP address in the KDE: Click K Menu > Computer > Administrator Settings (YaST). Figure 134 openSUSE 10.3: K Menu > Computer Menu MAX318M2W User’s Guide...
Page 221 When the Run as Root - KDE su dialog opens, enter the admin password and click OK. Figure 135 openSUSE 10.3: K Menu > Computer Menu When the YaST Control Center window opens, select Network Devices and then click the Network Card icon. Figure 136 openSUSE 10.3: YaST Control Center MAX318M2W User’s Guide...
Page 222 Appendix B Setting Up Your Computer’s IP Address When the Network Settings window opens, click the Overview tab, select the appropriate connection Name from the list, and then click the Configure button. Figure 137 openSUSE 10.3: Network Settings MAX318M2W User’s Guide...
Page 223 Select Dynamic Address (DHCP) if you have a dynamic IP address. Select Statically assigned IP Address if you have a static IP address. Fill in the IP address, Subnet mask, and Hostname fields. Click Next to save the changes and close the Network Card Setup window. MAX318M2W User’s Guide...
Page 224 If you know your DNS server IP address(es), click the Hostname/DNS tab in Network Settings and then enter the DNS server information in the fields provided. Figure 139 openSUSE 10.3: Network Settings Click Finish to save your settings and close the window. MAX318M2W User’s Guide...
Page 225 From the Options sub-menu, select Show Connection Information. Figure 140 openSUSE 10.3: KNetwork Manager When the Connection Status - KNetwork Manager window opens, click the Statistics tab to see if your connection is working properly. Figure 141 openSUSE: Connection Status - KNetwork Manager MAX318M2W User’s Guide...
Page 226 Appendix B Setting Up Your Computer’s IP Address MAX318M2W User’s Guide...
Page 227: Appendix C Pop-Up Windows, Javascript And Java Permissions
Disable Pop-up Blockers In Internet Explorer, select Tools, Pop-up Blocker and then select Turn Off Pop-up Blocker. Figure 142 Pop-up Blocker You can also check if pop-up blocking is disabled in the Pop-up Blocker section in the Privacy tab. MAX318M2W User’s Guide...
Page 228 Click Apply to save this setting. Enable Pop-up Blockers with Exceptions Alternatively, if you only want to allow pop-up windows from your device, see the following steps. In Internet Explorer, select Tools, Internet Options and then the Privacy tab. MAX318M2W User’s Guide...
Page 229 Select Settings…to open the Pop-up Blocker Settings screen. Figure 144 Internet Options: Privacy Type the IP address of your device (the web page that you do not want to have blocked) with the prefix “http://”. For example, http://192.168.167.1. MAX318M2W User’s Guide...
Page 230 Figure 145 Pop-up Blocker Settings Click Close to return to the Privacy screen. Click Apply to save this setting. JavaScript If pages of the web configurator do not display properly in Internet Explorer, check that JavaScript is allowed. MAX318M2W User’s Guide...
Page 231 Figure 146 Internet Options: Security Click the Custom Level... button. Scroll down to Scripting. Under Active scripting make sure that Enable is selected (the default). Under Scripting of Java applets make sure that Enable is selected (the default). MAX318M2W User’s Guide...
Page 232 Figure 147 Security Settings - Java Scripting Java Permissions From Internet Explorer, click Tools, Internet Options and then the Security tab. Click the Custom Level... button. Scroll down to Microsoft VM. Under Java permissions make sure that a safety level is selected. MAX318M2W User’s Guide...
Page 233 Click OK to close the window. Figure 148 Security Settings - Java JAVA (Sun) From Internet Explorer, click Tools, Internet Options and then the Advanced tab. Make sure that Use Java 2 for <applet> under Java (Sun) is selected. MAX318M2W User’s Guide...
Page 234 Mozilla Firefox 2.0 screens are used here. Screens for other versions may vary. You can enable Java, Javascript and pop-ups in one screen. Click Tools, then click Options in the screen that appears. Figure 150 Mozilla Firefox: TOOLS > Options MAX318M2W User’s Guide...
Page 235 Appendix C Pop-up Windows, JavaScript and Java Permissions Click Content.to show the screen below. Select the check boxes as shown in the following screen. Figure 151 Mozilla Firefox Content Security MAX318M2W User’s Guide...
Page 236 Appendix C Pop-up Windows, JavaScript and Java Permissions MAX318M2W User’s Guide...
Page 237: Appendix D Ip Addresses And Subnetting
). Each of these four parts is known as an octet. An octet is an eight- digit binary number (for example 11000000, which is 192 in decimal notation). Therefore, each octet has a possible range of 00000000 to 11111111 in binary, or 0 to 255 in decimal. MAX318M2W User’s Guide...
Page 238: Subnet Masks
Table 87 IP Address Network Number and Host ID Example OCTET: OCTET: OCTET: OCTET (192) (168) IP Address (Binary) 11000000 10101000 00000001 00000010 Subnet Mask (Binary) 11111111 11111111 11111111 00000000 Network Number 11000000 10101000 00000001 Host ID 00000010 MAX318M2W User’s Guide...
Page 239 MAXIMUM NUMBER OF SUBNET MASK HOST ID SIZE HOSTS 8 bits 255.0.0.0 24 bits – 2 16777214 16 bits 255.255.0.0 16 bits – 2 65534 24 bits 255.255.255.0 8 bits – 2 29 bits 255.255.255.2 3 bits – 2 MAX318M2W User’s Guide...
Page 240 In this example, the company network address is 192.168.1.0. The first three octets of the address (192.168.1) are the network number, and the remaining octet is the host ID, allowing a maximum of 2 – 2 or 254 possible hosts. MAX318M2W User’s Guide...
Page 241 You can “borrow” one of the host ID bits to divide the network 192.168.1.0 into two separate sub-networks. The subnet mask is now 25 bits (255.255.255.128 or /25). The “borrowed” host ID bit can have a value of either 0 or 1, allowing two subnets; 192.168.1.0 /25 and 192.168.1.128 /25. MAX318M2W User’s Guide...
Page 242 Similarly, to divide a 24-bit address into four subnets, you need to “borrow” two host ID bits to give four possible combinations (00, 01, 10 and 11). The subnet mask is 26 bits (11111111.11111111.11111111.11000000) or 255.255.255.192. MAX318M2W User’s Guide...
Page 243 Lowest Host ID: 192.168.1.129 192.168.1.128 Broadcast Address: Highest Host ID: 192.168.1.190 192.168.1.191 Table 94 Subnet 4 LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER VALUE IP Address 192.168.1. IP Address (Binary) 11000000.10101000.00000001 11000000 Subnet Mask (Binary) 11111111.11111111.11111111 11000000 MAX318M2W User’s Guide...
Page 244 The following table is a summary for subnet planning on a network with a 24-bit network number. Table 96 24-bit Network Number Subnet Planning NO. “BORROWED” NO. HOSTS PER SUBNET MASK NO. SUBNETS HOST BITS SUBNET 255.255.255.128 (/25) 255.255.255.192 (/26) 255.255.255.224 (/27) 255.255.255.240 (/28) 255.255.255.248 (/29) 255.255.255.252 (/30) 255.255.255.254 (/31) MAX318M2W User’s Guide...
Page 245 Device that is easy to remember (for instance, 192.168.1.1) but make sure that no other device on your network is using that IP address. The subnet mask specifies the network number portion of an IP address. Your WiMAX Device will compute the subnet mask automatically based on the IP MAX318M2W User’s Guide...
Page 246 A has a static (or fixed) IP address that is the same as the IP address that a DHCP server assigns to computer B which is a DHCP client. Neither can access the Internet. This problem can be solved by assigning a different static IP MAX318M2W User’s Guide...
Page 247 Figure 156 Conflicting Computer IP Addresses Example Conflicting Computer and Router IP Addresses Example More than one device can not use the same IP address. In the following example, the computer and the router’s LAN port both use 192.168.1.1 as the IP address. MAX318M2W User’s Guide...
Page 248 Appendix D IP Addresses and Subnetting The computer cannot access the Internet. This problem can be solved by assigning a different IP address to the computer or the router’s LAN port. Figure 157 Conflicting Computer and Router IP Addresses Example MAX318M2W User’s Guide...
Page 249: Appendix E Importing Certificates
In this appendix, you can import a public key certificate for: • Internet Explorer on page 250 • Firefox on page 260 • Opera on page 266 • Konqueror on page 274 MAX318M2W User’s Guide...
Page 250 If your device’s web configurator is set to use SSL certification, then the first time you browse to it you are presented with a certification error. Figure 158 Internet Explorer 7: Certification Error Click Continue to this website (not recommended). Figure 159 Internet Explorer 7: Certification Error MAX318M2W User’s Guide...
Page 251 Appendix E Importing Certificates In the Address Bar, click Certificate Error > View certificates. Figure 160 Internet Explorer 7: Certificate Error In the Certificate dialog box, click Install Certificate. Figure 161 Internet Explorer 7: Certificate MAX318M2W User’s Guide...
Page 252 Figure 162 Internet Explorer 7: Certificate Import Wizard If you want Internet Explorer to Automatically select certificate store based on the type of certificate, click Next again and then go to step 9. Figure 163 Internet Explorer 7: Certificate Import Wizard MAX318M2W User’s Guide...
Page 253 Browse. Figure 164 Internet Explorer 7: Certificate Import Wizard In the Select Certificate Store dialog box, choose a location in which to save the certificate and then click OK. Figure 165 Internet Explorer 7: Select Certificate Store MAX318M2W User’s Guide...
Page 254 Appendix E Importing Certificates In the Completing the Certificate Import Wizard screen, click Finish. Figure 166 Internet Explorer 7: Certificate Import Wizard 10 If you are presented with another Security Warning, click Yes. Figure 167 Internet Explorer 7: Security Warning MAX318M2W User’s Guide...
Page 255 12 The next time you start Internet Explorer and go to a ZyXEL web configurator page, a sealed padlock icon appears in the address bar. Click it to view the page’s Website Identification information. Figure 169 Internet Explorer 7: Website Identification MAX318M2W User’s Guide...
Page 256 Figure 170 Internet Explorer 7: Public Key Certificate File In the security warning dialog box, click Open. Figure 171 Internet Explorer 7: Open File - Security Warning Refer to steps 4-12 in the Internet Explorer procedure beginning on page 250 complete the installation process. MAX318M2W User’s Guide...
Page 257 This section shows you how to remove a public key certificate in Internet Explorer Open Internet Explorer and click TOOLS > Internet Options. Figure 172 Internet Explorer 7: Tools Menu In the Internet Options dialog box, click Content > Certificates. Figure 173 Internet Explorer 7: Internet Options MAX318M2W User’s Guide...
Page 258 Remove. Figure 174 Internet Explorer 7: Certificates In the Certificates confirmation, click Yes. Figure 175 Internet Explorer 7: Certificates In the Root Certificate Store dialog box, click Yes. Figure 176 Internet Explorer 7: Root Certificate Store MAX318M2W User’s Guide...
Page 259 Appendix E Importing Certificates The next time you go to the web site that issued the public key certificate you just removed, a certification error appears. MAX318M2W User’s Guide...
Page 260 If your device’s web configurator is set to use SSL certification, then the first time you browse to it you are presented with a certification error. Select Accept this certificate permanently and click OK. Figure 177 Firefox 2: Website Certified by an Unknown Authority MAX318M2W User’s Guide...
Page 261 The certificate is stored and you can now connect securely to the web configurator. A sealed padlock appears in the address bar, which you can click to open the Page Info > Security window to view the web page’s security information. Figure 178 Firefox 2: Page Info MAX318M2W User’s Guide...
Page 262 Open Firefox and click TOOLS > Options. Figure 179 Firefox 2: Tools Menu In the Options dialog box, click ADVANCED > Encryption > View Certificates. Figure 180 Firefox 2: Options MAX318M2W User’s Guide...
Page 263 Use the Select File dialog box to locate the certificate and then click Open. Figure 182 Firefox 2: Select File The next time you visit the web site, click the padlock in the address bar to open the Page Info > Security window to see the web page’s security information. MAX318M2W User’s Guide...
Page 264 This section shows you how to remove a public key certificate in Firefox 2. Open Firefox and click TOOLS > Options. Figure 183 Firefox 2: Tools Menu In the Options dialog box, click ADVANCED > Encryption > View Certificates. Figure 184 Firefox 2: Options MAX318M2W User’s Guide...
Page 265 In the Delete Web Site Certificates dialog box, click OK. Figure 186 Firefox 2: Delete Web Site Certificates The next time you go to the web site that issued the public key certificate you just removed, a certification error appears. MAX318M2W User’s Guide...
Page 266 If your device’s web configurator is set to use SSL certification, then the first time you browse to it you are presented with a certification error. Click Install to accept the certificate. Figure 187 Opera 9: Certificate signer not found MAX318M2W User’s Guide...
Page 267 Appendix E Importing Certificates The next time you visit the web site, click the padlock in the address bar to open the Security information window to view the web page’s security details. Figure 188 Opera 9: Security information MAX318M2W User’s Guide...
Page 268 Rather than browsing to a ZyXEL web configurator and installing a public key certificate when prompted, you can install a stand-alone certificate file if one has been issued to you. Open Opera and click TOOLS > Preferences. Figure 189 Opera 9: Tools Menu MAX318M2W User’s Guide...
Page 269 Appendix E Importing Certificates In Preferences, click ADVANCED > Security > Manage certificates. Figure 190 Opera 9: Preferences MAX318M2W User’s Guide...
Page 270 Appendix E Importing Certificates In the Certificates Manager, click Authorities > Import. Figure 191 Opera 9: Certificate manager Use the Import certificate dialog box to locate the certificate and then click Open. Figure 192 Opera 9: Import certificate MAX318M2W User’s Guide...
Page 271 Next, click OK. Figure 194 Opera 9: Install authority certificate The next time you visit the web site, click the padlock in the address bar to open the Security information window to view the web page’s security details. MAX318M2W User’s Guide...
Page 272 This section shows you how to remove a public key certificate in Opera 9. Open Opera and click TOOLS > Preferences. Figure 195 Opera 9: Tools Menu In Preferences, ADVANCED > Security > Manage certificates. Figure 196 Opera 9: Preferences MAX318M2W User’s Guide...
Page 273 The next time you go to the web site that issued the public key certificate you just removed, a certification error appears. Note: There is no confirmation when you delete a certificate authority, so be absolutely certain that you want to go through with it before clicking the button. MAX318M2W User’s Guide...
Page 274 If your device’s web configurator is set to use SSL certification, then the first time you browse to it you are presented with a certification error. Click Continue. Figure 198 Konqueror 3.5: Server Authentication Click Forever when prompted to accept the certificate. Figure 199 Konqueror 3.5: Server Authentication MAX318M2W User’s Guide...
Page 275 Appendix E Importing Certificates Click the padlock in the address bar to open the KDE SSL Information window and view the web page’s security details. Figure 200 Konqueror 3.5: KDE SSL Information MAX318M2W User’s Guide...
Page 276 Figure 201 Konqueror 3.5: Public Key Certificate File In the Certificate Import Result - Kleopatra dialog box, click OK. Figure 202 Konqueror 3.5: Certificate Import Result The public key certificate appears in the KDE certificate manager, Kleopatra. Figure 203 Konqueror 3.5: Kleopatra MAX318M2W User’s Guide...
Page 277 Appendix E Importing Certificates The next time you visit the web site, click the padlock in the address bar to open the KDE SSL Information window to view the web page’s security details. MAX318M2W User’s Guide...
Page 278 On the Peer SSL Certificates tab, select the certificate you want to delete and then click Remove. Figure 205 Konqueror 3.5: Configure The next time you go to the web site that issued the public key certificate you just removed, a certification error appears. MAX318M2W User’s Guide...
Page 279 Appendix E Importing Certificates Note: There is no confirmation when you remove a certificate authority, so be absolutely certain you want to go through with it before clicking the button. MAX318M2W User’s Guide...
Page 280 Appendix E Importing Certificates MAX318M2W User’s Guide...
Page 281: Appendix F Common Services
Border Gateway Protocol. BOOTP_CLIENT DHCP Client. BOOTP_SERVER DHCP Server. CU-SEEME 7648 A popular videoconferencing solution from White Pines Software. 24032 TCP/UDP Domain Name Server, a service that matches web names (for example www.zyxel.com) to IP numbers. MAX318M2W User’s Guide...
Page 282 ICMP echo requests to test whether or not a remote host is reachable. POP3 Post Office Protocol version 3 lets a client computer get e-mail from a POP3 server through a temporary connection (TCP/IP or other). MAX318M2W User’s Guide...
Page 283 Access Controller Access Control System). TELNET Telnet is the login and terminal emulation protocol common on the Internet and in UNIX environments. It operates over TCP/IP networks. Its primary function is to allow users to log into remote host systems. MAX318M2W User’s Guide...
Page 284 Table 98 Commonly Used Services (continued) NAME PROTOCOL PORT(S) DESCRIPTION TFTP Trivial File Transfer Protocol is an Internet file transfer protocol similar to FTP, but uses the UDP (User Datagram Protocol) rather than TCP (Transmission Control Protocol). VDOLIVE 7000 Another videoconferencing solution. MAX318M2W User’s Guide...
Page 285: Appendix G Legal Information
ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimers ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein.
Page 286 • To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. 注意 ! 依據低功率電波輻射性電機管理辦法第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。 MAX318M2W User’s Guide...
Page 287 ZyXEL. This warranty shall not apply if the product has been modified, misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions. MAX318M2W User’s Guide...
Page 288 To obtain the services of this warranty, contact your vendor. You may also refer to the warranty policy for the region in which you bought the device at http:// www.zyxel.com/web/support_warranty_info.php. Registration Register your product online to receive e-mail notices of firmware upgrades and information at www.zyxel.com. MAX318M2W User’s Guide...
Page 289: Index
UPnP counter mode see CCMP coverage area cryptography base station see BS 63–64 links data 195–197 BYE request decryption encryption flow DHCP server diameter 65, 66 MAX318M2W User’s Guide...
Page 290 Internet Telephony Service Provider EAP-TTLS see ITSP echo cancellation interoperability encryption 195–197 IP-PBX traffic ITSP Ethernet ITU-T encapsulation Extensible Authorization Protocol see EAP request and reply FCC interference statement firewall restrictions limitations G.168 G.711 G.729 MAC address MAX318M2W User’s Guide...
Page 291 Shared Secret Key outbound proxy Real-time Transport Protocol see RTP outbound proxy server register server registration product related documentation remote management and NAT pattern-spotting remote management limitations required bandwidth PBX services RFC 1889 RFC 3489 peer-to-peer calls per-hop behavior MAX318M2W User’s Guide...
Page 292 Universal Plug and Play user agent see UPnP SIP outbound proxy UPnP application SNMP auto-discovery manager security issues sound quality Windows XP 63, 64 use NAT SSID user agent, SIP STUN 141, 142 user authentication subnet mask subnetting subscriber station MAX318M2W User’s Guide...
Page 293 SSID 100, 120, 121 adding stations example limitations push button 100, 121 Wireless Metropolitan Area Network see MAN wireless network access standard wireless security wizard setup 100, 120, 121 adding stations example limitations push button 100, 121 MAX318M2W User’s Guide...
Page 294 Index MAX318M2W User’s Guide...
