ITEM
PART NO.
1
0G80700ST14
2
0G81020ST14
0G81030ST14
0G81040ST14
0G81060ST14
3
0C2237
3A
077220
3B
077220A
4
074908
5
024912
6
0A1658
7
063617
8
0E7889
0F9213
9
0A1495
10
0A1661
11
081108
12
0G8095AST14
13
0G81300ST14
14
0F4790
15
023897
16
022717A
17
0E6155
18
0G8233A
19
0G8139
0G8140
0H6394
0G8141
20
074138
21
036933
22
077033
23
048766
24
022152
25
0A7215
26
066849
27
0H6399A
0H6399B
0H6399C
28
0D2572
29
073590A
30
0E7888
31
0E7888A
32
0E7888B
33
0E7888C
34
0E7888D
35
0E7888E
36
0G80860ST14
37
0H6395
0H6396
0H6397
0E7889
Load Center Exploded View Drawing 0H6388-A
QTY.
DESCRIPTION
1
GTS LOAD CENTER ENCLOSURE GRAY
1
COVER 10 POS.GTS LOAD CTR GRAY
1
COVER 12 POS.GTS LOAD CTR GRAY
1
COVER 14 POS.GTS LOAD CTR GRAY
1
COVER 16 POS.GTS LOAD CTR GRAY
1
TRANSFER SWITCH HOME STANDBY 100A 2P 250V
1
COIL UTILITY
1
COIL STANDBY
4
SCREW HHTT M5-0.8 X 10
1
SCREW TAPTITE 1/4-20 X 5/8
1
LOCK WASHER, SPECIAL-1/4"
1
RELAY PANEL 12VDC DPDT 10A@240VAC
1
12CIR L/CENTR 125A/240V (ALSO USED FOR 10 CIRCUIT)
1
16CIR L/CENTR 125A/240V (ALSO USED FOR 14 CIRCUIT)
4
SCREW HHTT M4-0.7 X 10
2
RIVET POP .156" X .675"
1
PLUG PLASTIC
1
HARNESS ADAPTER PLATE GRAY
1
SUBPLATE GTS LOAD CENTER GRAY
5.28"
U-CHANNEL
6
WASHER FLAT #10 ZINC
1
GROMMET 3/8 X 1/16 X 1/4
1
ARM EXTENDER PIN
4
CABLE TIE SELF MOUNTING 4.3LG
1
HARN GTS-MAIN PNL 10CIR W/NEUT
1
HARN GTS-MAIN PNL 12CIR W/NEUT
1
HARN GTS-MAIN PNL 14CIR W/NEUT
1
HARN GTS-MAIN PNL 16CIR W/NEUT
3
LUG QUICK DISCONNECT NI-S 10X45 DEG BRASS / TIN
6
SCREW PPHM #10-32X3/8
6
LUG SLDLSS 1/0-#14X9/16 AL/CU
1
BLOCK TERM 20A 2 X 6 X 1100V
6
WASHER LOCK #10
10
SCREW SW 1/4"-20 X 5/8" WITH WASHER
2
SCREW HHTT M5-0.8 X 16 (10, 12, 14, 16 CIRCUIT)
1
HARNESS LOAD CTR INT.CONN 10-16 (NOT SHOWN)
1
HARNESS LOAD CTR INT.CONN T1 (NOT SHOWN)
1
HARNESS LOAD CTR INT.CONN T2 (NOT SHOWN)
1
FUSEBLOCK 30A 600V 3POS W/SQ
3
FUSE 5A
A/R
CIRCUIT BREAKER 20A 2P
A/R
CIRCUIT BREAKER 30A 2P
A/R
CIRCUIT BREAKER 15A 1P
A/R
CIRCUIT BREAKER 20A 1P
A/R
CIRCUIT BREAKER 40A 2P
A/R
CIRCUIT BREAKER 50A 2P
1
HARNESS ENTRY COVER GRAY
1
HARN GTS-EXT CONN BOX 8KW
1
HARN GTS-EXT CONN BOX 10KW
1
HARN GTS-EXT CONN BOX 14/17KW
1
12CIR L/CENTR 125A/240V (ALSO USED FOR 10 CIRCUIT)
10
12
14
16 CIRCUIT
1
1
1
1
1
3
5
4
5
3
3
6
5
1
1
1
1
15
