remove the other end of the same cable from the booster
battery.
11. Remove the other cable by disconnecting at the discharged
battery first and then disconnect the opposite end from the
booster battery.
12. Discard the damp cloths that were placed over the battery
vent caps.
WARNING
Any procedure other than the preceding could result in:
(a) personal injury caused by electrolyte squirting out the
battery vents,
(b) personal injury or property damage due to battery
explosion,
(c) damage to the charging system of the booster vehicle or
of the immobilized vehicle.
Do not attempt to jump start a vehicle having a frozen battery
because the battery may rupture or explode. If a frozen battery
is suspected, examine all fill vents on the battery. If ice can
be seen or if the electrolyte fluid cannot be seen, do not
attempt to start with jumper cables as long as the battery
remains frozen.

Troubleshooting

While normal care and regular maintenance will extend the life
of your equipment, prolonged or constant use may eventually
require that service be performed to allow it to continue to
operating properly.
This troubleshooting guide lists the most common problems,
their causes and remedies.
Refer to Maintenance Procedures for instructions on how to
perform most of these minor adjustments and service repairs
yourself. If you prefer, all of these procedures can be performed
for you by your local authorized dealer.
WARNING
Remove ignition key prior to performing maintenance on the
unit.
To avoid serious injury, perform maintenance on the unit or
mower deck only when the engine is stopped and the parking
brake is engaged.
Always remove the ignition key, disconnect the spark plug
wire(s) and fasten it away from the plug(s) before beginning
the maintenance, to prevent accidental starting of the engine.

Troubleshooting Charts

Troubleshooting the Rider
Problem: Engine will not turn over or start.
Cause
Parking brake not engaged.
36
Remedy
Engage parking brake.
Problem: Engine will not turn over or start.
PTO (electric clutch) switch in ON
position.
Ground speed control levers not in
"NEUTRAL" position.
Out of fuel.
Engine flooded.
Fuse blown.
Battery terminals require cleaning.
Battery discharged or dead.
Wiring loose or broken.
Solenoid or starter motor faulty.
Safety interlock switch faulty.
Spark plug(s) faulty, fouled, or
incorrectly gapped.
Water in fuel.
Gas is old or stale.
Problem: Engine starts hard or runs poorly.
Cause
Fuel mixture too rich.
Spark plug(s) faulty, fouled, or
incorrectly gapped.
Problem: Engine knocks.
Cause
Low oil level.
Using wrong grade oil.
Problem: Excessive oil consumption.
Cause
Engine running too hot.
Using wrong weight oil.
Too much oil in crankcase.
Engine exhaust is black.
Cause
Dirty air filter.
Engine choke is in closed position.
Problem: Engine runs, but rider will not drive.
Cause
Transmission release lever(s) in
"free-wheel" position
Belt is broken.
Drive belt slips.
Brake is not fully released.
Place in OFF position.
Move ground speed control levers to
the "NEUTRAL" position.
If engine is hot, allow it to cool, then
refill the fuel tank.
Move choke control to the closed
position.
Replace fuse.
Clean the battery terminals.
Recharge or replace.
Visually check wiring and replace
broken or frayed wires. Tighten loose
connections.
Repair or replace. See authorized
dealer.
Replace as needed. See authorized
dealer.
Clean and gap, or replace. See engine
operator's manual.
Drain fuel and replace with fresh fuel.
Drain fuel and replace with fresh fuel.
Remedy
Clean air filter. Check choke
adjustment.
Clean and gap, or replace. See engine
operator's manual.
Remedy
Check and add oil as required.
See engine operator's manual.
Remedy
Clean engine fins, blower screen, and
air cleaner.
See engine operator's manual.
Drain excess oil.
Remedy
Replace air filter. See engine
operator's manual.
Open choke control.
Remedy
Move transmission release lever(s) to
the "drive" position.
Replace belt. See Transmission Drive
Belt Replacement.
See problem and cause below.
See authorized dealer.
