9J-4 Hood / Fenders / Doors:
5) Remove door assembly (1) by loosening hinge
mounting bolts (2).
1
2
Installation
Reverse removal procedure to install door assembly
noting the following instructions.
• When replacing door, coat replacement door inside
with wax for proper anti-corrosion treatment. Refer to
"Sealant Application Areas in Section 9L".
• Tighten front door hinge bolts, nuts and door open
stopper bolt to specified torque referring to "Front
Door Assembly Components".
• Apply sealant to contact face "A" of hinge (1) and
apply grease to rotating part "B" of hinge (1).
Specified sealant and grease.
"A": Sealant 99000–31110 (SUZUKI Bond
No.1215)
"B": Grease 99000–25011 (SUZUKI Super Grease
A)
• When door open stopper (1) is installed, be careful
make sure punch mark (2) comes to the top.
Door open stopper installing direction
Left side door: L punch mark is upward
Right side door: R punch mark is upward
I4RS0A9A0006-01
• Adjust door latch striker position referring to "Front
Door Lock Assembly Removal and Installation in
Section 9F".
• After installation, open and close the door to check
looseness.
