Icom IC-FR3000 Service Manual page 18

I
ADJUSTMENT MODE CH LIST
CH RX TX
A01 173.925 173.725
A02 173.925 173.725
A03 162.075 162.275
A04 150.075 150.275
A05 150.075 150.275
A06 162.075 162.275
A07 162.075 162.275
A08 150.075 150.275
A09 173.925 173.725
A10 162.075 162.275
A11 162.075 162.275
A12 162.075 162.275
A13 160.275 165.275
A14 160.275 165.275
I LCD DISPLAY IN THE ADJUSTMENT MODE
A01 LW TXREF 127
LCD DISPLAY
A01 LW TXREF ***
A02 LW HRTUN ***
A03 LW MRTUN ***
A04 LW LRTUN ***
A05 LW RPTSQL ***
A06 HW POWER ***
A07 LW M DEV ***
A08 LW LMODC***
A09 LW HMODC***
A10 LW CTCDEV***
A11 LW DTCADJ ***
A12 LN CTCDEV ***
A13 LW RPTAF ***
A14 LN RPTAF ***
W/N
W TVCO/RVCO adjustment.
Reference frequency adjustment.
W RX sensitivity adjustment.
W RX sensitivity adjustment.
W RX sensitivity adjustment.
W RPT SQL adjustment.
W TX power adjustment.
W TX modulation adjustment.
W TX modulation adjustment.
W TX modulation adjustment.
N CTCSS modulation adjustment
W DTCS modulation adjustment.
N CTCSS modulation adjustment. (NARROW)
W RPT modulation adjustment.
N RPT modulation adjustment.
Adjustment value
Adjustment item
Band width (WIDE)
TX power (LOW)
Adjustment frequency channel
4 - 3
ADJUSTMENT
(WIDE)
(NARROW)
