Parts List / Option Parts List

Ersatzteileliste / Tuningteileliste

En Parts List
Parts # Description
1418 Gasket for cylinder (0.2mm/21BB
1420 Brass Collet (21BB)
1427 Screw M2.6x6mm for Cover Plate (8 pcs/21BB)
1428 Pullstart assy. (w/o one-way bearing/21BB)
1430 One Way Bearing for Pullstart
1433 Starting Pin/Pressure Spring (21BB)
1468 Washer Set for Fuel Line Fitting (21BB)
1470 Main Needle Valve Holder (21BB)
1471 Main Needle (21BB)
1473 Fuel Line Fitting/Washer Set (21BB)
1477 Uniball (21BB)
1504 Glow Plug Cold R5
6122 Body Pin (Medium/10pcs)
6819 Silicone O-ring P-3 (red/5pcs)
15112 Connecting Rod
15114 Retainer for Piston Pin (2pcs)
15131 Lock Pin for Carburetor
15140 Cylinder/Piston Set
15141 Cylinder/Piston/Connecting Rod Set
15142 Piston Pin/retainer Set
15143 Cylinder head w/screws
15144 Underhead
15145 Crank Case (black/G3.0) w/bearings
15146 Crankshaft (SG type/G3.0)
15147 Starting Shaft (G3.0)
15148 Back plate with o-rings and screw set
68186 HD Silcone Fuel Tube 300mm
105381 HPI TF-40 2.4GHz Transmitter
104105 HPI SF-10W Servo (waterproof/4.5kg-cm6.0V)
105383 HPI RF-40 2.4GHz Receiver
80575 Reciever Switch
80576 Receiver Battery Case
86896 Ball Stud 4.8x12mm (10pcs)
100329 Nylon Tie Strap 2.4x94mm (10pcs)
100550 Pan Head Screw M5x8mm (hex socket/10pcs)
101037 13T Clutch Bell
101047 Racing Clutch Shoe 2pcs
101048 Racing Clutch Spring 2pcs
101049 Disk Brake
101051 Disk Brake Plate
101052 Disk Pads
101053 Screw M3 x 14mm
101062 Clutch Nut Trophy 3.5
101120 14T Clutch Bell
101159 RECEIVER BOX SET
101160 Differential Case Bullet
101203 Engine Mount
101204 Fuel Tank
101205 Diff Case
101206 Center Diff Housing Set
101207 54T Spur Gear MT/ST
101208 Upright Set
101209 Front Hub Carriers (10Degrees)
101210 Chassis Brace Set
101211 Rod End Set
101212 Shock Parts Set (Pr)
101213 Suspension Arm Set
101214 Steering Bellcrank Set
101215 40T Diff. Gear
101216 13T Input Gear
101217 Center Diff. Plate Orange
101218 Radio Tray Bullet MT/ST Orange
101219 Rear Lower Arm Brace Orange
101220 Front Lower Arm Brace Orange
101221 Diff Case Gasket (3pcs)
101222 Shock Bladder (4pcs)
101223 Servo Saver Posts 5x35mm
101224 Servo Saver Set
101225 Ball 5.8x5mm (5pcs)
101226 Steering Nut 3mm (4pcs)
101227 Flange Pipe (4pcs)
101228 Axle 5x40mm (Pr)
101229 Gear Shaft 5x29mm (Pr)
101230 Diff Shaft 5x23.5mm (Pr)
101231 Cup Joint (F) 4.5x18.5mm
101232 Cup Joint (R)4.5x18mm
101233 Slipper Gear Shaft 6x43.5mm
101234 Drive shaft 6x72mm
101235 Heavy Duty Drive shaft 6x83mm Silver (Pr)
101236 Heavy Duty Drive shaft 6x84mm Silver (Pr)
101237 Turnbuckle M3.5x25mm
101238 Turnbuckle M3.5x53mm (Pr)
101239 Pin 1.7x11mm (10pcs)
101240 Shock Shaft 3x52mm (Pr)
101241 Slipper Clutch Hub (F)
101242 Slipper Clutch Hub (R)
101243 Slipper Clutch Spring 7x9x1.7mm 3coils
Liste de pièces / Liste des pièces optionnelles
パーツリス ト / オプションパーツリス ト
Parts # Description
101244 Spring 13.5x63x1.2mm 11coils (2pcs)
101245 TP. Flat Head Screw M3*14mm (10pcs)
101246 TP. Button Head Screw M3*19mm (10pcs)
101247 Exhaust Gaskets
101248 Cap Head Screw M2.6x14mm (10pcs)
101249 TP. Button Head Screw M2.6*12mm (10pcs)
101250 Slipper Clutch Pad (2pcs)
101251 Flywheel
101252 Bullet ST Wheels Black Chrome (Pr)
101253 Ball 5.8x14mm (5pcs)
101256 Tuned Pipe Set
101258 12T Clutch Bell
101265 Exhaust Header Set
101266 Dust Protection and o-ring complete Set
101267 ALUM.CNC Front Gearbox Plate
101268 ALUM.CNC Front Anti-bending plate set
101269 ALUM. CNC Rear anti-bending plate set
101270 Bullet 3.0 CVD shaft set
101272 Throttle slide drum
101273 TP. Flat Head Screw M2.6x12mm (12pcs)
101274 Roto-Start Back Plate (Bullet 3.0)
101275 Mid Range Needle Valve with o-rings
101276 Idle Adjustment screw and throttle guide screw set
101277 Slide carburetor with two o-rings
101291 Gearbox Spacer Set
101292 Main Chassis 6061
101293 Body Mount Set
101294 Shock Body Set (2sets)
101295 Front Bumper Set
101296 Rear Bumper Set
101297 Support Parts Set
101298 Diff. Gear Set
101299 3*51.8mm Front Inner Suspension Shaft (2pcs)
101300 3*56.3mm Rear Inner Suspension Shaft (2pcs)
101301 Diff. Shaft Set
101302 3*25mm Front Outer Suspension Shaft (2pcs)
101303 3*35.3mm Rear Outer Suspension Shaft (2pcs)
101304 Brake Cam Shaft Set MT
101305 Wheel Spacer Set (4pcs)
101306 Shock Tower (2pcs)
101307 Bullet ST Tyres (2pcs)
101308 Bullet MT Ammunition Tyres (2pcs)
101309 Bullet MT Wheels Black Chrome (Pr)
101310 G3.0 Engine slide carb w/pull start
101652 Bullet Nitro Air filter foam elements (Pr)
101831 Bullet Nitro Water Resistant Air Filter Set
101936 Plazma 6.0V 1600mAh Receiver Pack
115507 Trimmed & Painted Bullet 3.0 ST Body (Black) w/Decals
115508 Trimmed & Painted Bullet 3.0 MT Body (Black) w/Decals
115515 Bullet MT Clear body with Nitro/Flux (BLACK) Decal sheets
115516 Bullet ST Clear body with Nitro/Flux (BLACK) Decal sheets
A020 O-Ring P5 Black (4Pcs)
A046 O-Ring P3 Black (4Pcs)
A133 Ball 5.8x6mm (4pcs)
B021 5x10x4 Bearing (pr)
B030 Ball Bearing 10x15x4mm (2pcs)
Z150 Aerial Tube
Z224 M3x8mm Washer (10pcs)
Z241 E Clip E2.5mm (20pcs)
Z242 E Clip E2mm (20pcs)
Z263 Pin 2x8mm (12pcs)
Z303 Cap Head Screw M3x42mm (6pcs)
Z423 Cap Head Screw M2.6x12mm (12pcs)
Z517 Binder Head Screw M3x8mm (10 pcs)
Z527 Flat Head Screw M3x10mm (6pcs)
Z538 Cap Head Screw M3x25mm (6pcs)
Z542 Cap Head Screw M3x8mm (12pcs)
Z543 Cap Head Screw M3x10mm (6pcs)
Z552 TP. Button Head Screw M3x10mm (10pcs)
Z553 TP. Button Head Screw M3x12mm (6pcs)
Z554 TP. Button Head Screw M3x15mm (10pcs)
Z558 TP. Button Head Screw M3x28mm (10Pcs)
Z561 TP. Flanged Screw M3x10mm (6pcs)
Z579 TP. Flat Head Screw M3x15mm (12pcs)
Z581 TP. Flat Head Screw M3x18mm (10pcs)
Z663 Nylon Nut M3 (6pcs)
Z669 Lock Nut M6 Thin Type (5pcs)
Z684 Flange Nylon Lock Nut M4 (4pcs)
Z700 Set Screw M3 x 3mm (6pcs)
Z721 Set Screw M4 x 4mm (4pcs)
Z800 Spring Washer 3mm (20pcs)
