Explorer I
B. Clearances to Combustibles
NOTE: A, C and F measure-
ments are to center of fl ue
Vertical Install Through Ceiling And Alcove
SINGLE WALL PIPE
DOUBLE WALL PIPE
Horizontal Install Through Back Wall
SINGLE & DOUBLE
WALL PIPE
90° Elbow Off The Top Of The Appliance, Then Through Back Wall
SINGLE WALL PIPE
DOUBLE WALL PIPE
INSTALLATION: ALCOVE - Six inch (6") [152] diameter listed DOUBLE WALL air insulated connector pipe with UL 103 HT listed factory-built Class
"A" chimney, or a masonry chimney. (Mobile Home must be equipped with a spark arrestor.) Maximum depth of Alcove shall be no more than 48"
[1220] with a minimum height of 84" [2134] to top of appliance, and the referenced clearances. Canada must comply with CAN/ULC-S269 M87 for
the 650° factory built chimney
HORIZONTAL THROUGH WALL
TOP AND SIDE VIEW
24"
(610mm)
11"
(280mm)
ALCOVE TOP VIEW
NOTE: Clearances may only be reduced by means
approved by the regulatory authority having jurisdiction
8
A
B
17 [432]
12-1/2 [318]
13-1/2 [343]
9 [229]
N/A
8 [203]
17 [432]
12-1/2 [318]
12-1/2 [318]
8 [203]
MANTEL
12" MAX
53-1/2"
(1359mm)
8"
(204mm)
ALCOVE SIDE VIEW
C
C
D
24 [607]
11 [279]
7-1/2 [191]
23 [584]
10 [254]
24 [607]
11 [279]
24 [607]
11 [279]
23 [584]
10 [254]
BACKWALL / SIDEWALL
A
B
G
A
7062-197B
E
F
18 [457]
53-1/2
[1359]
3 [77]
13-1/2 [343]
53-1/2
[1359]
N/A
N/A
53-1/2
[1359]
N/A
N/A
53-1/2
[1359]
N/A
N/A
53-1/2
[1359]
* Follow Pipe Manufacturer's clearances
** Acceptable per NFPA 211
CORNER INSTALLATION
C
D
STOVE TO CEILING
CLEARANCE
WARNING
Fire Risk.
•
Comply with all minimum clearances to
combustibles as specifi ed.
•
Failure to comply may cause house fi re.
G
H*
*
*
*
18 [457] **
18 [457]
F
E
H*
G
February 8, 2016
