Explorer I
2
Getting Started
A. Design and Installation Considerations
Consideration must be given to:
•
Safety
•
Convenience
•
Traffi c fl ow
•
Chimney and chimney connector required
It is a good idea to plan your installation on paper, using exact
measurements for clearances and fl oor protection, before
actually beginning the installation. If you are not using an
existing chimney, place the appliance where there will be a
clear passage for a factory-built listed chimney through the
ceiling and roof.
We recommend that a qualifi ed building inspector and your
insurance company representative review your plans before
and after installation.
If this appliance is in an area where children may be near it is
recommended that you purchase a decorative barrier to go
in front of the appliance. Remember to always keep children
away while it is operating and do not let anyone operate
this appliance unless they are familiar with the operating
instructions.
CAUTION
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult insurance carrier, local building, fire officials or
authorities having jurisdiction about restrictions, installation
inspection, and permits.
WARNING
Asphyxiation Risk.
• DO NOT CONNECT THIS APPLIANCE TO A CHIM-
NEY FLUE SERVICING ANOTHER APPLIANCE.
• DO NOT CONNECT TO ANY AIR DISTRIBUTION
DUCT OR SYSTEM.
May allow fl ue gases to enter the house.
4
Install Guide
• Installation and use of any damaged appliance.
• Modifi cation of the appliance.
• Installation other than as instructed by Hearth & Home
• Installation and/or use of any component part not approved
• Operating appliance without fully assembling all components.
• Operating appliance without legs attached (if supplied with
• Do NOT Over-fi re - If appliance or chimney connector glows,
Any such action that may cause a fi re hazard.
B. Fire Safety
To provide reasonable fi re safety, the following should be given
serious consideration:
1.
2.
3.
4.
5.
NOTICE: HEARTH & HOME TECHNOLOGIES ASSUMES NO
•
•
•
•
•
•
7062-197B
WARNING
Fire Risk.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be
voided by, the following actions:
Technologies.
by Hearth & Home Technologies.
appliance).
you are over-fi ring.
Install at least one smoke detector on each fl oor of your
home to ensure your safety. They should be located
away from the heating appliance and close to the sleeping
areas. Follow the smoke detector manufacturer's
placement and installation instructions, and be sure to
maintain regularly.
A conveniently located Class A fire extinguisher to
contend with small fi res resulting from burning embers.
A CO detector should be installed in the room with the
appliance.
A practiced evacuation plan, consisting of at least two
escape routes.
A plan to deal with a chimney fi re as follows:
In the event of a chimney fi re:
a
Evacuate the house immediately
b.
Notify fi re department.
RESPONSIBILITY FOR THE IMPROPER PERFORMANCE
OF THE APPLIANCE SYSTEM CAUSED BY:
Inadequate draft due to environmental conditions
Downdrafts
Tight sealing construction of the structure
Mechanical exhausting devices
Overdrafting caused by excessive chimney heights
Ideal performance is with height of chimney between 14-16
feet (4.26-4.88m) measured from the base of the appliance.
February 8, 2016
