1
Important Safety Information
A. Appliance Certifi cation
Model:
Explorer I
Laboratory:
OMNI Test Laboratories Inc.
Report No:
0061WS091S
Type:
Safety
Standard:
UL 1482-11 & 737-11; ULC S627-00
The Quadra-Fire Explorer I meets the U.S. Environmental
Protection Agency's 2015 particulate emission standards.
B. BTU & Effi ciency Specifi cations
EPA Certifi ed Emissions: 2.2 grams per hour
*LHV Tested Effi ciency: 80.1%
**HHV Tested Effi ciency: 74.1%
***EPA BTU Output: 12,100 to 32,000 / hr.
****Peak BTU/Hour Output: 52,400
Vent Size: 6 inches
Firebox Size: 1.68 cubic feet
Recommended Log Length 16 inches
Fuel Orientation: Side to Side
*Weighted average LHV (Low Heating Value) effi ciency using
Douglas Fir dimensional lumber and data collected during EPA
emission test. LHV assumes the moisture is already in a vapor
state so there is no loss in energy to vaporize.
**Weighted average HHV (High Heating Value) effi ciency using
Douglas Fir dimensional lumber and data collected during EPA
emission test. HHV includes the energy required to vaporize the
water in the fuel.
***A range of BTU outputs based on EPA Default Effi ciency and
the burn rates from the low and high EPA tests, using Douglas
Fir dimensional lumber.
****The peak BTU out of the appliance is calculated using the
maximum fi rst hour burn rate from the High EPA Test and the
BTU content of cordwood (8600) times the effi ciency.
C. Mobile Home Approved (USA ONLY)
• This appliance is approved for mobile home installa-
tions in the USA when not installed in a sleeping room
and when an outside combustion air inlet is provided.
• The structural integrity of the mobile home fl oor, ceil-
ing, and walls must be maintained.
• The appliance must be properly grounded to the frame
of the mobile home with #8 copper ground
• Outside Air Kit, part OAK-ACC must be installed in a
mobile home installation.
NOTE: Hearth & Home Technologies, manufacturer of
this appliance, reserves the right to alter its products, their
specifi cations and/or price without notice.
February 8, 2016
Fuel Seasoned Cord Wood
wire.
Fire Risk.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be voided
by, the following actions:
•
Installation and use of any damaged appliance.
•
Modifi cation of the appliance.
•
Installation other than as instructed by Hearth & Home
Technologies.
•
Installation and/or use of any component part not approved
by Hearth & Home Technologies.
•
Operating appliance without fully assembling all
components.
•
Operating appliance without legs attached (if supplied with
it).
•
Do NOT Over-fi re - If appliance or chimney connector glows,
you are over-fi ring.
Any such action that may cause a fi re hazard.
NOTE: This installation must conform with local codes. In the
absence of local codes you must comply with the UL1482-07,
(UM) 84-HUD and NFPA211 in the U.S.A. and the ULC S627-
00 and CAN/CSA-B365 Installation Codes in Canada. NOT
APPROVED FOR MOBILE HOME INSTALLATIONS IN
CANADA!
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
For assistance or additional information, consult a qualifi ed
installer, service agency or your dealer.
Hearth & Home Technologies WILL NOT warranty applianc-
es that exhibit evidence of over-fi ring. Evidence of over-fi r-
ing includes, but is not limited to:
• Warped air tube
• Deteriorated refractory brick retainers
• Deteriorated baffl e and other interior components
D. Glass Specifi cations
This appliance is equipped with 5mm ceramic glass.
Replace glass only with 5mm ceramic glass. Please con-
tact your dealer for replacement glass.
E. Non-Combustible Materials
Material which will not ignite and burn, composed of any
combination of the following:
- Steel
- Brick
- Concrete
- Glass
Materials reported as passing ASTM E 136, Standard
Test Method for Behavior of Metals, in a Vertical Tube
Furnace of 750° C.
F. Combustible Materials
Material made of/or surfaced with any of the following ma-
terials:
- Wood
- Plant Fibers
- Plywood/OSB
Any material that can ignite and burn: fl ame proofed or not,
plastered or un-plastered.
7062-197B
Explorer I
WARNING
- Plaster
- Iron
- Tile
- Slate
- Compressed Paper
- Plastic
- Sheet Rock (drywall)
3
