INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
EXPEDITION II AUSTRALIAN
WOOD INSERT
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL NUMBER:
EXPEDITIONII-AU
1
Owner's Manual
Operation & Care
®
Quadrafire • Expedition II AU Owner's Manual_Rev B • 2020 - ___ • 03/21
!
If the information in these instructions is
not followed exactly, a fire could result
causing
property
injury, or death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not over fire - If appliance or chimney connector
glows, you are over firing. Over firing will void
your warranty.
• Comply with all minimum clearances to combustibles
as specified.
Failure to comply may cause house fire.
!
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
• Do not touch glass until it is cooled
• Use leather gloves when reloading fuel
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as appliance.
• Alert
children
and
high temperatures
• High temperatures may ignite clothing or other
flammable materials.
• Keep
clothing,
furniture,
flammable materials away.
!
Fire Risk.
For use with solid wood fuel only.
Other fuels may over fire and generate
poisonous gases (i.e. carbon monoxide).
WARNING
damage,
personal
WARNING
adults
to
hazards
draperies
and
WARNING
7095-819
of
other
