Draytek Vigor2820 Series User Manual page 18

LAN
1(Giga)
LAN
2/3/4
WAN 2
Interface
Factory Reset
Phone S0
ISDN/Phone S0
Phone
Line
LAN (1-4)
DSL
WAN 2
USB
PWR
ON/OFF
10
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Description
Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and keep
for more than 5 seconds. When you see the ACT LED begins to blink rapidly
than usual, release the button. Then the router will restart with the factory
default configuration.
Connecter for ISDN phone(s) only via ISDN phone adapter. Do not connect
any other device to such port or connect ISDN line, otherwise the router
might be damaged.
Connecter for ISDN line or ISDN phone adapter in particular condition.
Refer to section 2.2 for more details.
Connecter for PSTN phone.
Connector for PSTN life line.
Connecters for local networked devices.
Connecter for accessing the Internet through ADSL2/2+.
Connecter for remote networked devices.
Connecter for a USB device (for 3G USB Modem or printer).
Connecter for a power adapter.
Power Switch.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is disconnected with 10/100Mbps.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 100Mbps.
The port is disconnected with 10Mbps.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 100Mbps.
The port is disconnected with 10Mbps.
Vigor2820 Series User's Guide
