NordicTrack U 60 NTEVEX78915.0 User Manual

Hide thumbs

Advertisement

Table of Contents

Model No. NTEVEX78915.0
Serial No.
Write the serial number in the
space above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 1D, The Gateway
Fryers Way, Silkwood Park
OSSETT
WF5 9TJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for NordicTrack U 60 NTEVEX78915.0

Summary of Contents for NordicTrack U 60 NTEVEX78915.0

  • Page 1 Model No. NTEVEX78915.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 1D, The Gateway Fryers Way, Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    The BLUETOOTH word mark and logos are registered trademarks of ® Bluetooth SIG, Inc. and are used under license. Google Maps is a trademark of Google Inc. NORDICTRACK is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK U 60 exercise bike. Cycling is one of manual. To help us assist you, note the product model ® the most effective exercises for increasing cardiovas- number and serial number before contacting us.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tools: • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you finish all assembly steps.

  • Page 7: Front Of The Frame (1

    3. Set a sturdy piece of packing material under the front of the Frame (1). Attach the Front Stabilizer (2) to the Frame (1) with two M10 x 98mm Screws (53). Then, remove the packing material. 4. Raise the Upright (4) to the vertical position. Have a second person hold the Upright until you complete this step.
  • Page 8 5. Attach the Accessory Tray (8) to the Upright (4) with an M6 x 50mm Screw (89). 6. Have a second person hold the Handlebar (5) near the Upright (4). See the inset drawing. Route the Upper Wire (87) through the Pivot Post (78) and the Pivot Bracket (71) as shown.
  • Page 9 7. While a second person holds the Console (13) near the Pivot Bracket (71), plug the Upper Wire (87) and the two Pulse Wires (61) into the recep- Avoid pinching tacles on the Console. the wires IMPORTANT: The connectors on the Wires (61, 87) should slide easily into the recep- tacles and snap into place.
  • Page 10 9. Remove the Seat Knob (26) from the Seat Bracket (30) inside the Seat Carriage (24). Next, hold the Seat Carriage (24) on the Seat Post (6). Insert the Seat Knob (26) upward into the Seat Post, and tighten the Seat Knob into the Seat Bracket (30) inside the Seat Carriage.
  • Page 11 11. Identify the Right Pedal (21). Using an adjustable wrench, firmly tighten the Right Pedal (21) clockwise into the Right Crank Arm (19). Firmly tighten the Left Pedal (not shown) counterclockwise into the Left Crank Arm (not shown). IMPORTANT: You must turn the Left Pedal counterclockwise to attach it.

  • Page 12: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO PLUG IN THE POWER ADAPTER HOW TO ADJUST THE LATERAL POSITION OF THE SEAT IMPORTANT: If the exercise bike has been exposed to cold temperatures, allow it to warm to room To adjust the lateral temperature before you plug in the power adapter.
  • Page 13 CONSOLE DIAGRAM MAKE YOUR FITNESS GOALS A REALITY WITH Upload your workout results to the iFit cloud IFIT.COM and track your accomplishments. With your new iFit-compatible fitness equipment, you can use an array of features on iFit.com to make your Set calorie, time, or distance goals for your fitness goals a reality: workouts.
  • Page 14 FEATURES OF THE CONSOLE HOW TO USE THE MANUAL MODE The advanced console offers an array of features 1. Begin pedaling or press any button on the console to turn on the console. designed to make your workouts more effective and enjoyable.
  • Page 15 Distance (Dist.)—This display mode will show Press the Home button to exit the workout and the distance that you have pedaled in miles or return to the default menu (see HOW TO CHANGE kilometers. CONSOLE SETTINGS on page 21 to set the default menu).
  • Page 16 6. Turn on the fan if desired. If the pedals do not move for several minutes and the buttons are not pressed, the console will turn The fan has low and high off and the display will be reset. speed settings. Press the fan increase and decrease but- Note: The console features a display demo mode, tons repeatedly to select a fan...
  • Page 17 HOW TO USE AN ONBOARD WORKOUT the next segment, the resistance level and/or target speed will appear in the display for a few seconds 1. Begin pedaling or press any button on the to alert you. The resistance of the pedals will then console to turn on the console.
  • Page 18 HOW TO USE A SET-A-GOAL WORKOUT Note: The calorie goal is an estimate of the number of calories that you will burn during 1. Begin pedaling or press any button on the the workout. The actual number of calories that console to turn on the console.
  • Page 19 HOW TO USE AN IFIT WORKOUT Press the Map button, the Train button, or the Lose Wt. button to download the next workout of that You must have an iFit module to use an iFit workout. type in your schedule. To purchase an iFit module at any time, go to www.iFit.com or call the telephone number on the Press the Compete button to compete in a race...
  • Page 20 6. Follow your progress with the display. HOW TO USE THE SOUND SYSTEM See step 4 on page 14. To play music or audio books through the console sound system while you exercise, plug a 3.5 mm male The My Trail tab will show a map of the trail or it will to 3.5 mm male audio cable (not included) into the jack show a track and the number of laps you complete.
  • Page 21 HOW TO CHANGE CONSOLE SETTINGS To view distance in miles, select ENGLISH. To view distance in kilometers, select METRIC. 1. Select the settings mode. Demo—The console features a display demo To select the settings mode, press the Settings mode, designed to be used if the exercise bike is button.

  • Page 22: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE HOW TO ADJUST THE DRIVE BELT Regular maintenance is important for optimal per- If the pedals slip while you are pedaling, even while the formance and to reduce wear. Inspect and properly resistance is adjusted to the highest setting, the drive belt may need to be adjusted.
  • Page 23 HOW TO ADJUST THE REED SWITCH Locate the Reed Switch (57). Rotate the Left Crank Arm (20) until a Magnet (55) is aligned with the Reed If the console does not display correct feedback, the Switch. Next, loosen the M5 x 16mm Flat Head Screw reed switch should be adjusted.

  • Page 24: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 25: Part List

    PART LIST Model No. NTEVEX78915.0 R0515A Key No. Qty. Description Key No. Qty. Description Frame Resistance Motor Front Stabilizer M8 x 18mm Screw Rear Stabilizer Knob Nut Upright M8 x 76mm Bolt Handlebar J-bolt Seat Post #10 x 12mm Screw Rear Shield Cover M10 x 98mm Screw Accessory Tray...

  • Page 26: Exploded Drawing

    EXPLODED DRAWING A Model No. NTEVEX78915.0 R0515A...
  • Page 27 EXPLODED DRAWING B Model No. NTEVEX78915.0 R0515A...

  • Page 28: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
