Installation Manual
Installation Guide
Included Installation Instructions
Network Camera
WV-SW559/WV-SW558
Model No.
(This illustration represents WV-SW559.)
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
This document is the Installation Guide for use in other countries except Japan.
Advertisement
Table of Contents
Related Manuals for Panasonic WV-SW559
Summary of Contents for Panasonic WV-SW559
-
Page 1: Network Camera
Network Camera WV-SW559/WV-SW558 Model No. (This illustration represents WV-SW559.) Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. The model number is abbreviated in some descriptions in this manual. - Page 2 For Europe WARNING: We declare under our sole responsibility that the product • To prevent injury, this apparatus must be to which this declaration relates is in conformity with the securely attached to the floor/wall/ceiling in standard or other normative document following the provisions of Directive 2004/108/EC.
-
Page 3: Table Of Contents
Network security ........................... 9 Precautions ..........................10 Precautions for installation ......................13 Major operating controls ......................15 Preparations ..........................17 Insert/remove a SD memory card (WV-SW559 Only)*..............23 Connection ..........................24 Installation ........................... 29 Adjustment ..........................34 Configure the network settings ....................39 Troubleshooting ........................... -
Page 4: Important Safety Instructions
Important safety instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Clean only with dry cloth. 6) Do not block any ventilation openings. Install in accordance with the manufacturer's instruc- tions. 7) Do not install near any heat sources such as radiators, heat registers, stoves, or other appara- tus (including amplifiers) that produce heat. -
Page 5: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL Panasonic System Networks Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 6: Preface
Preface The network camera WV-SW559/WV-SW558 is designed to operate using a PC on a network (10BASE-T/100BASE-TX), and can be installed under eaves (sheltered outdoor). By connecting to a network (LAN) or the Internet, images and audio from the camera can be moni- tored on a PC via a network. -
Page 7: About The User Manuals
About the user manuals There are 2 sets of operating instructions for the WV-SW559, WV-SW558 as follows. • Installation Guide: Explains how to install and connect devices. • Operating Instructions (included in the CD-ROM): Explains how to perform the settings and how to operate this camera. -
Page 8: Trademarks And Registered Trademarks
* A phenomenon in which portions of the screen are displayed out of alignment • For information on the operation verification of the supported operating systems and web browsers, refer to our website at http://security.panasonic.com/pss/security/support/index.html. Trademarks and registered trademarks • Adobe, Acrobat Reader, and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. -
Page 9: Copyright
Copyright Distributing, copying, disassembling, reverse compiling and reverse engineering of the software provided with this product are all expressly prohibited. In addition, exporting any software provided with this product violating export laws is prohibited. Network security As you will use this unit connected to a network, your attention is called to the following security risks. -
Page 10: Precautions
Precautions Refer installation work to the dealer. Do not use this product in an inflammable Installation work requires technique and experi- atmosphere. ences. Failure to observe this may cause fire, Failure to observe this may cause an explosion electric shock, injury, or damage to this prod- resulting in injury. - Page 11 Do not rub the edges of metal parts with Handle this product with care. your hand. Do not drop this product, nor apply shock or Failure to observe this may cause injury. vibration to the product. Failure to observe this may cause trouble.
-
Page 12: Code Label
About SD memory card AVC Patent Portfolio License • Before removing the SD memory card, THIS PRODUCT IS LICENSED UNDER THE make sure to select “Not use” for “SD AVC PATENT PORTFOLIO LICENSE FOR THE memory card” on the [SD memory card] PERSONAL USE OF A CONSUMER OR tab of “Basic”... -
Page 13: Precautions For Installation
Precautions for installation Panasonic assumes no responsibility for injuries or property damage resulting from fail- ures arising out of improper installation or operation inconsistent with this documenta- tion. This product is designed to be installed Be sure to remove this product if it is not under eaves. - Page 14 Do not remove or loosen the screws on PoE (Power over Ethernet) the rear of this product. Use a PoE hub/device that is compliant with If the screws (7 pcs.) are loosened, water expo- IEEE802.3af standard. sure may cause damage or malfunction of the product, or dropping may result in injury.
-
Page 15: Major Operating Controls
Major operating controls Dome cover Camera attachment (accessory) Enclosure Mount bracket (accessory) Base cover Cap for the female thread (accessory) for the conduit Focus ring Zoom lock knob Inner dome Tilting table Azimuth adjustment ring Tilting lock screw (x2) Network cable RJ-45 (female) Alarm input/output cable Power cable (12 V DC) - Page 16 Panning lock screw Panning table SD memory card slot SW559 Auto focus (AF) button/ <WV-SW558> < W V-SW558> Extra optical zoom button Monitor out connector for adjustment Initial set button SW559 SD memory card error indicator Auto focus indicator (blinks when adjusting auto focus) Access indicator (blinks when accessing) Link indicator (lit when linking) About the [INITIAL SET] button...
-
Page 17: Preparations
Preparations When installing the camera on a wall or a ceiling, there are two methods as specified below. • Using a two-gang junction box • Use the supplied mount bracket IMPORTANT: • Procure 4 screws (M4) to secure the camera attachment (accessory) or the mount bracket (accessory) to a wall or a ceiling according to the material of the installation area. - Page 18 • For wall mounting: The camera attachment (accessory) shall be mounted with "TOP" facing upward. • For ceiling mounting: The camera attachment (accessory) shall be mounted with "FRONT" facing in the direction of the camera front (the side where the Panasonic logo is).
- Page 19 Using the mount bracket (accessory) Note: • When the camera is mounted on the wall or ceiling with a hole for cable running, or the camera is mounted using open wiring, the mount bracket is used. IMPORTANT: • If open wiring is conducted, be sure to use conduits and run the cables inside the tubes to protect the cables from direct sunlight.
-
Page 20: Camera Attachment
• For wall mounting: The camera's upwards direction (the side opposite to where the Panasonic log is) is fixed. Select which direction to make the upward direction for the mount bracket. • For ceiling mounting: Select which direction to face the front (the side where the Panasonic logo is) of the camera. - Page 21 <Using a conduit> Align the direction of the conduit to the direction of female thread for the conduit on the mount bracket, and mount the mount bracket to hole A or hole B on the wall or ceiling. [For use of the hole A] Conduit Mount bracket (accessory)
- Page 22 • For ceiling mounting: The camera attachment (accessory) shall be mounted with aligning the front side (the side where the Panasonic logo is) of the camera with the position of the arrow in "FRONT". IMPORTANT: • For installations on the wall, to prevent water from accumulating on the surface of the dehu- ☞...
-
Page 23: Insert/Remove A Sd Memory Card (Wv-Sw559 Only)
Insert/remove a SD memory card (WV-SW559 Only) IMPORTANT: • When inserting a SD memory card, make sure the direction. • Before removing the SD memory card, make sure to select “Not use” for “SD memory card” on ☞ the [SD memory card] tab of the “Basic” page on the setup menu first. (... -
Page 24: Connection
Connection Caution: • ONLY CONNECT 12 V DC CLASS 2 POWER SUPPLY (UL 1310/CSA 223) or LIMITED POWER SOURCE (IEC/EN/UL/CSA 60950-1). Before starting the connection, turn off the power of this camera and the devices to be connected. Check and prepare the required devices and cables for connection. Note: •... - Page 25 Connect an external amplifier-embedded speaker to the audio output cable (for use of the audio transmission function). SW559 Connect a stereo mini plug (ø3.5 mm) (Audio output is monaural.). • Recommended cable length: Less than 10 m {32.8 ft} Connect the alarm input/output cable. <Ratings>...
- Page 26 IMPORTANT: • Input and output of the EXT I/O terminal 2 and 3 can be switched by configuring the setting. "Off" is selected by default. It is possible to determine whether or not to receive input from EXT I/O terminal 2 and 3 (ALARM IN2, 3) by selecting "Off", "Alarm input", "Alarm output" or "AUX output"...
-
Page 27: Mount Bracket
Waterproof treatment for the cable joint sections Adequate waterproof treatment is required for the cables when installing the camera with cables exposed or installing it under the eaves. The camera body is waterproof, but the cable ends are not waterproof. Be sure to use the supplied waterproof tape at the points where the cables are connected to apply waterproof treatment in the following procedure. - Page 28 Connection example when connecting to a network using a PoE hub Video monitor Powered speaker (for adjustment use only) (option) SW559 PoE device (hub) LAN cable (category 5 or better, straight, STP*) Microphone LAN cable SW559 (option) (category 5 or better, straight, STP*) Powered speaker (option)
-
Page 29: Installation
Installation Mount the camera. <Using a two-gang junction box> ☞ ☞ q Connect each cable. ( Page 24) Waterproof the connecting portion. ( Page 27) w Align the "OPEN" on the camera with the projection of the camera attachment (accessory). e Engage the camera attachment fixing screws on the rear of the camera in the camera mounting holes of the camera attachment (accessory) and rotate the camera in the arrow direction to secure the camera attachment (accessory) and camera. - Page 30 <Using the mount bracket> q Attach the camera onto the camera attachment (accessory) while aligning the "OPEN" mark of the camera with the projection of the camera attachment (accessory). Projection IMPORTANT: • When mounting the camera body, cables shall be run between the camera attachment (acces- sory) and mount bracket as indicated by the arrows in the illustration.
- Page 31 w Engage the camera attachment fixing screws of the camera with the screw hole of the camera attachment (accessory) and rotate the camera in the direction of the arrow to secure the cam- era to the camera attachment (accessory). Rotate the camera until a click is heard so that Projection the projection of the camera attachment (acces- sory) will be set to the "LOCK"...
- Page 32 t Attach the base cover (accessory) that was removed according the steps in page 19. Base cover (accessory) y Use the bit for tamperproof screw (accessory) to tighten the fixing screws provided on both sides of the base cover (accessory). (Recommended tightening torque: 0.78 N·m {0.58 lbf·ft}) Detach the enclosure from the main...
- Page 33 Secure the camera to the mount bracket with the camera fixing screw (red, 1 posi- tion). The illustration is an example of using the mount bracket (accessory). IMPORTANT: • Be sure to tighten the camera fixing screw. Failure to observe this may cause camera trouble due to water leakage or camera falling.
-
Page 34: Adjustment
Adjustment Adjust the camera angle. When determining the camera angle, repeat fine adjustments by gradually moving the panning table, tilting table, and azimuth adjustment ring. Horizontal position (Panning) Loosen the panning lock screw, rotate the panning table to adjust the pan direction. (Adjustable range: 340 °) Panning is possible within the range of 180 °... - Page 35 <Lens angular field of view (q Angle)> Horizontal: 24.20° (TELE) to 86.60° (WIDE) After adjustment, tighten the tilting lock screws (x2) to fix the tilting table. (Recommended tightening torque: 0.59 N·m {0.44 lbf·ft}) Note: • When the tilting table is turned to the edge of the adjustable range (±75°), it must be noted that the shadow of the enclosure may be projected.
- Page 36 Adjust the angular field of view and the focus. Adjust the angular field of view in accordance with the distance between the camera lens and a photographic subject. These adjustments shall be performed together with the camera angle adjustment. Auto focus (AF) button/ Extra optical zoom button Zoom lock knob Loosen...
- Page 37 IMPORTANT: • Do not move the focus ring. • Defocus may be caused by the reinstalled enclosure. In this case, perform the auto focus func- tion from the setup menu. • After performing basic adjustments, make sure to press the auto focus (AF) button once to per- form detailed adjustments.
- Page 38 Attach the enclosure to the camera. Attach the cutout part of the main unit to the grooved part of the enclosure. Groove for mounting Cutout for mounting IMPORTANT: • Securely tighten all the fixing screws (x3) of enclosure. Otherwise, water exposure may cause damage or malfunction of camera, or camera dropping may result in injury.
-
Page 39: Configure The Network Settings
• Refer to “Using the CD-ROM” in the Operating Instructions on the provided CD-ROM for further information about CDLauncher. Click the [Run] button next to [IP Setting Software]. [Panasonic IP Setting] screen will be displayed. Click the [Network Settings] button after select- ing the MAC address/IP address of the camera to be configured. - Page 40 Select the camera you want to configure, and click [Access Camera]. Note: • When cameras are displayed in [Panasonic IP Setting] screen, click the camera with same MAC address as the MAC address printed on the camera that you want to configure.
-
Page 41: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages When using DC power supply... -
Page 42: Specifications
Specifications • Basic Power source: 12 V DC, PoE (IEEE802.3af compliant) SW559 Power consumption: 12 V DC: 850 mA, PoE 48 V: 180 mA (Class 0 devices) SW558 12 V DC: 830 mA, PoE 48 V: 175 mA (Class 0 devices) * ONLY CONNECT 12 V DC CLASS 2 POWER SUPPLY (UL 1310/CSA 223) or LIMITED POWER SOURCE (IEC/EN/UL/ CSA 60950-1). - Page 43 • Camera Image sensor: 1/3-type MOS image sensor Effective pixels: Approx. 3.1 megapixels Scanning area: 4.51 mm (H) × 3.38 mm (V) {3/16 inches (H) x 1/8 inches (V)} Scanning system: Progressive SW559 Minimum illumination : Color: 0.5 lx {0.05 footcandle} (F1.3, Auto slow shutter: Off (1/30 s), Gain: On(High)) 0.03 lx {0.003 footcandle} (F1.3, Auto slow shutter: max.
- Page 44 • Lens Zoom ratio: 3.6x Extra optical zoom: 10.8x (Imaging mode: 2 megapixel, under 640x360 resolution) Focal length: 2.8 mm - 10 mm Maximum aperture ratio: 1:1.3 (WIDE) - 1:3.0 (TELE) ■ Image capture mode: 2 mega pixel [16:9], 1.3 mega pixel [16:9] Angular field of view: Horizontal: 24.20°...
- Page 45 (Including the camera itself) Compatible SDXC/SDHC/ SW559 SD memory card (option) : Manufactured by Panasonic (SD speed class 4 or higher) SDXC memory card: 64 GB SDHC memory card: 4 GB, 8 GB, 16 GB, 32 GB SD memory card: 2 GB...
-
Page 46: Standard Accessories
Standard accessories Installation Guide (this document) ............1 set Warranty card ...................1 set CD-ROM* ..................1 pc. Code label* ..................1 pc. The following parts are used during installation procedures. 4P alarm cable ..................1 pc. Camera attachment ................1 pc. 2P power cable .................1 pc. Fixing screws (M4 x 8 mm) ......5 pcs. - Page 48 Authorised Representative in EU: Panasonic Testing Centre Panasonic Canada Inc. Panasonic Marketing Europe GmbH 5770 Ambler Drive, Mississauga, Winsbergring 15, 22525 Hamburg, Germany Ontario, L4W 2T3 Canada (905)624-5010 www.panasonic.ca © Panasonic System Networks Co., Ltd. 2013 avs1113-0 PGQX1440ZA Printed in China...
