User's Manual & Operating Instructions
Factory ID: 522
CONSUMER: READ AND SAVE THESE INSTRUCTIONS
GENERAL HAZARD WARNING:
DANGER
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH
THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS
OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN. ASPHYXIATION, CARBON
MONOXIDE POISONING AND / OR ELECTRIC SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE
OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS
MANUAL, LABEL, ETC. CONTACT THE MANUFACTURER.
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID
WARNING
COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR
CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY
THESE INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR MAY
CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNERS, DUST PARTICLES OR UNKNOWN CHEMICALS.
668 Stony Hill Road #302 Yardley, PA 19067 USA
Fax: (215)-891-8461
Model Number
HH-18-PCH-A
© 2015 Pinnacle Products International, Inc.
• Web: www.masterindustrialproducts.com • Email: info@pinnacleint.com
Toll Free (800)-641-6996
•
247000271-14
Advertisement
Table of Contents
Related Manuals for Remington HH-18-PCH-A
Summary of Contents for Remington HH-18-PCH-A
- Page 1 User’s Manual & Operating Instructions Model Number HH-18-PCH-A Factory ID: 522 CONSUMER: READ AND SAVE THESE INSTRUCTIONS GENERAL HAZARD WARNING: DANGER FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN.
-
Page 2: Table Of Contents
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Table Of Contents Safety Information..........1-3 Storage / Maintenance.........9 Specifications and Features........4 Troubleshooting Guide........10 Assembly..............5 Exploded View / Parts List.........11 Operation............6-8 Warranty.............12 Ventilation............9 Safety Information NOT FOR HOME OR RECREATIONAL VEHICLE USE. -
Page 3: Safety Information
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Safety Information RISK OF INDOOR AIR PROPANE IS AN WARNING DANGER POLLUTION! EXPLOSIVE GAS. The products described in this manual are WHAT TO DO IF THE SMELL OF GAS IS PRESENT: propane direct-fired, forced air heaters. -
Page 4: Assembly
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Safety Information – ALWAYS install the heater so that it is not directly – Use only the regulator and hose assembly exposed to water spray, rain, dripping water, or provided with this heater. -
Page 5: Specifications
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Specifications Model # HH-18-PCH-A 6,600 / 12,000 / 18,000 Fuel Consumption (Lbs./hr) 0.31 / 0.56 / 0.83 Heat Settings Maximum Operating Hours 65 / 36 / 24 Required Cylinder Lbs. - Page 6 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Missing Parts? Please Call 800-641-6996 For Assistance Unpacking and Assembly Connecting to Gas Supply - Remove heater and base from carton (save IMPORTANT! - Always use a propane (LP) carton and packing materials for later storage) cylinder that has a connection device that is...
-
Page 7: Operation
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Operation Propane Supply / Information: Propane is safe to use when CAUTION properly handled. Careless handling of the LP cylinder could result in a Propane (LP) fire and or an explosion. - Page 8 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Operation Pre-Lighting Instructions: – With heater gas valve knob still in OFF position turn ON the LP cylinder valve and Connecting the LP Cylinder check for leaks with soap solution.
-
Page 9: Lighting Instructions
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Operation EXTREMELY HOT during operation. Do Not touch any metal components while in WARNING operation. Keep gasoline and any other flammable liquids away from the heater. Lighting Instructions: Test Firing Heater It is always a good idea to test fire your heater... -
Page 10: Ventilation
Poisoning. Minimum Ventilation Opening Needed – ALWAYS provide a fresh air opening in the HH-18-PCH-A heated space of at least 3 square feet (2,800 sq. cm) for each 100,000 BTU / Hr. of heater 0.54 ft. output. Provide a larger opening if more 16.5 cm... -
Page 11: Troubleshooting Guide
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Troubleshooting Guide Locating Your Serial Number: Your serial number can be found on the heater’s rating label. It will begin with the letters PGCV followed by 8 digits. -
Page 12: Exploded View / Parts List
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE Exploded View Parts List Item Item Description HH-18-PCH-A Description HH-18-PCH-A Body Frame Assembly 50-001-0515 Front Castor 50-011-0110 Valve Knob 50-013-0210 50-007-0210 Regulator Assembly... -
Page 13: Limited Warranty
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE LIMITED WARRANTY Pinnacle Products International, Inc. warrants this heater If Pinnacle Products International, Inc. finds the item to to the original retail purchaser only, to be free from defects be in normal operating condition, or not defective the item in material and workmanship for a period of one (1) year will be returned freight collect. - Page 14 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE CONNECTED TO A FUEL SOURCE ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________...
