FCS-1040
WCS-2040
IP Camera
User's Manual
V3.0

Advertisement

Table of Contents
loading

Related Manuals for LevelOne WCS-2040

Summary of Contents for LevelOne WCS-2040

  • Page 1 FCS-1040 WCS-2040 IP Camera User’s Manual V3.0...

  • Page 2: Table Of Contents

    Network Setting .............................17 PPPoE Setting ............................17 Accessing the Network Camera 24 Using Web Browsers ..........................24 Using RTSP Players ..........................26 Using 3GPP-compatible Mobile Devices ....................27 Using LevelOne Recording Software ....................28 Main Page 29 Client Settings 33 Configuration 35 System ..............................36 Security ..............................38 HTTPS (Hypertext Transfer Protocol over SSL) ...................39...

  • Page 3: Overview3

    The FCS-1040v3/WCS-2040v3 is incorporated with LevelOne’s self- developed Bach SoC; therefore, users can benefit from the advantages of dual-codec video and two-way audio.

  • Page 4: Physical Description

    Physical Description Front panel Lens Built-in Microphone Status LED Rear panel Antenna (WCS-2040v3 only) Microphone In Ethernet 10/100 AV Out RJ45 Socket Recessed Reset Button Power Cord Socket General I/O External/Internal Terminal Block Microphone Switch General I/O Terminal Block This Network Camera provides a general I/O terminal block which is used to connect external input / output devices.

  • Page 5: Status Led

    DI/DO Diagram Please refer to the following illustration for the connection method. Status LED The color of LED indicates the status of the Network Camera. Status LED Color Description Blinking red Power is being supplied to the Network Camera. Solid green The Network Camera is booting up.
  • Page 6 Hardware Reset The reset button is used to reset the system or restore the factory default settings. Sometimes resetting the system can return the camera to normal operation. If the system problems remain after rebooting, restore the factory settings and install again. Reset: Press and release the recessed reset button with a paper clip or thin object.

  • Page 7: Installation 7

    Installation Hardware Installation Follow the steps below to install the Network Camera to the ceiling: 1. Attach ceiling mount bracket A to the Network Camera and secure it with two small screws. 2. Drill three pilot holes into the ceiling; hammer the plastic anchors into the holes. 3.

  • Page 8: Network Deployment

    Network Deployment Setup the Network Camera over the Internet This section explains how to confi gure the Network Camera over an Internet connection. 1. If you have external devices such as sensors and alarms, connect them to the general I/O terminal block.
  • Page 9 2. In this case, if the Local Area Network (LAN) IP address of your Network Camera is 192.168.0.3, please forward the following ports for the Network Camera on the router. ■ HTTP port ■ RTSP port ■ RTP port for audio ■...
  • Page 10 Set up the Network Camera through Power over Ethernet (PoE) (FCS-1040v3 only) When using a PoE-enabled switch The Network Camera is PoE-compliant, which allows it to be powered via a single Ethernet cable. If your switch/router supports PoE, refer to the following illustration to connect the Network Camera to a PoE-enabled switch/router.
  • Page 11 When using a non-PoE switch If your switch/router does not support PoE, use a PoE power injector (optional) to connect between the Network Camera and a non-PoE switch/router. PoE Power Injector (optional) Non-PoE Switch User's Manual - 11...

  • Page 12: Software Installation

    Software Installation The following are steps for the software installation. Note: The default user name is root and the password is blank How to Use Installation Wizard Installation The following are steps for the software installation. STEP. 1 Put the Installation disk into the CD-ROM drive, and the installation should start automatically.

  • Page 13: Using Installation Wizard

    STEP 4: After clicking “Install” button, the install system will install the Installation Wizard to your computer, and a progress bar will display on the dialog. After completed the installation, please click on the “Close” button. Completed Using Installation Wizard User Interface Once you run the Installation Wizard, after a short searching time, you will see the user interface as below.

  • Page 14: Manual Setup

    Installation wizard allows you to setup or upgrade multiple devices (of the same model) at the same time. If you selected different models, then the buttons will be disabled. There are five buttons on the bottom of the main page, and five buttons on the left panel of the main page. Buttons Click on this button to clean up the device list and search all devices on the within the same subnet again.

  • Page 15: System Setting

    Authentication error System Setting After connected to the selected device, the Installation Wizard will switch to system setting page as below. System setting page User's Manual - 15...

  • Page 16: Change Root Password

    Click on this button to cancel the setup progress. Click on this button to keep the present setting and go to the next page. Change Host Name The “Hostname” is used for the homepage title of main page and is displayed as the title in the video window of the main page.

  • Page 17: Network Setting

    Network Setting The Installation Wizard can help you to setup the network connection with LAN or PPPoE. After you clicked on the “Next” button on the System page, the Installation Wizard would lead you to the PPPoE setting page. If you want to connect your server to Internet via PPPoE, please click on “Yes”...

  • Page 18: Lan Setting

    LAN Setting If you click on “No” in the “Network Type” dialog window, you will be led to the Network setting page. In this page, you can change the server’s IP address, subnet mask, default gateway, primary DNS server, secondary DNS and DHCP server. Please refer to the below page. Network Setting for LAN You could set up the network with DHCP or fixed IP: 1.DHCP: Check the “Get IP by DHCP Server automatically”...
  • Page 19 Mobile Access Apply to selected device After configuring all the settings, the apply page will show up. Click on “Apply” button to apply the changes to the selected device or click on “Back” button to go back to the previous page and modify the setting again.

  • Page 20: Device Information

    Click on the “Firmware Upgrade” Device Information After connected to the selected device(s), it would display as below. If you select more than one device, then the device information will show all the selected devices. You can switch to the server info by click on the tab control.
  • Page 21 Multiple devices information Firmware Information The selected firmware information will show the information about the file that you selected. Firmware version: The version number of the selected firmware. Select Firmware You can use the “Select firmware” button to browse the file that you want upgrade onto the se- lected device(s).
  • Page 22 Firmware Information Warning message for unmatched firmware 22 - User's Manual...
  • Page 23 Start Upgrade Clicking on the “Start Upgrade” button to upgrade the firmware of the selected device(s), and it will be a pop-up dialog window to show the progress of the upgrading process. Usually, it will take about 5 to 10 minutes to finish the firmware upgrading. It depends on your server model and network bandwidth.

  • Page 24: Accessing The Network Camera 24

    3. The live video will be displayed in your web browser. 4. If this is the first time installing the LevelOne network camera, an information bar will pop up as shown below. Follow the instructions to install the required plug-in on your computer.
  • Page 25 ► By default, the Network Camera is not password-protected. To prevent unauthorized access, it is highly recommended to set a password for the Network Camera. For more information about how to enable password protection, please refer to Security on page 26. ®...

  • Page 26: Using Rtsp Players

    Using RTSP Players To view the MPEG-4 streaming media using RTSP players, you can use one of the following applications that support RTSP streaming. Quick Time Player Real Player VLC media player 1. Launch the RTSP player. 2. Choose File > Open URL. A URL dialog box will pop up. mpegable Player 3.

  • Page 27: Using 3Gpp-Compatible Mobile Devices

    Using 3GPP-compatible Mobile Devices To view the streaming media through 3GPP-compatible mobile devices, make sure the Network Camera can be accessed over the Internet. For more information on how to set up the Network Camera over the Internet, please refer to Setup the Network Camera over the Internet on page 8. To utilize this feature, please check the following settings on your Network Camera: 1.

  • Page 28: Using Levelone Recording Software

    Using LevelOne Recording Software The product software CD also contains LevelOne’s recording software, allowing simultaneous monitoring and video recording for multiple Network Cameras. Please install the recording software, then launch the program to add the Network Camera to the Channel list. For detailed information about how to use the recording software, please refer to the user’s manual of the...

  • Page 29: Main Page 29

    Main Page This chapter explains the layout of the main page. It is composed of the following sections: LevelOne INC. Logo, Host Name, Camera Control Area, PTZ Control Panel, Configuration Area, and Live video window. LevelOne INC. Logo Click this logo to visit the LevelOne website.
  • Page 30 Pan: Click this button to start the auto pan. When the current position is Home or on the left side of Home, the camera starts panning from the current position to the left-most position, then to the right- most position, and finally backward to the original position. When the current position is on the right side of Home, the camera starts panning from the current position to the right-most position, then to the left- most position, and finally backward to the original position.
  • Page 31 Video Title: The video title can be confi gured. For more information, please refer to Video Settings on page 51. MPEG-4 Protocol and Media Options: The transmission protocol and media options for MPEG-4 video streaming. For further confi guration, please refer to Client Settings on page 21. Time: Display the current time.
  • Page 32 Go to: Once the Administrator has determined the list of preset positions, you can aim the camera using this command. For more information, please refer to Camera Control on page 59. ■ The following window is displayed when the video mode is set to MJPEG: Video Title: The video title can be confi gured.

  • Page 33: Client Settings 33

    Client Settings This chapter explains how to select the stream transmission mode and saving options on the local computer. When finished with the settings on this page, click Save on the bottom of the page to enable the settings. MPEG-4 Media Options Select whether to stream video or audio data or both.
  • Page 34 MP4 Saving Options Users can record live video as they are watching by clicking Start MP4 Recording on the main page. Here, you can specify the storage destination and file name. Folder: Specify the storage destination for the recorded video files. File name prefix: Enter the text that will be appended to the front of the video file name.

  • Page 35: Configuration 35

    Click Configuration on the main page to enter the camera setting pages. Note that only Administrators can access the configuration page. LevelOne offers an easy-to-use user interface that helps you set up your network camera with minimal effort. To simplify the setting procedure, two types of user interfaces are available: Advanced Mode for professional users and Basic Mode for entry-level users.

  • Page 36: System

    Advanced Mode Each function on the configuration list will be explained in the following sections. Those functions that are displayed only in Advanced Mode are marked with Advanced Mode . If you want to set up the advanced functions, please click [Advanced Mode] on the bottom of the configuration list to quickly switch over.
  • Page 37 System Time Keep current date and time: Select this option to preserve the current date and time of the Network Camera. The Network Camera’s internal real-time clock maintains the date and time even when the system power is turned off. Sync with computer time: Select this option to synchronize the date and time of the Network Camera with the local computer.

  • Page 38: Security

    Security This section explains how to enable password protection and create multiple accounts. Root Password The administrator account name is “root”, which is permanent and can not be deleted. If you want to add more accounts in the Manage User column, please set a password for the “root” account first. 1.

  • Page 39: Https (Hypertext Transfer Protocol Over Ssl)

    HTTPS (Hypertext Transfer Protocol over SSL) Advanced Mode This section explains how to enable authentication and encrypted communication over SSL (Secure Socket Layer). It helps protect streaming data transmission over the Internet on higher security level. Enable HTTPS Check this item to enable HTTPS communication, then select a connection option: "HTTP & HTTPS" or "HTTPS only".
  • Page 40 4. The Certificate Information will automatically de displayed in the third column as shown below. You can click Property to view detailed information about the certificate. 5. Click Home to return to the main page. Change the address from “http://” to “https://“ in the address bar and press Enter on your keyboard.
  • Page 41 Create self-signed certificate manually 1. Select this option. 2. Click Create to open a Create Certificate page, then click Save to generate the certificate. 3. The Certificate Information will automatically be displayed in the third column as shown below. You can click Property to see detailed information about the certificate.
  • Page 42 3. If you see the following Information bar, click OK and click on the Information bar on the top of the page to allow pop-ups. 4. The pop-up window shows an example of a certificate request. 42 - User's Manual...
  • Page 43 5. Look for a trusted certificate authority that issues digital certificates. Enroll the Network Camera. Wait for the certificate authority to issue a SSL certificate; click Browse... to search for the issued certificate, then click Upload in the second column. NOTE ►...

  • Page 44: Network

    Use fixed IP address: Select this option to manually assign a static IP address to the Network Camera. 1. You can make use of LevelOne Installation Wizard 2 on the software CD to easily set up the Network Camera on LAN. Please refer to Software Installation on page 11 for details.
  • Page 45 Enable UPnP port forwarding: To access the Network Camera from the Internet, select this option to allow the Network Camera to open ports on the router automatically so that video streams can be sent out from a LAN. To utilize of this feature, make sure that your router supports UPnP and it is activated.
  • Page 46 ► Steps to enable the UPnP user interface on your computer: Note that you must log on to the computer as a system administrator to install the UPnP components. 1. Go to Start, click Control Panel, then click Add or Remove Programs. 2.
  • Page 47 4. In the Networking Services dialog box, select Universal Plug and Play and click OK. 5. Click Next in the following window. 6. Click Finish. UPnP is enabled. ► How does UPnP work? UPnP networking technology provides automatic IP confi guration and dynamic discovery of devices added to a network.
  • Page 48 Enable IPv6 Select this option and click Save to enable IPv6 settings. Please note that this only works if your network environment and hardware equipment support IPv6. The ® browser should be Microsoft Internet Explorer 6.5, Mozilla Firefox 3.0 or above. When IPv6 is enabled, by default, the network camera will listen to router advertisements and be assigned with a link-local IPv6 address accordingly.
  • Page 49 Please follow the steps below to link to an IPv6 address: 1. Open your web browser. 2. Enter the link-global or link-local IPv6 address in the address bar of your web browser. 3. The format should be: 4. Press Enter on the keyboard or click Refresh button to refresh the webpage. For example: NOTE ►...
  • Page 50 HTTP Advanced Mode To utilize HTTP authentication, make sure that your have set a password for the Network Camera fi rst; please refer to Security on page 26 for details. Authentication: Depending on your network security requirements, the Network Camera provides two types of security settings for an HTTP transaction: basic and digest.
  • Page 51 URL command -- http://<ip address>:<http port>/<access name for stream1 or stream2> For example, when the Access name for stream 2 is set to video2.mjpg: 1. Launch Mozilla Firefox or Netscape. 2. Type the URL command in the address bar. Press Enter. 3.
  • Page 52 The FTP server allows the user to save recorded video clips. You can utilize LevelOne Installation Wizard 2 to upgrade the fi rmware via FTP server. By default, the FTP port is set to 21. It also can be assigned to another port number between 1025 and 65535.
  • Page 53 RTSP Streaming To utilize RTSP streaming authentication, make sure that you have set a password for the Network Camera fi rst; please refer to Security on page 26 for details. Authentication: Depending on your network security requirements, the Network Camera provides three types of security settings for streaming via RTSP protocol: disable, basic, and digest.
  • Page 54 RTSP port /RTP port for video, audio/ RTCP port for video, audio ■ RTSP (Real-Time Streaming Protocol) controls the delivery of streaming media. By default, the port number is set to 554. ■ The RTP (Real-time Transport Protocol) is used to deliver video and audio data to the clients. By default, the RTP port for video is set to 5556 and the RTP port for audio is set to 5558.

  • Page 55: Wireless Lan (Wcs-2040V3 Only)

    Wireless LAN (WCS-2040v3 only) SSID (Service Set Identifier): This is the name that identifies a wireless network. Access Points and wireless clients attempting to connect to a specific WLAN (Wireless Local Area Network) must use the same SSID. The default setting is “default”. Note: The maximum length for an SSID is 32 single-byte characters and cannot consist of “, <, >, or blank spaces.
  • Page 56 WEP (Wired Equivalent Privacy): This allows communication only with other devices with identical WEP settings. ■ Authentication Mode: Choose one of the following modes. The default setting is “Open”. Open – Communicates the key across the network. Shared – Allows communication only with other devices with identical WEP settings. ■...
  • Page 57 ► After wireless configurations are completed, click Save and the camera will reboot. Wait for the live image ito be reloaded to your browser. For LevelOne 7000-series cameras, you have to unplug the power and Ethernet cables from the camera; then re-plug the power cable to the camera. The camera will switch to wireless mode.

  • Page 58: Ddns

    DDNS: Dynamic domain name service Enable DDNS: Select this option to enable the DDNS setting. Provider: Select a DDNS provider from the provider drop-down list. LevelOne offers Safe100.net, a free dynamic domain name service, to LevelOne customers. It is recommended that you register Safe100.net to access LevelOne’s Network Cameras from the Internet.
  • Page 59 4. Select Enable DDNS and click Save to enable the setting. ■ CustomSafe100 LevelOne offers documents to establish a CustomSafe100 DDNS server for distributors and system integrators. You can use CustomSafe100 to register a dynamic domain name if your distributor or system integrators offer such services.

  • Page 60: Access List

    Access List Advanced Mode This section explains how to control access permission by verifying the client PC’s IP address. General Settings Maximum number of concurrent streaming connection(s) limited to: Simultaneous live viewing for 1~10 clients (including stream 1 and stream 2). The default value is 10. If you modify the value and click Save, all current connections will be disconnected and automatically attempt to re-link (IE Explore or Quick Time Player).
  • Page 61 ■ Refresh: Click this button to refresh all current connections. ■ Add to deny list: You can select entries from the Connection Status list and add them to the Deny List to deny access. Please note that those checked connections will only be disconnected temporarily and will automatically try to re-link again (IE Explore or Quick Time Player).
  • Page 62 Network: This rule allows the user to assign a network address and corresponding subnet mask to the Allow/Deny List. For example: IP address 192.168.2.x will be bolcked. Range: This rule allows the user to assign a range of IP addresses to the Allow/Deny List. This rule is only applied to IPv4.

  • Page 63: Audio And Video

    Audio and Video This section explains how to cofigure the audio and video settings of the Network Camera. It is composed of the following two columns: Video Settings and Audio Settings. Video Settings Video title: Enter a name that will be displayed on the title bar of the live video. Color: Select to display color or black/white video streams.
  • Page 64 Network Camera. This function can work seamlessly with LevelOne’s IP CamSecure recording software. When an event occurs, the recording software can request time shift cache stream from the camera, which allows the user to get an earlier video data.
  • Page 65 ■ Saturation: Adjust the image saturation level, which ranges from -5 to +5. The default value is set to 0. ■ Contrast: Adjust the image contrast level, which ranges from -5 to +5. The default value is set to 0. ■...
  • Page 66 Enable BLC (Back Light Compensation): Select it when the object is too dark or too bright to be recognized. It will give the captured images the necessary light compensation. BLC sens level: Select 0~7 level to adjust the sensitivity of BLC detection. Select a higher level will raise the sensitivity.
  • Page 67 There are four parameters provided in MPEG-4 mode which allow you to adjust the video performance: ■ Frame size Select the video size. Note that a larger frame size takes up more bandwidth. The frame sizes are selectable in the following resolutions: NTSC 704 x 480 704 x 576...

  • Page 68: Audio Settings

    ■ Maximum frame rate This limits the maximum refresh frame rate per second. Set the frame rate higher for smoother video quality. The frame rates are selectable at 1fps, 2fps, 3fps, 5fps, 8fps, 10fps, 15fps, 20fps, 25fps, and 30fps. You can also select Customize and manually enter a value. ■...

  • Page 69: Motion Detection

    Motion Detection This section explains how to confi gure the Network Camera to enable motion detection. A total of three motion detection windows can be confi gured. Follow the steps below to enable motion detection: 1. Click New to add a new motion detection window. 2.
  • Page 70 A green bar indicates that even though motions have been detected, the event has not been triggered because the image variations still fall under the defi ned threshold. NOTE ► How does motion detection work? There are two motion detection parameters: Sensitivity and Percentage. In the illustration above, frame A and frame B are two sequential images.

  • Page 71: Camera Control

    Camera Control This section explains how to control the Network Camera’s Pan/Tilt/Zoom/Focus operation via the control panel and how to preset positions. Preset Locations On this page, you can preset positions for the Network Camerato go to directly or patrol. A total of 128 preset positions can be configured.
  • Page 72 Patrol Settings You can select preset locations for the Network Camera to patrol. Please follow the steps below to set up a patrol schedule: 1. Click a preset location on the list and click Select. 2. The selected preset locations will be displayed on the Selected locations list. 3.

  • Page 73: Digital Zoom

    Digital Zoom If you check this optionand click the Save button, the digital zoom function of CCD module will be enabled. Zoom Times Display If you check this item and click the Save button, the zoom indicator will be displayed on the screen when you zoom in/out as shown in the illustration above.

  • Page 74: Homepage Layout

    Theme Options, the third column on this page. The settings will automatically show up in this Preview field. The following shows the homepage using the default settings: ■ Hide Powered by LevelOne: If you check this item, it will be removed from the homepage. Logo Here you can change the logo at the top of your homepage.
  • Page 75 Theme Options Here you can change the color of your homepage layout. There are three types of preset patterns for you to choose from. The new layout will simultaneously appear in the Preview filed. Click Save to enable the settings. Preset Patterns User's Manual - 75...
  • Page 76 ■ Follow the steps below to set up the customed homepage: 1. Click Custom on the left column. 2. Click the field where you want to change the color on the right column. Color Selector Custom Pattern 3. The palette window will pop up as shown below. 4.

  • Page 77: Application

    Please note that there is a limited number of customized scripts you can upload; if the current amount of customized scripts has reached the limit, an alert message will pop up. If you need more information, please ask for LevelOne’s technical support. Click to upload a file...

  • Page 78: Event Settings

    Event Settings In the Event Settings column, click Add to open the Event Settings page. On this page, you can arrange three elements -- Trigger, Schedule, and Action to set an event. A total of 3 event settings can be configured.
  • Page 79 An event is an action initiated by a user-defined trigger source; it is the causal arrangement of the following three elements: Trigger, Event Schedule, and Action. Trigger This is the cause or stimulus which defines when to trigger the Network Camera. The trigger source can be configured to use the Network Camera’s built-in motion detection mechanism or external digital input devices.
  • Page 80 Event Schedule Specify the period for the event. ■ Select the days of the week. ■ Select the recording schedule in 24-hr time format. Action Define the actions to be performed by the Network Camera when a trigger is activated. ■...
  • Page 81 Here is an example of Event Settings page: When completed, click Save to enable the settings and click Close to exit Event Settings page. The new event settings / server settings / media settings will appear in the event drop-down list on the Application page.
  • Page 82 Here is an example of Application page with an event setting: When the Event Status is ON, once an event is triggered by motion detection, the Network Camera will automatically send snapshots via e-mail. If you want to stop the event trigger, you can click to turn it to status or click Delete to remove the event setting.
  • Page 83 Server Settings Click Add Server on Event Settings page to open the Server Setting page. On this page, you can specify where the notifi cation messages are sent when a trigger is activated. A total of 5 server settings can be confi gured.
  • Page 84 FTP: Select to send the media fi les to an FTP server when a trigger is activated. ■ Server address: Enter the domain name or IP address of the FTP server. ■ Server port By default, the FTP server port is set to 21. It can also be assigned to another port number between 1025 and 65535.
  • Page 85 HTTP: Select to send the media fi les to an HTTP server when a trigger is activated. ■ URL: Enter the URL of the HTTP server. ■ User name: Enter the user name if necessary. ■ Password: Enter the password if necessary. To verify if the HTTP settings are correctly confi gured, click Test.
  • Page 86 Media Settings Click Add Media on the Event Settings page to open the Media Settings page. On this page, you can specify the type of media that will be sent when a trigger is activated. A total of 5 media settings can be configured.
  • Page 87 Video clip: Select to send video clips when a trigger is activated. ■ Source: Select to record video clips from stream 1 or stream 2. ■ Pre-event recording The Network Camera has a buffer area; it temporarily holds data up to a certain limit. Enter a number to decide the duration of recording before a trigger is activated.
  • Page 88 Recording notify message: Select to send a recording notification message when a trigger is activated. The following is an example of a recording notification message (.txt file), which shows a list of deleted previously-recorded data due to cycle recording. When completed, click Save to enable the settings and click Close to exit this page. The new media settings will appear on the Event Settings page.
  • Page 89 Click 20081120 to open the directory: The format is: HH (24r) Click to open the file list for that hour Click to go back to the previous Click to delete level of the directory selected items Click to delete all recorded data The format is: File name prefix + Minute (mm) You can set up the file name prefix on Media Settings page.

  • Page 90: Recording

    Recording Advanced Mode This section explains how to configure the recording settings for the Network Camera. Recording Settings NOTE ► Before setting up this page, please set up the Network Storage on the Server Settings page first. Network Storage Setting Click Server to open the Server Settings page and follow the steps below to set up:...
  • Page 91 If successful, you will receive a test.txt file on the network storage server. 3. Enter a server name. 4. Click Save to complete the settings and click Close to exit the page. Recording Settings Click Add to open the recording setting page. On this page, you can define the recording source, recording schedule and recording capacity.
  • Page 92 Source: Select the recording source (stream 1 or stream 2). Recording Schedule: Specify the recording duration. ■ Select the days of the week. ■ Select the recording start and end times in 24-hr time format. Destination: You can select the network storage to store the recorded video files. Capacity: You can choose either the “entire free space available”...

  • Page 93: System Log

    System Log Advanced Mode This section explains how to configure the Network Camera to send the system log to the remote server as backup. Remote Log You can confi gure the Network Camera to send the system log fi le to a remote server as a log backup. Before utilizing this feature, it is suggested that the user install a log-recording tool to receive system log messages from the Network Camera.

  • Page 94: View Parameters

    View Parameters Advanced Mode The View Parameters page lists the entire system’s parameters in alphabetical order. If you need technical assistance, please provide the information listed on this page. 94 - User's Manual...

  • Page 95: Maintenance

    Maintenance This chapter explains how to restore the Network Camera to factory default, upgrade firmware version, etc. Reboot This feature allows you to reboot the Network Camera, which takes about one minute to complete. When completed, the live video page will be displayed in your browser. The following message will be displayed during the rebooting process.
  • Page 96 Export / Upload Files Advanced Mode This feature allows you to Export / Upload daylight saving time rules, custom language fi les, and setting backup fi les. Export daylight saving time confi guration fi le: Click to set the start and end time of DST. Follow the steps below to export: 1.

  • Page 97: Upgrade Firmware

    Follow the steps below to upgrade the fi rmware: 1. Download the latest fi rmware fi le from the LevelOne website. The fi le is in .pkg fi le format. 2. Click Browse… and specify the fi rmware fi le.
  • Page 98 The following message is displayed when the upgrade has succeeded. The following message is displayed when you have selected an incorrect firmware file. 98 - User's Manual...
