18 C 2: VCX B
HAPTER
T — M
USINESS ELEPHONE ODEL
9 Telephone key pad — Use these buttons to dial telephone numbers and
to access additional features.
10 Hold button — Places a caller on hold. See
11 Transfer button — Sends the currently active call to another telephone.
See Transferring a
12 Conference button — Establishes a single call with up to three internal
parties, external parties, or a combination of both. See
Conference Call.
13 Redial button — Redials the last telephone number or extension that
you called. See
14 Speaker button — Enables you to use the speaker phone feature. Press
the Speaker button before you dial the call, when your telephone is
ringing, or while a call is in progress. To turn the speaker phone off and
resume the conversation, pick up the handset.
15 FWD MAIL button — Directs all incoming calls, after one ring, to your
call coverage point (by default, voice mail). See
Coverage Point. The light next to the FWD MAIL button remains red as
long as this option is enabled.
16 MSG (Message) button and Message Waiting Light — Press this
button to access your messages through the voice mail system (refer to
the IP Messaging Module User Guide for information on messaging). The
light next to the MWI light remains red as long as there is at least one
new, unreviewed message (voice, e-mail, or fax) in your mailbox, or in a
mailbox monitored by your telephone (for example, a hunt group mailbox
or the mailbox associated with a bridged line).
17 Hands Free button — Allows you to answer internal (intercom) calls
without picking up the handset. An external call (a call from outside your
VCX system) rings to your telephone as usual. See
Feature. The light next to the Hands Free button remains red as long as
this option is enabled.
18 Headset connector — Located on the underside of the telephone, this
RJ-11 connector enables you to plug in a headset so that you can listen to
calls and have your hands free. See
To enable the use of a connected headset, press the Headset button (by
default, button 16 at the top of the right column of buttons).
19 Volume down — Lowers the volume of the ringer, the speaker, the
handset, or the headset. See
3102
Call.
Making a Call to a Remote
Controlling the
Putting a Call on
Setting up a
Office.
Configuring a Call
Using the Hands Free
Using a Headset.
Volume.
Hold.
