1.7 Scope of Delivery

Please ensure you check the scope of delivery before signing any delivery documentation.
Below is a guideline checklist for what should be contained in each pack.
Claims for missing or damaged parts after signing for the delivery will not be accepted.
There are 3 options to select from when installing a Dimplex Heat Pump:
Pack 1 - Space heating and Dimplex A-Class Cylinder
This pack should contain four boxes;
• Heat Pump
• ACCHYPK Hydraulics Kit A (contains all of the necessary hydraulic components)
• Cylinder
• Cylinder Accessories
A separate wiring centre is not required as the wiring centre is built into the cylinder.
Pack 2 - Space heating and Dimplex Standard Heat Pump Cylinder
This pack should contain five boxes;
• Heat Pump
• ACCHYPK Hydraulics Kit A (contains all of the necessary hydraulic components)
• Cylinder
• Cylinder Accessories
• Wiring Centre
A separate wiring centre is required as the wiring centre is not built into the standard cylinder.
Pack 3 – Space heating only
This pack should contain three boxes;
• Heat Pump
• ACSHYPK Hydraulics Kit B (contains all of the necessary hydraulic components)
• Wiring Centre
• Accessories
A separate wiring centre is required to wire the circulation pumps and controls.
NOTE: Details for each installation pack are shown on pages 11-13.
All hydraulic kits listed in the following tables include the following documents;
ASHP Installation manual, part number 8/60472/0
•
• ASHP User manual, part number 8/60476/0
Please ensure that these manuals are left with the end user. Manuals must be stored safely for
future reference.
