8.5 POINT LISTS

8.5 POINT LISTS
POINT LIST FOR:
Index Description
0 Logic Input 1 Operated
1 Logic Input 2 Operated
2 Logic Input 3 Operated
3 Logic Input 4 Operated
4 Logic Input 5 Operated
5 Logic Input 6 Operated
6 Logic Input 7 Operated
7 Logic Input 8 Operated
8 Logic Input 9 Operated
9 Logic Input 10 Operated
10 Logic Input 11 Operated
11 Logic Input 12 Operated
12 Logic Input 13 Operated
13 Logic Input 14 Operated
14 Logic Input 15 Operated
15 Logic Input 16 Operated
16 Output Relay 1 Energized
17 Output Relay 2 Energized
18 Output Relay 3 Energized
19 Output Relay 4 Energized
20 Output Relay 5 Energized
21 Output Relay 6 Energized
22 Output Relay 7 Energized
23 Output Relay 8 Energized
24 Self-Test Relay Energized
25 Setpoint Group 1 Active
8
26 Setpoint Group 2 Active
27 Setpoint Group 3 Active
28 Setpoint Group 4 Active
Notes:
1. Any detected change in the state of any point will cause the generation of an event object.
