Page 1 Title Page GE Industrial Systems T35 Transformer Management Relay UR Series Instruction Manual T35 Revision: 4.6x Manual P/N: 1601-0114-K1 (GEK-113015) Copyright © 2005 GE Multilin 828742A1.CDR ISO9001:2000 GE Multilin 215 Anderson Avenue, Markham, Ontario Canada L6E 1B3 GE Multilin's Quality Management...
Page 3 GE Industrial Systems ADDENDUM This Addendum contains information that relates to the T35 Transformer Management Relay relay, version 4.6x. This addendum lists a number of information items that appear in the instruction manual GEK-113015 (revision K1) but are not included in the current T35 operations.
Page 5: Table Of Contents
IMPORTANT CONCEPTS ................. 1-4 1.3 ENERVISTA UR SETUP SOFTWARE 1.3.1 PC REQUIREMENTS ..................1-5 1.3.2 INSTALLATION....................1-5 1.3.3 CONNECTING ENERVISTA UR SETUP WITH THE T35......... 1-7 1.4 UR HARDWARE 1.4.1 MOUNTING AND WIRING................1-10 1.4.2 COMMUNICATIONS..................1-10 1.4.3 FACEPLATE DISPLAY ..................1-10 1.5 USING THE RELAY...
Page 6 FLEXCURVES™ ....................5-56 5.4 FLEXLOGIC™ 5.4.1 INTRODUCTION TO FLEXLOGIC™..............5-63 5.4.2 FLEXLOGIC™ RULES ..................5-68 5.4.3 FLEXLOGIC™ EVALUATION ................5-68 5.4.4 FLEXLOGIC™ EXAMPLE ................5-69 5.4.5 FLEXLOGIC™ EQUATION EDITOR..............5-73 5.4.6 FLEXLOGIC™ TIMERS ...................5-73 5.4.7 FLEXELEMENTS™ ..................5-74 5.4.8 NON-VOLATILE LATCHES ................5-78 T35 Transformer Management Relay GE Multilin...
Page 7 FLEXELEMENTS™ ..................6-15 6.3.6 TRANSDUCER INPUTS/OUTPUTS ..............6-15 6.4 RECORDS 6.4.1 USER-PROGRAMMABLE FAULT REPORTS ..........6-16 6.4.2 EVENT RECORDS ..................6-16 6.4.3 OSCILLOGRAPHY ..................6-16 6.4.4 DATA LOGGER ....................6-17 6.4.5 BREAKER MAINTENANCE ................6-17 GE Multilin T35 Transformer Management Relay...
Page 8 STORE MULTIPLE SETTINGS (FUNCTION CODE 10H) ........ B-5 B.2.6 EXCEPTION RESPONSES................B-5 B.3 FILE TRANSFERS B.3.1 OBTAINING UR FILES VIA MODBUS .............. B-6 B.3.2 MODBUS PASSWORD OPERATION ............... B-7 B.4 MEMORY MAPPING B.4.1 MODBUS MEMORY MAP ................. B-8 viii T35 Transformer Management Relay GE Multilin...
Page 9 COUNTERS .....................E-14 E.2.4 ANALOG INPUTS ....................E-15 F. MISCELLANEOUS F.1 CHANGE NOTES F.1.1 REVISION HISTORY ..................F-1 F.1.2 CHANGES TO THE T35 MANUAL ..............F-1 F.2 ABBREVIATIONS F.2.1 STANDARD ABBREVIATIONS ................. F-4 F.3 WARRANTY F.3.1 GE MULTILIN WARRANTY ................F-6 GE Multilin...
Page 10 TABLE OF CONTENTS T35 Transformer Management Relay GE Multilin...
Page 11: Getting Started
• registration card (attached as the last page of the manual) • Fill out the registration form and return to GE Multilin (include the serial number located on the rear nameplate). • For product information, instruction manual updates, and the latest software updates, please visit the GE Multilin web- site at http://www.GEindustrial.com/multilin.
Page 12: Ur Overview
This new generation of equipment must also be easily incorporated into automation systems, at both the station and enterprise levels. The GE Multilin Universal Relay (UR) has been developed to meet these goals. T35 Transformer Management Relay...
Page 13: Hardware Architecture
(dual) ring configuration. This feature is optimized for speed and intended for pilot- aided schemes, distributed logic applications, or the extension of the input/output capabilities of a single relay chassis. GE Multilin T35 Transformer Management Relay...
Page 14: Software Architecture
CTs and VTs is in the Introduction to AC Sources section in Chapter 5. A description of how digital signals are used and routed within the relay is contained in the Introduction to FlexLogic™ section in Chapter 5. T35 Transformer Management Relay GE Multilin...
Page 15: Enervista Ur Setup Software
Video capable of displaying 800 x 600 or higher in high-color mode (16-bit color) • RS232 and/or Ethernet port for communications to the relay The following qualified modems have been tested to be compliant with the T35 and the EnerVista UR Setup software. • US Robotics external 56K FaxModem 5686 •...
Page 16 “CD” if you do not have a web connection, then click the Check Now button to list software items for the T35. Select the T35 software program and release notes (if desired) from the list and click the Download Now button to obtain the installation program.
Page 17: Connecting Enervista Ur Setup With The T35
1 GETTING STARTED 1.3 ENERVISTA UR SETUP SOFTWARE 10. Click Finish to end the installation. The T35 device will be added to the list of installed IEDs in the enerVista Launch- pad window, as shown below. 1.3.3 CONNECTING ENERVISTA UR SETUP WITH THE T35 This section is intended as a quick start guide to using the EnerVista UR Setup software.
Page 18 Enter the physical communications parameters (baud rate and parity settings) in their respective fields. Click the Read Order Code button to connect to the T35 device and upload the order code. If an communications error occurs, ensure that the EnerVista UR Setup serial communications values entered in the previous step correspond to the relay setting values.
Page 19 The Display Properties settings can now be edited, printed, or changed according to user specifications. Refer to Chapter 4 in this manual and the EnerVista UR Setup Help File for more information about the using the EnerVista UR Setup software interface. NOTE GE Multilin T35 Transformer Management Relay...
Page 20: Ur Hardware
Figure 1–4: RELAY COMMUNICATIONS OPTIONS To communicate through the T35 rear RS485 port from a PC RS232 port, the GE Multilin RS232/RS485 converter box is required. This device (catalog number F485) connects to the computer using a “straight-through” serial cable. A shielded twisted-pair (20, 22, or 24 AWG) connects the F485 converter to the T35 rear communications port.
Page 21: Using The Relay
MESSAGE key from a setting value or actual value display returns to the header display. HIGHEST LEVEL LOWEST LEVEL (SETTING VALUE) ## SETTINGS # PASSWORD ACCESS LEVEL: ## PRODUCT SETUP # SECURITY Restricted ## SETTINGS ## SYSTEM SETUP GE Multilin T35 Transformer Management Relay 1-11...
Page 22: Relay Activation
Refer to the Changing Settings section in Chapter 4 for complete instructions on setting up security level passwords. NOTE 1.5.6 FLEXLOGIC™ CUSTOMIZATION FlexLogic™ equation editing is required for setting up user-defined logic for customizing the relay operations. See the Flex- Logic™ section in Chapter 5 for additional details. 1-12 T35 Transformer Management Relay GE Multilin...
Page 23: Commissioning
View the event recorder and oscillography or fault report for correct operation of inputs, outputs, and elements. If it is concluded that the relay or one of its modules is of concern, contact GE Multilin or one of its representatives for prompt service.
Page 24 1.5 USING THE RELAY 1 GETTING STARTED 1-14 T35 Transformer Management Relay GE Multilin...
Page 25: Product Description
Another option provides two 10BaseF fiber optic ports for redundancy. The Ethernet port supports IEC 61850, Modbus TCP, and TFTP protocols, and allows access to the relay via any standard web browser (T35 web pages). The IEC 60870- 5-104 protocol is supported on the Ethernet port. DNP 3.0 and IEC 60870-5-104 cannot be enabled at the same time.
Page 26: Ordering
CT/VT, digital input/output, transducer input/output. Each of these modules can be supplied in a number of configurations specified at the time of ordering. The information required to completely specify the relay is provided in the following table (see Chapter 3 for full details of relay modules). T35 Transformer Management Relay GE Multilin...
Page 27 2.1 INTRODUCTION Table 2–3: T35 ORDER CODES T35 - * 00 - H * * - F ** - H ** - M ** - P ** - U ** - W ** For Full Size Horizontal Mount T35 - * 00 - V F * - F ** - H ** - M **...
Page 28 4 dcmA Inputs, 4 dcmA Outputs (only one 5A module is allowed) INPUTS/OUTPUTS 8 RTD Inputs 4 RTD Inputs, 4 dcmA Outputs (only one 5D module is allowed) 4 dcmA Inputs, 4 RTD Inputs 8 dcmA Inputs T35 Transformer Management Relay GE Multilin...
Page 29: Specifications
IEEE Moderately/Very/Extremely harmonic inhibit level: 1.0 to 40.0% in steps of 0.1 Inverse; IEC (and BS) A/B/C and Short harmonic inhibit function: Adaptive, Traditional, Disabled Inverse; GE IAC Inverse, Short/Very/ harmonic inhibit mode: Per-phase, 2-out-of-3, Average Extremely Inverse; I t; FlexCurves™...
Page 30: User-Programmable Elements
Pickup & dropout delay: 0.000 to 65.535 s in steps of 0.001 chronize to a 3-bit control input NON-VOLATILE LATCHES Type: Set-dominant or Reset-dominant Number: 16 (individually programmed) Output: Stored in non-volatile memory Execution sequence: As input prior to protection, control, and FlexLogic™ T35 Transformer Management Relay GE Multilin...
Page 31: Monitoring
±1.0% of reading at I = 0.1 to 0.25 pu: ±0.05 Hz –0.8 < PF ≤ –1.0 and 0.8 < PF ≤ 1.0 I > 0.25 pu: ±0.02 Hz (when current signal is used for frequency measurement) GE Multilin T35 Transformer Management Relay...
Page 32: Inputs
Nominal AC voltage: 100 to 240 V at 50/60 Hz, 0.7 A INTERRUPTING CAPACITY Min/max AC voltage: 88 / 265 V at 48 to 62 Hz 100 000 A RMS symmetrical 10 000 A T35 Transformer Management Relay GE Multilin...
Page 33: Outputs
Internal Limiting Resistor: 100 Ω, 2 W 99% Settling time to a step change: 100 ms Isolation: 1.5 kV Driving signal: any FlexAnalog quantity Upper and lower limit for the driving signal: –90 to 90 pu in steps of 0.001 GE Multilin T35 Transformer Management Relay...
Page 34: Communications
1300 nm LED, Multimode –11 dBm asymmetry) channel delays using GPS satellite clock: 10 ms 1300 nm ELED, Singlemode –14 dBm 1300 nm Laser, Singlemode –14 dBm 1550 nm Laser, Singlemode –14 dBm 2-10 T35 Transformer Management Relay GE Multilin...
Page 35: Environmental
CLEANING Attach mounting brackets using 20 inch-pounds (±2 inch-pounds) Normally, cleaning is not required; but for situations where dust of torque. has accumulated on the faceplate display, a dry cloth can be used. GE Multilin T35 Transformer Management Relay 2-11...
Page 36 2.2 SPECIFICATIONS 2 PRODUCT DESCRIPTION 2-12 T35 Transformer Management Relay GE Multilin...
Page 37: Hardware
The relay must be mounted such that the faceplate sits semi-flush with the panel or switchgear door, allowing the operator access to the keypad and the RS232 communications port. The relay is secured to the panel with the use of four screws supplied with the relay. Figure 3–1: T35 HORIZONTAL MOUNTING AND DIMENSIONS GE Multilin T35 Transformer Management Relay...
Page 38: Module Withdrawal And Insertion
NOTE The version 4.0 release of the T35 relay includes new hardware (CPU and CT/VT modules). The new CPU mod- ules are specified with the following order codes: 9E, 9G, and 9H. The new CT/VT modules are specified with the following order codes: 8F, 8G, 8H, 8J.
Page 39: Rear Terminal Layout
(nearest to CPU module) which is indicated by an arrow marker on the terminal block. See the following figure for an example of rear terminal assignments. Figure 3–4: EXAMPLE OF MODULES IN F AND H SLOTS GE Multilin T35 Transformer Management Relay...
Page 40: Wiring
3.2 WIRING 3 HARDWARE 3.2WIRING 3.2.1 TYPICAL WIRING VOLTAGE SUPV. VOLT & CURRENT SUPV. WINDING 2 WINDING 3 WINDING 1 Figure 3–5: TYPICAL WIRING DIAGRAM T35 Transformer Management Relay GE Multilin...
Page 41: Dielectric Strength
(RFI) and electromagnetic interference (EMI). These protective components can be damaged by application of the ANSI/IEEE C37.90 specified test voltage for a period longer than the specified one minute. GE Multilin T35 Transformer Management Relay...
Page 42: Control Power
OCCUR! CAUTION The T35 relay, like almost all electronic relays, contains electrolytic capacitors. These capacitors are well known to be subject to deterioration over time if voltage is not applied periodically. Deterioration can be avoided by powering the relays up once a year.
Page 43 The phase voltage channels are used for most metering and protection purposes. The auxiliary voltage channel is used as input for the Synchrocheck and Volts/Hertz features. 827831AA-X5.CDR 827831AA-X3.CDR Figure 3–8: CT/VT MODULE WIRING Wherever a tilde “~” symbol appears, substitute with the Slot Position of the module. NOTE GE Multilin T35 Transformer Management Relay...
Page 44: Contact Inputs/Outputs
Cont Op x Ioff Load b) Current with optional voltage monitoring Current monitoring only Both voltage and current monitoring (external jumper a-b is required) 827821A5.CDR Load c) No monitoring Figure 3–9: FORM-A /SOLID STATE CONTACT FUNCTIONS T35 Transformer Management Relay GE Multilin...
Page 45 Fast Form-C ~6a, ~6c 2 Inputs Form-A ~7a, ~7c 2 Inputs Fast Form-C ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~8a, ~8c 2 Inputs Fast Form-C ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs GE Multilin T35 Transformer Management Relay...
Page 46 OUTPUT TERMINAL OUTPUT ASSIGNMENT ASSIGNMENT Not Used 2 Outputs Solid-State 2 Outputs Not Used 2 Outputs Solid-State 2 Outputs Not Used 2 Outputs Solid-State 2 Outputs Not Used 2 Outputs Solid-State Not Used 3-10 T35 Transformer Management Relay GE Multilin...
Page 47 3 HARDWARE 3.2 WIRING 827719CY-X1.dwg Figure 3–10: DIGITAL INPUT/OUTPUT MODULE WIRING (1 of 2) GE Multilin T35 Transformer Management Relay 3-11...
Page 48 – MOSFET Solid State Contact 827719CY-X2.dwg Figure 3–11: DIGITAL INPUT/OUTPUT MODULE WIRING (2 of 2) CORRECT POLARITY MUST BE OBSERVED FOR ALL CONTACT INPUT AND SOLID STATE OUTPUT CON- NECTIONS FOR PROPER FUNCTIONALITY. CAUTION 3-12 T35 Transformer Management Relay GE Multilin...
Page 49 There is no provision in the relay to detect a DC ground fault on 48 V DC control power external output. We recommend using an external DC supply. NOTE GE Multilin T35 Transformer Management Relay 3-13...
Page 50: Transducer Inputs/Outputs
(5A, 5C, 5D, 5E, and 5F) and channel arrangements that may be ordered for the relay. Wherever a tilde “~” symbol appears, substitute with the Slot Position of the module. NOTE 827831AB-X1.CDR Figure 3–13: TRANSDUCER INPUT/OUTPUT MODULE WIRING 3-14 T35 Transformer Management Relay GE Multilin...
Page 51: Rs232 Faceplate Port
Cabling for the RS232 port is shown in the following figure for both 9 pin and 25 pin connectors. The baud rate for this port is fixed at 19200 bps. NOTE Figure 3–14: RS232 FACEPLATE PORT CONNECTION GE Multilin T35 Transformer Management Relay 3-15...
Page 52: Cpu Communications Ports
To ensure maximum reliability, all equipment should have similar transient protection devices installed. Both ends of the RS485 circuit should also be terminated with an impedance as shown below. 3-16 T35 Transformer Management Relay GE Multilin...
Page 53 When splicing optical fibers, the diameter and numerical aperture of each fiber must be the same. In order to engage or dis- engage the ST type connector, only a quarter turn of the coupling is required. GE Multilin T35 Transformer Management Relay 3-17...
Page 54: Irig-B
UR-series relays can be synchronized. The IRIG-B repeater has a bypass function to maintain the time signal even when a relay in the series is powered down. Figure 3–18: IRIG-B REPEATER 3-18 T35 Transformer Management Relay GE Multilin...
Page 55: Direct I/O Communications
3.3DIRECT I/O COMMUNICATIONS 3.3.1 DESCRIPTION The T35 direct inputs/outputs feature makes use of the Type 7 series of communications modules. These modules are also used by the L90 Line Differential Relay for inter-relay communications. The direct input/output feature uses the communica- tions channel(s) provided by these modules to exchange digital state information between relays.
Page 56 Channel 1 - G.703; Channel 2 - 1550 nm, single-mode, LASER IEEE C37.94, 820 nm, multi-mode, LED, 1 channel IEEE C37.94, 820 nm, multi-mode, LED, 2 channels OBSERVING ANY FIBER TRANSMITTER OUTPUT MAY CAUSE INJURY TO THE EYE. CAUTION 3-20 T35 Transformer Management Relay GE Multilin...
Page 57: Fiber: Led And Eled Transmitters
1 Channel 2 Channels 831720A3.CDR Figure 3–23: LASER FIBER MODULES When using a LASER Interface, attenuators may be necessary to ensure that you do not exceed Maximum Optical Input Power to the receiver. WARNING GE Multilin T35 Transformer Management Relay 3-21...
Page 58: Interface
Remove the top cover by sliding it towards the rear and then lift it upwards. Set the Timing Selection Switches (Channel 1, Channel 2) to the desired timing modes. Replace the top cover and the cover screw. 3-22 T35 Transformer Management Relay GE Multilin...
Page 59 Loop Timing Mode for connections to higher order systems. For connection to a higher order system (UR- to-multiplexer, factory defaults), set to Octet Timing (S1 = ON) and set Timing Mode = Loop Timing (S5 = OFF and S6 = OFF). GE Multilin T35 Transformer Management Relay 3-23...
Page 60: Rs422 Interface
The shield pins (6a and 7b) are internally connected to the ground pin (8a). Proper shield termination is as follows: Site 1: Terminate shield to pins 6a and/or 7b; Site 2: Terminate shield to ‘COM’ pin 2b. 3-24 T35 Transformer Management Relay GE Multilin...
Page 61 1 as shown in the following figure. If the Terminal Timing feature is not available or this type of connection is not desired, the G.703 interface is a viable option that does not impose timing restrictions. GE Multilin T35 Transformer Management Relay 3-25...
Page 62 Figure 3–29: TIMING CONFIGURATION FOR RS422 TWO-CHANNEL, 3-TERMINAL APPLICATION Data Module 1 provides timing to the T35 RS422 interface via the ST(A) and ST(B) outputs. Data Module 1 also provides timing to Data Module 2 TT(A) and TT(B) inputs via the ST(A) and AT(B) outputs. The Data Module pin numbers have been omitted in the figure above since they may vary depending on the manufacturer.
Page 63: Rs422 And Fiber Interface
When using a LASER Interface, attenuators may be necessary to ensure that you do not exceed Maximum Optical Input Power to the receiver. WARNING Shld. Tx - G.703 Rx - CHANNEL 1 Tx + Rx + SURGE FIBER CHANNEL 2 Figure 3–32: G.703 AND FIBER INTERFACE CONNECTION GE Multilin T35 Transformer Management Relay 3-27...
Page 64: Ieee C37.94 Interface
Loop Timed Internal Timing Mode xt te xt te xt te xt te xt te xt te xt te xt te xt te xt te Switch Internal Loop Timed 3-28 T35 Transformer Management Relay GE Multilin...
Page 65 Once the clips have cleared the raised edge of the chassis, engage the clips simultaneously. When the clips have locked into position, the module will be fully inserted. Figure 3–33: C37.94 TIMING SELECTION SWITCH SETTING GE Multilin T35 Transformer Management Relay 3-29...
Page 66 3.3 DIRECT I/O COMMUNICATIONS 3 HARDWARE 3-30 T35 Transformer Management Relay GE Multilin...
Page 67: Human Interfaces
To start using the EnerVista UR Setup software, a site definition and device definition must first be created. See the EnerV- ista UR Setup Help File or refer to the Connecting EnerVista UR Setup with the T35 section in Chapter 1 for details.
Page 68 UR FIRMWARE UPGRADES The firmware of a T35 device can be upgraded, locally or remotely, via the EnerVista UR Setup software. The correspond- ing instructions are provided by the EnerVista UR Setup Help file under the topic “Upgrading Firmware”.
Page 69: Enervista Ur Setup Main Window
Settings List control bar window Device data view window(s), with common tool bar Settings File data view window(s), with common tool bar Workspace area with data view tabs Status bar Figure 4–1: ENERVISTA UR SETUP SOFTWARE MAIN WINDOW GE Multilin T35 Transformer Management Relay...
Page 70: Faceplate Interface
RESET command must be initiated to allow the latch to be reset. • ALARM: Indicates that the selected FlexLogic™ operand serving as an Alarm switch has operated. This indicator is never latched. T35 Transformer Management Relay GE Multilin...
Page 71 Firmware revisions 2.9x and earlier support eight user setting groups; revisions 3.0x and higher support six setting groups. For convenience of users using earlier firmware revisions, the relay panel shows eight NOTE setting groups. Please note that the LEDs, despite their default labels, are fully user-programmable. GE Multilin T35 Transformer Management Relay...
Page 72 Microsoft Word 97 or later software for editing the template. • 1 each of: 8.5" x 11" white paper, exacto knife, ruler, custom display module (GE Multilin Part Number: 1516-0069), and a custom module cover (GE Multilin Part Number: 1502-0015).
Page 73: Display
SETTINGS COMMANDS TARGETS " " " " ## ACTUAL VALUES ## SETTINGS ## COMMANDS No Active ## STATUS ## PRODUCT SETUP ## VIRTUAL INPUTS Targets USER DISPLAYS (when in use) " User Display 1 GE Multilin T35 Transformer Management Relay...
Page 74 FLASH MESSAGE play Properties. TIME: 1.0 s " To view the remaining settings associated with the Display Properties subheader, DEFAULT MESSAGE repeatedly press the MESSAGE key. The last message appears as shown. INTENSITY: 25% T35 Transformer Management Relay GE Multilin...
Page 75: Changing Settings
ENTERING ALPHANUMERIC TEXT Text settings have data values which are fixed in length, but user-defined in character. They may be comprised of upper case letters, lower case letters, numerals, and a selection of special characters. GE Multilin T35 Transformer Management Relay...
Page 76: Settings
RELAY SETTINGS: NEW SETTING Not Programmed Programmed HAS BEEN STORED When the "NEW SETTING HAS BEEN STORED" message appears, the relay will be in "Programmed" state and the In Service LED will turn on. 4-10 T35 Transformer Management Relay GE Multilin...
Page 77 (for each security level) before a new password can be entered. In the event that a password has been lost (forgotten), submit the corresponding Encrypted Password from the PASSWORD menu to the Factory for decoding. SECURITY GE Multilin T35 Transformer Management Relay 4-11...
Page 78 4.2 FACEPLATE INTERFACE 4 HUMAN INTERFACES 4-12 T35 Transformer Management Relay GE Multilin...
Page 79: Overview
See page 5–34. # INSTALLATION See page 5–39. ## SETTINGS # AC INPUTS See page 5–40. ## SYSTEM SETUP # POWER SYSTEM See page 5–42. # SIGNAL SOURCES See page 5–43. # TRANSFORMER See page 5–45. GE Multilin T35 Transformer Management Relay...
Page 80 See page 5–108. # REMOTE DEVICES See page 5–109. # REMOTE INPUTS See page 5–110. # REMOTE OUTPUTS See page 5–111. # DNA BIT PAIRS # REMOTE OUTPUTS See page 5–111. # UserSt BIT PAIRS T35 Transformer Management Relay GE Multilin...
Page 81: Introduction To Elements
(based on VT ratio and connection) to secondary VT voltage applied to the relay. For example, on a system with a 13.8 kV nominal primary voltage and with 14400:120 V Delta-connected VTs, the secondary nominal voltage (1 pu) would be: GE Multilin T35 Transformer Management Relay...
Page 82: Introduction To Ac Sources
BACKGROUND The T35 may be used on systems with breaker-and-a-half or ring bus configurations. In these applications, each of the two three-phase sets of individual phase currents (one associated with each breaker) can be used as an input to a breaker fail- ure element.
Page 83 The CT/VT modules calculate total waveform RMS levels, fundamental frequency phasors, symmetrical components and harmonics for voltage or current, as allowed by the hardware in each channel. These modules may calculate other parameters as directed by the CPU module. GE Multilin T35 Transformer Management Relay...
Page 84 Source is a transformer winding, on which a three phase voltage is mea- sured, and the sum of the currents from CTs on each of two breakers is required to measure the winding current flow. T35 Transformer Management Relay GE Multilin...
Page 85: Product Setup
If an entered password is lost (or forgotten), consult the factory with the corresponding ENCRYPTED PASSWORD The T35 provides a means to raise an alarm upon failed password entry. Should password verification fail while accessing a password-protected level of the relay (either settings or commands), the FlexLogic™...
Page 86: Display Properties
Some customers prefer very low currents to display as zero, while others prefer the current be displayed even when the value reflects noise rather than the actual signal. The T35 applies a cut- off value to the magnitudes and angles of the measured currents.
Page 87 VOLTAGE CUT-OFF LEVEL CURRENT CUT-OFF LEVEL as valid measurements. Unless dictated otherwise by a specific application, the default settings of “0.02 pu” for and “1.0 V” for are recommended. NOTE CURRENT CUT-OFF LEVEL VOLTAGE CUT-OFF LEVEL GE Multilin T35 Transformer Management Relay...
Page 88: Clear Relay Records
Selected records can be cleared from user-programmable conditions with FlexLogic™ operands. Assigning user-program- mable pushbuttons to clear specific records are typical applications for these commands. Since the T35 responds to rising edges of the configured FlexLogic™ operands, they must be asserted for at least 50 ms to take effect.
Page 89: Communications
0 ms The T35 is equipped with up to 3 independent serial communication ports. The faceplate RS232 port is intended for local use and is fixed at 19200 baud and no parity. The rear COM1 port type is selected when ordering: either an Ethernet or RS485 port.
Page 90 MODBUS SLAVE ADDRESS grammed. For the RS485 ports each T35 must have a unique address from 1 to 254. Address 0 is the broadcast address which all Modbus slave devices listen to. Addresses do not have to be sequential, but no two devices can have the same address or conflicts resulting in errors will occur.
Page 91 DEADBAND: 30000 Range: 0 to 65535 in steps of 1 DNP OTHER DEFAULT MESSAGE DEADBAND: 30000 Range: 1 to 10080 min. in steps of 1 DNP TIME SYNC IIN MESSAGE PERIOD: 1440 min GE Multilin T35 Transformer Management Relay 5-13...
Page 92 DNP VOLTAGE SCALE FACTOR Input points that are voltages will be returned with values 1000 times smaller (e.g. a value of 72000 V on the T35 will be returned as 72). These settings are useful when analog input values must be adjusted to fit within certain ranges in DNP masters.
Page 93 47, etc. The minimum number of binary input points that can be selected is 16 (1 block). If all of the BIN INPUT BLOCK X settings are set to “Not Used”, the standard list of 928 points will be in effect. The T35 will form the binary inputs points list from the settings up to the first occurrence of a setting value of “Not Used”.
Page 94 The T35 supports the Manufacturing Message Specification (MMS) protocol as specified by IEC 61850. MMS is supported over two protocol stacks: TCP/IP over ethernet and TP4/CLNP (OSI) over ethernet. The T35 operates as an IEC 61850 server. The Remote Inputs/Outputs section in this chapter describe the peer-to-peer GSSE/GOOSE message scheme.
Page 95 Internet Explorer or Netscape Navigator. This feature is available only if the T35 has the ethernet option installed. The web pages are organized as a series of menus that can be accessed starting at the T35 “Main Menu”. Web pages are available showing DNP and IEC 60870-5-104 points lists, Modbus registers, Event Records, Fault Reports, etc.
Page 96 NUMBER: The Trivial File Transfer Protocol (TFTP) can be used to transfer files from the T35 over a network. The T35 operates as a TFTP server. TFTP client software is available from various sources, including Microsoft Windows NT. The dir.txt file obtained from the T35 contains a list and description of all available files (event records, oscillography, etc.).
Page 97 T35 clock is closely synchronized with the SNTP/NTP server. It may take up to one minute for the T35 to signal an SNTP self-test error if the server is offline.
Page 98 MESSAGE (Modbus register address range) Fast exchanges (50 to 1000 ms) are generally used in control schemes. The T35 has one fast exchange (Exchange 1) and two slow exchanges (Exchanges 2 and 3). The settings menu for the slow EGD exchanges is shown below: !"...
Page 99: Modbus User Map
See also the !" menu for manually setting the relay clock. COMMANDS SET DATE AND TIME setting allows changes to the date and/or time to be captured in the event record. REAL TIME CLOCK EVENTS GE Multilin T35 Transformer Management Relay 5-21...
Page 100: User-Programmable Fault Report
The user programmable record contains the following information: the user-programmed relay name, detailed firmware revision (4.6x, for example) and relay model (T35), the date and time of trigger, the name of pre-fault trigger (specific Flex- Logic™ operand), the name of fault trigger (specific FlexLogic™ operand), the active setting group at pre-fault trigger, the active setting group at fault trigger, pre-fault values of all programmed analog channels (one cycle before pre-fault trigger), and fault values of all programmed analog channels (at the fault trigger).
Page 101: Oscillography
64 samples per cycle, i.e. it has no effect on the fundamental calculations of the device. When changes are made to the oscillography settings, all existing oscillography records will be CLEARED. WARNING GE Multilin T35 Transformer Management Relay 5-23...
Page 102: Data Logger
Range: Off, any FlexAnalog parameter. See Appendix A: DATA LOGGER CHNL 16: MESSAGE FlexAnalog Parameters for complete list. Range: Not applicable - shows computed data only DATA LOGGER CONFIG: MESSAGE 0 CHNL x 0.0 DAYS 5-24 T35 Transformer Management Relay GE Multilin...
Page 103: User-Programmable Leds
Stage 1: All 62 LEDs on the relay are illuminated. This is a quick test to verify if any of the LEDs is “burned”. This stage lasts as long as the control input is on, up to a maximum of 1 minute. After 1 minute, the test will end. GE Multilin T35 Transformer Management Relay 5-25...
Page 104 Configure User-Programmable Pushbutton 1 by making the following entries in the SETTINGS !" menu: PRODUCT SETUP USER-PROGRAMMABLE PUSHBUTTONS USER PUSHBUTTON 1 “Self-reset” PUSHBUTTON 1 FUNCTION: “0.10 s” PUSHBTN 1 DROP-OUT TIME: 5-26 T35 Transformer Management Relay GE Multilin...
Page 105 ‘Latched’, the LED, once lit, remains so until reset by the faceplate RESET button, from a remote device via a communi- cations channel, or from any programmed operand, even if the LED operand state de-asserts. GE Multilin T35 Transformer Management Relay 5-27...
Page 106: User-Programmable Self Tests
ANY MINOR ALARM ANY SELF-TEST minor alarms continue to function along with other major and minor alarms. Refer to the Relay Self-Tests section in Chapter 7 for additional information on major and minor self-test alarms. 5-28 T35 Transformer Management Relay GE Multilin...
Page 107: Control Pushbuttons
LED test, switching setting groups, and invoking and scrolling though user-pro- grammable displays, etc. The location of the control pushbuttons in the following figure. An additonal four control pushbuttons are included when the T35 is ordered with twelve user programmable pushbuttons. STATUS...
Page 108: User-Programmable Pushbuttons
MESSAGE EVENTS: Disabled The T35 has 12 optional user-programmable pushbuttons available, each configured via 12 identical menus. The pushbut- tons provide an easy and error-free method of manually entering digital information (On, Off) into FlexLogic™ equations as well as protection and control elements. Typical applications include breaker control, autorecloser blocking, ground protec- tion blocking, and setting groups changes.
Page 109: Flex State Parameters
The state bits may be read out in the "Flex States" register array beginning at Modbus address 900 hex. 16 states are packed into each register, with the lowest-numbered state in the lowest-order bit. There are 16 registers in total to accom- modate the 256 state bits. GE Multilin T35 Transformer Management Relay 5-31...
Page 110: User-Definable Displays
Range: 0 to 65535 in steps of 1 DISP 1 ITEM 3 MESSAGE Range: 0 to 65535 in steps of 1 DISP 1 ITEM 4 MESSAGE Range: 0 to 65535 in steps of 1 DISP 1 ITEM 5: MESSAGE 5-32 T35 Transformer Management Relay GE Multilin...
Page 111 This item is not being used - there is no corresponding DISP 1 ITEM 5: MESSAGE Tilde marker in Top or Bottom lines. Shows the resultant display content. USER DISPLAYS Current X 0.850 A → Current Y 0.327 A GE Multilin T35 Transformer Management Relay 5-33...
Page 112: Direct Inputs/Outputs
128 kbps. For local relays configured with all other communication cards (i.e. 7E, 7F, 7G, 7L, 7M, 7N, 7P, 7R, 7S, 7T, 7W, 74, 75, 76 and 77), the baud rate will be set to 64 kbps. All IEDs communicating over direct inputs/outputs must be set to 5-34 T35 Transformer Management Relay GE Multilin...
Page 113 2, 3, and 4, to the upstream device that monitors a single incomer of the busbar, as shown below. UR IED 1 BLOCK UR IED 4 UR IED 2 UR IED 3 842712A1.CDR Figure 5–7: SAMPLE INTERLOCKING BUSBAR PROTECTION SCHEME GE Multilin T35 Transformer Management Relay 5-35...
Page 114 Figure 5–9: THREE-TERMINAL LINE APPLICATION A permissive pilot-aided scheme could be implemented in a two-ring configuration as shown below (IEDs 1 and 2 constitute a first ring, while IEDs 2 and 3 constitute a second ring): 5-36 T35 Transformer Management Relay GE Multilin...
Page 115 IED 2 to IED 3: 0.2 of power system cycle The two communications configurations could be applied to both permissive and blocking schemes. Speed, reliability and cost should be taken into account when selecting the required architecture. GE Multilin T35 Transformer Management Relay 5-37...
Page 116 MESSAGE EVENTS: Disabled The T35 checks integrity of the incoming direct input/output messages using a 32-bit CRC. The CRC Alarm function is available for monitoring the communication medium noise by tracking the rate of messages failing the CRC check. The monitoring function counts all incoming messages, including messages that failed the CRC check.
Page 117: Installation
MESSAGE EVENTS: Disabled The T35 checks integrity of the direct input/output communication ring by counting unreturned messages. In the ring config- uration, all messages originating at a given device should return within a pre-defined period of time. The Unreturned Mes- sages Alarm function is available for monitoring the integrity of the communication ring by tracking the rate of unreturned messages.
Page 118: System Setup
1000:1 CT before summation. If a protection element is set up to act on SRC 1 currents, then a pickup level of 1 pu will operate on 1000 A primary. The same rule applies for current sums from CTs with different secondary taps (5 A and 1 A). 5-40 T35 Transformer Management Relay GE Multilin...
Page 119 On a 14.4 kV system with a Delta connection and a VT primary to secondary turns ratio of 14400:120, the voltage value entered would be 120, i.e. 14400 / 120. Any ordered module banks containing VTs must be plugged into slot F. NOTE GE Multilin T35 Transformer Management Relay 5-41...
Page 120: Power System
"Disabled" in very unusual circumstances; consult the factory for spe- FREQUENCY TRACKING cial variable-frequency applications. NOTE Systems with a phase sequence of ACB require special consideration as described in the Phase Relation- ships of Three-phase Transformers sub-section of Chapter 5. NOTE 5-42 T35 Transformer Management Relay GE Multilin...
Page 121: Signal Sources
A disturbance detector is provided for each Source. The 50DD function responds to the changes in magnitude of the sequence currents. The disturbance detector scheme logic is as follows: GE Multilin T35 Transformer Management Relay 5-43...
Page 122 CT/VT inputs that are used to provide the data. DSP Bank Source 1 Source 2 Amps Amps Source 3 51BF-1 51BF-2 Volts Amps Amps Volts Source 4 UR Relay Figure 5–13: EXAMPLE USE OF SOURCES 5-44 T35 Transformer Management Relay GE Multilin...
Page 123: Transformer
See page 5–47. MESSAGE The T35 Transformer Management Relay has been designed to provide primary protection for medium to high voltage power transformers. It performs this function on a variety of power transformer configurations with up to six sets of three phase inputs available.
Page 124 C = 0.02 × (weight of core and aluminum coils from the nameplate) • WINDING THERMAL TIME CONSTANT: Required for insulation aging calculation. If this value is not available from the transformer data, select “2 min.”. 5-46 T35 Transformer Management Relay GE Multilin...
Page 125 CTs and tapped relay windings with some combination of CT connections. The T35 simplifies these configuration issues. All CTs at the transformer are connected Wye (polarity markings pointing away from the transformer). User-entered settings in the relay characterizing the transformer being protected and allow the relay to automatically perform all necessary magnitude, phase angle, and zero sequence compensation.
Page 126 The reason the source phase sequence must be stated when describing the winding phase relationships is that these rela- tionships change when the phase sequence changes. The example shown below shows why this happens, using a trans- former described in IEC nomenclature as a type “Yd1” or in GE Multilin nomenclature as a “Y/d30.” 828716A1.CDR Figure 5–14: EXAMPLE TRANSFORMER...
Page 127 Note that the delta winding currents leads the wye winding currents by 30°, (which is a type Yd11 in IEC nomenclature and a type Y/d330 in GE Multilin nomenclature) which is in disagreement with the transformer nameplate. This is because the physical connections and hence the equations used to calculate current for the delta winding have not changed.
Page 128 5.3 SYSTEM SETUP 5 SETTINGS The T35 automatically corrects for CT mismatch errors. All currents are magnitude compensated to be in units of the CTs of one winding before the calculation of differential and restraint quantities. The reference winding (w ) is the winding to which all currents are referred.
Page 129 The T35 performs this phase angle compensation and zero sequence removal automatically, based on the settings entered for the transformer. All CTs are connected Wye (polarity markings pointing away from the transformer). All currents are phase and zero sequence compensated internally before the calculation of differential and restraint quantities.
Page 130 ------ - I – – ------ - I ------ - I ------ - I ------ - I – – ------ - I ------ - I ------ - I ------ - I – – 5-52 T35 Transformer Management Relay GE Multilin...
Page 131 = magnitude, phase and zero sequence compensated winding w phase currents = magnitude compensation factor for winding w (see previous sections) [ ] I , and = phase and zero sequence compensated winding w phase currents (see earlier) GE Multilin T35 Transformer Management Relay 5-53...
Page 132 SYSTEM SETUP SIGNAL !" settings menu. SOURCES SOURCE n “WDG 1X” SOURCE 1 NAME: “F1” SOURCE 1 PHASE CT: “None” SOURCE 1 GROUND CT: “None” SOURCE 1 PHASE VT: “None” SOURCE 1 AUX VT: 5-54 T35 Transformer Management Relay GE Multilin...
Page 133 SYSTEM SETUP SIGNAL !" settings menu. SOURCES SOURCE n “WDG 2" SOURCE 2 NAME: “M1” SOURCE 2 PHASE CT: “M1” SOURCE 2 GROUND CT: “None” SOURCE 2 PHASE VT: “None” SOURCE 2 AUX VT: GE Multilin T35 Transformer Management Relay 5-55...
Page 134: Flexcurves
1, i.e. 0.98 pu and 1.03 pu. It is recommended to set the two times to a similar value; otherwise, the linear NOTE approximation may result in undesired behavior for the operating quantity that is close to 1.00 pu. 5-56 T35 Transformer Management Relay GE Multilin...
Page 135 Multiplier and Adder settings only affect the curve portion of the characteristic and not the MRT and HCT settings. The HCT settings override the MRT settings for multiples of pickup greater than the HCT Ratio. NOTE GE Multilin T35 Transformer Management Relay 5-57...
Page 136 EnerVista UR Setup software generates an error message and discards the proposed changes. NOTE e) STANDARD RECLOSER CURVES The standard Recloser curves available for the T35 are displayed in the following graphs. 5-58 T35 Transformer Management Relay...
Page 137 CURRENT (multiple of pickup) 842723A1.CDR Figure 5–20: RECLOSER CURVES GE101 TO GE106 GE142 GE138 GE120 GE113 0.05 7 8 9 10 12 CURRENT (multiple of pickup) 842725A1.CDR Figure 5–21: RECLOSER CURVES GE113, GE120, GE138 AND GE142 GE Multilin T35 Transformer Management Relay 5-59...
Page 138 Figure 5–22: RECLOSER CURVES GE134, GE137, GE140, GE151 AND GE201 GE152 GE141 GE131 GE200 7 8 9 10 12 CURRENT (multiple of pickup) 842728A1.CDR Figure 5–23: RECLOSER CURVES GE131, GE141, GE152, AND GE200 5-60 T35 Transformer Management Relay GE Multilin...
Page 139 Figure 5–24: RECLOSER CURVES GE133, GE161, GE162, GE163, GE164 AND GE165 GE132 GE139 GE136 GE116 0.05 GE117 GE118 0.02 0.01 7 8 9 10 12 CURRENT (multiple of pickup) 842726A1.CDR Figure 5–25: RECLOSER CURVES GE116, GE117, GE118, GE132, GE136, AND GE139 GE Multilin T35 Transformer Management Relay 5-61...
Page 140 Figure 5–26: RECLOSER CURVES GE107, GE111, GE112, GE114, GE115, GE121, AND GE122 GE202 GE135 GE119 7 8 9 10 12 CURRENT (multiple of pickup) 842727A1.CDR Figure 5–27: RECLOSER CURVES GE119, GE135, AND GE202 5-62 T35 Transformer Management Relay GE Multilin...
Page 141: Flexlogic
Figure 5–28: UR ARCHITECTURE OVERVIEW The states of all digital signals used in the T35 are represented by flags (or FlexLogic™ operands, which are described later in this section). A digital “1” is represented by a 'set' flag. Any external contact change-of-state can be used to block an element from operating, as an input to a control feature in a FlexLogic™...
Page 142 "1"). The operands available for this relay are listed alphabetically by types in the following table. Table 5–7: T35 FLEXLOGIC™ OPERANDS (Sheet 1 of 4) OPERAND TYPE OPERAND SYNTAX...
Page 143 5 SETTINGS 5.4 FLEXLOGIC™ Table 5–7: T35 FLEXLOGIC™ OPERANDS (Sheet 2 of 4) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION ELEMENT: Counter 1 HI Digital Counter 1 output is ‘more than’ comparison value Digital Counters Counter 1 EQL Digital Counter 1 output is ‘equal to’ comparison value Counter 1 LO Digital Counter 1 output is ‘less than’...
Page 144 5.4 FLEXLOGIC™ 5 SETTINGS Table 5–7: T35 FLEXLOGIC™ OPERANDS (Sheet 3 of 4) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION FIXED OPERANDS Logic = 0. Does nothing and may be used as a delimiter in an equation list; used as ‘Disable’ by other features.
Page 145 5 SETTINGS 5.4 FLEXLOGIC™ Table 5–7: T35 FLEXLOGIC™ OPERANDS (Sheet 4 of 4) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION SELF- ANY MAJOR ERROR Any of the major self-test errors generated (major error) DIAGNOSTICS ANY MINOR ERROR Any of the minor self-test errors generated (minor error)
Page 146: Flexlogic™ Rules
When making changes to settings, all FlexLogic™ equations are re-compiled whenever any new setting value is entered, so all latches are automatically reset. If it is necessary to re-initialize FlexLogic™ during testing, for example, it is suggested to power the unit down and then back up. 5-68 T35 Transformer Management Relay GE Multilin...
Page 147: Flexlogic™ Example
DIGITAL ELEMENT 1 on Dropout State=Pickup (200 ms) DIGITAL ELEMENT 2 Timer 1 State=Operated Time Delay on Pickup (800 ms) CONTACT INPUT H1c State=Closed VIRTUAL OUTPUT 3 827026A2.VSD Figure 5–30: LOGIC EXAMPLE WITH VIRTUAL OUTPUTS GE Multilin T35 Transformer Management Relay 5-69...
Page 148 Following the procedure outlined, start with parameter 99, as follows: 99: The final output of the equation is Virtual Output 3, which is created by the operator "= Virt Op n". This parameter is therefore "= Virt Op 3." 5-70 T35 Transformer Management Relay GE Multilin...
Page 149 87: The input just below the upper input to OR #1 is operand “Virt Op 2 On". 86: The upper input to OR #1 is operand “Virt Op 1 On". 85: The last parameter is used to set the latch, and is operand “Virt Op 4 On". GE Multilin T35 Transformer Management Relay 5-71...
Page 150 In the following equation, Virtual Output 3 is used as an input to both Latch 1 and Timer 1 as arranged in the order shown below: DIG ELEM 2 OP Cont Ip H1c On AND(2) 5-72 T35 Transformer Management Relay GE Multilin...
Page 151: Flexlogic Equation Editor
TIMER 1 PICKUP DELAY: Sets the time delay to pickup. If a pickup delay is not required, set this function to "0". • TIMER 1 DROPOUT DELAY: Sets the time delay to dropout. If a dropout delay is not required, set this function to "0". GE Multilin T35 Transformer Management Relay 5-73...
Page 152: Flexelements
The element can be programmed to respond either to a signal level or to a rate-of-change (delta) over a pre-defined period of time. The output operand is asserted when the operating signal is higher than a threshold or lower than a threshold as per user's choice. 5-74 T35 Transformer Management Relay GE Multilin...
Page 153 The FLEXELEMENT 1 DIRECTION following figure explains the application of the FLEXELEMENT 1 DIRECTION FLEXELEMENT 1 PICKUP FLEXELEMENT 1 HYS- settings. TERESIS GE Multilin T35 Transformer Management Relay 5-75...
Page 154 DIRECTION = Under; FLEXELEMENT INPUT MODE = Signed; FlexElement 1 OpSig FLEXELEMENT 1 PKP FLEXELEMENT DIRECTION = Under; FLEXELEMENT INPUT MODE = Absolute; FlexElement 1 OpSig 842706A2.CDR Figure 5–38: FLEXELEMENT™ INPUT MODE SETTING 5-76 T35 Transformer Management Relay GE Multilin...
Page 155 “Delta”. FLEXELEMENT 1 COMP MODE This setting specifies the pickup delay of the element. The setting FLEXELEMENT 1 PKP DELAY FLEXELEMENT 1 RST DELAY specifies the reset delay of the element. GE Multilin T35 Transformer Management Relay 5-77...
Page 156: Non-Volatile Latches
LATCH 1 SET: FLEXLOGIC OPERANDS Off=0 LATCH 1 ON Dominant LATCH 1 OFF Previous Previous SETTING State State LATCH 1 SET: Off=0 RESET 842005A1.CDR Figure 5–39: NON-VOLATILE LATCH OPERATION TABLE (N=1 to 16) AND LOGIC 5-78 T35 Transformer Management Relay GE Multilin...
Page 157: Grouped Elements
TRANSFORMER # TRANSFORMER # PERCENT See page 5–80. # DIFFERENTIAL # INSTANTANEOUS See page 5–84. MESSAGE # DIFFERENTIAL The T35 Transformer Management Relay contains Percent Differential and Instantaneous Differential protection elements for transformers. GE Multilin T35 Transformer Management Relay 5-79...
Page 158 “Σ” has as its output the vector sum of inputs, and “max” has as its output the input of maximum magnitude; these calculations are performed for each phase. 5-80 T35 Transformer Management Relay GE Multilin...
Page 159 The T35 Percent Differential element is based on a configurable dual-breakpoint / dual-slope differential restraint character- istic. The purpose of the preset characteristic is to define the differential restraint ratio for the transformer winding currents at different loading conditions and distinguish between external and internal faults. Differential restraint ratio variations occur due to current unbalance between primary and secondary windings and can be caused by the following: Inherent CT inaccuracies.
Page 160 2nd harmonic function. If set to "2-out-of-3", the relay checks 2nd harmonic level in all three phases individually. If any two phases establish a blocking condition, the remaining phase is restrained automatically. 5-82 T35 Transformer Management Relay GE Multilin...
Page 161 Iad5 LEVEL ACTUAL VALUES > XFMR PCNT DIFF 5TH B Ibd5 LEVEL DIFF 5TH HARM > XFMR PCNT DIFF 5TH C Icd5 LEVEL Iad5 Ibd5 Icd5 828001A5.CDR Figure 5–42: PERCENT DIFFERENTIAL SCHEME LOGIC GE Multilin T35 Transformer Management Relay 5-83...
Page 162 XFMR INST DIFF OP C Iad > PICKUP INST DIFF BLOCK: FLEXLOGIC OPERAND Ibd > PICKUP Off=0 XFMR INST DIFF OP ACTUAL VALUE Icd > PICKUP 828000A1.CDR DIFF PHASOR Figure 5–43: INSTANTANEOUS DIFFERENTIAL SCHEME LOGIC 5-84 T35 Transformer Management Relay GE Multilin...
Page 163: Phase Current
5.5.4 PHASE CURRENT a) INVERSE TOC CURVE CHARACTERISTICS The inverse time overcurrent curves used by the time overcurrent elements are the IEEE, IEC, GE Type IAC, and I t stan- dard curve shapes. This allows for simplified coordination with downstream devices. If however, none of these curve shapes is adequate, FlexCurves™...
Page 164 5.041 4.827 38.634 22.819 14.593 11.675 10.130 9.153 8.470 7.960 7.562 7.241 51.512 30.426 19.458 15.567 13.507 12.204 11.294 10.614 10.083 9.654 10.0 64.390 38.032 24.322 19.458 16.883 15.255 14.117 13.267 12.604 12.068 5-86 T35 Transformer Management Relay GE Multilin...
Page 165 0.60 1.835 1.067 0.668 0.526 0.451 0.404 0.371 0.346 0.327 0.311 0.80 2.446 1.423 0.890 0.702 0.602 0.538 0.494 0.461 0.435 0.415 1.00 3.058 1.778 1.113 0.877 0.752 0.673 0.618 0.576 0.544 0.518 GE Multilin T35 Transformer Management Relay 5-87...
Page 166 = characteristic constant, and T = reset time in seconds (assuming energy capacity is 100% RESET is “Timed”) RESET Table 5–16: GE TYPE IAC INVERSE TIME CURVE CONSTANTS IAC CURVE SHAPE IAC Extreme Inverse 0.0040 0.6379 0.6200 1.7872 0.2461...
Page 167 = Reset Time in seconds (assuming energy capacity is 100% and RESET: Timed) RESET RECLOSER CURVES: The T35 uses the FlexCurve™ feature to facilitate programming of 41 recloser curves. Please refer to the FlexCurve™ sec- tion in this chapter for additional details. GE Multilin...
Page 168 (Mvr) corresponding to the phase-phase voltages of the voltage restraint characteristic curve (see the figure below); the pickup level is calculated as ‘Mvr’ times the setting. If the voltage restraint feature PHASE TOC1 PICKUP is disabled, the pickup level always remains at the setting value. 5-90 T35 Transformer Management Relay GE Multilin...
Page 169 Multiplier PHASE TOC1 C DPO Multiplier-Phase C PHASE TOC1 C OP SETTING PHASE TOC1 PKP PHASE TOC1 VOLT RESTRAINT: PHASE TOC1 OP Enabled PHASE TOC1 DPO 827072A4.CDR Figure 5–45: PHASE TOC1 SCHEME LOGIC GE Multilin T35 Transformer Management Relay 5-91...
Page 170: Ground Current
GROUND TOC 1 SETTING RESET: GROUND TOC1 PKP GROUND TOC1 GROUND TOC1 DPO IG ≥ PICKUP SOURCE: GROUND TOC1 OP SETTING GROUND TOC1 BLOCK: 827036A3.VSD Off = 0 Figure 5–46: GROUND TOC1 SCHEME LOGIC 5-92 T35 Transformer Management Relay GE Multilin...
Page 171: Control Elements
The assigned VIR- operand is used to control the “On” state of a particular settings group. TUAL OUTPUT 1 Figure 5–47: EXAMPLE FLEXLOGIC™ CONTROL OF A SETTINGS GROUP GE Multilin T35 Transformer Management Relay 5-93...
Page 172: Selector Switch
SELECTOR 1 TIME-OUT: This setting defines the time-out period for the selector. This value is used by the relay in the following two ways. When the is “Time-out”, the setting specifies the required period of SELECTOR STEP-UP MODE 5-94 T35 Transformer Management Relay GE Multilin...
Page 173 3-bit control inputs. Note that the stepping up control input and 3-bit control TIME-OUT input have independent acknowledging signals ( , accordingly). SELECTOR 1 ACK SELECTOR 1 3BIT ACK GE Multilin T35 Transformer Management Relay 5-95...
Page 174 3BIT A1 3BIT A2 POS 1 POS 2 POS 3 POS 4 POS 5 POS 6 POS 7 BIT 0 BIT 1 BIT 2 STP ALARM BIT ALARM ALARM 842737A1.CDR Figure 5–48: TIME-OUT MODE 5-96 T35 Transformer Management Relay GE Multilin...
Page 175 3BIT A2 3BIT ACK POS 1 POS 2 POS 3 POS 4 POS 5 POS 6 POS 7 BIT 0 BIT 1 BIT 2 STP ALARM BIT ALARM ALARM 842736A1.CDR Figure 5–49: ACKNOWLEDGE MODE GE Multilin T35 Transformer Management Relay 5-97...
Page 176 SELECTOR 1 BIT ALARM 3-bit position out SELECTOR 1 ALARM SELECTOR 1 PWR ALARM SELECTOR 1 BIT 0 SELECTOR 1 BIT 1 SELECTOR 1 BIT 2 842012A1.CDR Figure 5–50: SELECTOR SWITCH LOGIC 5-98 T35 Transformer Management Relay GE Multilin...
Page 177: Digital Counters
–2,147,483,648 counts, the counter will rollover to +2,147,483,647. • COUNTER 1 BLOCK: Selects the FlexLogic™ operand for blocking the counting operation. All counter operands are blocked. GE Multilin T35 Transformer Management Relay 5-99...
Page 178 COUNTER 1 RESET: COUNTER 1 FROZEN: Off = 0 STORE DATE & TIME Date & Time SETTING COUNT1 FREEZE/RESET: Off = 0 827065A1.VSD SETTING COUNT1 FREEZE/COUNT: Off = 0 Figure 5–51: DIGITAL COUNTER SCHEME LOGIC 5-100 T35 Transformer Management Relay GE Multilin...
Page 179: Monitoring Elements
Breaker arcing currents and fault duration values are available under the !" !" ACTUAL VALUES RECORDS MAINTENANCE menus. BREAKER 1(6) GE Multilin T35 Transformer Management Relay 5-101...
Page 180 BKR 1 ARCING AMP C 827071A3.CDR Φ BKR 1 OPERATING TIME A Φ BKR 1 OPERATING TIME B Φ BKR 1 OPERATING TIME C BKR 1 OPERATING TIME Figure 5–53: BREAKER ARCING CURRENT SCHEME LOGIC 5-102 T35 Transformer Management Relay GE Multilin...
Page 181: Inputs/Outputs
The DC input voltage is compared to a user-settable threshold. A new contact input state must be maintained for a user- settable debounce time in order for the T35 to validate the new contact state. In the figure below, the debounce time is set at 2.5 ms;...
Page 182 Event Records menu, make the following settings changes: "Breaker Closed (52b)" CONTACT INPUT H5A ID: "Enabled" CONTACT INPUT H5A EVENTS: Note that the 52b contact is closed when the breaker is open and open when the breaker is closed. 5-104 T35 Transformer Management Relay GE Multilin...
Page 183: Virtual Inputs
SETTING “Virtual Input 1 to OFF = 0” VIRTUAL INPUT 1 ID: SETTING (Flexlogic Operand) Virt Ip 1 VIRTUAL INPUT 1 TYPE: Latched Self - Reset 827080A2.CDR Figure 5–55: VIRTUAL INPUTS SCHEME LOGIC GE Multilin T35 Transformer Management Relay 5-105...
Page 184: Contact Outputs
This scheme is often called ‘trip seal-in’. This can be realized in the T35 using the ‘Cont Op 1 IOn’ FlexLogic™ operand to seal-in the contact output as follows: “Cont Op 1"...
Page 185 5.7 INPUTS/OUTPUTS The T35 latching output contacts are mechanically bi-stable and controlled by two separate (open and close) coils. As such they retain their position even if the relay is not powered up. The relay recognizes all latching output contact cards and pop- ulates the setting menu accordingly.
Page 186: Virtual Outputs
For example, if Virtual Output 1 is the trip signal from FlexLogic™ and the trip relay is used to signal events, the settings would be programmed as follows: "Trip" VIRTUAL OUTPUT 1 ID: "Disabled" VIRTUAL OUTPUT 1 EVENTS: 5-108 T35 Transformer Management Relay GE Multilin...
Page 187: Remote Devices
The remote input/output facility provides for 32 remote inputs and 64 remote outputs. b) LOCAL DEVICES: ID OF DEVICE FOR TRANSMITTING GSSE MESSAGES In a T35 relay, the device ID that identifies the originator of the message is programmed in the SETTINGS PRODUCT SETUP !"...
Page 188: Remote Inputs
Logic 0. When communication resumes, the input becomes fully operational. For additional information on GSSE/GOOOSE messaging, refer to the Remote Devices section in this chap- ter. NOTE 5-110 T35 Transformer Management Relay GE Multilin...
Page 189: Remote Outputs
METHOD: GSSE For more information on GSSE/GOOSE messaging, refer to Remote Inputs/Outputs Overview in the Remote Devices section. NOTE 5.7.8 RESETTING !" !" PATH: SETTINGS INPUTS/OUTPUTS RESETTING Range: FlexLogic™ operand # RESETTING RESET OPERAND: GE Multilin T35 Transformer Management Relay 5-111...
Page 190: Direct Inputs/Outputs
APPLICATION EXAMPLES The examples introduced in the earlier Direct Inputs/Outputs section (part of the Product Setup section) direct inputs/out- puts are continued below to illustrate usage of the direct inputs and outputs. 5-112 T35 Transformer Management Relay GE Multilin...
Page 191 5 SETTINGS 5.7 INPUTS/OUTPUTS EXAMPLE 1: EXTENDING INPUT/OUTPUT CAPABILITIES OF A T35 RELAY Consider an application that requires additional quantities of digital inputs and/or output contacts and/or lines of program- mable logic that exceed the capabilities of a single UR-series chassis. The problem is solved by adding an extra UR-series IED, such as the C30, to satisfy the additional inputs/outputs and programmable logic requirements.
Page 192 "3" (effectively, this is a message from IED 1) DIRECT INPUT 6 BIT NUMBER: UR IED 2: "1" DIRECT INPUT 5 DEVICE ID: "2" DIRECT INPUT 5 BIT NUMBER: "3" DIRECT INPUT 6 DEVICE ID: "2" DIRECT INPUT 6 BIT NUMBER: 5-114 T35 Transformer Management Relay GE Multilin...
Page 193 In three-terminal applications, both the remote terminals must grant permission to trip. Therefore, at each terminal, Direct Inputs 5 and 6 should be ANDed in FlexLogic™ and the resulting operand configured as the permission to trip ( HYB POTT setting). GE Multilin T35 Transformer Management Relay 5-115...
Page 194: Transducer I/O
–20 to +180 MW; in this case the value would be “–20” and the DCMA INPUT F1 MIN VALUE DCMA INPUT F1 MAX value “180”. Intermediate values between the min and max values are scaled linearly. VALUE 5-116 T35 Transformer Management Relay GE Multilin...
Page 195: Rtd Inputs
CTs and VTs. Each channel is assigned a slot letter followed by the row number, 1 through 8 inclusive, which is used as the channel number. Both the output range and a signal driving a given output are user-programmable via the following settings menu (an exam- ple for channel M5 is shown). GE Multilin T35 Transformer Management Relay 5-117...
Page 196 VT ratio = 120. The nominal current is 800 A primary and the nominal power factor is 0.90. The power is to be monitored in both importing and exporting directions and allow for 20% overload compared to the nominal. 5-118 T35 Transformer Management Relay GE Multilin...
Page 197 0 to 1 mA. The VT secondary setting is 66.4 V, the VT ratio setting is 6024, and the VT connection setting is “Delta”. The voltage should be monitored in the range from 70% to 110% of nominal. GE Multilin T35 Transformer Management Relay 5-119...
Page 198 254.03 kV 1.27 kV – • ±0.5% of reading For example, under nominal conditions, the positive-sequence reads 230.94 kV and the worst-case error is 0.005 x 230.94 kV + 1.27 kV = 2.42 kV. 5-120 T35 Transformer Management Relay GE Multilin...
Page 199: Testing
The Test Mode starts when the selected operand assumes a Logic 1 state. TIATE When in Test Mode, the T35 remains fully operational, allowing for various testing procedures. In particular, the protection and control elements, FlexLogic™, and communication-based inputs and outputs function normally.
Page 200: Force Contact Outputs
USER PUSHBUTTON 1 PUSHBUTTON 1 FUNCTION Input 1 to initiate the Test mode, make the following changes in the !" menu: SETTINGS TESTING TEST MODE “Enabled” and “ ” TEST MODE FUNCTION: TEST MODE INITIATE: 5-122 T35 Transformer Management Relay GE Multilin...
Page 201: Actual Values
# STATUS ## ACTUAL VALUES # TRANSFORMER See page 6-11. ## METERING # SOURCE SRC 1 See page 6-12. # SOURCE SRC 2 # SOURCE SRC 3 # SOURCE SRC 4 # SOURCE SRC 5 GE Multilin T35 Transformer Management Relay...
Page 202 # OSCILLOGRAPHY See page 6-16. # DATA LOGGER See page 6-17. # MAINTENANCE See page 6-17. ## ACTUAL VALUES # MODEL INFORMATION See page 6-18. ## PRODUCT INFO # FIRMWARE REVISIONS See page 6-18. T35 Transformer Management Relay GE Multilin...
Page 203: Contact Inputs
The state displayed will be that of the remote point unless the remote device has been established to be “Offline” in which case the value shown is the programmed default state for the remote input. GE Multilin T35 Transformer Management Relay...
Page 204: Contact Outputs
The present state of up to 16 programmed Remote Devices is shown here. The message indi- ALL REMOTE DEVICES ONLINE cates whether or not all programmed Remote Devices are online. If the corresponding state is "No", then at least one required Remote Device is not online. T35 Transformer Management Relay GE Multilin...
Page 205: Digital Counters
Range: Off, On # FLEX STATES PARAM 1: Off ↓ Range: Off, On PARAM 256: Off MESSAGE There are 256 FlexState bits available. The second line value indicates the state of the given FlexState bit. GE Multilin T35 Transformer Management Relay...
Page 206: Ethernet
The UNRETURNED MSG COUNT CRC FAIL COUNT values can be cleared using the command. CLEAR DIRECT I/O COUNTERS values represent the state of the x-th direct input. DIRECT INPUT x T35 Transformer Management Relay GE Multilin...
Page 207: Direct Devices Status
# SLOW EXCHANGE 1 EXCH 1 SIGNATURE: EXCH 1 SIZE: MESSAGE These values provide information that may be useful for debugging an EGD network. The EGD signature and packet size for the slow EGD exchanges are displayed. GE Multilin T35 Transformer Management Relay...
Page 208: Metering Conventions
PF = Lag WATTS = Negative VARS = Positive PF = Lead PF = Lag PF = Lead Current UR RELAY 827239AC.CDR S=VI Generator Figure 6–1: FLOW DIRECTION OF SIGNED VALUES FOR WATTS AND VARS T35 Transformer Management Relay GE Multilin...
Page 209 • ABC phase rotation: • ACB phase rotation: -- - V -- - V -- - V -- - V -- - V -- - V The above equations apply to currents as well. GE Multilin T35 Transformer Management Relay...
Page 210 The power system voltages are phase-referenced – for simplicity – to VAG and VAB, respectively. This, however, is a relative matter. It is important to remember that the T35 displays are always referenced as specified under SETTINGS !"...
Page 211: Transformer
It can be reset by either changing the setting or through the XFMR INITIAL LOSS OF LIFE !" !" command. COMMANDS CLEAR RECORDS CLEAR LOSS OF LIFE RECORDS GE Multilin T35 Transformer Management Relay 6-11...
Page 212: Sources
SRC 1 RMS Vag: # SRC 1 0.000 SRC 1 RMS Vbg: MESSAGE 0.000 SRC 1 RMS Vcg: MESSAGE 0.000 SRC 1 PHASOR Vag: MESSAGE 0.000 0.0° SRC 1 PHASOR Vbg: MESSAGE 0.000 0.0° 6-12 T35 Transformer Management Relay GE Multilin...
Page 213 REACTIVE PWR MESSAGE 3φ: 0.000 SRC 1 REACTIVE PWR MESSAGE φa: 0.000 SRC 1 REACTIVE PWR MESSAGE φb: 0.000 SRC 1 REACTIVE PWR MESSAGE φc: 0.000 SRC 1 APPARENT PWR MESSAGE 3φ: 0.000 GE Multilin T35 Transformer Management Relay 6-13...
Page 214: Tracking Frequency
The tracking frequency is displayed here. The frequency is tracked based on configuration of the reference source. The is based upon positive sequence current phasors from all line terminals and is synchronously TRACKING FREQUENCY adjusted at all terminals. If currents are below 0.125 pu, then the is used. NOMINAL FREQUENCY 6-14 T35 Transformer Management Relay GE Multilin...
Page 215: Flexelements
RTD INPUT xx -50 °C Actual values for each RTD input channel that is enabled are displayed with the top line as the programmed Channel ID and the bottom line as the value. GE Multilin T35 Transformer Management Relay 6-15...
Page 216: Records
Chapter 5 for further details. A trigger can be forced here at any time by setting "Yes" to the command. Refer to the !" FORCE TRIGGER? COMMANDS menu for clearing the oscillography records. CLEAR RECORDS 6-16 T35 Transformer Management Relay GE Multilin...
Page 217: Data Logger
BKR 1 ARCING AMP !" menu for clearing breaker arcing current records. The COMMANDS CLEAR RECORDS BREAKER OPERATING TIME defined as the slowest operating time of breaker poles that were initiated to open. GE Multilin T35 Transformer Management Relay 6-17...
Page 218: Product Information
BOOT DATE: MESSAGE Date and time when the boot program was built. 2004/09/15 16:41:32 The shown data is illustrative only. A modification file number of 0 indicates that, currently, no modifications have been installed. 6-18 T35 Transformer Management Relay GE Multilin...
Page 219: Commands And
COMMANDS CLEAR RECORDS Range: No, Yes ## COMMANDS CLEAR USER FAULT ## CLEAR RECORDS REPORTS? No Range: No, Yes CLEAR EVENT RECORDS? Range: No, Yes CLEAR OSCILLOGRAPHY? Range: No, Yes CLEAR BREAKER 1 ARCING AMPS? No GE Multilin T35 Transformer Management Relay...
Page 220 If an update occurs, the following message is shown. UPDATING... PLEASE WAIT There is no impact if there have been no changes to the hardware modules. When an update does not occur, the ORDER message will be shown. CODE NOT UPDATED T35 Transformer Management Relay GE Multilin...
Page 221: Targets Menu
In Service LED indicator is turned off • a RELAY OUT OF SERVICE event is recorded Most of the minor self-test errors can be disabled. Refer to the settings in the User-Programmable Self-Tests section in Chapter 5 for additional details. GE Multilin T35 Transformer Management Relay...
Page 222 SYSTEM EXCEPTION Abnormal restart from modules Event driven. Contact the factory. being removed/inserted when powered-up, abnormal DC supply, or internal relay failure. WATCHDOG ERROR Some tasks are behind schedule. Event driven. Contact the factory. T35 Transformer Management Relay GE Multilin...
Page 223: Commissioning
CT is the 1 A or 5 A tap, and M[1] is the calculated magnitude compensation factor (see the Transformer section in Chapter 5 for details on calculating the M[1] and M[2] factors). GE Multilin T35 Transformer Management Relay...
Page 224 2 current as restraint and repeat the steps above by substituting the Breakpoint 2 value in the equations above with the new per-unit restraint current value. The above two tests can be repeated for Phases B and C. (pu) (pu) Figure 8–1: DIFFERENTIAL RESTRAINT CHARACTERISTIC T35 Transformer Management Relay GE Multilin...
Page 225: Differential Characteristic Test Examples
8.2DIFFERENTIAL CHARACTERISTIC TEST EXAMPLES 8.2.1 INTRODUCTION The T35 commissioning tests are based on secondary current injections, where two or three individually adjustable cur- rents are required. The differential protection compares the magnitudes of the varying HV and LV currents in real time.
Page 226: Test Example 1
Slope 2 Angle WRT 0° Angle WRT 0° Resistance 3Ph 10.000 ohms Resistance 3Ph 10.000 ohms APPLICATION OF EXCESSIVE CURRENT (> 3 × In) FOR EXTENTED PERIODS WILL CAUSE DAMAGE TO THE RELAY! WARNING T35 Transformer Management Relay GE Multilin...
Page 227 0 A ∠0° 0.15 A ∠0° 0.23 A ∠–180° 0.15 A ∠–180° 0.23 A ∠0° The following differential and restraint current should be read from the T35 actual values menu: PHASE DIFFERENTIAL CURRENT (I PHASE RESTRAINT CURRENT (I 0 ∠0°...
Page 228 0 A ∠0° 0.48 A ∠0° 1 A ∠–180° 0.48 A ∠–180° 1 A ∠0° The following differential and restraint current should be read from the T35 actual values menu: PHASE DIFFERENTIAL CURRENT (I PHASE RESTRAINT CURRENT (I 0 ∠0°...
Page 229: Test Example 2
0 A ∠0° 1.2 A ∠0° 3.5 A ∠–180° 1.2 A ∠–180° 3.5 A ∠0° The following differential and restraint current should be read from the T35 actual values menu: PHASE DIFFERENTIAL CURRENT (I PHASE RESTRAINT CURRENT (I 0 ∠0°...
Page 230 0 A ∠0° 0.5 A ∠0° 9 A ∠–180° 0.5 A ∠–180° 9 A ∠0° The following differential and restraint current should be read from the T35 actual values menu: PHASE DIFFERENTIAL CURRENT (I PHASE RESTRAINT CURRENT (I 0 ∠0°...
Page 231: Test Example 2
0 ∠0° 7.915 ∠0° 8.646 ∠0° 0.2 ∠0° 15 ∠–180° 7.918 ∠–180° 8.650 ∠–180° Slope 2 Operate = 95.7% 0 ∠0° 0 ∠0° 0 ∠0° 0 ∠0° 0.2 ∠–180° 0 ∠0° 7.916 ∠0° 8.650 ∠0° GE Multilin T35 Transformer Management Relay...
Page 232: Test Example 3
4 ∠0° 0 ∠0° 0 ∠0° 0 ∠0° Slope 2 Operate = 95.7% 8 ∠–180° 0.6 ∠0° 12.13 ∠–180° 12.73 ∠0° > Slope 2 = 95% 4 ∠0° 0.6 ∠–180° 12.13 ∠0° 12.73 ∠–180° 8-10 T35 Transformer Management Relay GE Multilin...
Page 233: Test Example 4
0 ∠0° 0 ∠0° 0 ∠0° 0 ∠0° Slope 2 Operate = 96% 0.18 ∠–90° 8.33 ∠–270° 8 ∠–270° 8.33 ∠–270° > Slope 2 = 95% 0.18 ∠–270° 8.33 ∠–90° 8 ∠–90° 8.33 ∠–90° GE Multilin T35 Transformer Management Relay 8-11...
Page 234: Inrush Inhibit Test Procedure
Apply a second harmonic to Phase A with a level greater than the set threshold and monitor the operation of the Per- cent Differential element. The element should drop out when the injected second harmonic level becomes three times larger than the set threshold. 8-12 T35 Transformer Management Relay GE Multilin...
Page 235: Overexcitation Inhibit Test Procedure
2 A ∠–180° 9.5% 2 pu 4 pu Block 2 A ∠0° 4 A ∠–180° 8.5% 2 pu 4 pu Operate 2 A ∠0° 4 A ∠–180° 9.5% 2 pu 4 pu Block GE Multilin T35 Transformer Management Relay 8-13...
Page 236: Commissioning Test Tables
Slope 2 Status: ____________ = _____________ 8.5.2 INRUSH INHIBIT TESTS Table 8–4: INRUSH INHIBIT TEST TABLE PHASE INECTED DISPLAYED STATUS (BLOCK/ W1 2ND W2 2ND (PU) (PU) OPERATE) CURRENT HARMONIC CURRENT HARMONIC HARMONIC 8-14 T35 Transformer Management Relay GE Multilin...
Page 237: Overexcitation Inhibit Tests
8 COMMISSIONING 8.5 COMMISSIONING TEST TABLES 8.5.3 OVEREXCITATION INHIBIT TESTS Table 8–5: OVEREXCITATION INHIBIT TEST RESULTS PHASE INECTED DISPLAYED STATUS W1 5TH W2 5TH (PU) (PU) (BLOCK/ CURRENT HARMONIC CURRENT HARMONIC HARMONIC OPERATE) GE Multilin T35 Transformer Management Relay 8-15...
Page 238 8.5 COMMISSIONING TEST TABLES 8 COMMISSIONING 8-16 T35 Transformer Management Relay GE Multilin...
Page 239: Flexanalog
SRC 3 Ib RMS 6408 SRC 5 Phase A Current Magnitude SRC 5 Ia Mag 6276 SRC 3 Phase C Current RMS SRC 3 Ic RMS 6410 SRC 5 Phase A Current Angle SRC 5 Ia Angle GE Multilin T35 Transformer Management Relay...
Page 240 SRC 1 Vbc RMS 6798 SRC 3 Phase CG Voltage Angle SRC 3 Vcg Angle 6675 SRC 1 Phase CA Voltage RMS SRC 1 Vca RMS 6799 SRC 3 Phase AB Voltage RMS SRC 3 Vab RMS T35 Transformer Management Relay GE Multilin...
Page 241 SRC 5 Vbg Angle 7176 SRC 1 Three Phase Reactive Power SRC 1 Q 6924 SRC 5 Phase CG Voltage Magnitude SRC 5 Vcg Mag 7178 SRC 1 Phase A Reactive Power SRC 1 Qa GE Multilin T35 Transformer Management Relay...
Page 242 SRC 4 Three Phase Apparent Power SRC 4 S 7696 SRC 2 Demand Ia SRC 2 Demand Ia 7282 SRC 4 Phase A Apparent Power SRC 4 Sa 7698 SRC 2 Demand Ib SRC 2 Demand Ib T35 Transformer Management Relay GE Multilin...
Page 243 Transformer Diff. 2nd Harm Icd Angle Xfmr Harm2 Icd Angle 13577 RTD Inputs 26 Value RTD Inputs 26 Value 8983 Transformer Diff. 5th Harm Icd Mag. Xfmr Harm5 Icd Mag 13578 RTD Inputs 27 Value RTD Inputs 27 Value GE Multilin T35 Transformer Management Relay...
Page 244 FlexElement 13 Actual FlexElement 13 Value 39451 FlexElement 14 Actual FlexElement 14 Value 39453 FlexElement 15 Actual FlexElement 15 Value 39455 FlexElement 16 Actual FlexElement 16 Value 40971 Current Setting Group Active Setting Group T35 Transformer Management Relay GE Multilin...
Page 245: Modbus Communications
Broadcast mode is only recognized when associated with Function Code 05h. For any other function code, a packet with broadcast mode slave address 0 will be ignored. GE Multilin T35 Transformer Management Relay...
Page 246: Algorithm
No: go to 8; Yes: G (+) A --> A and continue. Is j = 8? No: go to 5; Yes: continue i + 1 --> i Is i = N? No: go to 3; Yes: continue A --> CRC T35 Transformer Management Relay GE Multilin...
Page 247: Modbus Function Codes
DATA #1 - low NUMBER OF REGISTERS - low DATA #2 - high CRC - low DATA #2 - low CRC - high DATA #3 - high DATA #3 - low CRC - low CRC - high GE Multilin T35 Transformer Management Relay...
Page 248: Execute Operation (Function Code 05H
DATA STARTING ADDRESS - low DATA STARTING ADDRESS - low DATA - high DATA - high DATA - low DATA - low CRC - low CRC - low CRC - high CRC - high T35 Transformer Management Relay GE Multilin...
Page 249: Store Multiple Settings (Function Code 10H
PACKET FORMAT EXAMPLE (HEX) SLAVE ADDRESS SLAVE ADDRESS FUNCTION CODE FUNCTION CODE CRC - low order byte ERROR CODE CRC - high order byte CRC - low order byte CRC - high order byte GE Multilin T35 Transformer Management Relay...
Page 250: File Transfers
Cleared Date to the present date and time. To read binary COMTRADE oscillography files, read the following filenames: OSCnnnn.CFG and OSCnnn.DAT Replace “nnn” with the desired oscillography trigger number. For ASCII format, use the following file names OSCAnnnn.CFG and OSCAnnn.DAT T35 Transformer Management Relay GE Multilin...
Page 251: Modbus Password Operation
COMMAND or SETTING password security access is restricted to the particular port or particular TCP/IP connection on which the entry was made. Passwords must be entered when accessing the relay through other ports or connections, and the passwords must be re-entered after disconnecting and re-connecting on TCP/IP. GE Multilin T35 Transformer Management Relay...
Page 252: Memory Mapping
0 (Off) 0419 Virtual Input 26 State 0 to 1 F108 0 (Off) 041A Virtual Input 27 State 0 to 1 F108 0 (Off) 041B Virtual Input 28 State 0 to 1 F108 0 (Off) T35 Transformer Management Relay GE Multilin...
Page 253 ...Repeated for Remote Device 3 155D ...Repeated for Remote Device 4 1561 ...Repeated for Remote Device 5 1565 ...Repeated for Remote Device 6 1569 ...Repeated for Remote Device 7 156D ...Repeated for Remote Device 8 GE Multilin T35 Transformer Management Relay...
Page 254 F060 1824 Source 1 Differential Ground Current Angle -359.9 to 0 degrees F002 1825 Reserved (27 items) F001 1840 ...Repeated for Source 2 1880 ...Repeated for Source 3 18C0 ...Repeated for Source 4 B-10 T35 Transformer Management Relay GE Multilin...
Page 255 Source 1 Phase C Reactive Power -1000000000000 to 0.001 F060 1000000000000 1C10 Source 1 Three Phase Apparent Power -1000000000000 to 0.001 F060 1000000000000 1C12 Source 1 Phase A Apparent Power -1000000000000 to 0.001 F060 1000000000000 GE Multilin T35 Transformer Management Relay B-11...
Page 256 Transformer Differential 5th Harm Ibd Angle -359.9 to 0 degrees F002 2311 Transformer Differential Phasor Icd Magnitude 0 to 30 0.001 F001 2312 Transformer Differential Phasor Icd Angle -359.9 to 0 degrees F002 B-12 T35 Transformer Management Relay GE Multilin...
Page 257 Number of Available Events 0 to 4294967295 F003 3404 Event Recorder Last Cleared Date 0 to 4294967295 F050 Event Recorder (Read/Write Command) 3406 Event Recorder Clear Command 0 to 1 F126 0 (No) GE Multilin T35 Transformer Management Relay B-13...
Page 258 -32768 to 32767 °C F002 3509 RTD Input 26 Value -32768 to 32767 °C F002 350A RTD Input 27 Value -32768 to 32767 °C F002 350B RTD Input 28 Value -32768 to 32767 °C F002 B-14 T35 Transformer Management Relay GE Multilin...
Page 259 F001 4083 RS485 Com1 Baud Rate 0 to 11 F112 8 (115200) 4084 RS485 Com1 Parity 0 to 2 F113 0 (None) 4085 RS485 Com2 Baud Rate 0 to 11 F112 8 (115200) GE Multilin T35 Transformer Management Relay B-15...
Page 260 0 (Not Used) 4140 DNP Object 1 Default Variation 1 to 2 F001 4141 DNP Object 2 Default Variation 1 to 2 F001 4142 DNP Object 20 Default Variation 0 to 3 F523 0 (1) B-16 T35 Transformer Management Relay GE Multilin...
Page 261 ...Repeated for User-Programmable LED 15 429E ...Repeated for User-Programmable LED 16 42A0 ...Repeated for User-Programmable LED 17 42A2 ...Repeated for User-Programmable LED 18 42A4 ...Repeated for User-Programmable LED 19 42A6 ...Repeated for User-Programmable LED 20 GE Multilin T35 Transformer Management Relay B-17...
Page 262 VT Settings (Read/Write Setting) (3 modules) 4500 Phase VT 1 Connection 0 to 1 F100 0 (Wye) 4501 Phase VT 1 Secondary 50 to 240 F001 4502 Phase VT 1 Ratio 1 to 24000 F060 B-18 T35 Transformer Management Relay GE Multilin...
Page 263 User Displays Settings (Read/Write Setting) (16 modules) 4C00 User-Definable Display 1 Top Line Text F202 “ “ 4C0A User-Definable Display 1 Bottom Line Text F202 ““ 4C14 Modbus Addresses of Display 1 Items (5 items) 0 to 65535 F001 GE Multilin T35 Transformer Management Relay B-19...
Page 264 ...Repeated for FlexLogic™ Timer 7 5838 ...Repeated for FlexLogic™ Timer 8 5840 ...Repeated for FlexLogic™ Timer 9 5848 ...Repeated for FlexLogic™ Timer 10 5850 ...Repeated for FlexLogic™ Timer 11 5858 ...Repeated for FlexLogic™ Timer 12 B-20 T35 Transformer Management Relay GE Multilin...
Page 265 Reserved (6 items) 0 to 1 F001 5D10 ...Repeated for Ground Time Overcurrent 2 5D20 ...Repeated for Ground Time Overcurrent 3 5D30 ...Repeated for Ground Time Overcurrent 4 5D40 ...Repeated for Ground Time Overcurrent 5 GE Multilin T35 Transformer Management Relay B-21...
Page 266 ...Repeated for dcmA Inputs 3 7348 ...Repeated for dcmA Inputs 4 7360 ...Repeated for dcmA Inputs 5 7378 ...Repeated for dcmA Inputs 6 7390 ...Repeated for dcmA Inputs 7 73A8 ...Repeated for dcmA Inputs 8 B-22 T35 Transformer Management Relay GE Multilin...
Page 267 ...Repeated for RTD Input 28 7700 ...Repeated for RTD Input 29 7710 ...Repeated for RTD Input 30 7720 ...Repeated for RTD Input 31 7730 ...Repeated for RTD Input 32 7740 ...Repeated for RTD Input 33 GE Multilin T35 Transformer Management Relay B-23...
Page 268 -90 to 90 0.001 F004 1000 900C FlexElement™ 1 DeltaT Units 0 to 2 F518 0 (Milliseconds) 900D FlexElement™ 1 DeltaT 20 to 86400 F003 900F FlexElement™ 1 Pickup Delay 0 to 65.535 0.001 F001 B-24 T35 Transformer Management Relay GE Multilin...
Page 269 FlexElement™ 3 Actual -2147483.647 to 2147483.647 0.001 F004 9A07 FlexElement™ 4 Actual 0.001 F004 -2147483.647 to 2147483.647 9A09 FlexElement™ 5 Actual 0.001 F004 -2147483.647 to 2147483.647 9A0B FlexElement™ 6 Actual -2147483.647 to 2147483.647 0.001 F004 GE Multilin T35 Transformer Management Relay B-25...
Page 270 Reserved (4 items) F001 AD0A ...Repeated for Non-Volatile Latch 2 AD14 ...Repeated for Non-Volatile Latch 3 AD1E ...Repeated for Non-Volatile Latch 4 AD28 ...Repeated for Non-Volatile Latch 5 AD32 ...Repeated for Non-Volatile Latch 6 B-26 T35 Transformer Management Relay GE Multilin...
Page 271 0 to 65534 F206 (None) B865 IEC 61850 Logical Node MMXUx Name Prefix (6 items) 0 to 65534 F206 (None) B877 IEC 61850 Logical Node GGIOx Name Prefix (2 items) 0 to 65534 F206 (None) GE Multilin T35 Transformer Management Relay B-27...
Page 272 IEC 61850 GGIO2.CF.SPCSO14.ctlModel Value 2 to 3 F001 BC0E IEC 61850 GGIO2.CF.SPCSO15.ctlModel Value 2 to 3 F001 BC0F IEC 61850 GGIO2.CF.SPCSO16.ctlModel Value 2 to 3 F001 BC10 IEC 61850 GGIO2.CF.SPCSO17.ctlModel Value 2 to 3 F001 B-28 T35 Transformer Management Relay GE Multilin...
Page 273 ...Repeated for Contact Input 31 C0F8 ...Repeated for Contact Input 32 C100 ...Repeated for Contact Input 33 C108 ...Repeated for Contact Input 34 C110 ...Repeated for Contact Input 35 C118 ...Repeated for Contact Input 36 GE Multilin T35 Transformer Management Relay B-29...
Page 274 ...Repeated for Contact Input 85 C2A8 ...Repeated for Contact Input 86 C2B0 ...Repeated for Contact Input 87 C2B8 ...Repeated for Contact Input 88 C2C0 ...Repeated for Contact Input 89 C2C8 ...Repeated for Contact Input 90 B-30 T35 Transformer Management Relay GE Multilin...
Page 275 Reserved (5 items) F001 CCA0 ...Repeated for Virtual Output 2 CCB0 ...Repeated for Virtual Output 3 CCC0 ...Repeated for Virtual Output 4 CCD0 ...Repeated for Virtual Output 5 CCE0 ...Repeated for Virtual Output 6 GE Multilin T35 Transformer Management Relay B-31...
Page 276 ...Repeated for Virtual Output 55 D000 ...Repeated for Virtual Output 56 D010 ...Repeated for Virtual Output 57 D020 ...Repeated for Virtual Output 58 D030 ...Repeated for Virtual Output 59 D040 ...Repeated for Virtual Output 60 B-32 T35 Transformer Management Relay GE Multilin...
Page 277 ...Repeated for Contact Output 30 D470 ...Repeated for Contact Output 31 D480 ...Repeated for Contact Output 32 D490 ...Repeated for Contact Output 33 D4A0 ...Repeated for Contact Output 34 D4B0 ...Repeated for Contact Output 35 GE Multilin T35 Transformer Management Relay B-33...
Page 278 Clear Breaker 6 Arcing Current operand 0 to 65535 F300 D82F Clear Unauthorized Access operand 0 to 65535 F300 D831 Clear Platform Direct Input/Output Statistics operand 0 to 65535 F300 D833 Reserved (13 items) F001 B-34 T35 Transformer Management Relay GE Multilin...
Page 279 0 to 65535 F300 DD01 Direct Output 1 Events 0 to 1 F102 0 (Disabled) DD02 ...Repeated for Direct Output 2 DD04 ...Repeated for Direct Output 3 DD06 ...Repeated for Direct Output 4 GE Multilin T35 Transformer Management Relay B-35...
Page 280 Remote Device 1 ID F202 “Remote Device 1“ E00A Remote Device 1 Virtual LAN Identifier 0 to 4095 F001 E00B Remote Device 1 Ethernet APPID 0 to 16383 F001 E00C ...Repeated for Device 2 B-36 T35 Transformer Management Relay GE Multilin...
Page 281 ...Repeated for Remote Input 31 E17C ...Repeated for Remote Input 32 E180 ...Repeated for Remote Input 33 E184 ...Repeated for Remote Input 34 E188 ...Repeated for Remote Input 35 E18C ...Repeated for Remote Input 36 GE Multilin T35 Transformer Management Relay B-37...
Page 282 ...Repeated for Remote Output 18 E648 ...Repeated for Remote Output 19 E64C ...Repeated for Remote Output 20 E650 ...Repeated for Remote Output 21 E654 ...Repeated for Remote Output 22 E658 ...Repeated for Remote Output 23 B-38 T35 Transformer Management Relay GE Multilin...
Page 283 ...Repeated for Remote Output 27 E6EC ...Repeated for Remote Output 28 E6F0 ...Repeated for Remote Output 29 E6F4 ...Repeated for Remote Output 30 E6F8 ...Repeated for Remote Output 31 E6FC ...Repeated for Remote Output 32 GE Multilin T35 Transformer Management Relay B-39...
Page 284: Data Formats
POWER_FACTOR (SIGNED 16 BIT INTEGER) 0 = Time-Out, 1 = Acknowledge Positive values indicate lagging power factor; negative values indicate leading. F084 ENUMERATION: SELECTOR POWER UP 0 = Restore, 1 = Synchronize, 2 = Sync/Restore B-40 T35 Transformer Management Relay GE Multilin...
Page 285 0 = Instantaneous, 1 = Timed, 2 = Linear F118 F105 ENUMERATION: OSCILLOGRAPHY MODE ENUMERATION: LOGIC INPUT 0 = Automatic Overwrite, 1 = Protected 0 = Disabled, 1 = Input 1, 2 = Input 2 GE Multilin T35 Transformer Management Relay B-41...
Page 286 Phase Time Overcurrent 1 Auxiliary Undervoltage 1 Phase Time Overcurrent 2 Phase Undervoltage 1 Phase Time Overcurrent 3 Phase Undervoltage 2 Phase Time Overcurrent 4 Auxiliary Overvoltage 1 Phase Time Overcurrent 5 Phase Overvoltage 1 B-42 T35 Transformer Management Relay GE Multilin...
Page 287 Non-volatile Latch 11 Non-volatile Latch 12 F131 Non-volatile Latch 13 ENUMERATION: FORCED CONTACT OUTPUT STATE Non-volatile Latch 14 0 = Disabled, 1 = Energized, 2 = De-energized, 3 = Freeze Non-volatile Latch 15 GE Multilin T35 Transformer Management Relay B-43...
Page 288 Relay Out Of Service Battery Failure Watchdog Reset Primary Ethernet Failure Oscillography Clear Secondary Ethernet Failure Reboot Command EEPROM Data Error Led Test Initiated SRAM Data Error Flash Programming Program Memory Fault Report Trigger Watchdog Error B-44 T35 Transformer Management Relay GE Multilin...
Page 289 0 = Offline, 1 = Online F163 ENUMERATION: TRANSFORMER WINDING CONNECTION 0 = Wye, 1 = Delta, 2 = Zig-zag F164 ENUMERATION: TRANSFORMER WINDING GROUNDING 0 = Not within zone, 1 = Within zone GE Multilin T35 Transformer Management Relay B-45...
Page 290 0 = Per Phase, 1 = 2-out-of-3, 2 = Average 0 to –1 mA 0 to 1 mA –1 to 1 mA 0 to 5 mA 0 to 10 mA 0 to 20 mA 4 to 20 mA B-46 T35 Transformer Management Relay GE Multilin...
Page 291 Contact Inputs 1 to 16 Contact Inputs 17 to 32 F199 Contact Inputs 33 to 48 ENUMERATION: DISABLED/ENABLED/CUSTOM Contact Inputs 49 to 64 0 = Disabled, 1 = Enabled, 2 = Custom Contact Inputs 65 to 80 GE Multilin T35 Transformer Management Relay B-47...
Page 292 The FlexLogic™ BASE type is 6 bits and is combined with a 9 bit descriptor and 1 bit for protection element to form a 16 bit value. The combined bits are of the form: PTTTTTTDDDDDDDDD, B-48 T35 Transformer Management Relay GE Multilin...
Page 293 Default Variation F511 BITFIELD: 3-PHASE SIMPLE ELEMENT STATE 0 = Operate, 1 = Operate A, 2 = Operate B, 3 = Operate C F515 ENUMERATION ELEMENT INPUT MODE 0 = SIGNED, 1 = ABSOLUTE GE Multilin T35 Transformer Management Relay B-49...
Page 294 UR_UINT16: FLEXANALOG PARAMETER Corresponds to the modbus address of the value used when this parameter is selected. Only certain values may be used as Flex- Analogs (basically all metering quantities used in protection) B-50 T35 Transformer Management Relay GE Multilin...
Page 295: Iec 61850
The T35 relay supports IEC 61850 server services over both TCP/IP and TP4/CLNP (OSI) communication protocol stacks. The TP4/CLNP profile requires the T35 to have a network address or Network Service Access Point (NSAP) to establish a communication link. The TCP/IP profile requires the T35 to have an IP address to establish communications. These addresses are located in the !"...
Page 296: Communication Software Utilities
C.1.6 COMMUNICATION SOFTWARE UTILITIES The exact structure and values of the supported IEC 61850 logical nodes can be seen by connecting to a T35 relay with an MMS browser, such as the “MMS Object Explorer and AXS4-MMS” DDE/OPC server from Sisco Inc.
Page 297: Asci Conformance
Setting group control REPORTING Buffered report control M7-1 sequence-number M7-2 report-time-stamp M7-3 reason-for-inclusion M7-4 data-set-name M7-5 data-reference M7-6 buffer-overflow M7-7 entryID M7-8 BufTm M7-9 IntgPd M7-10 Unbuffered report control M8-1 sequence-number M8-2 report-time-stamp M8-3 reason-for-inclusion GE Multilin T35 Transformer Management Relay...
Page 298: Asci Services Conformance Statement
AA: TP/MC SERVER/ UR FAMILY PUBLISHER SERVER (CLAUSE 6) ServerDirectory APPLICATION ASSOCIATION (CLAUSE 7) Associate Abort Release LOGICAL DEVICE (CLAUSE 8) LogicalDeviceDirectory LOGICAL NODE (CLAUSE 9) LogicalNodeDirectory GetAllDataValues DATA (CLAUSE 10) GetDataValues SetDataValues GetDataDirectory GetDataDefinition T35 Transformer Management Relay GE Multilin...
Page 299 (qchg) S27-3 data-update (dupd) GetURCBValues SetURCBValues LOGGING (CLAUSE 14) LOG CONTROL BLOCK GetLCBValues SetLCBValues QueryLogByTime QueryLogByEntry GetLogStatusValues GENERIC SUBSTATION EVENT MODEL (GSE) (CLAUSE 14.3.5.3.4) GOOSE-CONTROL-BLOCK SendGOOSEMessage GetReference GetGOOSEElementNumber GetGoCBValues SetGoCBValues GSSE-CONTROL-BLOCK SendGSSEMessage GetReference GE Multilin T35 Transformer Management Relay...
Page 300 (QueryLogByTime or QueryLogAfter) c8: shall declare support for at least one (SendGOOSEMessage or SendGSSEMessage) NOTE c9: shall declare support if TP association is available c10: shall declare support for at least one (SendMSVMessage or SendUSVMessage) T35 Transformer Management Relay GE Multilin...
Page 301: Logical Nodes
RDRS: Disturbance record handling XCBR: Circuit breaker RBRF: Breaker failure XSWI: Circuit switch RDIR: Directional element T: LOGICAL NODES FOR INSTRUMENT TRANSFORMERS RFLO: Fault locator TCTR: Current transformer RPSB: Power swing detection/blocking TVTR: Voltage transformer RREC: Autoreclosing GE Multilin T35 Transformer Management Relay...
Page 302 ZCAP: Capacitor bank ZCON: Converter ZGEN: Generator ZGIL: Gas insulated line ZLIN: Power overhead line ZMOT: Motor ZREA: Reactor ZRRC: Rotating reactive component ZSAR: Surge arrestor ZTCF: Thyristor controlled frequency converter ZTRC: Thyristor controlled reactive component T35 Transformer Management Relay GE Multilin...
Page 303: Iec 60870-5-104
Address Field of the Link: Balanced Transmision Not Present (Balanced Transmission Only) Unbalanced Transmission One Octet Two Octets Structured Unstructured Frame Length (maximum length, number of octets): Not selectable in companion IEC 60870-5-104 standard GE Multilin T35 Transformer Management Relay...
Page 304 <18> := Packed start events of protection equipment with time tag M_EP_TB_1 <19> := Packed output circuit information of protection equipment with time tag M_EP_TC_1 Ë <20> := Packed single-point information with status change detection M_SP_NA_1 T35 Transformer Management Relay GE Multilin...
Page 305 <103> := Clock synchronization command (see Clause 7.6 in standard) C_CS_NA_1 <104> := Test command C_TS_NA_1 Ë <105> := Reset process command C_RP_NA_1 <106> := Delay acquisition command C_CD_NA_1 Ë <107> := Test command with time tag CP56Time2a C_TS_TA_1 GE Multilin T35 Transformer Management Relay...
Page 306 Blank boxes indicate functions or ASDU not used. • ‘X’ if only used in the standard direction TYPE IDENTIFICATION CAUSE OF TRANSMISSION MNEMONIC <1> M_SP_NA_1 <2> M_SP_TA_1 <3> M_DP_NA_1 <4> M_DP_TA_1 <5> M_ST_NA_1 <6> M_ST_TA_1 <7> M_BO_NA_1 <8> M_BO_TA_1 T35 Transformer Management Relay GE Multilin...
Page 307 <21> M_ME_ND_1 <30> M_SP_TB_1 <31> M_DP_TB_1 <32> M_ST_TB_1 <33> M_BO_TB_1 <34> M_ME_TD_1 <35> M_ME_TE_1 <36> M_ME_TF_1 <37> M_IT_TB_1 <38> M_EP_TD_1 <39> M_EP_TE_1 <40> M_EP_TF_1 <45> C_SC_NA_1 <46> C_DC_NA_1 <47> C_RC_NA_1 <48> C_SE_NA_1 <49> C_SE_NB_1 GE Multilin T35 Transformer Management Relay...
Page 308 <102> C_RD_NA_1 <103> C_CS_NA_1 <104> C_TS_NA_1 <105> C_RP_NA_1 <106> C_CD_NA_1 <107> C_TS_TA_1 <110> P_ME_NA_1 <111> P_ME_NB_1 <112> P_ME_NC_1 <113> P_AC_NA_1 <120> F_FR_NA_1 <121> F_SR_NA_1 <122> F_SC_NA_1 <123> F_LS_NA_1 <124> F_AF_NA_1 <125> F_SG_NA_1 <126> F_DR_TA_1*) T35 Transformer Management Relay GE Multilin...
Page 309 Long pulse duration (duration determined by a system parameter in the outstation) Ë Persistent output Ë Supervision of maximum delay in command direction of commands and setpoint commands Ë Maximum allowable delay of commands and setpoint commands: 10 s GE Multilin T35 Transformer Management Relay...
Page 310 Transmission of sequences of events Transmission of sequences of recorded analog values Ë File transfer in control direction: Transparent file Ë Background scan: Background scan Ë Acquisition of transmission delay: Acquisition of transmission delay T35 Transformer Management Relay GE Multilin...
Page 311 The suitable selection of documents from RFC 2200 defined in this standard for given projects has to be chosen by the user of this standard. Ethernet 802.3 Ë Serial X.21 interface Ë Ë Other selection(s) from RFC 2200 (list below if selected) GE Multilin T35 Transformer Management Relay...
Page 312: Point List
Transformer Differential 2nd Harm Icd Magnitude 2043 SRC 1 Auxiliary Voltage Angle 2089 Transformer Differential 2nd Harm Icd Angle 2044 SRC 1 Zero Sequence Voltage Magnitude 2090 Transformer Differential 5th Harm Icd Magnitude D-10 T35 Transformer Management Relay GE Multilin...
Page 313 Virtual Input States[1] - Select Required M_IT_NA_1 Points 4000 Digital Counter 1 Value 4001 Digital Counter 2 Value 4002 Digital Counter 3 Value 4003 Digital Counter 4 Value 4004 Digital Counter 5 Value GE Multilin T35 Transformer Management Relay D-11...
Page 314 D.1 IEC 60870-5-104 PROTOCOL APPENDIX D D-12 T35 Transformer Management Relay GE Multilin...
Page 315: Dnp Protocol
2048 Maximum Data Link Re-tries: Maximum Application Layer Re-tries: None None Ë Ë Fixed at 2 Configurable Ë Ë Configurable Ë Requires Data Link Layer Confirmation: Ë Never Always Ë Sometimes Ë Configurable Ë GE Multilin T35 Transformer Management Relay...
Page 316 FlexLogic™. The On/Off times and Count value are ignored. “Pulse Off” and “Latch Off” operations put the appropriate Virtual Input into the “Off” state. “Trip” and “Close” operations both put the appropriate Virtual Input into the “On” state. T35 Transformer Management Relay GE Multilin...
Page 317: Counters
Default Object: Ë 16 Bits (Counter 8) Default Variation: 1 32 Bits (Counters 0 to 7, 9) Ë Point-by-point list attached Ë Other Value: _____ Ë Point-by-point list attached Ë Sends Multi-Fragment Responses: Ë Ë GE Multilin T35 Transformer Management Relay...
Page 318: E.1.2 Implementation Table
Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for change- event objects, qualifiers 17 or 28 are always responded.) Note 3: Cold restarts are implemented the same as warm restarts – the T35 is not restarted, but the DNP process is restarted. T35 Transformer Management Relay GE Multilin...
Page 319 Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for change- event objects, qualifiers 17 or 28 are always responded.) Note 3: Cold restarts are implemented the same as warm restarts – the T35 is not restarted, but the DNP process is restarted. GE Multilin T35 Transformer Management Relay...
Page 320 Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for change- event objects, qualifiers 17 or 28 are always responded.) Note 3: Cold restarts are implemented the same as warm restarts – the T35 is not restarted, but the DNP process is restarted. T35 Transformer Management Relay GE Multilin...
Page 321 Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for change- event objects, qualifiers 17 or 28 are always responded.) Note 3: Cold restarts are implemented the same as warm restarts – the T35 is not restarted, but the DNP process is restarted. GE Multilin T35 Transformer Management Relay...
Page 322: E.2.1 Binary Inputs
Virtual Input 25 Virtual Output 23 Virtual Input 26 Virtual Output 24 Virtual Input 27 Virtual Output 25 Virtual Input 28 Virtual Output 26 Virtual Input 29 Virtual Output 27 Virtual Input 30 Virtual Output 28 T35 Transformer Management Relay GE Multilin...
Page 323 Contact Input 6 Contact Input 53 Contact Input 7 Contact Input 54 Contact Input 8 Contact Input 55 Contact Input 9 Contact Input 56 Contact Input 10 Contact Input 57 Contact Input 11 Contact Input 58 GE Multilin T35 Transformer Management Relay...
Page 324 Contact Output 51 Contact Output 5 Contact Output 52 Contact Output 6 Contact Output 53 Contact Output 7 Contact Output 54 Contact Output 8 Contact Output 55 Contact Output 9 Contact Output 56 E-10 T35 Transformer Management Relay GE Multilin...
Page 325 Control Pushbutton 2 Remote Device 3 Control Pushbutton 3 Remote Device 4 Control Pushbutton 4 Remote Device 5 Control Pushbutton 5 Remote Device 6 Control Pushbutton 6 Remote Device 7 Control Pushbutton 7 GE Multilin T35 Transformer Management Relay E-11...
Page 326 LED State 2 (TROUBLE) User-Programmable Pushbutton 10 LED State 3 (TEST MODE) User-Programmable Pushbutton 11 LED State 4 (TRIP) User-Programmable Pushbutton 12 LED State 5 (ALARM) LED State 6 (PICKUP) LED State 9 (VOLTAGE) E-12 T35 Transformer Management Relay GE Multilin...
Page 327: E.2.2 Binary And Control Relay Outputs
Virtual Input 22 Virtual Input 23 Virtual Input 24 Virtual Input 25 Virtual Input 26 Virtual Input 27 Virtual Input 28 Virtual Input 29 Virtual Input 30 Virtual Input 31 Virtual Input 32 GE Multilin T35 Transformer Management Relay E-13...
Page 328: E.2.3 Counters
Events Since Last Clear A counter freeze command has no meaning for counters 8 and 9. T35 Digital Counter values are represented as 32-bit inte- gers. The DNP 3.0 protocol defines counters to be unsigned integers. Care should be taken when interpreting negative counter values.
Page 329: Analog Inputs
Deadbands for individual Analog Input Points can be set using DNP Object 34. When using the T35 in DNP systems with limited memory, the Analog Input Points below may be replaced with a user- definable list. This user-definable list uses the same settings as the Modbus User Map and can be configured with the Mod- bus User Map settings.
Page 330 SRC 1 Phase C Apparent Power SRC 1 Three Phase Power Factor SRC 1 Phase A Power Factor SRC 1 Phase B Power Factor SRC 1 Phase C Power Factor SRC 1 Frequency Transformer Reference Winding E-16 T35 Transformer Management Relay GE Multilin...
Page 331: Miscellaneous
URX-151 1601-0114-J1 4.4x 15 September 2004 URX-156 1601-0114-K1 4.6x 15 February 2005 URX-176 F.1.2 CHANGES TO THE T35 MANUAL Table F–2: MAJOR UPDATES FOR T35 MANUAL REVISION K1 PAGE PAGE CHANGE DESCRIPTION (J1) (K1) Title Title Update Manual part number to 1601-0114-K1...
Page 332 F.1 CHANGE NOTES APPENDIX F Table F–3: MAJOR UPDATES FOR T35 MANUAL REVISION J1 PAGE PAGE CHANGE DESCRIPTION (H2) (J1) Title Title Update Manual part number to 1601-0114-J1 5-15 Remove Removed UCA/MMS PROTOCOL sub-section 5-15 Added IEC 61850 PROTOCOL sub-section...
Page 333 APPENDIX F F.1 CHANGE NOTES Table F–7: MAJOR UPDATES FOR T35 MANUAL REVISION G1 PAGE PAGE CHANGE DESCRIPTION (F2) (G1) Title Title Update Manual part number to 1601-0114-G1. Update Updated T35 ORDER CODES table Update Updated ORDER CODES FOR REPLACEMENT MODULES table...
Page 334: Abbreviations
MVA ....MegaVolt-Ampere (total 3-phase) FDH....Fault Detector high-set MVA_A ... MegaVolt-Ampere (phase A) FDL ....Fault Detector low-set MVA_B ... MegaVolt-Ampere (phase B) FLA....Full Load Current MVA_C... MegaVolt-Ampere (phase C) FO ....Fiber Optic T35 Transformer Management Relay GE Multilin...
Page 335 ....With Option RST ....Reset WRT....With Respect To RSTR ..... Restrained RTD....Resistance Temperature Detector X .....Reactance RTU....Remote Terminal Unit XDUCER..Transducer RX (Rx) ..Receive, Receiver XFMR....Transformer s ..... second Z......Impedance, Zone S..... Sensitive GE Multilin T35 Transformer Management Relay...
Page 336: Warranty
24 months from date of shipment from factory. In the event of a failure covered by warranty, GE Multilin will undertake to repair or replace the relay providing the warrantor determined that it is defective and it is returned with all transportation charges prepaid to an authorized service centre or the factory.
Page 337 C37.94 COMMUNICATIONS ......... 3-28, 3-29 actual values .............. 6-5 ............2-11 CE APPROVALS ..............5-99 settings ........F-1, F-2, F-3 CHANGES TO MANUAL ..............5-38 CRC ALARM CHANNEL COMMUNICATION ........3-20 ............ B-2 CRC-16 ALGORITHM CHANNELS GE Multilin T35 Transformer Management Relay...
Page 338 Modbus registers specifications ..............5-112 ..........4-5 settings EVENT CAUSE INDICATORS DIRECT I/O EVENT RECORDER see also DIRECT INPUTS and DIRECT OUTPUTS actual values ............. 6-16 ........5-113, 5-114 ............. 5-10, 7-1 application example clearing T35 Transformer Management Relay GE Multilin...
Page 339 ........1-12, 7-3 ..........3-9 high impedance circuits INPUTS ............3-8, 3-9, 3-13 outputs ............2-8, 5-40 AC current specifications ............. 2-9 ............2-8, 5-41 AC voltage FORM-C RELAY contact inputs ........2-8, 3-11, 5-103, 5-121 GE Multilin T35 Transformer Management Relay...
Page 340 MEMORY MAP DATA FORMATS ........B-40 ...........7-2 ORDER CODES, UPDATING MENU HEIRARCHY ..........1-11, 4-8 ............. 2-2, 2-3, 2-4 ORDERING ........1-11, 4-7, 4-8 MENU NAVIGATION ......2-11 OSCILLATORY TRANSIENT TESTING METERING OSCILLOGRAPHY conventions ............6-8, 6-9 T35 Transformer Management Relay GE Multilin...
Page 341 FlexLogic™ operands configuration logic ................ 5-91 specifications ............2-10 ............B-21 ...............3-15 Modbus registers wiring ..............5-90 settings RS422 ............. 2-5 .............3-24 specifications configuration PHONE NUMBERS ............1-1 timing ...............3-26 ..........3-25 POWER METERING two-channel application GE Multilin T35 Transformer Management Relay...
Page 342 ........... 4-4 STATUS INDICATORS ............. 6-16 actual values ............2-11 SURGE IMMUNITY ............. 5-10, 7-1 clearing ..... 6-9 SYMMETRICAL COMPONENTS METERING Modbus registers ............B-13 SYSTEM FREQUENCY ..........5-42 ..............5-22 settings ............5-40 SYSTEM SETUP USER-PROGRAMMABLE LEDs T35 Transformer Management Relay GE Multilin...
Page 343 ...............5-105 logic ..........B-8, B-31 Modbus registers settings ..............5-105 VIRTUAL OUTPUTS ZERO SEQUENCE CORE BALANCE ....... 3-7 .............. 6-4 actual values ....5-52, 5-53 ZERO-SEQUENCE COMPENSATION ..........5-66 FlexLogic™ operands Modbus registers ............B-31 GE Multilin T35 Transformer Management Relay...
Page 344 INDEX viii T35 Transformer Management Relay GE Multilin...

GE T35 Instruction Manual

1 Getting Started

Important Procedures

Ur Overview

Enervista Ur Setup Software

Ur Hardware

Using the Relay

2 Product Description

Introduction

Specifications

3 Hardware

Description

Wiring

Direct I/O Communications

4 Human Interfaces

Enervista Ur Setup Software Interface

Faceplate Interface

5 Settings

Overview

Product Setup

System Setup

Flexlogic

Grouped Elements

Control Elements

Inputs/Outputs

Transducer I/O

Testing

6 Actual Values

Overview

Status

Records

Product Information

7 Commands and

Commands

8 Commissioning

Differential Characteristic Test

Differential Characteristic Test Examples

Commissioning Test Tables

Flexanalog

Flexanalog List

Modbus Communications

Modbus Rtu Protocol

Modbus Function Codes

File Transfers

Memory Mapping

Iec 61850

Introduction

Asci Conformance

Logical Nodes

Iec 60870-5-104

Iec 60870-5-104 Protocol

Dnp Protocol

Miscellaneous

Change Notes

Abbreviations

Warranty

Quick Links

Related Manuals for GE T35

Summary of Contents for GE T35
