11 SETPOINT TABLES 11.1 COMMISSIONING SUMMARY
Table 11–1: SETPOINTS PAGE 1 – 745 SETUP
DESCRIPTION
PREFERENCES
Beeper
Flash Message Time
Default Message Timeout
Default Message Intensity
COMMUNICATIONS
Slave Address
COM1 Baud Rate
COM1 Parity
COM1 Hardware
COM2 Baud Rate
COM2 Parity
Front Baud Rate
Front Parity
DNP COMMUNICATIONS
DNP port
DNP Point Mapping
Transmission delay
Data Link Confirm
Data Link Confirm Timeout
Data Link Confirm Retries
Select/Operate Arm Timeout
Write Time Interval
Cold Restart Inhibit
RESETTING
Local Reset Block
Remote Reset Signal
CLOCK
IRIG-B Signal Type
GE Power Management
DEFAULT USER VALUE
Enabled
4.0 s
300 s
25 %
254
19200 Baud
None
RS485
19200 Baud
None
19200 Baud
None
None
Enabled
0 ms
Never
1000 ms
3
10000 ms
0 min
Disabled
Disabled
Disabled
None
