Page 1: Operating Instructions
HAZEMAX Operating Instructions P/N 100021 (120 VAC w/DMX) P/N 100026 (230 VAC w/DMX) - Page 2 Thank you for purchasing this HAZEMAX As you will notice from the table of contents, the manual for your new product is quite extensive. To guarantee perfect and successful work with this machine, please take some time to read the manual carefully.
-
Page 3: Table Of Contents
1. Set of Equipment Supplied 2. Accessories and Parts 3. Description 4. Safety Instructions 5. Operating the HazeMax 5.1 Selecting the Location 5.2 Electrical Power Requirements 5.3 Hooking things up 5.4 Operating the machine 5.5 DMX Control 5.6 Rest Period 5.7 Shut Down... -
Page 4: Set Of Equipment Supplied
C-Clamp w/Safety Cable P/N 250110 HazeMax Road Case P/N 250211 C-Clamp w/eyebolt & hanging harness for 5 gal. (19 liter) Cubitainer (P/N 250076) The following miscellaneous parts are available for the HazeMax 600301 Bracket Hardware with Knobs 600302 Bracket 600304 Switch... -
Page 5: Description
1-channel DMX on board, remote control cycle-timer and hanging bracket. Best bet for professional haze. Uses water-based CITC hazing fluid. The extra dry haze leaves no mess, no residue and can be fully controlled with DMX (included). -
Page 6: Operating The Hazemax Tm
This machine requires a well-grounded 120 VAC (or 230VAC) circuit for operation. The HazeMax draws approximately 15 amps at 120 VAC. (The 230VAC model draws approximately 8 amps.) During HazeMax operation this circuit should be dedicated to the HazeMax . If you have any doubts about the capacity or grounding of your existing circuits, consult a qualified electrician. -
Page 7: 5.6 Rest Period
5.6 Rest Period Continuous operation of this machine can be accomplished when volume is set at the 3 o’clock position. If dial is set for full output or blast, 30 minutes is the maximum time of haze ability before a 3-minute rest period for reheating is necessary. If you wait a full 10 minutes, you will be able to haze again for at least 30 minutes on full. -
Page 8: Service And Maintenance
Once your hazer is warm and the green ready lite is on, you may control the haze output from the control booth. Service and Maintenance Care of your HazeMax will give you years of service. Note: cleaning your unit is going to pay off in constant good performance. -
Page 9: Technical Data
Technical Data HazeMax Technical Data P/N 100021 (230V P/N 100026) Dimensions: 22" x 9" x 11" (56cm x 23cm x 28cm) Weight: 27 lbs (13 kg) Shipping Weight 32 lbs (14.5 kg) Shipping Dimensions 26 x 16 x 13 (66cm x 40.6cm x 33cm) -
Page 10: Limited Warranty Conditions
CITC. The right of limited warranty service is also lost if a fluid other than appropriate CITC fluid has been used or if units are sent to in with full fluid bottles. - Page 11 Obtain your RMA# by calling CITC. Payment arrangements for repair must be made before receiving RMA # in case unit is not covered under Limited Warranty.
