- Page 1 FOG-MAX Operating Instructions P/N 100092 (110 VAC w/DMX) P/N 100096 (230 VAC w/DMX)
- Page 2 And finally, we believe you will enjoy years of great smoke effects if you care for and maintain your FOG-MAX CITC 2100 196 St. S.W., Ste. 138 Lynnwood, WA 98036 (888) 786-CITC www.citcfx.com...
-
Page 3: Table Of Contents
Contents 1. Set of Equipment Supplied 2. Accessories and Parts 3. Description 4. Safety Instructions 5. Operating the Fog-Max 5.1 Selecting the Location 5.2 Electrical Power Requirements 5.3 Hooking things up 5.4 Operating the machine 5.5 DMX Control 5.6 Rest Period 5.7 Shut Down 5.8 Troubleshooting 5.9 Notes on DMX Control... -
Page 4: Accessories And Parts 3
" Bracket for hanging Instruction booklet " 2. Accessories and Parts CITC Natural Fogging Fluid (available in gallons (3.8 liter) and 5-gallon (19 liter) cubitainer) P/N 150450 Long-Lasting Fog Fluid P/N 150410 Regular Fog Fluid P/N 150490 Low-Ground fog Fluid C-Clamp w/Safety Cable (P/N 250110) "... -
Page 5: Safety Instructions
1500 watt heating head, a 1-channel DMX on board, remote control cycle-timer and hanging bracket. Best bet for professional fog. Uses water- based CITC fogging fluid, regular, long-lasting or low-ground. The extra dry fog leaves no mess, no residue and can be fully controlled with DMX. -
Page 6: Operating The Fog-Max
Plug the 5-pin XLR of the Remote Control to the inlet marked “Remote Control”. Fill the bottle with CITC’s Natural Fogging Fluid in Low-Ground, Long-Lasting or Regular. Place the filter end of the tube inside the bottom of the bottle and tighten cap. Be sure the vent hole in the cap is not blocked. -
Page 7: Rest Period
Rest Period Continuous operation of this machine can be accomplished when volume is set at the 3 o’clock position. If dial is set for full output or blast, 30 minutes is the maximum time of fog ability before a 3 minute rest period for reheating is necessary. If you wait a full 10 minutes, you will be able to fog again for at least 30 minutes on full. -
Page 8: Service And Maintenance
Notes on DMX operation Each DMX’d unit will occupy a unique DMX address on the DMX chain. By adjusting the dip switches on the side of the machine near the DMX cable plug-ins, the user may assign one address to the machine, giving you on/off and volume control with one DMX channel (there is no timer on this DMX). -
Page 9: Technical Data 8
33 lbs (15 kg) Shipping Box Size 26” x 13” x 13” (66 cm x 33 cm x 41 cm) Built in DMX (optional) CITC Fogging Fluid Long-Lasting P/N 150450 (water-based) Regular P/N 150410 Low-Ground P/N 150490 Warm Up Time... -
Page 10: Limited Warranty Conditions 9
The right of limited warranty service is also lost if a fluid other than CITC water-based Natural Fogging Fluid has been used or if units are sent to us with full fluid bottles. - Page 11 If you should send the unit for service, do not forget to remove any liquid from the fluid bottle. Obtain your RMA# by calling CITC. Payment arrangements for repair must be made before receiving RMA # in case unit is not covered under Limited Warranty.
