Summary of Contents for CITC FogMax 100090
- Page 1 FOGMAX Operating Instructions P/N 100090 (120 VAC w/DMX) P/N 100095 (230 VAC w/DMX)
- Page 2 And finally, we believe you will enjoy years of great smoke effects if you care for and maintain your FOGMAX CITC 1420 80 St. SW #D Everett, WA 98203 (888) 786-CITC www.citcfx.com...
-
Page 3: Table Of Contents
Contents 1. Set of Equipment Supplied 2. Accessories and Parts 3. Description 4. Safety Instructions 5. Operating the FogMax 5.1 Selecting the Location 5.2 Electrical Power Requirements 5.3 Hooking things up 5.4 Operating the machine 5.5 DMX Control 5.6 Rest Period 5.7 Shut Down 5.8 Troubleshooting 5.9 Notes on DMX Control... - Page 4 Instruction booklet 2. Accessories and Parts CITC SmartFog™ Fluid (available in gallons (3.8 liter) and 5-gallon (19 liter) cubitainer) P/N 150460 60 Minute Longest-Lasting SmartFog™ Fluid P/N 150450 45 Minute Long-Lasting SmartFog™ Fluid P/N 150410 25 Minute Regular SmartFog™ Fluid P/N 150411 15 Minute “Fog-It”...
-
Page 5: Safety Instructions
The FogMax™ is your best bet for professional fog. Uses water-based CITC SmartFog™ fluid in 15 Minute, 1 Minute, 3 Minute, 25 Minute, 45 Minute or 60 Minute. The extra dry fog leaves no mess, no residue and can be fully controlled with DMX. -
Page 6: Operating The Fogmax
Plug the 5-pin XLR of the Remote Control to the inlet marked “Remote Control”. Fill the bottle with CITC’s SmartFog Fluid. Place the filter end of the tube inside the bottom of the bottle and tighten cap. Be sure the vent hole in the cap is not blocked. -
Page 7: Rest Period
Rest Period Continuous operation of this machine can be accomplished when volume is set at the 3 o’clock position. If dial is set for full output or blast, the fogger may cool enough to require a 3 minute rest period for reheating before continuing to fog. Shut down When finished with the machine, clean the tube and pump by operating the unit while running a pint of 5% vinegar/distilled water mix through the pump and then rinse with a... -
Page 8: Service And Maintenance
26” x 13” x 16” (66 cm x 33 cm x 41 cm) Shipping Weight 33 lbs (15 kg) Built in 1-channel DMX CITC SmartFog™ Fluid P/N 150460 60 Minute Longest-Lasting (water-based) P/N 150450 45 Minute Long-Lasting P/N 150410 25 Minute Regular... - Page 9 Our customer service department will respond to your problems immediately. Subject to the following conditions, CITC will repair any defect or fault in the unit if it is caused by a proven factory defect within one year of delivery to the end user.
- Page 10 CITC. The right of limited warranty service is also lost if a fluid other than appropriate CITC fluid has been used or if units are sent in without first emptying the equipment of fluid.
