- Page 1 CFS-2000 CHILLER Operating Instructions P/N 100100 (110 VAC) P/N 100105 (230 VAC)
- Page 2 And finally, we believe you will enjoy years of great ground fog effects if you care for and maintain your CFS-2000 CHILLER CITC 2100 196 St. S.W., Ste. 138 Lynnwood, WA 98036 (888) 786-CITC www.citcfx.com...
-
Page 3: Table Of Contents
Contents 1. Set of Equipment Supplied 2. Accessories and Parts 3. Description 4. Safety Instructions 5. Operating the CFS-2000 Chiller 5.1 Selecting the Location 5.2 Electrical Power Requirements 5.3 Hooking things up 5.4 Loading the dry ice 5.5 Operating the machine 5.6 Shut Down 5.7 Troubleshooting 5.8 Notes on optional Universal DMX control... -
Page 4: Set Of Equipment Supplied
Because the unit is made of durable plastic, it will last for years to come. We recommend using with CITC’s water-based low-ground fogging fluid in your fogger. It’s designed to be thick, dry, stay low to the ground and not leave a residue. -
Page 5: Safety Instructions
Do not bend the hoses in any sharp angle as this would cause back pressure and reduce fog output. Place your water-based fog machine (CITC Fog Max or other) with the fogger outlet 3”- 4” (8–10cm) away from side intake opening of chiller Electrical Power Requirements This machine requires a 110VAC (or 230VAC) circuit for operation. -
Page 6: Hooking Things Up
5.3 Hooking things up Plug in cord under the control box. NOTE: The control box receptacle has a pull-out fused box under the cord insert with an extra fuse inside for emergency replacement (Fuse P/N 704052 (3.15 amp), P/N 704076 (1 amp)). Recommended accessories are two (2) eight foot (2.4m) tubes with 45 elbows. -
Page 7: Operating The Machine
5.5 Operating the machine Adjust your water-based fog machine (CITC Fog Max or other), to 40% of fog capacity. The water-based fogger should be adjustable to low amounts of continuous fog for best effect. Do not over fog. Warm up water-based fogger, and then switch chiller on. Fog will begin slowly rolling out. -
Page 8: Notes On Optional Universal Dmx Control
now. Check to hear any sound coming from the pump side (nearest the top). A slight vibrating sound should be heard if the pump is pumping fluid. A loud knocking sound will be heard if only air is in the line and fluid has not come in yet. Force fluid through the line to get it started. -
Page 9: Technical Data
5” (13cm) hoses User Supplies Dry ice blocks and variable speed fog machine such as CITC FogMax Recommended Fluid CITC’s water-based Low –Ground Fog Fluid P/N 150490 Power cord... -
Page 10: Limited Warranty Conditions
4. Freight costs to CITC when under the limited warranty services are the responsibility of the customer. CITC will pay freight upon return. - Page 11 If you should send the unit for service, do not forget to remove any liquid from inside the unit. Obtain your RMA# by calling CITC. Payment arrangements for repair must be made before receiving RMA # in case unit is not covered under Limited Warranty.
