UBI EasyCoder 501 Ticketing – User's Manual
TROUBLE SHOOTING
Printout Troubles
Symptom
Overall weak printout
Printout weaker on one side
Weak spots
Overall dark printout
Excessive bleeding
Dark lines along paper web
White lines along paper web
Large part of dot line missing
Last part of label missing
Printout missing along inner edge Bad paper alignment
The list below is intended to help the operator to correct possible
printout troubles or flaws in printout quality, and to decide when
assistance from the Service Dept. of the nearest UBI distributor
is required. Note that most problems are due to operating errors
or normal wear of the printhead.
Possible Cause
Printhead pressure too low
Wrong Paper type setup
Low Contrast setup
Worn printhead
Wrong printhead voltage
Uneven printhead pressure
Foreign particles on paper/ribbon
Poor paper quality
Worn printhead
Worn pressing roller
Printhead pressure too high
Wrong Paper Type setup
High Contrast setup
Wrong printhead voltage
Printhead pressure too high
Wrong Paper Type setup
Contrast setup too high
Faulty energy control
Foreign objects on printhead
Printhead dirty
Missing dots on printhead
Wrong X-start or Width setup
Failing printhead
Failing strobe signal
Too small image buffer
X-start setup too low
Remedy Refer to
Adjust both knobs Technical Manual
Check/change Technical Manual
Check/change Technical Manual
Check/replace Technical Manual
Check/repair CPU Call Service
Adjust outer knob Technical Manual
Remove n.a.
Use other media Technical Manual
Check/replace Technical Manual
Check/replace Call Service
Adjust both knobs Technical Manual
Check/change Technical Manual
Check/change Technical Manual
Check/repair CPU Call Service
Adjust both knobs Technical Manual
Check/change Technical Manual
Check/change Technical Manual
Check CPU board Call Service
Check/clean User's Manual p. 8
Check/clean User's Manual p. 8
Replace printhead Technical Manual
Check/change Technical Manual
Check/replace Technical Manual
Check CPU-board Call Service
Check/increase Technical Manual
Adjust User's Manual p. 6
Check/increase Technical Manual
9
